ASSEMBLY

• To hire an authorized service technician to
assemble the treadmill, call 1-800-445-2480.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• After shipping, there may be an oily substance
on the exterior of the incline trainer. This is nor-
mal. If there is an oily substance on the incline
trainer, wipe it off with a soft cloth and a mild,
non-abrasive cleaner.
1. Make sure that the power cord is unplugged.
Place a piece of cardboard below the rear of the
Frame (56) to protect the floor or carpet.
Attach the Left Wheel Cap (96) to the Base (94)
with two #8 x 3/4" Screws (2).
Attach the Right Wheel Cap (not shown) to
the right side of the Base (94) in the same
way.
2. Pull the Upright Wire (81) and the Base Ground
Wire (110) through the indicated hole in the Base
(94).
Attach the Base Ground Wire (110) to the Base
(94) with a #8 x 1/2" Ground Screw (10).
• To identify small parts, see page 6.
• Assembly requires the following tools:
the included hex key
one adjustable wrench
one Phillips screwdriver
one pair of scissors
To avoid damaging parts, do not use power
tools.
1
94
2
2
Hole
81
10
7
56
96
Cardboard
110
94
