Before connecting, operating or adjusting this product, please read
the instructions completely.
Please keep this manual for future reference.
Note:
"EB" on the packaging indicates the United Kingdom.
Operations in these instructions are described using remote
control, but you can do the operations with the main unit if the
controls are the same.
Your unit may not look exactly as illustrated.
SUPPLIED ACCESSORIES
SUPPLIED ACCESSORIES
Please check and identify the supplied accessories.
Use numbers indicated in parentheses
replacement parts. (As of December 2007)
1 x Remote control
(N2QAYB000079)
1 x FM indoor antenna
(RSA0007-L1)
1 x Antenna plug adaptor
(K1YZ02000013)
EB
when asking for
1 x AC mains lead
(K2CT3CA00004)
1 x DAB "T" antenna
(N1EADY000001)
2 x Remote control
batteries
Operating Instructions
CD Stereo System
SC-PM46DB
Model No.

Table of contents

Caution for AC Mains Lead ................... 2
Safety precautions ................................ 2
Placement of speakers .......................... 3
Simple setup .......................................... 4
DEMO function ....................................... 5
Overview of controls ............................. 6
Discs ....................................................... 7
Using the FM radio ................................ 8
DAB ......................................................... 9
Using the timer ...................................... 12
Using sound effects .............................. 13
Using other equipment ......................... 13
Maintenance ........................................... 14
Troubleshooting guide .......................... 15
Specifi cations ......................... Back cover
RQTV0303-1B

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SC-PM46DB

Summary of Contents for Panasonic SC-PM46DB

  • Page 1: Table Of Contents

    Operating Instructions CD Stereo System SC-PM46DB Model No. Before connecting, operating or adjusting this product, please read the instructions completely. Please keep this manual for future reference. Note: "EB" on the packaging indicates the United Kingdom. Operations in these instructions are described using remote...

  • Page 2: Caution For Ac Mains Lead

    Set the unit up on an even surface away from direct sunlight, These operating instructions are applicable to the following system. high temperatures, high humidity, and excessive vibration. These System SC-PM46DB conditions can damage the cabinet and other components, thereby shortening the unit’s service life. Main unit...

  • Page 3: Placement Of Speakers

    • Visit our website for product information • E-mail: customer.care@panasonic.co.uk Note Direct Sales at Panasonic UK • Keep your speakers at least 10 mm away from the system for • Order accessory and consumable items for your product with proper ventilation.

  • Page 4: Simple Setup

    Simple setup Making the connections Making the connections Connect the AC mains lead only after all other connections have been made. Connect the DAB “T” antenna Connect the FM indoor antenna. The cross bar of the T should be kept fi rmly stretched. Find a position with good reception.

  • Page 5: Preparing The Remote Control

    Simple setup (continued) Optional antenna connections Optional antenna connections FM outdoor antenna DAB outdoor antenna FM outdoor antenna DAB outdoor antenna (not included) (not included) 75  coaxial cable (not included) Be sure to fully tighten the screw. • Never use an outdoor antenna during a lightning storm. •...

  • Page 6: Overview Of Controls

    Overview of controls Main unit Main unit Refer to the numbers in parentheses for page reference. AC supply indicator (AC IN) This indicator lights when the unit is connected to the AC mains supply. 1 Standby/on switch (y/l) (7, 12) Display panel Press to switch the unit from on to standby mode or vice versa.

  • Page 7: Discs

    Discs Advanced play Advanced play Basic play Basic play Repeat play Repeat play Press [y] to turn the unit on. You can repeat program play or other selected play mode. Press [0] to open the disc tray and then load the disc. Press [0] again to close the tray.

  • Page 8: Using The Fm Radio

    Using the FM radio Discs (continued) Note Manual tuning Manual tuning • This unit can play MP3 fi les and CD-DA format audio CD-R/RW that have been fi nalized. • It may not be able to play some CD-R/RW depending on the condition of the recording.

  • Page 9: Dab

    DAB stands for digital audio broadcasting. It is a new form of radio DAB reception method on this unit DAB reception method on this unit that is broadcast digitally. Unlike regular analogue broadcasting, digital radio deteriorates less, and is thus able to provide quality sound close to that of a disc.

  • Page 10: Dab Operation

    DAB (continued) Presetting Presetting DAB operation DAB operation Presetting channel Presetting channel Press [DAB] to enter DAB mode. The unit comes on. Up to 20 channels can be set. Press [ /4] or [ /¢] to select a station. Press [PROGRAM]. Press the numeric buttons to select a channel.
  • Page 11 Turning automatic clock Turning automatic clock Changing the Auto scan Changing the Auto scan adjustment function on adjustment function on frequency range frequency range To adjust the time information during DAB broadcasting and automatic Only the frequencies currently used in the UK as of December 2007 time adjustment.

  • Page 12: Using The Timer

    Using the timer Action Setting the clock Setting the clock change the settings Repeat steps 1 to 4 and 6. ˚ change the source 1) Press [ PLAY] to clear the timer This is a 24-hour clock. or volume indicator from the display. 2) Make changes to the source or volume.

  • Page 13: Using Sound Effects

    Using sound effects Using other equipment Connecting and playing a USB Connecting and playing a USB Selecting sound effects Selecting sound effects mass storage class device mass storage class device You can change the sound effect by selecting Preset EQ or adjusting the bass or treble effect.

  • Page 14: Maintenance

    Using other equipment (continued) Compatible devices Compatible devices Changing the remote control code Changing the remote control code Devices which are defi ned as USB mass storage class: • USB devices that support bulk only transfer. Change the code if you fi nd the remote control unintentionally also •...

  • Page 15: Troubleshooting Guide

    Troubleshooting guide Before requesting service, make the below checks. If you can’t fi x the system as described below, or if something not listed here occurs, refer to the enclosed directory to locate an Authorized Service Center convenient to you or contact your dealer. Common problems No sound.

  • Page 16: Specifi Cations

    8 fs D/A converter MASH (1 bit DAC) Matsushita Electric Industrial Co., Ltd. Web Site: http://panasonic.net Pursuant to at the directive 2004/108/EC, article 9 (2) Panasonic Testing Centre RQTV0303-1B Panasonic Marketing Europe GmbH L1207NC1018 Winsbergring 15, 22525 Hamburg, F.R. Germany...
