MINI COMPONENT SYSTEM
MODEL
CD-MPX850
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
CD-MPX850 Mini Component System consisting of CD-MPX850 (main
unit), CP-MPX850 (speaker system).
Accessories
Please confirm that the following accessories are included.
Remote control
1
AM loop antenna
(RRMCGA122AWSA)
(QANTL0010AWZZ)
Note:
Only the above accessories are included.
1
FM antenna
1
(92LFANT1535A)

Advertisement

Table of Contents
loading

Related Manuals for Sharp CD-MPX850

Summary of Contents for Sharp CD-MPX850

  • Page 1 Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. CD-MPX850 Mini Component System consisting of CD-MPX850 (main unit), CP-MPX850 (speaker system).

  • Page 2: Special Notes

    NOTES It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.

  • Page 3: Important Safety Instructions

    17) Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. CD-MPX850...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS CD-MPX850 18) Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions : a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the...

  • Page 5: Table Of Contents

    Specifications ........41 - 42 CONSUMER LIMITED WARRANTY ....Back cover CD-MPX850 Page...

  • Page 6: Precautions

    Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

  • Page 7: Controls And Indicators

    19. Remote Sensor ........13 CD-MPX850...

  • Page 8: Speaker System

    Controls and indicators (continued) CD-MPX850 AC INPUT 7 8 9 1. Disc Number Indicators ......20 2.
  • Page 9 29. Enter Button ........23 CD-MPX850...

  • Page 10: System Connections

    System connections CD-MPX850 Make sure to unplug the AC power cord before any connections. Right speaker Speaker light-up wire Speaker connection (see page 11) Antenna connection (see page 11) FM antenna AM loop antenna AC INPUT AC outlet (AC 120 V, 60 Hz)
  • Page 11 Do not let the bare speaker wires touch each other. Do not stand or sit on the speakers. You may be injured. Do not allow any objects to fall into or to be placed in the bass reflex duct. Black CD-MPX850 LEFT SPEAKER RIGHT SPEAKER Incorrect...

  • Page 12: System Connections

    System connections (continued) CD-MPX850 AC power connection After checking all the connections have been made correctly, plug the AC power cord of this unit into the AC outlet. If you plug in the unit first, the unit will enter the demonstration mode.

  • Page 13: Remote Control

    Point the remote control directly at the remote sensor on the unit. The remote control can be used within the range shown below: Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music. CD-MPX850 Remote sensor...

  • Page 14: General Control

    General control CD-MPX850 To turn the power on Press the ON/STAND-BY button to turn the power on. After use: Press the ON/STAND-BY button to enter the power stand-by mode. Illumination light control When the power is turned on, light illuminates around the display.

  • Page 15: Setting The Clock (Remote Control Only)

    (reset)” on page 40 for details.] 2 Perform “Setting the clock” from step 1. button to adjust the hour and button once to advance the time by button to adjust the minutes and button once to advance the time by button to display the CD-MPX850...

  • Page 16: Listening To A Cd Or Mp3/Wma Disc

    Listening to a CD or MP3/WMA disc CD-MPX850 This system can play back a standard CD, CD-R/RW in the CD format and CD-R/RW with MP3 or WMA files, but cannot record on them. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording.
  • Page 17 90 seconds). You can place discs on the trays 2 - 5 by following steps 3 - 5. Press the button to start playback. Disc play indicator CD-MPX850 3" (8 cm) MP3 indicator WMA indicator Total number of files...
  • Page 18 Listening to a CD or MP3/WMA disc (continued) CD-MPX850 Playback will begin from track 1 on disc 1. After that disc finishes playing, the next disc will automatically play. After the last track on the fifth disc is played, the unit will stop automatically.
  • Page 19 To change the display (MP3/WMA discs only) While a disc is playing, press the DISPLAY button. Each time the button is pressed, the display will change as follows. Track number Elapsed playback time File name CD-MPX850 Folder name...

  • Page 20: Advanced Cd Or Mp3/Wma Disc Playback

    Advanced CD or MP3/WMA disc playback CD-MPX850 To specify a disc to play You can play a disc by specifying the disc number. Press one of the 5 buttons to select the desired disc. Selected disc number Within 5 seconds, press the Playback will begin from track 1 on the chosen disc.
  • Page 21 In random play, the unit will select and play tracks automatically. (You cannot select the order of the tracks.) Caution: After performing repeat or random play, be sure to press the ) button. Otherwise, the disc(s) will play continuously. CD-MPX850...

  • Page 22: Advanced Cd Or Mp3/Wma Disc Playback

    Advanced CD or MP3/WMA disc playback (continued) CD-MPX850 Programmed play You can choose up to 32 selections for playback in the order you like. While in the stop mode, press the MEMORY button to enter the programming save mode. Press one of the 5 buttons to select the desired disc.

  • Page 23: Mp3/Wma Navigation (Only For Mp3/Wma Files)

    Up to 100 folders or 300 files can be read on the unit. If either limit is exceeded, no more folders/files are displayed. This unit recognizes and displays up to 48 characters for folder names, and up to 32 characters for title 1/2/3. All file/folder names appear in uppercase. CD-MPX850...
  • Page 24 MP3/WMA navigation (only for MP3/WMA files) (continued) CD-MPX850 File search (by folder or title 1/2/3) You can search and play files by folder or title 1/2/3 within one MP3/ WMA disc. Press one of the containing an MP3/WMA disc. Press the button, and the unit starts to read the MP3 disc.
  • Page 25 For example, press “2” four times to enter “C”. Characters: 2 ABC 3 DEF : indicates a space. cursor button to scroll and select a folder button to start playback. button. 4 GHI 5 JKL 6 MNO 7 PQRS 8 TUV 9 WXYZ CD-MPX850...

  • Page 26: Mp3/Wma Navigation (Only For Mp3/Wma Files)

    MP3/WMA navigation (only for MP3/WMA files) (continued) CD-MPX850 Programmed play (for folder, title 1/2/3) Folders or titles can be programmed within one MP3/WMA disc. Folder, title 1, title 2 and title 3 cannot be programmed together simultaneously. Perform steps 1 - 3 in “File search (by folder or title 1/2/3)”...

  • Page 27: Listening To The Radio

    “ ” will appear when an FM broadcast is in stereo. If the FM reception is weak, press the TUNER (BAND) button to extinguish the “ST” indicator. The reception changes to monaural, and the sound becomes clearer. FM stereo mode indicator FM stereo receiving indicator CD-MPX850 ) button again.

  • Page 28: Listening To The Radio

    Listening to the radio (continued) CD-MPX850 Memorizing a station You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning) Perform steps 1 - 3 in “Tuning” on page 27.

  • Page 29: Tape Playback

    (main unit): The unit turns on and playback of the last function starts (CD,TAPE,TUNER,GAME/VIDEO). Auto power off function: In the stop mode of tape operation, the main unit enters the stand-by mode after 15 minutes of inactivity. CD-MPX850 Tape play indicator...

  • Page 30: Tape Recording

    When recording important selections, make a preliminary test to ensure that the desired material is properly recorded. SHARP is not liable for damage or loss of your recording arising from malfunction of this unit. The volume and sound controls can be adjusted with no effect on the recorded signal (Variable Sound Monitor).
  • Page 31 Playback of the disc will start approximately 7 seconds after the tape starts. To stop recording: Press the (TAPE ) button. The disc and tape will stop. CD-MPX850...
  • Page 32 Recording on a cassette tape (continued) CD-MPX850 To perform programmed recording: 1 Program discs and tracks (see page 22). 2 Press the button. 3 Press the (TAPE ) button to start recording. To stop recording: Press the (TAPE ) button.

  • Page 33: Timer And Sleep Operation (Remote Control Only)

    Within 10 seconds, press the select “ONCE” or “DAILY”, and press the MEMORY button. Once timer Stop Set the clock to the correct time if “ONCE” or “DAILY” does not appear. cassette compartment. button to Continued to the next page CD-MPX850...
  • Page 34 Timer and sleep operation (Remote control only) (continued) CD-MPX850 Within 10 seconds, press the lect “ONCE SET” or “DAILY SET”, and press the MEMORY button. Press the “REC”, and press the MEMORY button. White The illustrations show the daily timer setting.
  • Page 35 3 Within 10 seconds, press the “ONCE ON” or “DAILY ON”, and press the MEMORY button. 4 Press the ON/STAND-BY button to enter the power stand-by mode. CD-MPX850 button to select button to select button to select button to select...

  • Page 36: Timer And Sleep Operation (Remote Control Only)

    Timer and sleep operation (Remote control only) (continued) CD-MPX850 Sleep operation The radio, CD, MP3/WMA disc and cassette tape can all be turned off automatically. Play back the desired sound source. Press the CLOCK/TIMER button. Within 10 seconds, press the button to select “SLEEP”, and press the...

  • Page 37: Enhancing Your System

    (CD,TAPE,TUNER,GAME/VIDEO). To record on a tape from game, VCR, etc. Insert a cassette in the TAPE 2 cassette compartment. Press the GAME/VIDEO button. Press the Press the Yellow Start the game system, VCR, etc. button. (TAPE ) button. CD-MPX850...

  • Page 38: Troubleshooting Chart

    Troubleshooting chart Many potential problems can be resolved by the owner without calling a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center. General disconnects speakers The clock is not set to the correct time.
  • Page 39 Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc (or cassette) in the unit until normal playback is possible (about 1 hour). Wipe off any condensation on the transmitter with a soft cloth before operating the unit. CD-MPX850...

  • Page 40: Troubleshooting Chart

    Troubleshooting chart (continued) CD-MPX850 If trouble occurs When this product is subjected to strong external interference (me- chanical shock, excessive static electricity, abnormal supply voltage due to lightning, etc.) or if it is operated incorrectly, it may malfunc- tion. If such a problem occurs, do the following: 1 Set the unit to the stand-by mode and turn the power on again.

  • Page 41: Maintenance

    Do not apply oil to the inside of the unit. It may cause malfunctions. Specifications As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.
  • Page 42 Specifications (continued) CD-MPX850 CD player Type 5-disc multi-play compact disc player Signal readout Non-contact, 3-beam semiconductor laser pickup D/A converter 1-bit D/A converter Frequency 20 - 20,000 Hz response Dynamic range 90 dB (1 kHz) Tuner Frequency range FM: 87.5 - 108.0 MHz...
  • Page 43 MEMO...

  • Page 44: Consumer Limited Warranty

    Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
