Summary of Contents for Tricity Bendix TBG700
- Page 1 User Manual TBG700...
- Page 2 Welcome to the world of Electrolux Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.
-
Page 3: Table Of Contents
Contents Important Safety Information ... 4 Instructions for the User ... 8 Description of the Hobs ... 6 Operation ... 8 Maintenance and Cleaning ... 10 Something Not Working? ... 12 Standard Guarantee Conditions ... 28 Service and Spare Parts ... 29 European Guarantee ... -
Page 4: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 950950 Installation This appliance must be installed and serviced by a competent person as stated in the Gas Safety (Installation and Use) Regulations Current Editions and the IEE Wiring Regulations. - Page 5 Ensure the control knobs are in the ‘OFF’ position when not in use. When using other electrical appliances, ensure the cable does not come into contact with the hot surfaces of the cooking appliance. Unstable or misshapen pans should not be used on the hob as unstable pans can cause an accident by tipping or spillage.
-
Page 6: Description Of The Hobs
Description of the Hob Hob Top Semi-rapid Burner Triple Crown Burner Rapid Burner Auxiliary Burner 6-10 Control Knobs... - Page 7 INSTALLATION Any gas installation must be carried out by a registered competent person, and in accordance with existing rules and regulations. The relevant instructions are to be found in the second section of this manual. Please, ensure that, once the hob is installed, it is easily accessible for the engineer in the event of a breakdown.
-
Page 8: Instructions For The User
Operation Hob burners control knobs The symbols on the knobs mean that : there is no gas supply there is maximum gas supply there is minimum gas supply Lighting the burners For easier lighting, proceed before putting a pan on the pan support. To light a burner: push in the relevant control knob and turn it anticlockwise to maximum position ), to ignite the burner. - Page 9 Burner Triple crown Large (rapid) Medium (semi-rapid) Small (auxiliary) As soon as a liquid starts boiling, turn down the flame so that it will barely keep the liquid simmering. Use only pans or pots with flat bottom. If you use a saucepan which is smaller than the recommended size, the flame will spread beyond the bottom of the vessel, causing the handle to overheat.
-
Page 10: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. This appliance cannot be cleaned with steam or with a steam cleaning machine. -
Page 11: The Burners
The Burners The burner caps and crowns can be removed for cleaning. Wash the burners caps and crowns using hot soapy water, and remove marks with a mild paste cleaner. A well moistened soap impregnated steel wool pad can be used with caution, if the marks are particularly difficult to remove. -
Page 12: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM There is no spark when lighting the gas. The gas ring burns unevenly. If after all these checks, your hob still does not operate correctly, contact your local Service Force Centre. -
Page 13: Instructions For The Installer
Instructions for the Installer Engineer technical data OVERALL DIMENSIONS CUT OUT DIMENSIONS SUPPLY CONNECTIONS Gas: R 1/2 inch (1/2 inch male) Rear right hand corner Electric: 230 V 50 Hz supply, 3 core flexible cable with non rewireable plug fitted with a 3 amp cartridge fuse HEAT INPUT Rear Left Burner (semi rapid) - Page 14 BURNER TYPE OF GAS POSITION NOMINAL THERMAL POWER NATURAL GAS 20 mbar NOMINAL FLOW VALUE = RATE 37.78 MJ/m NOZZLE REFERENCE Ws - 50.7 MJ/ m 1/100 mm NOMINAL THERMAL LPG GAS POWER 28-30/37 mbar NOMINAL FLOW VALUE = RATE 49.92 MJ/Kg NOZZLE REFERENCE 1/100 mm...
-
Page 15: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S. 813 Current Editions and the ETCI Rules for Electrical Installations. -
Page 16: Installation
CLEARANCES REQUIRED WHEN FITTING THE GAS HOB WITHOUT A COOKER HOOD ABOVE 700 mm 400 mm Installation IMPORTANT This hob must be installed by a competent person to the relevant Gas Standards. Any gas installation must be carried out by a registered competent person. -
Page 17: Gas Connection
Gas Connection Connection to the gas supply should be with either rigid or semi-rigid pipe, i.e. steel or copper. The connection should be suitable for connecting to R 1/2 (1/2 BSP male thread). When the final connection has been made, it is essential that a thorough leak test is carried out on the hob and installation. -
Page 18: Cut Out Size
Cut Out Size The dimensions of the cut-out are given in the diagram. -
Page 19: Building In
Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. It is also recommended to carry out the electrical connection to the hob as shown in diagrams 1 and 2. -
Page 20: Fitting The Hob Into The Worktop
Fitting the Hob into the Worktop Carry out the building in of the hob as follows: 1. place the seals supplied with the hob on the front edge of the cut out. Then, place them at 50 mm from the side edges and at 10 mm from the rear edge, as shown in the diagram, taking care that the seals meet without overlapping. -
Page 21: Electrical Connections
Electrical Connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed. This hob is designed to be connected to a 230 V 50 Hz AC electrical supply. -
Page 22: Wiring Diagram
Permanent Connection In the case of a permanent connection, it is necessary that you install a double pole switch between the hob and the electricity supply (mains), with a minimum gap of 3 mm between the switch contacts and of a type suitable for the required load in compliance with the current electric regulations. -
Page 23: Fault Finding
Fault Finding Preliminary Electrical Systems Check START Isolate appliance and carry out: A: Earth Continuity check. Has inlet fuse blown? Inlet wiring faulty. Rectify any fault. Isolate appliance and carry out: B: Insulation check. Rectify any fault including replacing fuses as necessary. Carry out: C: Polarity check. - Page 24 A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on W (Ohms) x 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 W (Ohm), check all earth wires for continuity and all contacts clean and tight.
- Page 25 Ignition System / Gas Ignition Ignitor does not spark Check plug top fuse and replace if necessary Check polarity and earth continuity of supply point Check earth continuity of appliance Check continuity from 'N' on the mains connector block and "O" on the ignitor unit Check continuity from 'L' on the mains connector block and the...
-
Page 26: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. 1) Turn the gas tap to the MAX position and ignite. 2) Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 27: Conversion From Natural Gas To Lpg
Conversion from Natural Gas to LPG IMPORTANT The replacement/conversion from natural gas to LPG should only be undertaken by a competent person. It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted. -
Page 28: Standard Guarantee Conditions
Standard Guarantee Conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •The appliance has been correctly installed and used only on the gas and electricity supply stated on the... -
Page 29: Service And Spare Parts
Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning 0870 5 929 929 Your telephone call will be automatically routed to the Service Force Centre co-vering your postcode area. -
Page 30: European Guarantee
European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications: •... - Page 32 www.tricity-bendix.co.uk 35674-6903 02/07 R.0...
