Page 1
This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation. No part of this publication may be reproduced without written permission.
Page 3
A Few Words About Safety Your safety, and the safety of others, is very important. And operating this motorcycle safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others.
Page 4
A Few Words About Safety You WILL be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be KILLED or SERIOUSLY HURT if you don’t follow instructions. You CAN be HURT if you don’t follow instructions. Safety Headings ––...
Page 5
........Why your motorcycle needs regular Important safety information, maintenance, what you need to know precautions about loading, accessories, before servicing your Honda, a and modifications, and the location of maintenance schedule, and instructions safety labels. for specific maintenance items.
Page 6
Handy facts about fuel, engine oil, tire sizes, and air pressures. Technical Information ......ID numbers, technical specifications, and other technical facts. Consumer Information ......Information on warranties and how to get Honda service manuals. Contents...
Page 7
It’s full of facts, instructions, safety information, and helpful When you own a Honda, you’re part of a tips. To make it easy to use, the manual worldwide family of satisfied customers contains a table of contents, a detailed list of people who appreciate Honda’s reputation for...
Page 8
Honda dealer knows your motorcycle best and is dedicated to your complete satisfaction. Please report any change of address or ownership to your Honda dealer so we will be able to contact you concerning important production information. You may also want to visit our website at www.honda.com.
Motorcycle Safety This section presents some of the most Important Safety Information ......important information and recommendations to Loading, Accessories & Modifications ... help you ride your motorcycle safely. Please Loading ............take a few moments to read these pages. This Accessories &...
Important Safety Information Your motorcycle can provide many years of Never Carry a Passenger service and pleasure if you take responsibility Your motorcycle is designed for one person for your own safety and understand the only. There are no handholds, footrests, or seat challenges you can meet while riding.
Important Safety Information Take Time to Learn and Practice Be Alert for Off-Road Hazards Developing off-road riding skills is a gradual, The terrain can present a variety of challenges step-by-step process. Start by practicing at low when you ride off-road. Continually ‘‘read’’ speeds in a safe area and slowly build your the terrain for unexpected turns, drop-offs, skills.
Page 13
So don’t drink and ride, and don’t let your friends drink and ride either. Keep Your Honda in Safe Condition It’s important to keep your motorcycle properly maintained and in safe riding condition. Having a breakdown can be difficult, especially if you are stranded off-road far from your base.
Loading, Accessories & Modifications Your Honda was designed as a rider-only More specific information on load limits, motorcycle. It was not designed to carry a accessories, and modifications follows. passenger or cargo. A passenger or cargo could interfere with your ability to move around to...
Loading, Accessories & Modifications Load Limits Place weight as close to the center of the Following are the load limits for your motorcycle as possible. motorcycle: Do not attach large or heavy items (such as a sleeping bag or tent) to the handlebar, fork, Maximum weight capacity or front fender.
Before you consider making any modifications and use of non-Honda accessories. Check with or adding an accessory, be sure to read the your dealer for assistance and always follow following information.
Loading, Accessories & Modifications Modifications We strongly advise you not to remove any original equipment or modify your motorcycle in any way that would change its design or operation. Such changes could seriously impair your motorcycle’s handling, stability, and braking, making it unsafe to ride. We also advise you not to make any modifications or remove any equipment (such as the USDA qualified spark arrester or...
This page shows the locations of safety labels on your motorcycle. Some labels warn you of potential hazards that could cause serious injury. Others provide important safety information. Read these labels carefully and don’t remove them. If a label comes off or becomes hard to read, contact your Honda dealer for a replacement. Motorcycle Safety...
Page 20
Operating Controls When you ride off-road, you need to operate Component Locations ........the throttle, clutch, brakes, and other controls Fuel Valve ............without stopping to look at them. Read this Choke Lever ........... section carefully before you ride. It describes Ignition Switch ..........
Operating Controls Fuel Valve Turning the fuel valve ON before attempting to start the engine allows fuel to flow from the fuel tank to the carburetor. Turning the fuel valve OFF after stopping the engine prevents the flow of fuel from the fuel tank to the carburetor.
Operating Controls The reserve fuel supply is: The choke lever is used for starting the engine 0.40 US gal (1.5 ) (page ). The choke increases the percentage of fuel in the fuel/air mixture delivered to the The tank should be refilled as soon as possible engine.
Operating Controls FRONT Ignition Switch The ignition switch is used to prevent unauthorized use of the motorcycle. Before riding, insert the key and turn it to the ON position. Function Key Removal Position The engine cannot be The key can operated.
Operating Controls Engine Stop Button Throttle The engine stop button is used to turn the The throttle controls engine rpm (speed). To engine off during normal riding situations. To increase engine rpm, rotate the grip toward you. operate, push the button in and hold it in until To reduce engine rpm, rotate the grip away the engine stops completely.
Operating Controls Shift Lever Kickstarter The shift lever is used to select the next higher The kickstarter is used to start the engine. To or lower gear in the transmission. To operate, operate, swing the kickstarter out from its raise the shift lever (after pulling in the clutch stored position and depress it through its entire lever) to engage the next higher gear or depress stroke.
Before Riding Before each ride, you need to make sure you Are You Ready to Ride? ........ and your Honda are both ready to ride. To help Protective Apparel ........get you prepared, this section discusses how to Is Your Motorcycle Ready to Ride? ....
Are You Ready to Ride? Before you ride your motorcycle for the first time, we strongly recommend that you: Protective Apparel read this owner’s manual make sure you understand all the safety For your safety, we strongly recommend that messages you always wear an approved motorcycle know how to operate all the controls helmet, eye protection, boots, gloves, long...
Are You Ready to Ride? (USA only). Always wear a face shield or goggles to protect your eyes and help your Not wearing a helmet increases the vision. chance of serious injury or death in a crash. Additional Riding Gear In addition to a helmet and eye protection, we Be sure you always wear a helmet, also recommend:...
Is Your Motorcycle Ready to Ride? Before each ride, it’s important to inspect your motorcycle and make sure any problem you Pre-ride Inspection find is corrected. A pre-ride inspection is a must because off-road riding can be tough on a Check the following items before you get on motorcycle and you don’t want to have a the motorcycle:...
Page 34
Is Your Motorcycle Ready to Ride? Engine Oil Check the level and add oil if Spark Plug Check for looseness (page needed (page & Cap Fuel Check the level and add fuel Check these items after you get on the (page ) if needed.
Page 35
Is Your Motorcycle Ready to Ride? Clutch Check for smooth operation and Lever adjust if needed (page Remember, be sure to take care of any problem you find or have your Honda dealer correct it before you ride. Before Riding...
Page 36
Braking ............Guide f or the Of f -Highway Motorcyclist Parking ............booklet that came with your Honda (USA only). Post-ride Inspection ........To protect your new engine and enjoy optimum performance and service life, refer to Break-in Guidelines (page...
Basic Operation & Riding Your motorcycle is not equipped with lights. Safe Riding Precautions Do not ride at night. Before riding your motorcycle for the first time, please review the Important Saf ety Inf ormation beginning on page and the previous section, titled Bef ore Riding.
Starting & Stopping the Engine Always follow the proper starting procedure described below. Starting Procedure Your motorcycle can be kickstarted with the To restart a warm engine, follow the procedure transmission in gear by pulling in the clutch High Air Temperature. lever before operating the kickstarter.
Page 39
Starting & Stopping the Engine Lightly depress the kickstarter until About a half-minute after the engine starts, resistance is felt. push the choke lever down all the way to Then let kickstarter return to the top of its fully OFF ( ). stroke.
Starting & Stopping the Engine High Air Temperature 35°C (95°F) or above Flooded Engine Do not use the choke. Start the engine following step under If the engine fails to start after repeated Normal Air Temperature. attempts, it may be flooded with excess fuel. To clear a flooded engine: Low Air Temperature 10°C (50°F) or below...
Starting & Stopping the Engine How to Stop the Engine To stop the engine, shift into neutral, push the engine stop button in, and hold it in until the engine stops. Basic Operation & Riding...
Shifting Gears Depress the shift lever from neutral down to 2 3 4 5 first gear. Release the front brake. Gradually open the throttle while you slowly release the clutch lever. If engine rpm (speed) is too low when you release the clutch lever, the engine will stall.
Page 43
Shifting Gears To continue shifting up to each higher gear, Downshifting can help slow your motorcycle, repeat step . especially on downhills. However, To shift down to a lower gear, close the downshifting when engine rpm is too high can throttle, pull the clutch lever in, and depress cause engine damage.
Braking To slow or stop, apply the front brake and rear Generally, reduce your speed or complete brake smoothly, while downshifting to match braking before beginning a turn. Avoid braking your speed. Gradually increase braking as you or closing the throttle quickly while turning. feel the brakes slowing your speed.
Page 45
Braking When descending a long, steep grade, use engine compression braking by downshifting, with intermittent use of both brakes. When you brake to a stop, pull the clutch lever in before stopping completely to prevent stalling the engine. For support, put your left foot on the ground first, then your right foot when you’re through braking.
Parking Lower the side stand to support your motorcycle. Turn the ignition switch OFF and remove the key. If you’re through riding for the day, also turn the fuel valve OFF. Always choose a level place to park. Basic Operation & Riding...
Post-ride Inspection When you return home after riding, thoroughly clean your motorcycle and remove any dirt, mud, brush, rocks or other objects you may have picked up along the way. After cleaning, carefully inspect your motorcycle for leaks or damage. Be sure to lubricate the drive chain (page to prevent rusting.
Servicing Your Honda Keeping your motorcycle well maintained is Bef ore You Service Your Honda absolutely essential to your safety. It’s also a The Importance of Maintenance ....good way to protect your investment, get Maintenance Safety ........maximum performance, avoid breakdowns, and Important Safety Precautions .....
If your motorcycle overturns or is involved in a is designed to be ridden over rough off-road crash, be sure your Honda dealer inspects all terrain. major parts, even if you are able to make some repairs.
Page 51
The Importance of Maintenance Remember, proper maintenance is the owner’s responsibility. Be sure to inspect your motorcycle before each ride and follow the Maintenance Schedule in this section. Servicing Your Honda...
Always follow the procedures and precautions in this owner’s manual. Injury from moving parts. Do not run the engine unless instructed to do so. (cont’d) Servicing Your Honda...
Page 53
To reduce the possibility of a fire or explosion, be careful when working around gasoline. Use only a non-flammable (high flash point) solvent such as kerosene not gasoline to clean parts. Keep cigarettes, sparks, and flames away from all fuel- related parts. Servicing Your Honda...
If you do not feel capable of performing a given task or need assistance, remember that The Maintenance Schedule also includes items your Honda dealer knows your motorcycle best that involve more extensive procedures and and is fully equipped to maintain and repair it.
Page 55
Refer to the official Honda Service Manual clean (page adjust In the interest of safety, we recommend lubricate these items be serviced only by your Honda replace dealer. Servicing Your Honda...
Page 56
Engine Oil Centrifugal Filter Engine Idle Speed Should be serviced by your Honda dealer, unless the owner has the proper tools and service data and is mechanically qualified. Refer to the official Honda Service Manual (page In the interest of safety, we recommend these items be serviced only by your Honda dealer.
Page 57
92, 98 Steering Head Bearings Should be serviced by your Honda dealer, unless the owner has the proper tools and service data and is mechanically qualified. Refer to the official Honda Service Manual (page In the interest of safety, we recommend these items be serviced only by your Honda dealer.
Months 600 (1,000) or 6 1,200 (2,000) or 12 1,800 (3,000) or 18 2,400 (4,000) or 24 3,000 (5,000) or 30 3,600 (6,000) or 36 4,200 (7,000) or 42 4,800 (8,000) or 48 5,400 (9,000) or 54 Servicing Your Honda...
Competition Inspection All items should be checked before each competition event. See your Honda dealer unless you are mechanically qualified and have the proper tools. Damage from competition use is not covered by the Distributor’s Limited Warranty on your Honda.
Page 60
NOTE 1: Competition use may cause more rapid clutch disc wear. Refer to the official Honda Service Manual, or see your Honda dealer for clutch disassembly and wear inspection. (cont’d) Servicing Your Honda...
Page 61
25.1 in (637 mm) / 41 pins replace max. length/pin sprockets wear and secure installation replace or tighten seat security tighten control cables smooth operation, kinks and correct lubricate or routing replace engine mounting bolts tightness tighten Servicing Your Honda...
The spark plug wrench ( ) and its handle ( ) are stored in the tool bag delivered with your motorcycle. You will need to provide your own tools to perform any owner maintenance other than removing the spark plug. (1) spark plug wrench (2) handle Servicing Your Honda...
Slide the top of the side cover under the bottom edge of the seat. Align the side cover prongs with the rubber grommets. Press the side cover into position. Install the securing screw and tighten it. LEFT SIDE (1) screw (3) rubber grommets (2) prongs Servicing Your Honda...
If pinging or spark knock occurs at a steady engine speed under normal load, change brands Fuel Recommendation of gasoline. If pinging or spark knock persists, consult your Honda dealer. unleaded Type We recommend that you use unleaded fuel Pump Octane...
Page 67
Stop the engine and keep heat, sparks and flame away. Handle fuel only outdoors. Wipe up spills immediately. (1) fuel fill cap (3) steering stem nut (2) breather tube (4) filler neck Servicing Your Honda...
Page 68
Fuel After refueling, turn the fuel fill cap clockwise until it is secure. Insert the breather tube in the steering stem nut. If you replace the fuel fill cap, use only a genuine Honda replacement part. Servicing Your Honda...
Running the engine with insufficient oil can viscosity (weight) SAE 10W-40 cause serious damage to the engine and JASO T 903 standard transmission. suggested oil Pro Honda GN4 or HP4 (without molybdenum additives) 4-stroke oil (USA & Canada), or Honda 4-stroke oil (Canada only), or an...
Page 70
Do not use API SH or higher oils displaying a circular API ‘‘energy conserving’’ service label on the container. They may affect lubrication and clutch performance. NOT RECOMMENDED Do not use non-detergent, vegetable, or castor based racing oils. Servicing Your Honda...
Page 71
4-stroke motorcycle engines. There are two classes: MA and MB. Oil conforming to the standard has the following classification on the oil container. (1) code number of the sales company of the oil (2) oil classification Servicing Your Honda...
Page 72
Insert the dipstick and screw it in tightly. (1) oil filler cap/dipstick Check for oil leaks. (2) upper level mark (3) lower level mark Park your motorcycle on a firm, level surface. Clean around the oil filler cap/dipstick ( ) and nearby surfaces. Servicing Your Honda...
Page 73
Pour the drained oil into a suitable container and dispose of it in an approved manner (page Improper disposal of drained f luids is harmf ul to the environment. (1) oil drain bolt (3) spring (2) O-ring (4) oil strainer screen Servicing Your Honda...
Page 74
11 lbf·ft (15 N·m , 1.5 kgf·m) Pour the recommended oil into the crankcase, approximately: 1.1 US qt (1.0 ) Install the oil filler cap/dipstick securely. Start the engine. Let it idle 3-5 minutes, then turn it off. Servicing Your Honda...
Your motorcycle’s air cleaner has very specific performance requirements. Use a new genuine Honda air cleaner specified for your model or an air cleaner of equal quality. Servicing Your Honda...
Page 76
Unhook the set spring ( ), take care to avoid bending the set spring and set spring holder ( ). Remove the air cleaner ( ). (1) screws (2) air cleaner housing cover (3) set spring (4) set spring holder (cont’d) (5) air cleaner Servicing Your Honda...
Page 77
Replace the air cleaner if it is damaged. Allow the air cleaner to dry thoroughly before applying oil. A wet air cleaner will not fully absorb the oil. (5) air cleaner (7) tabs (6) air cleaner holder (8) holes Servicing Your Honda...
Page 78
Air Cleaner Pour clean Pro Honda Foam Filter Oil or an Install the air cleaner housing cover and equivalent (Canada: Honda Foam Filter Oil screws. or an equivalent) over the entire surface of Install the right side cover (page the air cleaner. Use both hands to evenly spread the oil into the air cleaner.
Drain the deposits by pinching the plug ( ). Service more frequently if your motorcycle is ridden in the rain or often at full throttle. Service the breather if you can see deposits in the transparent section of the drain tube. LEFT SIDE (1) plug Servicing Your Honda...
After adjustment, check for smooth rotation of the throttle grip from fully closed to fully open in all steering positions. If you can’t get the freeplay within the specified range, contact your Honda dealer. (2) rubber dust cover (4) adjuster (3) lock nut...
Page 81
Check the cable for tension or stress in all steering positions. Lubricate the cable with a commercially- available cable lubricant to prevent premature rust and corrosion. (1) throttle (2) throttle cable Check that the throttle assembly is positioned properly and the securing bolts are tight. Servicing Your Honda...
Pull the rubber dust cover ( ) back. If necessary, adjust to the specified range. Loosen the upper lock nut ( ). Turn the upper clutch cable adjuster ( ) to Improper freeplay adjustment can cause obtain the specified freeplay. premature clutch wear. (cont’d) Servicing Your Honda...
Page 83
Turn the lower adjusting nut to obtain the RIGHT SIDE specified freeplay. Hold the lower adjusting nut and tighten the lower lock nut. Check the adjustment. (5) lower adjusting nut ( ) increase freeplay (6) lower lock nut ( ) decrease freeplay Servicing Your Honda...
Page 84
Lubricate the clutch cable with a kinked or worn, or the clutch discs may be commercially-available cable lubricant to worn. See your Honda dealer or refer to the prevent premature wear and corrosion. official Honda Service Manual (page Servicing Your Honda...
Engine Idle Speed Do not attempt to compensate for faults in RIGHT SIDE other systems by adjusting idle speed. See your Honda dealer for regularly scheduled carburetor adjustments. Warm up the engine, shift to neutral and place the motorcycle on its stand.
X24EPR-U9 (DENSO) For cold climate DPR7EA-9 (NGK) (below 5°C, 41°F) X22EPR-U9 (DENSO) (1) spark plug wrench (4) side electrode (2) handle (5) spark plug gap (3) center electrode Clean any dirt from around the spark plug base. (cont’d) Servicing Your Honda...
Page 87
Make sure the plug washer is in good condition. If you have to install a new plug, first check the gap. With the plug washer attached, thread the spark plug in by hand (to prevent cross- threading). Servicing Your Honda...
(1) spark arrester (3) gasket (2) bolts (4) muffler Allow the engine and muffler to cool. Remove the three bolts ( ), the spark arrester ( ), and the gasket ( ) from the muffler ( ). (cont’d) Servicing Your Honda...
Page 89
Be careful to avoid muffler and tighten the three bolts securely. damaging the spark arrester screen. The spark arrester must be free of breaks and holes. Replace, if necessary. Check the gasket. Replace, if necessary. Servicing Your Honda...
If any suspension components appear worn or damaged, see your Honda dealer for further inspection. Your dealer is qualified to determine whether or not replacement parts or repairs are needed.
Page 91
RIGHT SIDE Check the security of all handlebar and fork mounting bolts ( ). If any front suspension components appear worn or damaged, see your Honda dealer for further inspection. Rear Suspension Inspection LEFT SIDE (1) swingarm bearing Place the motorcycle on a maintenance stand.
Page 92
( ) and rear suspension linkage attachment points ( ) are secure. Check for oil leaks in the shock absorber. If any rear suspension components appear worn or damaged, see your Honda dealer for further inspection. Servicing Your Honda...
), there is probably air in the brake system. See your (1) front brake lever (3) lock nut Honda dealer to have the air bled from the (2) rubber dust cover (4) adjuster system. Never use adjusters other than those designed for this motorcycle.
Page 94
To position the brake lever closer to the If brake lever freeplay is not within this handgrip, turn the adjuster counterclockwise. range, see your Honda dealer. Tighten the lock nut. Return the dust cover to its normal position. Apply the brake, release it, then spin the wheel and check that it rotates freely.
Page 95
Worn brake pads should be replaced. If the Fluid Level Inspection pads are not worn, have your brake system inspected for leaks. Front Brake Fluid Level The recommended brake fluid is Honda DOT 4 RIGHT brake fluid from a sealed container, or an HANDLEBAR equivalent.
Page 96
More About: Brake Fluid Brake fluid should be added and replaced by your Honda dealer. The recommended brake fluid is Honda DOT 4 Brake Fluid, or any brake fluid of equal equality and performance. Use fresh brake fluid from a sealed container.
Page 97
13/16 1 3/16 in (20 30 mm) Freeplay: If necessary, adjust to the specified range. Adjustment RIGHT REAR (1) rear brake pedal (2) brake rod ( ) increase freeplay (3) adjusting nut ( ) decrease freeplay (4) brake arm pin Servicing Your Honda...
Page 98
Application of the Check the freeplay. If you can’t adjust the brake control (pedal) causes the arrow on the freeplay properly, see your Honda dealer. brake arm to move toward a reference mark on the brake panel.
Page 99
( ) upon full application of are tight. the brake. If replacement is necessary, see Rear: Make sure the brake rod, brake arm, your Honda dealer. spring, and fasteners are in good condition. Servicing Your Honda...
Page 100
Loosen the lock nut ( ) and turn the stopper Rear Brake Pedal Height Adjustment bolt ( ). Tighten the lock nut. RIGHT Check the freeplay (page SIDE (1) lock nut (3) rear brake pedal (2) stopper bolt Servicing Your Honda...
Excessively loose spokes may result in instability at high speeds and the possible loss of control. It’s also important that the rim locks are secure to prevent tire slippage. Servicing Your Honda...
Page 102
REAR Rotate the wheel slowly to see if it appears to ‘‘wobble.’’ If it does, the rim is out of round or not ‘‘true.’’ If the wobble is noticeable, see your Honda dealer for inspection. (1) wheel rim (2) spoke...
Page 103
The result will be loss of brake fluid. If this occurs, the brake system will require service. See your Honda dealer for this service. (1) axle holder nuts (2) axle holder (3) front axle...
Page 104
Check front brake adjustment (page (4) UP mark If a torque wrench was not used to install the wheel, see your Honda dealer as soon as Reverse the removal procedure. Insert the possible to verify proper assembly. Improper axle through the wheel hub and left fork leg.
Page 105
(2) brake rod (5) chain adjusters Take care to prevent getting grease, oil, or (3) brake arm (6) rear axle dirt on the brake shoe surfaces. This can cause poor brake performance or rapid brake shoe wear after reassembly. Servicing Your Honda...
Page 106
Repeat this procedure several times. If a torque wrench was not used to install the wheel, see your Honda dealer as soon as (7) lug possible to verify proper assembly. Improper (8) slot assembly may lead to loss of braking capacity.
Make sure the valve stem caps are secure. If necessary, install a new cap. The following pages give detailed information on how and when to check your air pressure, how to inspect your tires for wear and damage, Servicing Your Honda...
Page 108
15 psi (100 kPa , 1.0 kgf/cm ) If you decide to adjust tire pressures for a particular riding condition, make changes a little at a time. (1) tire tread depth (2) spoke nut (3) rim lock nut (cont’d) Servicing Your Honda...
Page 109
We recommend that tubes be replaced by your slipping inside the tire or the tire is slipping Honda dealer. Replacing a tube requires on the rim. See your Honda dealer. removing and reinstalling the wheel. Any time a tube is replaced, carefully inspect the tire as...
Page 110
Installing improper tires on your We recommend that tires be replaced by motorcycle can affect handling and your Honda dealer. stability. This can cause a crash in which you can be seriously hurt or killed. Always use the size and type of tires recommended in this owner’s manual.
Check the side stand assembly for freedom of movement. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean engine oil. (1) side stand spring (2) side stand Servicing Your Honda...
Check slack in the lower drive chain ( ) run service in the Maintenance Schedule. midway between the sprockets. Drive chain slack should allow the following vertical movement by hand: 13/16 1 3/16 in (20 30 mm) (cont’d) Servicing Your Honda...
Page 113
If the chain slider and lower slider are worn to the bottom of the cutouts ( ), have Excessive chain slack may allow the drive your Honda dealer replace the slider. chain to damage the engine cases. Replace the chain guide slider if the chain is...
Page 114
Do not use an ordinary farthest limit of adjustment. Excessive slack master link with this chain. indicates the chain is worn beyond its service limit. (cont’d) Servicing Your Honda...
Drive Chain Inspect the front and rear sprocket teeth for excessive wear or damage. If necessary, have Adjustment your Honda dealer replace a worn sprocket. LEFT REAR Damaged Sprocket Worn Sprocket Teeth Teeth REPLACE REPLACE RIGHT REAR Normal Sprocket Teeth...
If a torque wrench is not used for this Lubricate every 300 miles (500 km) or sooner installation, see your Honda dealer as soon as if chain appears dry. possible to verify proper assembly. The O-rings in this chain can be damaged by steam cleaning, high pressure washers, and certain solvents.
Page 117
O-rings. Your motorcycle has an endless (riveted master link) type chain. It should only be removed or replaced by your Honda dealer. When the drive chain becomes extremely dirty, it should be cleaned prior to lubrication. Clean the side surfaces of the chain with a dry cloth.
Page 118
Drive Chain Inspect the sprocket teeth for wear or damage. We recommend replacing the sprocket whenever a new chain is installed. Lubricate the drive chain. Servicing Your Honda...
Saf ety Precautions on page General Recommendations Frequent cleaning and polishing will keep your Honda looking newer longer. Frequent To clean your motorcycle, you may use: cleaning also identifies you as an owner who water values your motorcycle. A clean motorcycle is a mild, neutral detergent and water also easier to inspect and service.
Page 120
After washing, rinse your motorcycle thoroughly with plenty of clean water to remove any residue. High pressure water (or air) can damage Dry your motorcycle with a chamois or a certain parts of your motorcycle. soft towel. (cont’d) Servicing Your Honda...
Page 121
Start the engine and let it idle for several minutes. The engine heat will help dry moist areas. As a precaution, ride at a slow speed and apply the brakes several times. This will help dry the brakes and restore normal braking performance. Servicing Your Honda...
Preparing for a Ride ........114 off-road adventure, how to transport and store Transporting Your Honda ......116 your Honda, and how to be an environmentally Storing Your Honda ........118 responsible motorcycle owner. You & the Environment ....... .121...
Preparing for a Ride A safe and enjoyable ride begins with good planning and preparation. Always ride with at What to Take to the Riding Area least one other person in case you have trouble, and let someone know where you’re going and Along with your motorcycle and riding gear, when you expect to return.
Page 124
Preparing for a Ride For safety, all refueling should be done at a gas If you decide to take some tools, spare parts, or station on the way to the riding area or at your other supplies on the trail, be sure you can base camp.
Transporting Your Honda If you use a truck or motorcycle trailer to transport your Honda, we recommend that you follow these guidelines: Use a loading ramp. Make sure the fuel valve is off. Secure the motorcycle in an upright position, using motorcycle tie-down straps.
Page 126
Transporting Your Honda Check that the tie-down straps do not contact any control cables or electrical wiring. Tighten both straps until the front suspension is compressed about half-way. Too much pressure is unnecessary and could damage the fork seals. Use another tie-down strap to keep the rear of the motorcycle from moving.
Honda Motorcycle Winter Storage Guide, your motorcycle and correct any problem available from your Honda dealer (USA only). before storing it. That way, needed repairs won’t be forgotten and it will be easier to get We suggest you perform the following your motorcycle running again.
Page 128
Storing Your Honda Drain the carburetor into an approved Preparation for Storage gasoline container and dispose of it in an approved manner (page ). If storage will Change the engine oil (page last longer than one month, carburetor Fill the fuel tank. Make sure the fuel fill cap draining is important, to assure proper is properly installed.
Page 129
Storing Your Honda Wash and dry your motorcycle. Lubricate the drive chain. Removal from Storage Inflate the tires to their recommended pressures (page Uncover and clean your motorcycle. Store your motorcycle in an unheated area, If your motorcycle has been stored for more...
You & the Environment Owning and riding a motorcycle can be Choose Sensible Cleaners. Use a enjoyable, but you must do your part to protect biodegradeable detergent when you wash nature. When you show respect for the land, your motorcycle. Avoid aerosol spray wildlife, and other people, you also help cleaners that contain chloroflurocarbons preserve the sport of off-road riding.
Page 131
You & the Environment Recycle Wastes. It’s illegal and thoughtless to put used engine oil in the trash, down a drain, or on the ground. Used oil, gasoline, and cleaning solvents contain poisons that can hurt refuse workers and contaminate our drinking water, lakes, rivers, and oceans.
Taking Care of the Unexpected With all the challenges you can encounter off- General Guidelines ........124 road, there’s a chance that sometime something If Your Engine Quits or Won’t Start ... .125 may go wrong. This section gives practical If You Have a Flat Tire ........
Taking Care of the Unexpected If a problem is relatively minor and you have General Guidelines the tools, supplies, and skills to make a permanent repair, you may be able to fix it on If something goes wrong during a ride, the first the trail and continue riding.
Taking Care of the Unexpected If the problem is relatively minor and you The next area to check is the fuel system: have the tools, supplies, and skills to make a temporary repair, be sure to have permanent Make sure there is enough gas in the tank repairs made as soon as possible.
Taking Care of the Unexpected If the fuel system appears to be okay, check the ignition system (this requires a spark plug If You Have a Flat Tire wrench): How you handle a flat tire on the trail depends Check that the spark plug cap isn’t loose or on how serious the tube or tire damage is, and disconnected.
Taking Care of the Unexpected If the leak is more serious, or a temporary repair doesn’t hold, the tube must be replaced. If You Crash The tire will also need to be replaced if it is damaged (page ). Replacing a tube or tire Personal safety is your first priority after an involves removing and re-installing the wheel accident.
Also, be sure to have If you lose your key and aren’t carrying a your Honda dealer check the frame and duplicate, either get your spare or have one suspension after any serious crash.
Taking Care of the Unexpected If any component of the front brake system If a Component Fails is damaged, you may be able to ride carefully back to your base using the rear The drive chain, brake lever or pedal, control brake for slowing or stopping.
Technical Information This section contains dimensions, capacities, Vehicle Identification ........132 and other technical data, plus information on Specifications ..........134 government requirements and how to break-in Break-in Guidelines ........139 your motorcycle. High Altitude Carburetor Adjustment ..140 Emission Control Systems ......
Vehicle Identification RIGHT SIDE Serial Numbers The frame and engine serial numbers are required when you register your motorcycle. They may also be required when ordering replacement parts. You may record these numbers in the Quick Ref erence section at the rear of the manual.
Page 142
Vehicle Identification LEFT SIDE Color Label & Code The color label ( ) is attached to the frame behind the left side cover (page The color code is helpful when ordering replacement parts. You may record the color and code in the Quick Ref erence section at the rear of the manual.
Specifications Dimensions Fuel & Lubricants Overall length 76.2 in (1,936 mm) Fuel tank capacity 2.17 US gal (8.2 ) Overall width 31.5 in (799 mm) including reserve Overall height 44.1 in (1,120 mm) Fuel tank reserve 0.40 US gal (1.5 ) Wheelbase 52.1 in (1,323 mm) Fuel...
Page 144
API service label, SAE 10W-40, Capacities JASO T 903 standard Passenger operator only; capacity no passenger Pro Honda GN4 or HP4 Maximum weight 220 lbs (100 kg) (without molybdenum capacity additives) 4-stroke oil Cargo capacity none (USA & Canada) or...
Break-in Guidelines Help assure your motorcycle’s future reliability and performance by paying extra attention to how you ride during the first operating day or 15 miles (25 km). During this period, avoid full-throttle starts and rapid acceleration. Technical Information...
However, the carburetor must be returned to standard factory specifications when lower altitude riding is desired. See your Honda dealer for high altitude modification. Sustained operation at altitudes below 5,000 f eet (1,500 m) with high altitude carburetor modif ications may cause engine overheating and damage.
Emission Control Systems Exhaust Emission Requirements Noise Emission Requirements The California Air Resources Board (CARB) The EPA also requires that motorcycles built requires that your motorcycle comply with after January 1, 1983 comply with applicable applicable exhaust emissions standards during noise emission standards for one year or its useful life, when operated and maintained 1,865 miles (3,000 km) after the time of sale to...
Page 151
Carbon monoxide does not react in carburetor. the same way, but it is toxic. Honda Motor Co., Ltd. utilizes lean carburetor settings and other systems to reduce carbon monoxide and hydrocarbons. Exhaust Emission Control System...
Page 152
Emission Control Systems Noise Emission Control System AMONG THOSE ACTS PRESUMED TO TAMPERING WITH THE NOISE CONTROL CONSTITUTE TAMPERING ARE THE SYSTEM IS PROHIBITED: U. S. federal law ACTS LISTED BELOW: prohibits, or Canadian provincial laws may Removal of, or puncturing the muffler, prohibit the following acts or the causing baffles, header pipes, or any other thereof: (1) The removal or rendering...
Page 153
Problems that May Affect Motorcycle Emissions If you are aware of any of the following symptoms, have the vehicle inspected and repaired by your Honda Motorcycle Dealer: Hard starting or stalling after starting Rough idle Misfiring or backfiring during acceleration...
Oxygenated Fuels Some conventional gasolines are being blended ETHANOL (ethyl or grain alcohol) 10% by with alcohol or an ether compound. These Volume gasolines are collectively referred to as You may use gasoline containing up to 10% oxygenated fuels. To meet clean air standards, ethanol by volume.
Page 155
Oxygenated Fuels If you notice any undesirable operating symptoms, try another service station or switch to another brand of gasoline. Oxygenated f uels can damage paint and plastic. Damage caused by spilled f uel is not Fuel system damage or performance problems covered under warranty.
Consumer Information This section contains information on your Authorized Manuals ........148 warranty and how to get an official Honda Warranty Coverage ........151 service manual. Warranty Service .......... .152 Contacting Honda .........153 The Honda Rider’s Club (USA only) ..
61KPT01 ) used by your authorized Honda dealer is available from Helm, Inc. (USA only, Canada: See your Honda dealer to order authorized manuals.) Also available, but not necessary, to service your model is the Honda Common Service Manual (Publication No.
Page 158
By completing this form you can order the materials desired. You can pay by check or money order, or charge to your credit card. Mail to Helm, Inc. at the address shown on the back of this order form (USA only). Canada: See your Honda dealer to order authorized manuals. Publication Item Description Qty.
Page 159
NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent. Customer Name Attention Street Address - No P. O. Box Number Apartment Number City State Zip Code Daytime Telephone Number Check or money order enclosed payable to Helm Inc.
Please read the Honda Motorcycle Warranties Almost all of your warranty coverage can be Booklet given to you by your Honda dealer at extended through the Honda Protection Plan the time of purchase. Be sure to keep your (USA only).
If the problem If you believe you have a problem with your has already been reviewed with the Service Honda, call the service department of your Manager, Parts Manager, Sales Manager, etc., Honda dealer. Make an appointment for an contact the Owner of the dealership or his inspection and diagnosis.
2220, mailstop: 100-4W-5B, telephone: (310) owner’s manual can be answered by your 532-9811. Honda dealer. If he doesn’t have the answer right away, he will get it for you. Canada: Refer to the warranty booklet that was supplied with your vehicle.
One of the best ways to get the most enjoyment A subscription to Honda Red Rider, a bi- from owning and riding your Honda is to join monthly insider’s magazine for all members. the Honda Rider’s Club of America (HRCA). Special members-only HRCA website.
(Canada only). The same quality dependability of your Honda. that went into your Honda can be found in Genuine Honda replacement parts. You’ll also find comparable quality in the accessories and products available from the parts department.
Table of Contents The following presents the contents of each Side Stand ............section of your owner’s manual. BEFORE RIDING ........MOTORCYCLE SAFETY ......Are You Ready to Ride ......Important Safety Information ......Protective Apparel ........Loading, Accessories & Modifications ...
Page 166
Table of Contents SERVICING YOUR HONDA ....Engine Bef ore You Service Your Honda Throttle ............The Importance of Maintenance ....Clutch System ..........Maintenance Safety ........Engine Idle Speed .......... Important Safety Precautions ..... Spark Plug ............Maintenance Schedule ........
Page 167
Table of Contents TIPS ............. .113 TECHNICAL INFORMATION ....131 Preparing for a Ride ........114 Vehicle Identification ........132 Transporting Your Honda ......116 Specifications ..........134 Storing Your Honda ........118 Break-in Guidelines ........139 You & the Environment .......
Page 168
TABLE OF CONTENTS ......156 Authorized Manuals ........148 Warranty Coverage ........151 INDEX ............160 Warranty Service .......... .152 Contacting Honda .........153 QUICK REFERENCE The Honda Rider’s Club (USA only) ...154 Your Honda Dealer ........155 Table of Contents...
Index drive chain ............ .103 filter, air ............flat tire ............126 flooded engine, starting ......... fork ..............frame number ..........132 education, rider .........3, 155 front brake, emission control systems ......141 lever ............emission requirements ........141 lever freeplay ..........
How To Avoid Costly Repairs about your Honda. You’ll also find space to record important notes. The engine of your Honda can be the most expensive component to repair. Proper maintenance, especially the use of the recommended fluids and filters, prevents premature wear and damage.
Page 176
Quick Reference Record important information here: Frame No. Engine No. Ignition Key No. Color Label Owner’s: Name Address City/State Phone Dealer’s: Name Address City/State Phone Service Mgr. Quick Reference...
Page 177
API Service Classification SG or higher except oils labeled as energy conserving on the circular API service label, SAE 10W-40, JASO T 903 standard MA, Pro Honda GN4 or HP4 (without molybdenum additives) 4-stroke oil or equivalent Maximum Weight 220 lbs (100 kg)
