Dyna-Glo RMC-KFA50DGD User's Manual And Operating Instructions

Indoor/outdoor kerosene portable forced air heaters
Hide thumbs

Advertisement

Table of Contents

INDOOR/OUTDOOR PRODUCTS
KEROSENE PORTABLE
FORCED AIR HEATERS
"USER'S MANUAL AND

OPERATING INSTRUCTIONS"

COMPLIES WITH UL733 AND
ANSI A10.10-1990
CAN/CSA/B140.0-03 AND CSA
B140.8-1967
MODEL : RMC-KFA50DGD, RMC-KFA75TDGD, RMC-KFA125TDGD-01
RMC-KFA170TDGD-01, RMC-KFA210TDGD-01
Before the first use of this heater, please read this USER'S MANUAL very
carefully. This USER'S MANUAL has been designed to instruct you as to
the proper manner in which to assemble, maintain, store, and most
importantly, how to operate the heater in a safe and efficient manner.
Please keep this manual for future reference.
CONSUMER : Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. - 4:30 pm CST, Monday - Friday.
or email us at customerservice@ghpgroupinc.com

Advertisement

Table of Contents
loading

Related Manuals for Dyna-Glo RMC-KFA50DGD

Summary of Contents for Dyna-Glo RMC-KFA50DGD

  • Page 1: Operating Instructions

    COMPLIES WITH UL733 AND ANSI A10.10-1990 CAN/CSA/B140.0-03 AND CSA B140.8-1967 MODEL : RMC-KFA50DGD, RMC-KFA75TDGD, RMC-KFA125TDGD-01 RMC-KFA170TDGD-01, RMC-KFA210TDGD-01 Before the first use of this heater, please read this USER’S MANUAL very carefully. This USER’S MANUAL has been designed to instruct you as to the proper manner in which to assemble, maintain, store, and most importantly, how to operate the heater in a safe and efficient manner.
  • Page 2 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! DANGER: IMPROPER USE OF THIS HEATER CAN RESULT IN SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND/OR CARBON MONOXIDE POISONING. WARNINGS: 1. RISK OF INDOOR AIR POLLUTION! • Use this heater only in well ventilated areas. Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/hr.
  • Page 3 2. FEATURES Front Guard Hot Air Outlet Upper Shell Handle Fan Guard Lower Shell Fuel Tank Side Cover Lamp Fuel Gauge Thermostot Knob (75TDGD Model Only) Fuel Cap Power/Reset Switch Power Cord (Piggy Back, 75TDGD Model Only) Figure 1. RMC-KFA50DGD/75TDGD MODELS...
  • Page 4 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! Snap Fit Front Handle Snap Fit Rear Handle Upper Shell Hot Air Outlet Shell Lower Cord Wrap Fuel Gauge BTU Control Switch Fuel Cap Side Cover Pressure Gauge Lamp Fan Guard Thermostot Knob Room Temp.

  • Page 5: Unpacking And Assembly

    RMC-KFA210TDGD-01 Snap Fit Front Leg Wheel Threaded Axle Snap Fit front Handle Snap Fit Rear Handle Hardware kit : HW-KFA1000 Hardware kit : HW-KFA1015 Figure 4. RMC-KFA50DGD/75TDGD MODELS Hardware Kit Handle HW-KFA1000 Figure 5. RMC-KFA125/170/210TDGD-01 MODELS Bushings Cap Nuts Wheels Hardware Kit : HW-KFA1015 (10”...
  • Page 6 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 2. ASSEMBLY Screw Handle For RMC-KFA50DGD/75TDGD Models only Front Guard (Assembly time for this product is 3 minutes) Tools Required Wedged Portion • Medium Phillips Screwdriver. Slit Hole 1) Lift front guard for arrow direction and make sure that guard’s wedged portion fits into the slit...
  • Page 7 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 4. KEROSENE (1-K) For optimal performance of this heater, it is strongly suggested that 1-K kerosene be used. 1-K kerosene has been refined to virtually eliminate contaminants, such as sulpher. Which can cause a rotten egg odor during the operation of the heater.
  • Page 8 If this device activates and turns your heater off it may require service. Internal Shut-Off Temp. Reset Temperature MODELS Plus/Minus 10 Degrees Plus/Minus 10 Degrees RMC-KFA50DGD/75TDGD 176˚F/80˚C 122˚F/50˚C RMC-KFA125/170TDGD-01 230˚F/110˚C 194˚F/90˚C RMC-KFA210TDGD-01 194˚F/90˚C...

  • Page 9: Fueling Your Heater

    Room Temp. Display BTU Control Switch Push to “HIGH” Lamp Lamp Push to “LOW” Thermostat Power/Reset Thermostat Power/Reset Switch Control Knob Switch Control Knob (75TDGD/125TDGD-01 MODELS ONLY) RMC-KFA50DGD/75TDGD/ RMC-KFA170/210TDGD-01 Models Fan Guard Figure 8. Controls for All Models 125TDGD-01 Models...

  • Page 10: Long Term Storage Of Your Heater

    IMPORTANT : Do not store kerosene over summer months for use during next heating season. Using old fuel could damage heater. 4. Reinstall fuel cap. Properly dispose of old and dirty fuel. (For RMC-KFA50DGD/75TDGD Models Only) 5. Reinstall fuel drain bolt to Fuel tank and tighten firmly using 3/4” socket or adjustable wrench.

  • Page 11: Maintenance

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 9. MAINTENANCE WARNING!! : NEVER SERVICE HEATER WHILE IT IS PLUGGED IN OR WHILE HOT! USE ORIGINAL EQUIPMENT REPLACEMENT PARTS. Use of third party or other alternate components will void warranty and may cause unsafe operating conditions.
  • Page 12 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! E.) NOZZLE REMOVE DIRT IN NOZZLE AS NEEDED (SEE PAGE 16). Combustion Chamber (For RMC-KFA50DGD/75TDGD/125/170TDGD-01 Models Only) - Remove upper shell (See page 10). Screw - Remove fan blade (See page 10). Ignitor Wire - Remove fuel and air line hoses from burner head.
  • Page 13 F.) SPARK PLUG Spark Plug CLEAN AND REGAP EVERY 600 HOURS OPERATION OR REPLACE AS NEEDED. (For RMC-KFA50DGD/75TDGD/125/170TDGD-01 Models Only) - Remove upper shell (See page 10). - Remove fan (See page 10). Ignitor wire - Remove ignitor wire from spark plug.

  • Page 14: Pump Pressure Adjustment

    - Pull fuel line off fuel filter neck. - Turn fuel filter 90˚ to counter clockwise and pull to remove (RMC-KFA50DGD/75TDGD Models only). - Turn fuel filter 90˚ to clockwise and pull to remove (RMC-KFA125/170/210TDGD-01 Models only).

  • Page 15: Replacing Fuse

    To avoid fire, Do not substitute with a higher or lower current rating. 6. Replace switch wires to power switch. Fuse Holder 7. Replace side cover. Fuse NOTE : Specified fuse rating : AC 125/8A RMC-KFA75TDGD/125/170/210TDGD-01 Models Screw Side Cover Power Switch Switch Wire Fuse Fuse Holder RMC-KFA50DGD Figure 21. Replacing Fuse...

  • Page 16: Troubleshooting Guide

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 11. TROUBLE SHOOTING GUIDE TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION Heater ignites but MAIN PCB 1. Wrong pump pressure 1. See Pump Pressure Adjustment, assembly shuts heater off after Page 13. a short period of time. 2.

  • Page 17: Wiring Diagram

    NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 12. WIRING DIAGRAM A) WIRING DIAGRAM (RMC-KFA50DGD Model) B) WIRING DIAGRAM (RMC-KFA75TDGD/125/170TDGD-01 Models) 1/G WIRE MODEL CAPACITOR COLOR BLACK 75TDGD 12uF/230VAC BLACK 125TDGD-01 30uF/250VAC WHITE BLACK 170TDGD-01 30uF/250VAC BLUE C) WIRING DIAGRAM (RMC-KFA210TDGD-01 Model)

  • Page 18: Specifications

    13. SPECIFICATIONS RMC-KFA50DGD/75TDGD Models 170TDGD-01 125TDGD-01 210TDGD-01 47.4"(1,205 mm) 41.9"(1,063 mm) 21.5"(547 mm) 23.1"(587 mm) 32.4"(824 mm) 33.5"(850 mm) RMC-KFA125/170/210TDGD-01 Models MODEL RMC-KFA50DGD RMC-KFA75TDGD RMC-KFA125TDGD-01 RMC-KFA170TDGD-01 RMC-KFA210TDGD-01 HIGH 50,000 75,000 125,000 170,000 210,000 BTU/Hr. 100,000 135,000 170,000 HIGH 0.38(1.44) 0.57(2.16) 0.95(3.60)
  • Page 19 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (RMC-KFA50DGD/75TDGD Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS.
  • Page 20 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (RMC-KFA125/170TDGD-01 Models Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS.
  • Page 21 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 14. EXPLODED PARTS DRAWING (RMC-KFA210TDGD-01 Model Only) NOTE : SPECIFY MODEL NUMBER AND PART NUMBER WHEN ORDERING PARTS.
  • Page 22 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA50DGD/75TDGD Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA50DGD RMC-KFA75TDGD Fuel Tank Assembly 2151-0004-00 2151-0007-00 Fuel Drain-Bolt Fuel Gauge 2156-0046-00 2156-0049-00 Fuel Filter Assembly 2155-0005-00 2155-0005-00 Fuel Cap 2151-0003-00...
  • Page 23 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA50DGD/75TDGD Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA50DGD RMC-KFA75TDGD 27-4 Nut-Hex 4331-0013-00 4331-0013-00 27-5 Holder Capacitor 27-6 Pump Body 3541-0022-00 3541-0022-00 27-7 Bolt-BH Special 4321-0198-00 4321-0198-00 27-8 Rotor...
  • Page 24 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA125/170TDGD-01 Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA125TDGD-01 RMC-KFA170TDGD-01 Fuel Tank Assembly 2151-0008-00 2151 -0009-00 Fuel Drain-Bolt 4329-0072-00 4329-0072-00 2156-0050-00 Fuel Gauge 2156-0051-00 Fuel Filter Assembly 2155-0001-00 2155-0001-00 Fuel Cap 2151-0003-00 2151-0003-00...
  • Page 25 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA125/170TDGD-01 Models Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA125TDGD-01 RMC-KFA170TDGD-01 25-6 Pump Body 3970-0029-00 3541-0022-00 25-7 Bolt-BH Special 4321-0198-00 4321-0198-00 25-8 Rotor *SP-KFA1000 *SP-KFA1000 25-9 Blade See SP-KFA1000 See SP-KFA1000 25-10 Insert See SP-KFA1000...
  • Page 26 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA210TDGD-01 Model Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA210TDGD-01 Fuel Tank Assembly 2151-0009-00 Fuel Drain-Bolt 4329-0072-00 Fuel Gauge 2156-0052-00 Fuel Filter Assembly 2155-0001-00 Fuel Cap 2151-0003-00 Cord Bushing 3712-0013-00 Power Cord 3980-0087-00 Thermostat...
  • Page 27 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (RMC-KFA210TDGD-01 Model Only) PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA210TDGD-01 25-6 Pump Body 3541-0050-00 25-7 Bolt-BH Special 4321-0198-00 25-8 Rotor *SP-KFA1022 25-9 Blade See SP-KFA1022 25-10 Insert See SP-KFA1022 25-11 End Pump Cover 3531-0008-00 25-12...
  • Page 28 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING! 15. PARTS LIST (WHEELS AND HANDLE) 1) RMC-KFA50DGD/75TDGD MODELS PART NO. Quantity KEY NO. DESCRIPTION RMC-KFA50DGD RMC-KFA75TDGD Handle 3231-0073-00 3231-0073-00 Hardware Kit HW-KFA1000 HW-KFA1000 2) RMC-KFA125/170/210TDGD-01 MODELS PART NO. Quantity KEY NO. DESCRIPTION...

This manual is also suitable for:

Rmc-kfa75tdgdRmc-kfa210tdgd-01Rmc-kfa125tdgd-01Rmc-kfa170tdgd-01
