Operating Manual
MODEL
CD-MPX860H
MINI COMPONENT SYSTEM
This quick Start Guide will help you to correctly install and
operate your system.
1
Accessories
Remote control × 1
3
System connections
Right speaker
Red
Black
4
Turn on your system
The first time the unit is plugged in, the unit will enter the demonstration mode.
You will see words scroll.
1
Press the X-BASS/DEMO button to cancel the demonstration mode.
2
Press the ON/STAND-BY button to turn the power on.
AM loop aerial × 1
FM aerial × 1
FM aerial
2
Remote control battery installation
Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1
Open the battery cover.
2
Insert the batteries as shown.
3
Close the cover.
AM loop aerial
Left speaker
Wall socket
(AC 230 V, 50 Hz)
ANTENNA
FM
GND
AM
75 OHMS
TINSEA165AWZZ
07B R AS 1
