Supplied accessories
Please check and identify the supplied
accessories.
Use numbers indicated in parentheses
when asking for replacement parts.
(Product numbers correct as of March
2009. These may be subject to change.)
1 Remote control
(N2QAYB000396)
1 DAB "T" antenna
(N1EADY000001)
1 FM indoor antenna
(RSAX0002)
2 Batteries
1 AC mains lead
(K2CZ3YY00005)
1 Antenna plug adaptor
(K1YZ02000013)
Note
•
The included AC mains lead is for use with this
unit only. Do not use it with other equipment.
•
Do not use an AC mains lead from other
equipment.
EB
Operating Instructions
Compact Stereo System
Model No.
Dear customer
Thank you for purchasing this product.
Before connecting, operating or adjusting this
product, please read the instructions completely.
Please keep this manual for future reference.
Table of contents
Supplied accessories
Operations in these instructions are described using
remote control, but you can do the operations with
the main unit if the controls are the same.
Your unit may not look exactly as illustrated.
Note
"EB" on the packaging indicates the United Kingdom.
SC-HC3DB
Cover
2
4
5
5
6
8
10
10
14
15
16
18
20
20
21
RQTX0256-B
Advertisement
Table of Contents
Related Manuals for Panasonic SC-HC3DB
Summary of Contents for Panasonic SC-HC3DB
-
Page 1: Table Of Contents
Operating Instructions Compact Stereo System SC-HC3DB Model No. Dear customer Supplied accessories Thank you for purchasing this product. Before connecting, operating or adjusting this Please check and identify the supplied product, please read the instructions completely. accessories. Please keep this manual for future reference. -
