Mini Washing Machine User's manual This manual is for HWM20-0701 Please read this manual carefully before using. Retain it for future reference. 0030807846A...
Contents Names of the parts...1 Safety precautions ...2 Installation and adjustment ...4 Preparation before washing ...5 The musts in washing ...6 Usage of the detergent...6 Process washing...7 Disposal after washing ...8 Tr o u b l e s h o o t i n g ............. 9 Packing list *Specification...10...
Names of the parts Control panel Panel support Pulsator Top lid Cabinet Base frame Meaning and description of the symbols Warning sign Forbidding sign Please check if the power receptacle has good earthing condition before using to guarantee your safety. Water inlet Timer knob Back cover...
Safety precautions Please insert the power cord into special receptacle with rated vol- tage. Be sure to use single-phase three pins receptacle. The earthing terminal of the receptacle must be earthed reliably. If possible, please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department.
Page 5
Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Usage of the drain hose When washing, the drain hose must be hung up, if you want to drain, please refer to the below mention.
Preparation before washing Pay attention to followings before washing the laundries Check if Clear the Tie the long the laundries pocket. Take strips; fasten has special out the coins, the buttons; requirement sand, hairpins close zippers. on washing etc. a.Please check if the laundries are applicable for washing. b.Please mend seedyclothes before washing.
The musts in washing The capacity of washing of the machine refers to the largest weight of the standard laundries under dry condition that can be washed in one time. Laundries quantity in one washing cycle shall be lower than the rated capacity.
Process washing 1.Put into the laundry and detergent, then fill the water needed. Install the water inlet hose Insert the water inlet hose into the water-filling entrance on the control panel. The appliance is to be connected to the water mains using new hose-set and old hose-set should not be reused.
4.Washing duration reference Select washing duration depending on the laundry Laundry Washing Duration(min) About2 4 Silk fabric(thin laundry) Knitted fabric/chemical fabric About ~ Bed sheet About7~8 Cotton, blending or linen fabrics About8~10 About10~15 Very dirty or heavy laundry 5.Finish washing The tumbler stops revolving.
Trouble shooting The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. Phenomena The washing machine does not act There's abnormal sound inside the machine. How to check Is there power failure? Is the power plug inserted tightly? Is the machine slanting? Is there metal item inside the tub?
Packing list Name User's manual Water inlet hose Mini washing machine Specification Water level/Water quantity (about) Rated washing capacity(kg) Injection pressure(MPa) Quantity One piece One piece One set 1/7L 2/12L 3/18L 0.02 0.2...
