Summary of Contents for Panasonic QuintrixF TX-29AS1D
- Page 1 Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso TX ---29AS1D nic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasoni c¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡ Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pa nasonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Pana Colour television sonic¡Panasonic¡Panasonic¡Panasonic¡Panasonic¡Panaso...
-
Page 2: Table Of Contents
Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new colour television. This is a very advanced television; however, the Quick Start Guide will tell you how to have the TV operating quickly. -
Page 3: Accessories
ACCESSORIES Check that you have the accessories and items shown Operating Instruction book Remote Control Transmitter EUR511200 Batteries for the Remote Control Transmitter. (2 x R6 (UM3) size) TV Guarantee Remote control batteries D Make sure that the batteries are fitted the correct way round. -
Page 4: Quick Start Guide
QUICK START GUIDE Plug in aerial and connect ancillary equipment. SATELLITE RECEIVER Land Deutschland Österreich France Italia España Portugal Nederland Danmark Sverige Norge Suomi Belgien Schweiz ELLADA E.Eu Auswählen Start ATP Suchlauf Abbruch For Switzerland and Belgium, select Select your country the desired language First, ensure that the VCR is in Standby mode. - Page 5 QUICK START GUIDE Slight tilting of the picture may be noticeable or coloured patches may sometimes appear at the corners of the screen (colour purity). The Geomagnetic Correction feature can be used to eliminate them, if necessary: First, ensure the ATP and Q ---Link download procedures are complete. The screen should not be showing any On ---Screen Display menus.
-
Page 6: Basic Controls
BASIC CONTROLS : FRONT PANEL AND REMOTE CONTROL MAINS Power On/Off switch Red light indicates Standby mode. STR (Normalisation store) Headphone socket (see page 24) Used to store tuning and other function settings RCA Audio/Video sockets (page 24) F (Function select) S ---VHS socket (see page 24) Displays the On Screen Display functions, use repeatedly to select from the available... -
Page 7: Using The On Screen Displays
USING THE ON SCREEN DISPLAYS This TV has a comprehensive system of On Screen Display menus to access adjustments and options Select Change Instructions Exit TV/AV Picture menu Menu Title Contrast Sub- -menus Brightness Colour Sharpness Selection bar Indicator for options Colour balance Normal P- -NR... -
Page 8: Picture Menu
PICTURE MENU This menu allows you to make adjustments to the picture quality Open the Picture menu Select Adjust Move to your choice Exit TV/AV Picture menu Increase or decrease levels or Contrast set options Brightness Colour Sharpness TV/AV Press the TV/AV button to exit Colour balance Normal the Picture menu... -
Page 9: Sound Menu
SOUND MENU The Sound menu will allow you to set your personal preferences for all aspects of sound quality SOUND Open the Sound menu Select Adjust Move to your choice Exit TV/AV Sound menu Increase or decrease levels or Volume set options Bass Treble... -
Page 10: Setup Menu
SETUP MENU The Setup menu provides access to various advanced features and also to the Tuning menu SET UP Open the Setup menu Select Change Move to your choice Exit TV/AV Setup menu Increase or decrease levels, set options or access further menus Teletext FLOF Aspect... -
Page 11: Tuning Menu
TUNING MENU The Tuning menu provides access to manual, automatic and fine tuning menus SET UP Open the Setup menu Select Change Move to Tuning menu Exit TV/AV Setup menu Access Tuning menu Teletext FLOF Aspect Off timer Q- -Link Move to your choice Tuning menu OSD language... -
Page 12: Tuning Menu - - Programme Edit
TUNING MENU - - PROGRAMME EDIT The Programme edit menu allows you to edit the programme position settings SET UP Open the Setup menu Select Move to Tuning menu Change Exit TV/AV Setup menu Access Tuning menu Teletext FLOF Aspect Off timer Move to Programme edit menu Q- -Link... - Page 13 TUNING MENU - - PROGRAMME EDIT To add a programme position Choose the programme position Change where the new program is to be programme Select inserted option Return - - Exit TV/AV ’STR’ Button Store Programme edit Press the Green button Prog.
- Page 14 TUNING MENU - - PROGRAMME EDIT To tune a programme position Choose the programme position Change channel Select option Return - - Exit Move to the channel column TV/AV ’STR’ Button Store Programme edit Prog. Chan. Name Lock Increase or decrease channel CH41 number or use the ’C’...
- Page 15 TUNING MENU - - PROGRAMME EDIT To lock a programme position to prevent access Choose the programme position Lock Move to the lock column On/Off Select option Return - - Choose between lock on or lock off Exit TV/AV Store ’STR’...
-
Page 16: Tuning Menu - - Auto Setup
TUNING MENU - - AUTO SETUP (ATP) The Auto setup menu will allow you to automatically retune the TV to your local stations. It is useful if you move to a different region SET UP Open the Setup menu Select Access Move to Tuning menu Exit... -
Page 17: Tuning Menu - - Manual Tuning
TUNING MENU - - MANUAL TUNING Manual tuning of the Programme positions is available either from the On Screen Display menu or from the front panel controls Manual tuning menu SET UP Open the Setup menu Select CH41 Access Return - - Move to Tuning menu Exit TV/AV... -
Page 18: Osd Language
OSD LANGUAGE When you first installed the TV the On Screen Display language was set according to your choice of country. If you wish to use a different language then it can be chosen from the OSD language menu SET UP Open the Setup menu Select Access... -
Page 19: Q- -Link
Auto Power functions With Panasonic Q--Link VCRs these additional features are available: D If you insert a tape in your VCR and press the Play button, the television will automatically switch on and select the AV2 input so you can view the tape. -
Page 20: Av Select And Setup
AV SELECT AND SETUP The AV Select menu will allow you to choose which AV source to view TV/AV Press the TV/AV button Press the appropriate coloured button of remote control (whilst the options remain on screen) The options will disappear You may wish to make adjustments AV2/S AV3/S... -
Page 21: Vcr/Dvd Operation
VCR / DVD OPERATION The Remote Control is capable of operating some functions of selected Panasonic VCRs and DVD (Digital Versatile Disc) equipment. Some VCR and DVD equipment have different functions, so to ensure compatibility please refer to the equipment’s instruction book or consult your dealer for details. -
Page 22: Teletext Operation
TELETEXT OPERATION D Teletext features may vary depending on the Broadcasting Companies and is only available if the channel selected is transmitting Teletext. D Pressing the Picture button whilst in Teletext operation will display the contrast function with a cyan bar, press A "to alter the setting as required. -
Page 23: Sub Coded Page Access
TELETEXT OPERATION It is not possible to change the programme position when in News flash, Update or Sub Coded Page Access operation. Hold HOLD To hold the Teletext page when viewing multi--page information. Press again to return to automatic page update. Favourite Page (F.P .) Stores a favourite page in memory for instant recall. -
Page 24: Audio / Video (Av) Connections
AUDIO / VIDEO CONNECTIONS Front AV3 RCA Audio / Video and Headphone Sockets Press and release to open Video input to Output from S ---Video socket Headphone socket S ---V Video input to Audio input to V socket L / R sockets 3.5mm Stereo Plug 2 x RCA... -
Page 25: Via The Rear Av1 / Av2 21 Pin (Scart) And Rca Audio Out Terminals
AUDIO / VIDEO CONNECTIONS Rear AV1/AV2(S) 21 Pin SCART and RCA Audio Out Terminals HI- -FI SYSTEM 2 x RCA Audio Cables Output from L- -R AUDIO OUT Sockets Input/Output from Input/Output from AV2 SCART Socket AV1 SCART Socket Q--Link data SCART Cable SCART Cable S- -VIDEO VCR... -
Page 26: Troubleshooting
TROUBLESHOOTING Symptoms Checks Checks Picture Sound Aerial location, direction or connection Noisy Sound Snowy Picture Aerial location, direction or connection Normal Sound Multiple Images Electrical appliances Cars / Motorcycles Fluorescent lights Switch on P---NR in Picture menu to reduce picture noise Noisy Sound Interference... -
Page 27: For Your Guidance
D This type of picture tube damage, is not an operating If the set is not switched off when the TV station stops transmitting , defect, and as such is not covered by the Panasonic it will automatically go to standby mode after 30 minutes. This warranty. - Page 28 2001CX...
