Summary of Contents for Seagate Momentus Thin ST500LT012
Page 1
Product Manual Momentus Thin ® Standard models Self-Encrypting Drive models ST500LT012 ST500LT025 ST320LT025 ST320LT012 ST250LT025 ST250LT012 SED (FIPS 140-2) models Review Pending ST500LT015 ST320LT015 ST250LT015 Gen 9 100685367 Rev. G March 2013...
Page 2
Publication number: 100685367, Rev. G March 2013 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Momentus Thin and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
• Authorized Service Centers For information regarding Warranty Support, visit:http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/ For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Momentus Thin SATA Product Manual, Rev. G...
NTRODUCTION ® This manual describes the functional, mechanical and interface specifications for the following Seagate Momentus Thin model drives: SED (FIPS 140-2) models Standard models Standard SED models (Review Pending) ST500LT012 ST500LT025 ST500LT015 ST320LT012 ST320LT025 ST320LT015 ST250LT012 ST250LT025 ST250LT015 Previous generations of Seagate Self-Encrypting Drive models were called Full Disk Encryption (FDE) models before a differentiation between drive-based encryption and other forms of encryption was necessary.
ATA I BOUT THE ERIAL NTERFACE The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration ...
The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. Table 1 Drive Specifications Summary ST500LT012 ST320LT012 ST250LT012 ST500LT015...
RIVE PECIFICATIONS Table 1 Drive Specifications Summary (continued) ST500LT012 ST320LT012 ST250LT012 ST500LT015 ST320LT015 ST250LT015 RIVE PECIFICATION ST500LT025 ST320LT025 ST250LT025 37.7°C max (operating) Wet bulb temperature (max) 40.0°C max (nonoperating) Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, nonoperating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft)
RIVE PECIFICATIONS HYSICAL ORGANIZATION Drive model Read/write heads Number of discs ST500LT012, ST500LT015 and ST500LT025 ST320LT012, ST320LT015 and ST320LT025 ST250LT012, ST250LT015 and ST250LT025 ECORDING AND NTERFACE ECHNOLOGY Interface Serial ATA (SATA) Recording method Perpendicular Recording density 1958 Kb/in Track density...
RIVE PECIFICATIONS TART STOP TIMES Table 3 Start/stop times ° Typical seek times (ms) Typical Max @ 25 Power-on to ready (sec) Power-on to ready (sec) (SED models) Standby to ready (sec) OWER PECIFICATIONS The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 2 2.7.1 Power consumption...
RIVE PECIFICATIONS Table 4 DC Power Requirements (25° C) OWER ISSIPATION INPUT AVERAGE Spinup (max) 1.00A Seek average 1.40W Write average 1.70W Read average 1.20W Idle, performance 1.20W Idle, active 0.70W Idle, low power mode 0.45W Standby 0.18W Sleep 0.18W During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.
RIVE PECIFICATIONS 2.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10 ...
RIVE PECIFICATIONS NVIRONMENTAL PECIFICATIONS This section provides the temperature, humidity, shock, and vibration specifications for Momentus drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Table 5: Environmental specifications Parameters Operating...
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.
Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
2.13 NVIRONMENTAL ROTECTION Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive The European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006.
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging.
ONFIGURING AND OUNTING THE RIVE This section contains the specifications and instructions for configuring and mounting the drive. ANDLING AND TATIC ISCHARGE RECAUTIONS After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions.
ONFIGURING AND OUNTING THE RIVE RIVE OUNTING You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: Figure 3 Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling.
Figure 4 Mounting dimensions (for FIPS 140-2 models) BREATHER HOLE, DO NOT COVER OR SEAL RECOMMENDED CASE TEMP MEASUREMENT LOCATION ON THE END OF THE DRIVE Do Not Remove * Tamper Indicator * TAMPER PROOF LABELS ON BOTH SIDES DO NOT PEEL OR REMOVE. FIPS 140-2 Models Contain 3 Tamper Evident Stickers with the marking "Tamper Indicator - Do Not Remove".
For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website. To reference the product certification visit: http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/1401vend.htm, and search for “Seagate”. Security Level 2.
ATA (SATA) I ERIAL NTERFACE ATA (SATA) I ERIAL NTERFACE These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers.
ATA (SATA) I ERIAL NTERFACE ATA D ERIAL EVICE ONNECTOR EFINITIONS summarizes the signals on the Serial ATA interface and power connectors. Refer to the below. Table 8 Notes Table 8 Serial ATA Connector Pin Definitions EGMENT UNCTION EFINITION Ground 2nd mate Differential signal pair A from Phy Ground...
ATA (SATA) I ERIAL NTERFACE ATA C UPPORTED OMMANDS lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial Table 9 ATA International Organization: Serial ATA (Revision 2.6). Refer to www.sata-io.org Refer to on page 28 for details and subcommands used in the S.M.A.R.T.
Page 26
ATA (SATA) I ERIAL NTERFACE Table 9 Supported ATA commands ATA-standard commands names Command code (in hex) S.M.A.R.T. Enable Operations B0h/D8h S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh S.M.A.R.T. Enable One Attribute Modification B0h/E0h S.M.A.R.T. Execute Offline B0h/D4h S.M.A.R.T. Free Fall Protection Host Interface S.M.A.R.T.
0000 Retired 8000 Obsolete 0004 Firmware revision: 23–26 x.xx (8 ASCII character string, padded with blanks to end of string) ST500LT012 ST500LT015 ST500LT025 ST320LT012 Drive model number: 27–46 ST320LT015 (40 ASCII characters, padded with blanks to end of string) ST320LT025...
Page 28
NTERFACE Table 10 Identify Device command Word Description Value ST500LT012 = 0FFFFFFFh ST500LT015 = 0FFFFFFFh Total number of user-addressable sectors ST500LT025 = 0FFFFFFFh ST320LT012 = 0FFFFFFFh This field contains a value that is one greater than the total number of 60–61...
Page 29
ATA (SATA) I ERIAL NTERFACE Table 10 Identify Device command Word Description Value ST500LT012 = 976,773,168 ST500LT015 = 976,773,168 ST500LT025 = 976,773,168 Total number of user-addressable LBA sectors available ST320LT012 = 625,142,448 (see Section 3.2 for related information) 100–103 ST320LT015 = 625,142,448...
Page 30
ATA (SATA) I ERIAL NTERFACE Table 11 Bit Descriptions (continued) Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported.
ATA (SATA) I ERIAL NTERFACE 5.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.
) that eliminates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://www.seagate.com/support/downloads/seatools/. This drive is shipped with S.M.A.R.T. features disabled. You must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature.
Page 35
Track-to-track seek time 6 Transport major version number 25 UL60950-1 12 vibration 10 voltage dips, interrupts 11 voltage tolerance 9 warranty 12 weight 6 width 6 Write Buffer 22 Write DMA 22 Write DMA Extended 22 Write Long with Retries 22 Write Long without Retries 22 Write Multiple 22 Write Sectors 22...
Page 36
Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100685367, Rev.
