Onkyo T-4030 Instruction Manual

Dab/fm tuner
Hide thumbs Also See for T-4030:
Table of Contents

Advertisement

Quick Links

DAB/FM Tuner
T-4030
Instruction Manual
Thank you for purchasing an Onkyo Tuner. Please read
this manual thoroughly before making connections and
plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Tuner.
Please retain this manual for future reference.
Contents
Introduction
..................................En-
Connections
.............................. En-
Enjoying Audio Sources
Appendix
Troubleshooting
..................... En-
Specifications
......................... En-
2
10
14
...... En-
22
23
E
n

Advertisement

Table of Contents
loading

Related Manuals for Onkyo T-4030

Summary of Contents for Onkyo T-4030

  • Page 1 Instruction Manual Connections ......En- Enjoying Audio Sources ..En- Thank you for purchasing an Onkyo Tuner. Please read this manual thoroughly before making connections and plugging in the unit. Appendix Following the instructions in this manual will enable Troubleshooting .....

  • Page 2: Important Safety Instructions

    WARNING: WARNING AVIS RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR ELECTRIC DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS The lightning flash with arrowhead symbol, within an TO RAIN OR MOISTURE. equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Precautions

    ELECTRONICS GmbH are wet or damp. If water or any other liquid gets LIEGNITZERSTRASSE 6, inside this unit, have it checked by your Onkyo 82194 GROEBENZELL, GERMANY dealer. declare in own responsibility, that the ONKYO product 8.

  • Page 4: Features

    Features ❑ DAB+/DAB Capability ❑ Digital Outputs (Optical/Coaxial) ❑ 40 FM and 40 DAB+/DAB Preset ❑ FM Digital Output Capability ❑ RDS ❑ Preset Station Naming (Up to 8 Characters) ❑ Automatic/Manual Tuning ❑ FM Mono Mode for Weak Signals ❑...

  • Page 5: Table Of Contents

    Connecting Your Components......11 Before Making Any Connections......11 Cable and Jacks ............11 Connecting to an Amplifier........12 Connecting Onkyo R Components....... 13 Connecting the Power Cord ........13 Turning On and Standby ......... 13 Listening to the Radio........14 Listening to FM Stations.........

  • Page 6: Supplied Accessories

    • Expired batteries should be removed as soon as R cable To use R, T-4030 must be connected with an R cable. possible to prevent damage from leakage or corrosion. Aiming the Remote Controller When using the remote controller, point it toward the tuner’s remote control sensor, as shown below.

  • Page 7: Getting To Know The Tuner

    Getting to Know the Tuner Front Panel 3 4 5 For detailed information, see the pages in parentheses. k ON/STANDBY button (13, 22) PS/RT/PTY button (17, 20) DISPLAY button (18) MEMORY button (15, 16) BAND button (14, 18) TUNING MODE button (14, 16, 19, 22) PRESET a button (15, 20) TUNING a button (14, 18) PRESET s button (15, 20)

  • Page 8: Rear Panel

    Getting to Know the Tuner —Continued Rear Panel For detailed information, see the pages in parentheses. See “Connecting Antennas”, “Connecting Your AUDIO OUTPUT jacks (11, 12) Components” for connection ( pages 10 to 13). R REMOTE CONTROL jack (11, 12, 13) DIGITAL OUT COAXIAL and OPTICAL jacks (11, 12) DAB/FM ANTENNA jack (10)

  • Page 9: Remote Controller

    —Continued Getting to Know the Tuner Remote Controller For detailed information, see the pages in parentheses. k button (13) DIMMER button (21) DISPLAY button (18) BAND button (14, 18) Arrow [D]/[F]/[A]/[S] and ENTER buttons (14, 16, 18, 21) SETUP button (16, 19, 21) Number buttons (15, 16) D.TUN button (15) MODE button (14)

  • Page 10: Connecting Antennas

    Connecting Antennas This section explains how to connect the supplied Connecting the DAB/FM Antenna DAB/FM antenna. The tuner won’t pick up any radio signals if no antenna Screw the supplied DAB/FM antenna’s plug is connected, so you must connect the antenna to use the onto the DAB/FM ANTENNA jack.

  • Page 11: Connecting Your Components

    PCM. The maximum sampling rate for PCM output is 48kHz/16bit, 2ch. Orange Analog audio (RCA) White Analog audio connections (RCA) carry analog audio. To use R (Remote Interactive), you need to connect your Onkyo AV components with an R cable.

  • Page 12: Connecting To An Amplifier

    Use the supplied audio cable to connect the T-4030’s AUDIO OUTPUT L/R jacks to the LINE IN jacks on Note: your amplifier, as shown. • If the T-4030 is used with another Onkyo component, refer to its instruction manual as well. Digital (Optical or Coaxial) Connection T-4030 Connect either of them.

  • Page 13: Connecting Onkyo R Components

    Onkyo products. other components. Auto Power On When you turn on the T-4030, your Onkyo amplifier will Turning On and Standby turn on automatically. (The amplifier’s POWER switch must be set to ON for this to work.)

  • Page 14: Listening To The Radio

    Listening to the Radio Manual Tuning Listening to FM Stations To activate this mode, press the [TUNING MODE] button to turn off the “AUTO” indicator. In this With the built-in tuner, you can enjoy FM radio mode, you will receive the broadcast in monaural stations.
  • Page 15 —Continued Listening to the Radio ■ Tuning into Stations by Frequency Presetting FM Stations You can tune to FM stations directly by entering the PRESET appropriate frequency. TUNING AUTO MEMORY TUNING SCAN MODE Number buttons D.TUN ENTER Press the remote controller’s [D.TUN] button. SETUP Number buttons...
  • Page 16 Listening to the Radio —Continued ■ Selecting Presets When you’ve finished editing the name and To select a preset, use the number buttons on want to store it, be sure to use the arrow the remote controller, the remote controller’s [D]/[F]/[A]/[S] button to select “OK”...

  • Page 17: Using Rds

    —Continued Listening to the Radio RDS Program Types (PTY) Using RDS RDS only works in areas where RDS broadcasts are Type Display available. When tuned into an RDS station, the RDS None NONE indicator appears. News reports NEWS Current affairs AFFAIRS RDS indicator Information...

  • Page 18: Listening To Dab Digital Radio

    Listening to the Radio —Continued Using the Scan Function Manually Listening to DAB Digital Radio With the built-in tuner, you can enjoy DAB digital radio. BAND ENTER TUNING SETUP RETURN Press the tuner’s [BAND] button, or the remote controller’s [BAND] button to select “DAB”.
  • Page 19 —Continued Listening to the Radio ■ DAB Scan 2. Program Type This setting determines which DAB bands are scanned Displays the type of program. by the Auto Tuning function (see page 18). U.K: Band III (11B–12D). W.W (default):Band III (5A–13F). 3.
  • Page 20 Listening to the Radio —Continued Displaying Radio Text (RT) PS/RT/PTY When tuned to an RDS station that’s broadcasting text information, the text can be displayed. Press the [PS/RT/PTY] button once. The RT information scrolls across the display. Notes: • The message “Waiting” may appear while the tuner waits for the RT information.

  • Page 21: Advanced Setup

    Advanced Setup Setting the Display Brightness Press the [ENTER] button on the remote controller to complete the setting. You can adjust the brightness of the display. Note: • Press [RETURN] to return to the previous menu. Advanced Setup Menu DIMMER Auto Standby When “ASb”...

  • Page 22: Troubleshooting

    • Unplug the power cord from the electric outlet, wait 5 Onkyo is not responsible for damages (such as CD seconds or more, then plug it in again. rental fees) due to unsuccessful recordings caused by the unit’s malfunction.

  • Page 23: Specifications

    Specifications Tuner Section ■ FM Tuning Frequency Range 87.5 MHz– 108.0 MHz RDS Preset Channel Signal-to-noise ratio Stereo: 60 dB (IHF-A) Mono: 74 dB (IHF-A) THD (total harmonic distortion) Stereo: 1.0 % (1 kHz) Mono: 0.2 % (1 kHz) Frequency response 20 Hz–15 kHz / +1.5 dB, -4.0 dB Stereo Separation 40 dB (1 kHz)
  • Page 24 Unit 1033, 10/F, Star House, No 3, Salisbury Road, Tsim Sha Tsui Kowloon, Hong Kong. Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.onkyochina.com/ 1301, 555 Tower, No.555 West NanJin Road, Jin an, Shanghai, China 200041, Tel: 86-21-52131366 Fax: 86-21-52130396 http://www.cn.onkyo.com/ C1206-1 SN 29401267 (C) Copyright 2012 Onkyo Corporation Japan. All rights reserved.
