4" AIR ANGLE GRINDER
ASSEMBLY AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools. Diagrams within this
manual may not be drawn proportionally. Due to continuing improvements, actual
product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 11h
Model
95504
. All rights reserved. No portion of this
®
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 95504
Summary of Contents for Central Pneumatic 95504
- Page 1 © manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.
-
Page 2: Specifications
Do not force tool. It will do the job better and more safely at the rate for which it was intended. Do not use inappropriate attachments in an attempt to exceed the tool capacity. SKU 95504 Specifications DESCRIPTION 7-1/2”L x 5”W x 3-3/4”H 1”... - Page 3 Any part that is damaged should be properly repaired or replaced by a qualified technician. Do not use the tool if any switch does not turn On and Off properly. SKU 95504 Page 3...
- Page 4 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools. 19. Do not operate tool if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if your judgment or reflexes are impaired while taking drugs.
-
Page 5: Air Connection
Angle Grinder! When unpacking, check to make all parts listed on Page 8 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual. -
Page 6: Operation
Screw the Handle [35] into the threaded inlet on the side of the Angle Housing [13] as shown in the Assembly Diagram on Page 8. Set the Air Compressor’s pressure regulator to 90 PSI. Connect the Grinder to the Air Compressor’s hose. -
Page 7: Maintenance And Troubleshooting
Once you have turned the Grinder off, continue to hold onto the tool with both hands until the motor stops completely before you set it down. -
Page 8: Assembly Drawing
(not included) NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 95504 Assembly Drawing Page 8 REV 07i, 09l... -
