- Page 1 46” Full High Defi nition LCD TLE-04641C Questions? Need some help? This manual should help you understand your new product. If you have questions, call our toll-free number found on the insert with this icon: Or visit www.polaroid.com.
- Page 2 This TV incorporates High-Defi nition Multimedia Interface (HDMI ) technology. HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. DISPOSAL OF WASTE ELECTRONIC EQUIPMENT BY PRIVATE HOUSEHOLDS WITHIN THE EUROPEAN UNION This sign indicates that this product may not be disposed of with your regular household waste.
-
Page 3: Warnings And Precautions
Warnings and Precautions To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference. This symbol is intended to alert the user to avoid the risk of electric shock. - Page 4 Warnings and Precautions ▪ Use and handle the power cord with care. Do not place any heavy objects on the AC power cord. ▪ Do not pull the AC power cord. Do not handle the AC power cord with a wet hand. ▪...
-
Page 5: Antenna Safety Instructions
Warnings and Precautions Outdoor Antenna Safety Instructions If an outdoor antenna is connected, follow the precautions below: ▪ An outdoor antenna should not be located in any area where it could come in contact with overhead power lines, or any other electric light or power circuits. ▪... -
Page 6: Table Of Contents
CONTENTS Warnings and Precautions Important Safety Instructions ..................1 Antenna Safety Instructions ..................3 Chapter 1 Introducing the LCD TV Key Features ....................... 7 Package Contents ....................... 8 Setting Your LCD TV ....................9 Your LCD TV .......................11 Your Remote Control ....................13 Chapter 2 Installing the LCD TV Connecting a TV Cable or an Antenna .............. -
Page 7: Chapter 1 Introducing The Lcd Tv
Chapter 1 Introducing the LCD TV Chapter 1 Introducing the LCD TV Key Features Various Audio/Video terminals for external equipment connection ▪ 2 set of composite A/V input terminals ▪ 2 SCART input terminals ▪ 1 set of component Video input terminals ▪... -
Page 8: Package Contents
Chapter 1 Introducing the LCD TV Package Contents Make sure all of the following contents are included. LCD TV Bottom Stand / Screw Driver and 6 Screws Remote Control/ VIDEO Cable Component Cable AAA Batteries x 2 POWER P.MODE SWAP S.MODE MUTE CAPTION... -
Page 9: Setting Your Lcd Tv
Setting Your LCD TV How to install the TV Stand If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand, please reference the instructions included in the wall mounting kit(not included). - Page 10 Chapter 1 Introducing the LCD TV How to setup the TV Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal (refer to page 17). Connect the AC power cord at the back of the TV and connect the power cord to wall outlet. Insert the 2 batteries supplied in remote control.
-
Page 11: Your Lcd Tv
Chapter 1 Introducing the LCD TV Your LCD TV Front/Right Side View and Controls The LED light indicates when the LCD TV is activated. Infrared Receiver VOLUME VIDEO1 IN Adjusts the volume up and down. Connects to the composite Selects the main-menu item and change VIDEO Video and Audio output jacks values for items when in the OSD mode. - Page 12 Chapter 1 Introducing the LCD TV Rear View and Jacks VIDEO2 IN Connects to the composite VIDEO and AUDIO(L/R) output jacks on external video equipment. HDMI 1/HDMI 2 IN Connects the all digital AV equipment with HDMI connector.HDMI supports enhanced, high-defi nition video and two-channel digital audio.
-
Page 13: Your Remote Control
Chapter 1 Introducing the LCD TV Your Remote Control POWER Turns the LCD TV on and off. SWAP Swaps between the main and sub window in PIP/POP mode. FREEZE Pressing FREEZE to freeze the current picture, press again to restore the picture. - Page 14 Chapter 2 Installing the LCD TV EXIT Exits the OSD menu. MENU Displays the OSD menu on the screen. ▲▼►◄ Cycles through OSD options and selects individual menu items. OK confi rms option settings. S.MODE Selects sound effect options: Surround/ Live/Dance/Techno/Classic/Soft/Rock/ Pop/Off.
-
Page 15: Chapter 2 Installing The Lcd Tv
Chapter 2 Installing the LCD TV Chapter 2 Installing the LCD TV Refer to the owner’s manual of any external equipment to be connected. When connecting any external equipment, do not connect any AC power cords to wall outlets until all other connections are completed. Connecting a TV Cable or an Antenna Antenna Connection The antenna requirements for good color TV reception are more important than those for a black &... - Page 16 Chapter 2 Installing the LCD TV Use one of the following two diagrams when connecting an outdoor antenna. A: Shows how to use a VHF/UHF combination outdoor antenna. B: Shows how to use a separate VHF and/or UHF outdoor antenna. A.
- Page 17 Chapter 2 Installing the LCD TV Cable TV (CATV) Connection ■ A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75-ohm coaxial cable to the set, connect the 75- ohm cable into the ANT. terminal. ■...
- Page 18 Chapter 2 Installing the LCD TV Use a supplied antenna cable to connect the TV signal to the LCD TV’s TV CABLE terminal. Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.
- Page 19 Chapter 2 Installing the LCD TV SOURCE button on the remote to display the Source List. Use the ▲▼ buttons Press the to select TV, and press the OK button. Main: TV(CABLE/AIR) VIDEO1 (SIDE) VIDEO2 (REAR) VIDEO3 (Scart1) VIDEO4 (Scart2) VIDEO5 (YPbPr) VIDEO6 (HDMI1) VIDEO7 (HDMI2)
-
Page 20: Connecting A Vcr
Chapter 2 Installing the LCD TV Connecting a VCR Rear of TV AV Cable Use a composite cable to connect the VCR’s composite video/audio jacks to the LCD TV’s VIDEO2 IN jacks. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. -
Page 21: Connecting A Video Camera Or Game Console
Chapter 2 Installing the LCD TV Connecting a Video Camera or Game Console Rear of TV Right Side VIDEO AUDIO VIDEO1 IN AV Cable video camera’s or Game Console’s Use a composite cable to connect the composite video/ audio jacks to the LCD TV’s VIDEO2 IN jacks or VIDEO1 IN jacks. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. -
Page 22: Connecting A Dvd Player
Chapter 2 Installing the LCD TV Connecting a DVD Player Rear of TV COMPONENT/AUDIO Cable A/V Cable DVD PLAYER METHOD A: Use a composite cable to connect the DVD player’s composite video/audio jacks to the LCD TV’s VIDEO2 IN jacks. METHOD B: Use a component cable to connect the DVD player’s component output jacks to the LCD TV’s YPbPr IN input jacks. - Page 23 Chapter 2 Installing the LCD TV Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. Press the button on the remote to turn on the LCD TV. To watch a DVD, press the SOURCE button on the remote to select VIDEO2( METHOD A), or VIDEO5 (METHOD B).
-
Page 24: Connecting A Digital Tv Cable Box Or Digital Satellite Receiver
Chapter 2 Installing the LCD TV Connecting a Digital TV Cable Box or Digital Satellite Receiver Rear of TV COMPONENT/AUDIO Cable Use a component cable to connect the satellite receiver’s/TV Cable Box’s component (YPbPr) output jacks to the LCD TV’s component input jacks. Use an audio cable to connect the satellite receiver’s/TV Cable Box’s component audio jacks to the LCD TV’s audio input jacks. -
Page 25: Connecting An Av Equipment With Hdmi Connector
Chapter 2 Installing the LCD TV Connecting an AV Equipment with HDMI Connector Rear of TV HDMI Cable Use a HDMI cable to connect the AV equipment’s HDMI output jack to the LCD TV’s HDMI1/ HDMI2 IN jacks. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. -
Page 26: Connecting An Av Equipment With Dvi Connector
Chapter 2 Installing the LCD TV Connecting an AV Equipment with DVI Connector Rear of TV AUDIO Cable HDMI-to-DVI Cable Use a HDMI-to-DVI cable to connect the AV equipment’s DVI output jack to the LCD TV’s HDMI1/HDMI2 IN jacks. Use an audio cable to connect the AV equipment’s audio output jacks to LCD TV’s HDMI AUDIO jacks. - Page 27 Chapter 3 Using the LCD TV Connecting an A/V Device with SCART Connector Rear of TV DVD PLAYER SCART Cable Use a SCART cable to connect the external A/V device ’s SCART socket to the LCD TV’s VIDEO3(SCART1) or VIDEO4(SCART2) jack. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment.
-
Page 28: Connecting A Pc
Chapter 3 Using the LCD TV Connecting a PC Rear of TV AUDIO Cable VGA Cable Use a VGA cable to connect the PC’s VGA output jack to the LCD TV’s VGA input jack. Use an audio cable to connect the PC’s audio output jacks to LCD TV’s. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. -
Page 29: Connecting An Audio Receiver
Chapter 3 Using the LCD TV Connecting an Audio Receiver For better sound quality, you may want to play the LCD TV audio through your stereo system. AUDIO Cable Audio Receiver Connecting to Audio Receiver: Use an audio cable to connect the audio receiver’s audio LINE IN jacks to LCD TV’s AUDIO OUT jacks. -
Page 30: Chapter 3 Using The Features
Chapter 3 Using the LCD TV Chapter 3 USING THE FEATURES Using Picture-In-Picture The PIP/POP feature allows simultaneous viewing of video from two sources (TV, VCR, DVD etc). Only one source’s audio is played at a time; the user may select which source’s audio is heard. Press the PIP button once to enter Picture-in-Picture mode. - Page 31 Chapter 3 Using the LCD TV Press the PIP button again to view images side by side. Main ▪ Press ◄ ► to toggle the audio source between the main window and the sub window. ▪ Press the SWAP button to swap the pictures between the main and sub windows. ▪...
-
Page 32: Widescreen Viewing
Chapter 3 Using the LCD TV Widescreen Viewing Widescreen function allows viewing of 4:3/16:9 images in wide screen mode, cycling through the following wide screen settings. Press the P.SIZE button repeatedly to select the screen format you want. NORMAL Displays at 4:3 aspect ratio. FULL Stretches the image vertically and horizontally to keeps the image size... -
Page 33: Using Telextext Functions
Chapter 3 Using the LCD TV Using TELETEXT Functions The TELETEXT feature displays all sorts of information provided by the information system company on your screen, such as news, sports, travel offers, weather, fi lm & theater reviews, net issues etc. Press switch on or off teletext display. -
Page 34: Operating The Menu
Chapter 3 Using the LCD TV Operating the Menu Press the button to turn the LCD TV on. Press the MENU button on the remote control, the on-screen menu will appear on the screen. Use the ◄► buttons to select your main menu option. VIDEO MENU: Allows you to make adjustments to your picture settings. - Page 35 Chapter 3 Using the LCD TV TV MENU: Allows you to edit and label channels. Region Selection Searching Manual Scan Update Search Program Edit Favorite Select Exit SETUP MENU: Allows you to set up a variety of features: Language, factory reset, Parental Control, etc. Parental Language English...
-
Page 36: Customizing The Video Settings
Chapter 3 Using the LCD TV Customizing the VIDEO Settings Press the button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select the VIDEO. Use the ▲▼... - Page 37 Chapter 3 Using the LCD TV Display adjustment Press the OK button to enter the Display adjustment setting: H Position V Position Video Select Exit ▪ H Position Adjusts the position of the picture left and right in the window. ▪...
-
Page 38: Customizing The Audio Settings
Chapter 3 Using the LCD TV Customizing the AUDIO Settings Press the button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select the AUDIO. Use the ▲▼... -
Page 39: Customizing The Setup Settings
Chapter 3 Using the LCD TV Customizing the SETUP Settings Press the button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select the SETUP. Use the ▲▼... -
Page 40: Using The Parantal Settings
Chapter 3 Using the LCD TV Using the Parental Settings The Parental blocking can be set up on the TV to block a Channel or a Video Source. Use the ▼ button to select the Parental, and press the OK to display the Parental menu. -
Page 41: Customizing The Tv Settings
Chapter 3 Using the LCD TV Customizing the TV Settings Press the button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select the TV. Use the ▲▼... - Page 42 Chapter 3 Using the LCD TV Program Edit Allows Swap/Insertion/addition/removal of channels on the channel list. Press the OK button to display the Program Edit menu: Program Edit Freq System Name Skip 49.75 - - - - - - - - - - - - - - - - - -...
-
Page 43: Troubleshooting
VOL+ Press the button to increase the volume. Audio noise Move any infrared equipment away from the TV. “Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation, Waltham, MA, USA. For service, support and warranty information, visit www.polaroid.com. - Page 44 Specifications DISPLAY MODES The screen resolution has been optimized during production for the display modes listed below. If the signal from the system equals the standard signal mode, the screen adjusts automatically. If the signal from the system does not equal the standard signal mode, adjust the screen resolution by referring to your video card user guide, otherwise there may be no video.
- Page 45 Specifications SPECIFICATIONS MODEL TLE-04641C LCD Panel Panel Size 46” TFT LCD Brightness Contrast Ratio 1000:1 Max. Resolution 1920x1080 Input Connector VIDEO/AUDIO(L/R) SCART YPbPr/AUDIO(L/R) VGA/AUDIO(L/R) HDMI/AUDIO(L/R) AUDIO OUT(L/R) HEADPHONE Power Source AC 100-240V~, 50/60 HZ Power Consumption 350 W, standby < 3 W Dimension (W x H x D) 43.9 w x 32 h x 11.26 d inch...
