Kenwood KVT-827DVD Instruction Manual

Monitor with dvd receiver
Hide thumbs Also See for KVT-827DVD:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Installation Manual
MONITOR WITH DVD RECEIVER
KVT-827DVD

INSTRUCTION MANUAL

© B64-3174-00/00 (EV/E2V)

Advertisement

Table of Contents
loading

Related Manuals for Kenwood KVT-827DVD

Summary of Contents for Kenwood KVT-827DVD

  • Page 1: Instruction Manual

    MONITOR WITH DVD RECEIVER KVT-827DVD INSTRUCTION MANUAL © B64-3174-00/00 (EV/E2V)

  • Page 2: Table Of Contents

    Power Switch ..........8 Seek Mode Removing/Attaching the Protection Panel .. 9 Auto Memory Manual Memory KVT-827DVD Basic operations ....10 Preset Select Basic Operations of Remote Controller ... 12 Set Station Name About discs ..........15 DAB Tuner control ........44 Displaying the Easy Control Panel Switching Small Display ......
  • Page 3 DVD Setup ..............60 Sound Effects Menu ........82 Displaying the DVD SETUP 1 screen Sound Effects Menu ..........82 Displaying the DVD SETUP 2 screen Displaying the Control screen Displaying the DVD SETUP 3 screen Displaying the Sound Effects Menu screen Language Setup Audio Control ............83 Parental Level Setup...

  • Page 4: Before Use

    Normal brightness will return after using the monitor for a play. In such a situation, remove the disc and wait for the whilst. condensation to evaporate. If the unit still does not operate normally after a whilst, consult your Kenwood dealer. English...
  • Page 5 Region codes in the world The DVD players are given a region code according to the country or area it is marketed, as shown in the following map. Icons on the DVD discs Icon Description Indicates the region code where the disc can be played. Number of voice languages recorded with the audio function.

  • Page 6: Notes On Playing Mp3/Wma/Jpeg/Mpeg

    Notes on playing MP3/WMA/JPEG/MPEG This unit can play MP3 (MPEG1 Audio Layer 3)/ WMA/JPEG/MPEG (MPEG 1/MPEG 2). Note, however, • Play mode may not be possible when portions of the functions that the MP3/WMA/JPEG/MPEG recording media of Windows Media Player 9 or higher are used. and formats acceptable are limited.
  • Page 7 MP3/WMA/JPEG/MPEG playing order When selected for play, Folder Search, File Search, or for Folder Select, files and folders are accessed in the order in which they were written by the CD/DVD writer. Because of this, the order in which they are expected to be played may not match the order in which they are actually played.

  • Page 8: Opening/Closing The Monitor And Power Switch

    Opening/Closing the Monitor and Power Switch Open the monitor [OPEN/CLOSE] key Close the monitor Turn the power on Hold down the [SRC] key more than one second to turn it off. [SRC] key Do not touch the moving components when you are opening or closing the monitor. If you touch the moving components, •...

  • Page 9: Removing/Attaching The Protection Panel

    Removing/Attaching the Protection Panel Remove the protection panel Attach the protection panel Two hooks Place the right end of the protection panel onto hooks and push it until clicked and locked. Then, push the left end of the panel to lock it. Close the monitor first, then remove or attach the protection panel.

  • Page 10: Kvt-827Dvd Basic Operations

    KVT-827DVD Basic operations ■ When the monitor is open SCRN MODE M.CTRL V.SEL V.OFF AV OUT SEL OPEN/CLOSE DISP ■ When the monitor is closed OPEN/CLOSE DISP 1 Play Disc 4 Search Selectors [Disc insertion slot] [22]/[33] key A disc is played when you insert it.

  • Page 11: Volume Controls

    Band/Folder Selectors [FM]/[AM] key [FM] key switches to the FM1/2/3 band or next folder/ DVD/VCD disc. [AM] key switches to the AM band or previous folder/ TV */ Video disc. R-CAM * p Attenuater [ATT] key Navigation * Attenuaters the volume. Press it again to cancel muting.

  • Page 12: Basic Operations Of Remote Controller

    Basic Operations of Remote Controller ENTER ENTER CANCEL CANCEL MENU MENU RETURN RETURN – – BAND BAND ZOOM ZOOM ¢ ¢ ZOOM ZOOM POSITION POSITION MODE ROUTEM VIEW 1 . ? & 2 ABC 3 DEF MENU ZOOM TOP MENU AUDIO MAPDIR VOICE...
  • Page 13 6 [BAND] key w [2-ZONE] key (When 1 is set to "DVD" or "AUD") DISC DISC TUNER Select a disc and a folder. Turns Zone function on or off each time you press the (When 1 is set to "TV" or "AUD") key.
  • Page 14 Basic Operations of Remote Controller o [0] – [9] key [ ]/[ ] key (When 1 is set to "TV") (When 1 is set to "DVD") (When 1 is set to "AUD") TUNER : Slow Backward. — : Recall the stations on memory. : Slow Forward.

  • Page 15: About Discs

    About discs Handling discs Removing discs • Do not touch the recording surface of the disc. When removing discs from this unit pull them out horizontally. Discs that cannot be used • Discs that are not round cannot be used. •...

  • Page 16: Switching Small Display

    Switching Small Display The Small Display screen mode changes each time the [DISP] key is pressed. OPEN/CLOSE DISP [DISP] key Navigation "NAV" "AUX EXT" Band & Preset Number STANDBY "STANDBY" * Hold down the [DISP] key more than 1 second to switch to the Frequency display. English...

  • Page 17: Switching Screen Mode

    Switching Screen Mode The Screen mode of the monitor changes each time the [MODE] key is pressed. OPEN/CLOSE DISP Full picture mode (FULL) Justify picture mode (JUST) Cinema picture mode (CINEMA) Zoom picture mode (ZOOM) Normal picture mode (NORMAL) • When you select the Menu, Easy Control screen, or Navigation, the display is shown in the full-size display mode automatically. The screen mode of these displays cannot be changed.

  • Page 18: Jpeg Or Mpeg Playback

    Displays the Zoom Control buttons (page 23). w Information Display Button Area (page 23) • For DVD/VCD playback, DVD/VCD picture selection, or controller key operations, see <KVT-827DVD Basic Operations> (page 10). • The information display is cleared automatically after approximately 5 seconds. Also, the information can be displayed automatically when it is updated (page 68).

  • Page 19: Displaying The Easy Control Panel

    JPEG/MPEG playback screen e Folder/File Number Display P 0:01:48 DVD MEDIA r Forword File Search Area Mode: FULL AVOUT: Selects the next folder or file. t Backword File Search Area Selects the previous folder or file. y Picture Control Button Area (page 23) JPEG playback only.

  • Page 20: Displaying The Dvd/Vcd Control Screen

    Title 1 Chap T 0:05:20 c Plays or pauses. 13:50 KENWOOD v Slow Forwards or Backwards. b Turns the PBC function of VCD On or Off. (VCD Ver 2.0) n Switches the Repeat Play operations in the following sequence.
  • Page 21 Controling during DVD Video, Video CD, JPEG or MPEG Playback English...

  • Page 22: Dvd Disc Menu

    ZOOM Menu screen. When you touch a chapter and title, it is played back. Zoom Control Highlight [ Highlight On ] DVD Menu DVD Menu 1. KENWOOD 1. KENWOOD 2. KENWOOD 2. KENWOOD Zoom Cancel Exit 3. KENWOOD 3. KENWOOD 4.

  • Page 23: Vcd Zoom Control

    Controling during DVD Video, JPEG or MPEG Playback VCD Zoom Control Information Display Displays an enlarged VCD screen. Displays the DVD and AV information. Information Display Display the Zoom Control screen Button Area (page 18,19) Zoom Control Button Area (page 18) The information is displayed for 5 seconds.

  • Page 24: Control

    • For CD/MP3/WMA/JPEG/MPEG/Disc Changer playback DVD CD Track 1 P 11:10 and receiver key operations, see <KVT-827DVD Basic Operations> (page 10). During MP3/WMA/JPEG/MPEG playback • The Easy Control Panel is hidden when you touch a central area of the monitor.

  • Page 25: Changer Control Screen

    Displaying the CD/MP3/WMA/JPEG/ MPEG/Disc Changer Control screen During CD playback You can play the CD/MP3/WMA/JPEG/MPEG/Disc 9 Adjusts the volume. changer using various functions. p Calls the CD Menu. q Calls the Sound Effects Menu. (page 82) w Switches the source. Displays the Source Select screen.
  • Page 26 MP3/WMA/JPEG/MPEG Control screen During MP3/WMA/JPEG/MPEG play MENU / Ejects a disc. z Fast Forwards or Fast Backwards.. (Disabled when a JPEG is being played.) Direct DVD MEDIA DVD MEDIA x Stops to play. Folder Folder Next When pressed twice, the disc is played back from DISP SCRL its beginning in the next time.

  • Page 27: Set Disc Name

    CD/MP3/WMA/JPEG/MPEG/Disc Changer Play Control Disc Changer Control screen During play by the disc changer MENU I Selects a track. Disc Starts Fast Forward or Fast Backwards when it is held down. Direct CD-CH O Selects a disc. Disc Next : Plays or pauses. DISP SCRL TIME...

  • Page 28: Changer Menu Screen

    Displaying the CD/MP3/WMA/JPEG/ MPEG/Disc Changer Menu screen Selects options from various function menus. You can select menu options using various Returns to the CD/MP3/WMA/JPEG/MPEG/Disc functions. Changer Control screen. MENU • The available functions vary depending on the source used. CD Menu screen MENU MENU Name Set...

  • Page 29: Set Disc Name

    CD/MP3/WMA/JPEG/MPEG/Disc Changer Play Control Set Disc Name Select Folder (during MP3/WMA/JPEG/ MPEG play) Names a CD. The folders of an MP3/WMA/JPEG/MPEG disc are Play a CD you wish to name listed for quick search. Call the CD/Disc Changer Menu Call the MP3/WMA/JPEG/MPEG Menu MENU MENU Select the Set Name mode...

  • Page 30: Id3/Wma Tag Display (During Mp3/Wma Play)

    The discs loaded on the disc changer are listed for listed. quick disc selection. Call the MP3/WMA/JPEG/MPEG Menu Call the Disc Changer Menu MENU MENU Display the ID3/WMA TAG Call the Disc Select Menu Infomation CH Disc Select 1.KENWOOD MENU MENU Title: KENWOOD 2.KENWOOD DISP Artist: KENWOOD 3.KENWOOD 4.KENWOOD...

  • Page 31: Direct Search

    CD/MP3/WMA/JPEG/MPEG/Disc Changer Play Control Direct Search Searches for a disc or a track when its number is entered. During play on the built-in disc player Select the Direct Search mode # BS DIRECT The following items can be searched directly each time it is pressed.

  • Page 32: Tuner Control

    5 Switches the Seek mode. (see page 34 for the <Seek Mode>) Displaying the Easy Control Panel • For receiver key operations, see <KVT-827DVD Basic Operations> (page 10). • The Easy Control Panel is hidden when you touch a central area of the monitor.

  • Page 33: Displaying The Tuner Menu Screen

    ; Turns the Local seek function On or Off. a When buttons appear, you can recall the stations on memory. For memory of broadcasting stations, see <Auto Memory> (page 34) or <Manual Memory> (page 34). s Indicates current Seek mode. d Clock Display When touched, the display of Clock 1, Clock 2, and Clock 3 are switched one after the other.

  • Page 34: Seek Mode

    Seek Mode Manual Memory Sets a station selection. Stores the current receiving station in memory. Select a station you wish to store in memory SEEK is not shown, touch SEEK Next The mode is switched in following order each time Store in memory you touch the button.

  • Page 35: Preset Select

    Tuner Control Preset Select Lists and tunes in stations in memory one after the other. Call the Tuner Menu MENU Call the Preset Select Menu Preset Select P1 87.9 MHz MENU P2 90.1 MHz P3 98.1 MHz P4 87.9 MHz TUNER P5 87.9 MHz P6 87.9 MHz...

  • Page 36: Direct Search

    Direct Search Traffic Information Tunes in a station when its frequency is entered. When a traffic bulletin starts, any source is switched to the traffic information and it is displayed Select a band automatically. – BAND When the traffic bulletin starts... The Traffic Information screen appears automatically.

  • Page 37: Search For Program Type

    Tuner Control Search for Program Type Radio Text A program is tuned when you set its program type. You can display the radio text. (Only when receiving the FM broadcast.) (Only when receiving the FM broadcast.) Call the Tuner Menu Call the Tuner Menu MENU MENU...

  • Page 38: Tv/ Video Control

    Switches to TV1, TV2, VIDEO1 or VIDEO2. 8 Information Display Button Area • For TV picture selection and receiver key operations, see <KVT-827DVD Basic Operations> (page 10). • The information display is cleared automatically after approximately 5 seconds. Also, the information can be displayed automatically when it is updated (page 68).

  • Page 39: Displaying The Tv Control Screen

    Displaying the TV Control screen t Adjusts the volume. You can tune in a TV station using various y Calls the TV Menu. functions. u Calls the Sound Effects Menu. (page 82) i Displays the Source Select screen. (page 51) o Calls the Setup Menu.

  • Page 40: Displaying The Tv Menu Screen

    Displaying the TV Menu screen z Selects option from various function menus. You can select menu options using various x Returns to the TV Control screen. functions. MENU TV Menu screen MENU MENU Preset Select Name Set English...

  • Page 41: Seek Mode

    Before Use TV/ VIDEO Control Seek Mode Auto Memory Sets a TV station selection. Stores stations with good reception in memory automatically. SEEK Select a band you wish to store in memory is not shown, touch SEEK Next The mode is switched in following order each time you touch the button.

  • Page 42: Manual Memory

    Before Use Manual Memory Preset Select Stores the current receiving channel in memory. Lists and tunes in stations in memory one after the other. Select a channel you wish to store in memory Call the TV Menu (Page 39 y) MENU Store in memory Call the Preset Select Menu...

  • Page 43: Set Station Name

    TV/ VIDEO Control Set Station Name Names a station. Select a station you wish to name Call the TV Menu (Page 39 y) MENU Select the Set Name mode Name Set Enter a name For character entry details, see <Character Entry> (page 50).

  • Page 44: Dab Tuner Control

    Displaying the Easy Control Panel 6 Switches the Seek mode. (see page 46 for the <Seek Mode>) • For system key operations, see <KVT-827DVD Basic Operations> (page 10). • The Easy Control Panel is hidden when you touch a central area of the monitor.

  • Page 45: Displaying The Dab Tuner Menu Screen

    ; When buttons appear, you can recall a service on memory. a Indicates current Seek mode. s Clock Display When touched, the display of Clock 1, Clock 2, and Clock 3 are switched one after the other. Displaying the DAB Tuner Menu screen d Selects option from various function menus.

  • Page 46: Seek Mode

    Seek Mode Service Preset Memory A service selection method can be set. The current receiving service is stored in memory. Select a service you wish to store in memory SEEK Band Service Service is not shown, touch SEEK Next The mode is switched in following order each time Store in memory you touch the button.

  • Page 47: Service Select

    DAB Tuner control Service Select Language Filter The service list of the currently receiving ensemble The languages are list for your selection. is displayed for your selection. Call the DAB Tuner Menu Call the DAB Tuner Menu MENU MENU Call the Language Filter Menu Call the Service Select Menu Language Filter Service Select...

  • Page 48: Search For Program Type

    Search for Program Type Select a program type The services are received when you set its program type. Call the DAB Tuner Menu Select a Language 1. Display the Language select screen MENU LANG Call the PTY Search Menu MENU PTY Search News SRCH...

  • Page 49: Dab Information

    DAB Tuner control DAB Information DAB Announcement The DAB information is displayed. When the Announcement you have turned on starts, any source is switched to the Announcement Call the DAB Tuner Menu automatically. When the announcement starts... MENU The Announcement screen appears automatically. Display the DAB Information screen Announcement screen MENU...

  • Page 50: Character Entry

    Character Entry How To Use the Character Entry screen 1 Shifts the cursor. When you select the Set Disc Name mode or 2 Enters a space. others, the following screen appears for character If you erase a character, locate the cursor on it and entry.

  • Page 51: Source Select

    DVD VIDEO SCRL TIME Title 1 Chap T 0:05:20 13:50 KENWOOD Displaying the Source Select screen 1 Adjusts the volume. 2 Select the source. Direct 3 Returns to the Control screen previously displayed. 4 Calls the Sound Effects Menu. (page 82) 5 Calls the Setup Menu.

  • Page 52: Adjusting The Monitor Display Position And Quality

    Adjusting the Monitor Display Position and Quality You can adjust the position and picture quality of the monitor. Displaying the Screen Control screen 1 Brightness Control You can adjust the picture quality using the Disabled if the Auto Dimmer is On. following keys.

  • Page 53: Setup Menu

    DVD VIDEO SCRL TIME Title 1 Chap T 0:05:20 13:50 KENWOOD Displaying the Setup Menu screen 1 Adjusts the volume. 2 Scrolls the Setup Menu. 3 Calls each Setup Menu. 4 Calls the Sound Effects Menu. (page 82) Setup Menu screen...

  • Page 54: Audio Set Up

    Control during DVD Video, DVD Audio or Video CD Playback Audio Set Up (Other than STANDBY mode) You can set up the car type and speaker system you use together with this unit. Displaying the Car Type Set Up screen 1 Adjusts the volume.

  • Page 55: Displaying The Channel Level Screen

    Before Use Setup Menu Displaying the Channel Level screen r Selects a speaker to be set. You can set the volume at each setup position. (see <Channel Level>, page 57) t Sets the speaker volume. (see <Channel Level>, page 57) y Starts or stops test signal tone output for setup Channel Level screen check.

  • Page 56: Speaker Set Up

    Speaker Set Up Select a speaker type You can select a speaker type and its size to get the best sound effects. Select a speaker you wish to adjust You can select any of the following speaker types. (Page 54 8) Center speaker: NONE, 40mm x 70mm, 5cm, 10cm, 13cm, Speaker Set Up screen...

  • Page 57: Channel Level

    Before Use Setup Menu Channel Level You can set the volume at each setup position. Select a speaker you wish to adjust (Page 55 r) Channel Level setup screen MENU Test Front Right +8 dB Channel Level Channel Level Channel Level 1 Center speaker 2 Left front speaker 3 Right front speaker...

  • Page 58: Dta Setup

    Before Use DTA Setup Set a delay time Manually sets the sound output timing of each channel. Display the DTA Setup screen The speakers are virtually moved to the desired distance. (Page 54 6) When the values of center speaker and front speakers increase, they are virtually moved forward.

  • Page 59: Crossover Network Setup

    Before Use Setup Menu Crossover Network Setup You can manually set a crossover frequency of speakers. (Page 54 p) X'Over X'Over Subwoofer 100Hz 1kHz Frequency Phase Normal 80 Hz Phase Normal Slope 12dB/Oct Return 1 Sets a crossover frequency. 2 Sets a crossover slope. 3 Returns to the Speaker Set Up screen.

  • Page 60: Dvd Setup

    Before Use DVD Setup You can set up the DVD play. Displaying the DVD SETUP 1 screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. DVD SETUP 3 Calls the Sound Effects Menu. (page 82) DVD SETUP 1 screen 4 Calls the Setup Menu.

  • Page 61: Displaying The Dvd Setup 3 Screen

    Before Use Setup Menu Displaying the DVD SETUP 2 screen p Displays the Parental Lock screen.* OFF) (See <Parental Level Setup>, page 63) q Sets an angle mark display. ( w Selects the screen display mode.* 16:9) "16:9": Displays wide pictures. DVD SETUP 2 screen "4:3 (LB)": Displays wide pictures in the Letter Box format (having black stripes at the top...

  • Page 62: Language Setup

    Language Setup Abbreviation Language Abbreviation Language Latvian, Lettish Afar Selects a language you use for the speech and Malagasy Abkhazian Maori Afrikaans menus. Macedonian Amharic Malayalam Arabic Display the Language Setup screen Mongolian Assamese Moldavian Aymara See <Displaying the DVD SETUP 1 screen> (page Marathi Azerbaijani 60) and select a language you wish to use.

  • Page 63: Parental Level Setup

    Before Use Setup Menu Parental Level Setup Display the Parental Level Setup screen Sets a parental level. Enter Display the Parental Level code number screen Return (Page 61 p) Parental Pass Cancel Level 5 Level 5 1 Sets a parental level. Enter Clear 2 Returns to the DVD SETUP 2 screen.

  • Page 64: System Setup

    System Setup You can set up the system parameters. Displaying the System 1 screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. System Set Up 3 Calls the Sound Effects Menu. (page 82) System 1 screen 4 Calls the Setup Menu.

  • Page 65: Displaying The System 2 Screen

    Setup Menu Displaying the System 2 screen 9 Set a music CD playback. ( "1": Automatically recognizes and plays back an MP3/WMA disc, a DVD or a music CD. "2": Forcibly plays back a disc as a music CD. Select "2" if you wish to play a music CD System 2 screen having a special format or if you cannot play a disc in the "1"...

  • Page 66: Av Interface

    4 Calls the Setup Menu. 5 Selects a navigation system connection. ( RGB) MENU Navigation "RGB": Allows the Kenwood’s Navigation System to connect via its interface cable. AV-IN1 Name "AV-IN1": Allows a third-party navigation system to VIDEO1 connect via the AV INPUT1 port.

  • Page 67: Displaying The Av I/F 2 Screen

    Before Use Setup Menu Displaying the AV I/F 2 screen p Sets a method to switch to the rear view camera video display. ( Off) "On": Switches to the rear view camera video display when engaging the shift knob of car to "Reverse".

  • Page 68: User Interface

    Control during DVD Video, DVD Audio or Video CD Playback User Interface You can set up user interface (IF) parameters. Displaying the User I/F 1 screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. User Interface 3 Calls the Sound Effects Menu.

  • Page 69: Displaying The User I/F 3 Screen

    Setup Menu e Sets an on-screen display of the TV screen. Auto) (when the optional accessory TV tuner in connected only) "Auto": Information is displayed for 5 seconds when updated. "Manual": Information is displayed when you touch on the screen. r Displays the User I/F 1 screen.

  • Page 70: Touch Panel Adjustment

    Touch Panel Adjustment Adjust the positions You can adjust the touch panel operations. Display the Touch Panel Adjust screen Touch the center of left lower and right upper when requested. Touch is not shown, touch Touch Prev. to display it. Next MENU Touch Panel Adjust...

  • Page 71: Clock

    Setup Menu Clock You can adjust the clock time. Display the Clock screen Clock is not shown, touch Clock Prev. to display it. Next MENU 13:50 Reset RDS Synchronize Clock Clock Clock 1 Adjusts the volume. 2 Returns to the Control screen of the previous source.

  • Page 72: Security Code Setup

    Before Use Security Code Setup Start the security code registration You can set a security code to protect your receiver system against theft. PassWord Cancel • When the Security Code function is activated it cannot be released. Note, your Security Code is the 4 digit number entered in your "Car Audio Passport"...
  • Page 73 Before Use Setup Menu If you have pressed the Reset button or if you have disconnected the Receiver from battery... Enter the correct security code — You must enter the same security code as that you have entered in Step 3 above. Enter the security code Enter Now, you can use your Receiver.

  • Page 74: Set Up Memory

    1 Recalls the memorized settings. Set Up Memory 2 Memorizes the current Audio Set Up and AV Audio Set Up and AV Interface settings can be Interface settings. memorized. The memorized settings can be recalled 3 Clears the currently memorized settings. at any time.
  • Page 75 Setup Menu English...

  • Page 76: Tv Setup

    TV Setup The TV signal receiving areas can be set. (with the optional accessory TV Tuner connected only) Displaying the TV1 Area Set Up screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. TV Set Up 3 Calls the Sound Effects Menu.

  • Page 77: Rds Setup

    Setup Menu RDS Setup The related RDS parameters can be set. Displaying the RDS Set Up1 screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. RDS Set Up 3 Calls the Sound Effects Menu. (page 82) RDS Set Up1 screen 4 Calls the Setup Menu.

  • Page 78: Dab Set Up

    DAB Set Up You can set the DAB reception. (only with the optional accessory DAB Tuner connected) Displaying the DAB Set Up screen 1 Adjusts the volume. 2 Calls the Sound Effects Menu. (page 82) DAB Set Up 3 Returns to the Control screen of the previous source.

  • Page 79: Announcement Selection

    Setup Menu Announcement Selection Set the announcement parameters You can set various announcement reception Traffic News — Financial News parameters. Displays the Announcement Selection screen Traffic News Event (Page 78 9) Transport News Special Event Warning Radio Info News Sports News Traffic News Event Transport News...

  • Page 80: Amp Control

    Setup Menu AMP Control Sets the power amp connected via the LX bus. (with the optional accessory LX Power Amp connected only) Displaying the AMP Control screen 1 Adjusts the volume. 2 Calls the Setup Menu. 3 Calls the Sound Effects Menu. (page 82) 4 Returns to the Control screen of the previous AMP Control screen source.

  • Page 81: Muting Audio Volume Upon Reception Of Phone Call

    Muting Audio Volume upon Reception of Phone call Muting Audio Volume upon Reception of Phone call When the telephone is called, the system is paused automatically. When the telephone is called... The Phone Call ("CALL") screen appears, and system is paused. Phone Call ("CALL") screen MENU MENU...

  • Page 82: Sound Effects Menu

    DVD VIDEO DVD VIDEO SCRL TIME Title 1 Chap T 0:05:20 KENWOOD 12:56 Displaying the Sound Effects Menu screen 1 Adjusts the volume. 2 Calls the Sound Effects Menu. 3 Calls the Setup Menu. (page 53) 4 Returns to the Control screen of the previous Sound Effects screen source.

  • Page 83: Audio Control

    Before Use Audio Control You can adjust the front and rear and right and left audio balance. Displaying the Audio Control screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. Audio Control 3 Calls the Setup Menu. (page 53) Audio Control screen 4 Calls the Sound Effects Menu.

  • Page 84: Equalizer

    Equalizer You can set up the equalizer. Displaying the Equalizer screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. Equalizer 3 Calls the Setup Menu. (page 53) Equalizer screen 4 Calls the Sound Effects Menu. 5 Adjusts the bass boost of the B.M.S power amplifier MENU BMS AMP Bass...

  • Page 85: Parametric Equalizer

    Sound Effects Menu Parametric Equalizer Set a gain You can manually set the equalizer curve by adjusting the center frequency, gain and Q value. Display the Parametric Equalizer screen Set a Q value P-EQ Parametric Equalizer Flat Close the Parametric Equalizer screen Return 80Hz 315Hz...

  • Page 86: Surround Control

    Surround Control You can set up the sound field. Displaying the Surround Control screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. Surround Control 3 Calls the Setup Menu. (page 53) Surround Control screen 4 Calls the Sound Effects Menu.

  • Page 87: Surround Control Adjustment

    Sound Effects Menu Surround Control Adjustment • You cannot use the <Surround Control Adjustment> You can adjust the sound field. during playback of Multi channel source. Display the Surround Control screen • You cannot use the <Surround Control Adjustment> when the sound field of "Dolby PLII Movie", or "Dolby PLII Matrix"...

  • Page 88: Srs Wow Control

    SRS WOW Control You can set up the SRS WOW effect. Displaying the SRS WOW Control screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. SRS WOW 3 Calls the Setup Menu. (page 53) SRS WOW Control screen 4 Calls the Sound Effects Menu.

  • Page 89: Srs Wow User Setup

    Sound Effects Menu SRS WOW User Setup Display the SRS WOW Adjust screen Adjust SRS WOW Adjust screen SRS WOW Adjust TruBass 3 FOCUS 5 SRS 3D 1 Return 1 Adjusts the volume. 2 Selects a speaker to be set (Front, Rear or Center speaker).

  • Page 90: Position

    Position You can adjust the sound effects according to your listening position. Displaying the Position screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. Position 3 Calls the Setup Menu. (page 53) Position screen 4 Calls the Sound Effects Menu.

  • Page 91: Position Fine Control

    Sound Effects Menu 1 Center speaker Position Fine Control 2 Left front speaker You can fine-adjust your listening position. 3 Right front speaker 4 Left rear speaker Display the Position Fine Control screen 5 Right rear speaker 6 Subwoofer Adjust Set a delay time Position Fine Control screen Position Fine Control...

  • Page 92: Zone Control

    Sound Effects Menu Zone Control You can set the front and rear audio source. Displaying the Zone Control screen 1 Adjusts the volume. 2 Returns to the Control screen of the previous source. Zone Control 3 Calls the Setup Menu. (page 53) Zone Control screen 4 Calls the Sound Effects Menu.

  • Page 93: Glossary

    Glossary DVD: Digital Versatile Disc Title number (DVD) A type of disc which contains recording of audio/ The title is the largest unit of video and audio video packaged media with high video and audio recorded in a DVD. It usually corresponds to a quality, such as a movie, featuring large recording single movie of video software or an album (some- capacity and digital signal processing capability.

  • Page 94: Troubleshooting Guide

    Troubleshooting Guide Some system functions are limited to control depending on your setup. • Zone cannot be set. • The "Rear Bass Boost" of Surround Control Adjust cannot be set. The rear speakers have been set to • The rear speakers of DTA cannot be set. "NONE"...
  • Page 95 What might appear to be a malfunction in your unit may just be the result of slight misopera- tion or miswiring. Before calling service, first check the following table for possible problems. ✔ The parking brake is not engaged. General For safety reasons no television/video images The power does not turn on.
  • Page 96 Before Use The sound quality is poor or distorted. The voice (or subtitle) language cannot be ✔ One of the speaker wires is being pinched by a changed. ✔ screw in the car. The DVD disc being played does not contain Check the speaker wiring.
  • Page 97 Before Use Troubleshooting Guide MP3/WMA source The specified disc does not play, but another one plays instead. Cannot play an MP3/WMA. ✔ The specified CD is quite dirty. ✔ The media is scratched or dirty. Clean the CD. Clean the media, referring to the Disc cleaning ✔...
  • Page 98 Mecha Error The disc player is malfunctioning. ] Eject the disc and try inserting it again. Contact the Kenwood dealer if this indicator continues blinking or the disc cannot be ejected. Disc Error The unplayable discs is inserted. Read Error The disc is upside-down.

  • Page 99: Specifications

    Specifications Specifications subject to change without notice. Monitor Section DSP Section Picture size 4 BAND Parametric equalizer : 6.95 inches (diagonal) wide BAND1 frequency: 60/80/100/120/160/200Hz 154.1(W)×87.1(H)mm BAND2 frequency: 250/315/400/500/630/800/1kHz Display system BAND3 frequency: 1.25k/1.6k/2k/2.5k/3.15k/4kHz : Transparent TN LCD panel BAND4 frequency: 5k/6.3k/8k/10k/12.5k/16kHz Drive system Gain : TFT active matrix system...
  • Page 100 Specifications Video section Color system of external video input : NTSC/PAL External video input level (RCA jacks) : 1Vp-p/75Ω External audio max input level (RCA jacks) : 1V/22kΩ Analog RGB input : 0.7Vp-p/75Ω Audio section Maximum Power (Front&Rear) : 50W×4 Output power (Front&Rear) (DIN 45324, +B=14.4V) : 30W×4 Preout level (V)
  • Page 101 The marking of products using lasers (Except for some areas) CLASS 1 LASER PRODUCT The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit.
