- Page 1 2017 Quick Reference Guide...
-
Page 2: Basic Operation
For detailed operating and safety information, please refer to your owner’s Manual. basic opeRation Lock/Unlock doors Remote keyless entry system All doors will be locked. The driver’s door will be unlocked. (To unlock all doors, briefly press the button a second time within 5 seconds.) Trunk lid will be opened. -
Page 3: Tilt/Telescopic Steering Wheel
adjust each component Front seat Power seat (driver’s seat - if equipped): Forward and backward adjustment Seat cushion angle adjustment Seat height adjustment Seatback reclining adjustment Manual seat (if equipped): Forward and backward adjustment Seat height adjustment (driver’s seat only) Seatback reclining adjustment Tilt/telescopic steering wheel Adjust the seat position and pull the tilt/... -
Page 4: Start/Stop Engine
start/stop engine Push-button ignition switch (if equipped) To start engine: STEP1: Carry the access key, and sit in the driver’s seat. STEP2: Apply the parking brake. STEP3: Shift the select lever in the P position (CVT models) or shift lever in neutral (MT models). STEP4: Depress the brake pedal (CVT models) or brake pedal and clutch pedal (MT models) until the indicator on the push-button ignition... -
Page 5: Manual Transmission - If Equipped
operate select lever/shift lever Continuously variable transmission (if equipped) Select lever button With the brake pedal depressed, shift while pressing the button in Shift while pressing the button in Shift without pressing the button M = Manual mode: With the vehicle either moving or stationary, move Downshift Upshift the select lever from the D position to the M position... - Page 6 Main paRts anD opeRation Headlights/Turn signal/Fog lights (if equipped) Headlights Headlight flasher, High/Low beam change Turn signal Fog lights (if equipped): To turn on, rotate dial to Front fog lights operate only when headlight switch is in... position. - AUTO position and the headlights are on. ◆...
-
Page 7: Illumination Brightness Control
Windshield wiper and washer Wiper: : Mist (for a single wipe) : Off : Intermittent : Low speed : High speed Intermittent interval Washer Hazard warning flasher To turn on, press the button. Use in emergency conditions. Illumination brightness control To adjust the illumination brightness of the combination meter, the climate control panel, etc., turn the dial. -
Page 8: Trunk Lid Opener Switch
Trunk lid opener switch Press the switch for more than 1 second. Hood release knob Pull Power windows Lock switch For driver’s window For front passenger’s window For rear left window For rear right window Power door locking switch To lock all doors To unlock all doors ◆... -
Page 9: Audio Control Buttons
Seat heater (if equipped) HIGH (HI): Rapid heating LOW (LO): Normal heating Type B Type A Fuel filler lid release lever Pull Right side This indicates that the fuel filler door (lid) is located on the right side of the vehicle. Audio control buttons These buttons allow the driver to control audio functions without taking his/her hands off the steering wheel. -
Page 10: Child Safety Locks
Moonroof switch (if equipped) Tilting Sliding Raise Open Lower Close Child safety locks Located on the edge of the rear doors. While the lever is in the lock position, rear door cannot be opened from the inside. Front seat shoulder belt anchor height To lower To raise Pull the upper part of... - Page 11 FUnction FoR MoRe coMFoRtabLe DRiVe Vehicle Dynamics Control OFF switch Indicator lights on the combination meter Vehicle Dynamics Vehicle Dynamics Control mode Control OFF mode Traction mode Press the switch to deactivate the Vehicle Dynamics Control system. It may be useful to briefly deactivate the Vehicle Dynamics Control system to facilitate the following operations.
-
Page 12: Cruise Control
Cruise control Cruise control enables you to maintain a constant vehicle speed without holding your foot on the accelerator pedal and it is operative when the vehicle speed is 40 km/h (25 mph) or more. Cruise control main button : To activate and deactivate RES/SET switch : ▲... - Page 13 Driver’s Control Center Differential (DCCD) (STI models) DCCD indicator Auto mode Manual mode The driver's control center differential allows you to freely change the degree of limitation of the differential action (limited slip differential (LSD) torque) of the vehicle's center differential. AUTO-MANU switch : Press the switch from auto mode to manual mode or vice versa.
-
Page 14: Multifunction Display
Multi function display Outside temperature indicator Top display Clock Driving information display Control switch: By operating ▲ or ▼ of the control switch, the screens and selection items can be switched. When the ENTER button is pushed and held, Control the item can be selected and set. - Page 15 BSD/RCTA OFF switch (if equipped) If the BSD/RCTA OFF switch is pressed, the BSD/ RCTA warning indicator and BSD/RCTA OFF indicator are displayed on the multi information display of the combination meter, and the BSD/RCTA is deactivated. BSD/RCTA The BSD/RCTA consists of rear radar with Blind Spot Detection, Lane Change Assist and Rear Cross Traffic Alert.
-
Page 16: Warning Lights
ON. Warning lights Refer to your Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized SUBARU dealer. Seatbelt warning Front passenger’s seatbelt warning Remind the driver to fasten... - Page 17 All-wheel drive warning All-Wheel Drive disengaged/tires of different diameter fitted. Windshield washer fluid warning The fluid level in the windshield washer fluid tank decreases to the lower limit. Access key warning The access key is not inside the vehicle. For other situations, refer to your Owner’s Manual.
-
Page 18: Indicator Lights
indicator lights The following indicators show the current status of your car. Refer to your Owner’s Manual for more information. Turn signal Headlight High beam indicator indicator indicator Front fog light Security Traction mode indicator indicator indicator BSD/RCTA OFF Cruise control Cruise control indicator indicator... - Page 20 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
