- Page 1 Cappa Cooker hood Hotte de cuisine Dunstabzugshaube Dampkap Campana ZHC 920 Istruzioni per l’uso Operating Instructions Mode d’emploi Bedienungsanleitung Gebruiksaanwijzing Manual de instrucciones...
-
Page 2: Part 1 - Installation Instructions
Part 1 - INSTALLATION INSTRUCTIONS 1 - GENERAL DATA This hood has been designed to be wall-mounted above a cooking hob with one side resting against a wall. It works either by suction (external outlet) or filter (internal recycling). Because of the complexity and weight of the hood, its installation should be carried out by qualified staff, taking care to respect all local regulations on air discharge. -
Page 3: Selecting The Type Of Installation
clearance between the contacts. 3.4 - The appliance must be earthed. 3.5 - When installed, the hood must be positioned at least 65 cm above a cooking appliance. 3.6 - Never do flambé cooking under this cooker hood. 3.7 - Never leave frying pans unattended during use as overheated fats and oils may catch fire. - Page 4 2 - Air discharge towards the wall (fig. 3) In this case the hood can only be used in suction mode. 3 - Side air discharge, Lh or Rh (fig. 4a-b). In this case the hood can only be used in suction mode. S07_04 4.2 - Installation of the hood canopy C 1 - Drilling the wall...
- Page 5 2 - Fitting the fixing elements a) Insert the rawl plugs provided into holes 1 and 2. b) Fit the eye bolts O (fig. 6). c) Fix the wall bracket S in hole 2 using the screw V provided (fig. 7). 3 - Fitting the hood canopy C to the wall a) Remove the metal grease filters...
- Page 6 4.3 - Installation of the A03_12 chimney A No matter which type of installation is being used, any wooden shelves in the area where the hood is to be fitted must first be removed, drilled and later replaced. 1 - Drilling the shelves: a) Using the cardboard template provided, and taking hole “B”...
- Page 7 - Remove the plug from the upper part of the ducting fan unit (fig. 17), as it is not possible to insert the flange F with the plug in place. - Fit the flange F Ø120 or 150 mm (fig. 18), replace the plug. ·...
-
Page 8: Ducting Or Recirculation Fitting
4.4 - Ducting or recirculation fitting 1 - Ducting fitting. This is possible for all forms of installation: a) Connect the air outlet to the external ducting system. b) Remove the activated charcoal filter (if there is one) inside the hood canopy (see Maintenance). -
Page 9: Operation
2 - OPERATION Control panel (fig. 27) The cooker hood can be operated as follows: SWITCH L = controls the worktop illumination; SWITCH V1 = controls the fan speed for low speed, should be selected when simmering or using only one pan: the noise level is kept to the minimum. - Page 10 WARNING: Maintenance or replacement periods should be respected to avoid any fire hazards when the filters get saturated with grease. 3.3 - Light 1 - It consists of 2 20 W-halogen spotlights. 2 - Replacement (fig. 30) Remove the two screws that lock the metal ring, take the spotlight out of its holder by pulling slightly.
- Page 11 A01_055e1...
- Page 14 4329241 02 - 0999...
