ZHC 927
MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE
INSTALLATION, USE AND MAINTENANCE HANDBOOK
MANUEL D'INSTRUCTIONS POUR L'INSTALLATION, L'EMPLOI ET L'ENTRETIEN
HANDBUCH FÜR INSTALLATION, BEDIENUNG UND WARTUNG
INSTRUCTIES VOOR MONTAGE, GEBRUIK EN ONDERHOUD
Advertisement
Table of Contents
Related Manuals for Zanussi ZHC 927
Summary of Contents for Zanussi ZHC 927
- Page 1 Cappa Cooker hood Hotte de cuisine Dunstabzugshaube Dampkap ZHC 927 MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE INSTALLATION, USE AND MAINTENANCE HANDBOOK MANUEL D’INSTRUCTIONS POUR L’INSTALLATION, L’EMPLOI ET L’ENTRETIEN HANDBUCH FÜR INSTALLATION, BEDIENUNG UND WARTUNG INSTRUCTIES VOOR MONTAGE, GEBRUIK EN ONDERHOUD...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come.
-
Page 3: Installation
INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 Dimensions Components...
-
Page 5: Wall Drilling And Bracket Fixing
Wall drilling and bracket fixing Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed. • Draw a horizontal line at: 955 mm above the hob for installation without the back panel, a 955mm above the surface on which the pack panel rests,... -
Page 6: Mounting The Hood Body
REAR PANEL (OPTIONAL) The Rear Panel comprises a bottom panel and a top profile connecting to the Hood. The Rear Panel must be fitted before fixing the hood body and, for both upper and lower position fixing, must be fitted at the correct height prior to installing the bases. As this operation is rather complex, it should be carried out either by the kitchen installer or a qualified person who knows the final dimensions of the units. -
Page 7: Ducted Version Air Exhaust System
Connections DUCTED VERSION AIR EXHAUST SYSTEM When installing the ducted version, connect the hood to the chimney using either a flexible or rigid pipe ø 150 or 120 mm, the choice of which is left to the installer. • To install a ø 120 mm air exhaust connection, insert the reducer flange 9 on the hood body outlet. -
Page 8: Flue Assembly
Flue assembly Upper exhaust flue • Slightly widen the two sides of the upper flue and hook them behind the brackets 7.2.1, making sure that they are well seated. • Secure the sides to the brackets using the 4 screws 12c (2,9 x 6,5) supplied. Lower exhaust flue •... -
Page 9: Control Panel
Control panel Light Switches the lighting system on and off. S1 Led Motor running led. S2 Led Optimum speed led. S3 Led Intensive speed led. Grease filters saturated alarm led. Activated charcoal filter exhausted alarm led. To disable this indicator (Ducted hoods) simultaneously press buttons R (using a sharp object, for example a pencil) and V2. -
Page 10: Grease Filters
Grease filters CLEANING METAL SELF-SUPPORTING GREASE FILTERS The filters must be cleaned when led S4 starts to flash or at least once every two months of opera- tion, or more frequently with heavy usage, and can be washed in a dishwasher. Resetting the alarm signal •... -
Page 11: Light Replacement
Lighting LIGHT REPLACEMENT • 20 W halogen light. • Remove the 2 Screws fixing the Lighting support, and pull it out of from the Hood. • Extract the Lamp from the Support. • Replace with another of the same type, making sure that the two pins are properly inserted in the lamp holder socket holes.
