3/8" butterfly air impact wrench
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual & Safety Instructions
Save This Manual
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and
the receipt in a safe and dry place for future reference.
3/8" butterfly
air impact wrench
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright
2011 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly, operating,
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SaVE thiS manual.
ITEM 93100

Advertisement

Table of Contents
loading

Related Manuals for Central Pneumatic 93100

Summary of Contents for Central Pneumatic 93100

  • Page 1 2011 by Harbor Freight Tools No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein.

  • Page 2: Table Of Contents

    Addresses practices not related to personal injury. 3. Keep bystanders, children, and visitors away while operating the tool. Distractions are able to result in the loss of control of the tool. Item 93100...

  • Page 3: Personal Safety

    Item 93100 For technical questions, please call 1-800-444-3353. 5. Do not overreach. keep proper footing and balance at all times.

  • Page 4: Air Source

    WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved eye protection. WARNING marking concerning Risk of Hearing Loss. Wear hearing protection. WARNING marking concerning Risk of Respiratory Injury. Wear NIOSH-approved dust mask/respirator. WARNING marking concerning Risk of Explosion. Item 93100...

  • Page 5: Specific Safety Instructions

    SaVE thESE inStRuctiOnS. Item 93100 For technical questions, please call 1-800-444-3353. 4. Attach all accessories properly to the tool before connecting the air supply. A loose accessory may detach or break during operation.

  • Page 6: Specifications

    90 PSI 1/4″ -18 NPT 10,000 RPM 1000 BPM 4 CFM @ 90 PSI Excess air pressure is hazardous and may cause the tool to exceed stated maximum speed. Throttle Lever (5) Air Inlet (36) Air Regulator (38) Item 93100...

  • Page 7: Setup

    The air hose must be long enough to reach the work area with enough extra length to allow free movement while working. Item 93100 For technical questions, please call 1-800-444-3353. 3. Release the Throttle Lever. 4. Close the in-line shutoff valve between the compressor and the tool.
  • Page 8 Page 8 For technical questions, please call 1-800-444-3353. Item 93100...
  • Page 9 Item 93100 For technical questions, please call 1-800-444-3353. Page 9...

  • Page 10: Operation

    3. Secure loose workpieces using a vise or clamps (not included) to prevent movement while working. 4. There must not be hazardous objects (such as utility lines or foreign objects) nearby that will present a hazard while working. Item 93100...

  • Page 11: General Operating Instructions

    Throttle Lever (Forward - clockwise rotation). cautiOn! Do not hold the socket during use. Item 93100 For technical questions, please call 1-800-444-3353. 9. When the fastener/hardware is tightened or loosened, release the Throttle.

  • Page 12: Maintenance

    For technical questions, please call 1-800-444-3353. 2. Weekly - lubrication: Add a high quality machine oil to the oil inlet by removing the Oil Screw. Oil Screw (3) Figure 2 3. If the vanes need replacement, replace them all as a set. Item 93100...

  • Page 13: Troubleshooting

    4. Dirty, worn or damaged valve. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect air supply before service. Item 93100 For technical questions, please call 1-800-444-3353. likely Solutions 1. Check for loose connections and make sure that air supply is providing enough air flow (CFM) at required pressure (PSI) to the tool's air inlet.

  • Page 14: Parts List And Diagram

    Back Cap Gasket Back Cap Lock Washer Cap Screw - Long Cap Screw - Short Plunger Spring O Ring Valve Seat Valve Spring O Ring O Ring Air Inlet O Ring Air Regulator Retainer Plate Screw Retaining Ring Fixing Ring Item 93100...

  • Page 15: Assembly Diagram

    Diagram Item 93100 For technical questions, please call 1-800-444-3353. 22 23 Page 15...

  • Page 16: Warranty

    90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
