Important Safety Information You MUST read these warnings carefully before installing or using the oven. If you need assistance, contact our Customer Care Department on 08705 950950 Installation Unstable or misshapen pans should not be used on This appliance must be installed and serviced by a the hob as unstable pans can cause an accident by competent person as stated in the Gas Safety tipping or spillage.
Contents For the User For the Installer Important Safety Information Engineers technical data Description of the Hob Important safety requirements Operation Installation Maintenance and Cleaning Building In Something Not Working? Electrical connections Service and Spare Parts Wiring diagram Customer Care Department Fault finding Guarantee Conditions Commissioning...
Operation Hob Burners " To light a burner: push the electric ignition pushbutton which is marked by a little spark ( at the same time turn the relevant control knob anticlockwise to maximum position ( upon ignition, keep the knob pushed down about 5 seconds.
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool.
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
If you should move to another country within Europe then your guarantee moves with you to your new home We, Tricity Bendix, undertake that if, within 12 months of subject to the following qualifications: the date of the purchase, this Tricity Bendix appliance or...
Instructions for the Installer Engineers technical data Overall dimensions Rear Left Burner (semi-rapid) Width 580 mm. Heat Input 2.0 kW (6824 BTU/HR) Depth 500 mm. Height (Above worktop) 8 mm. Front Left Burner (rapid) Heat Input 3.0 kW Natural Gas (10236 BTU/HR) Cut out dimensions 2.8 kW L.P.G.
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) FITTING THE GAS HOB and the IEE Wiring Regulations (Current Edition). WITHOUT A COOKER HOOD ABOVE For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S.
Installation IMPORTANT WHEN THE HOB IS FIRST INSTALLED This hob must be installed by qualified personnel Once the hob has been installed, it is important to the relevant British Standards. to remove any protective materials, which were put on in the factory. Any gas installation must be carried out by a On the end of the shaft, which includes the GJ 1/2"...
Building In ON/OFF SWITCH Building over a cupboard or drawer FLEX If the hob is to be installed above a cupboard or OUTLET drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface.
Electrical Connections Permanent Connection THIS HOB MUST BE EARTHED. In the case of a permanent connection, it is necessary Any electrical work required to install this hob should that you install a double pole switch between the hob be carried out by a qualified electrician or competent and the electricity supply (mains), with a minimum gap person, in accordance with the current regulations.
Wiring diagram 220/240 A. IGNITOR SWITCH B. IGNITOR UNIT Fault finding Preliminary Electrical Systems SOCKET Check PLUG (with cover removed) (face view) Earth Wire Green/Yellow Blue Brown Green START Yellow Isolate appliance and carry out: Neutral Wire A: Earth Continuity Blue check.
Page 14
Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse and Light burner manually replace if necessary Check polarity and Check by pass simmer earth continuity of adjusted supply point Check position of the Check earth continuity electrode of appliance...
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
