Instructions
Manual Electrostatic
PRO
™
Air Spray Guns
For use with Class I Group D spray materials.
For use with Class II 2 G spray materials.
0.24 Mj
Important Safety Instructions:
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for Table of Contents and page 3 for List of Models.
100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure
100 psi (0.7 MPa, 7 bar) Maximum Working Fluid Pressure
U.S. Patent 7,226,004
Standard Model
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2001, Graco Inc. is registered to I.S. EN ISO 9001
Xs3 and PRO
ti1248a
Xs4
™
Smart Model
309292L
ti1600a
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Graco PRO XS3 309292L
Summary of Contents for Graco PRO XS3 309292L
- Page 1 Instructions Manual Electrostatic Xs3 and PRO ™ Air Spray Guns For use with Class I Group D spray materials. For use with Class II 2 G spray materials. 0.24 Mj Important Safety Instructions: Read all warnings and instructions in this manual. Save these instructions.
-
Page 2: Table Of Contents
Table of Contents List of Models ......3 Symbols ........4 Warning . -
Page 3: List Of Models
List of Models Smart Part No. Model Display 244400, PRO Xs3 Series C 244579, PRO Xs3 Series C 244575, PRO Xs3 Series C 244576, PRO Xs3 Series C 244401, PRO Xs4 Series C 244580, PRO Xs4 Series C 309292L Type of Coatings Standard High Conductivity List of Models... -
Page 4: Symbols
Symbols Symbols Warning Symbol WARNING This symbol alerts you to the possibility of serious injury or death if you do not follow the instructions. Fire, Explosion, and Electric Shock Hazard Improper grounding, poor air ventilation, open flames, or sparks can cause a hazardous condition and result in a fire, explosion, or electric shock. - Page 5 Equipment Misuse Hazard Equipment misuse can cause the equipment to rupture, malfunction, or start unexpectedly and result in a serious injury. • This equipment is for professional use only. • Read all manuals, tags, and labels before operating the equipment. •...
-
Page 6: Introduction
Introduction Introduction How the Electrostatic Air Spray Gun Works The air hose supplies air to the spray gun. Part of the air operates the turbine and the rest of the air atomizes the fluid being sprayed. The turbine generates power, which is converted by the power cartridge to supply high volt- age current to the gun’s electrode. -
Page 7: Installation
Installation Install the System WARNING Fire, Explosion, and Electric Shock Hazard Installing and servicing this equipment requires access to parts which may cause electric shock or other serious injury if work is not performed properly. • Do not install or service this equipment unless you are trained and qualified. - Page 8 Installation Fig. 2. Typical Installation Main Air Supply Line Ventilation Fan Interlock Solenoid Valve Main Air Supply Shutoff Valve (bleed-type) Pump Air Line Filter/Water Separator Pump Air Supply Shutoff Valve (bleed-type) Air Line Lubricator Air Pressure Regulator Pump Pump Ground Wire Fluid Filter Fluid Supply Line Shutoff Valve Fluid Pressure Regulator...
-
Page 9: Connect The Air Line
Connect the Air Line WARNING Electric Shock Hazard To reduce the risk of electric shock or other serious injury, the air supply hose must be electrically connected to a true earth ground. Use only Graco Grounded Air Supply Hose. 1. Connect the Graco Grounded Air Supply Hose (R) between the air supply line and the gun's air inlet (V). -
Page 10: Connect The Fluid Line
Installation Connect the Fluid Line 1. Before connecting the fluid line (N), blow it out with air and flush it with solvent. Use solvent which is compatible with the fluid to be sprayed. 2. Install a fluid regulator (M) on the fluid line to control fluid pressure to the gun. -
Page 11: 244919 Hc Conversion Kit
244919 HC Conversion Kit Part No. 244919 Conversion Kit converts PRO Xs3 standard coating guns (Part Nos. 244400 and 244579) to high conductivity guns (244575 and 244576). For fur- ther instruction and parts, see manual 309453. The kit is for use with fluids with low resistivity values. WARNING Pressurized Equipment Hazard To reduce the risk of an injury, follow the... -
Page 12: Grounding
Installation Grounding WARNING Fire, Explosion, and Electric Shock Hazard When operating the electrostatic gun, any ungrounded objects in the spray area (peo- ple, containers, tools, etc.) can become electrically charged. Improper grounding can result in static sparking, which can cause a fire, explosion, or electric shock. Follow the grounding instructions below. -
Page 13: Check Electrical Grounding
Check Electrical Grounding WARNING Fire, Explosion, and Electric Shock Hazard Megohmmeter Part No. 241079 (AA-see . 4.) is not approved for use in a hazard- ous area. To reduce the risk of sparking, do not use the megohmmeter to check electri- cal grounding unless: •... -
Page 14: Check Fluid Resistivity
Installation Check Fluid Resistivity WARNING Fire, Explosion, and Electric Shock Hazard Check the fluid resistivity in a non-hazard- ous area only. Resistance Meter 722886 and Probe 722860 are not approved for use in a hazardous area. Failure to follow this warning could cause fire, explosion, or electric shock and result in serious injury and property damage. -
Page 15: Operation
Operation INSTRUCTIONS Low Voltage Adjustment (Smart Guns Only) The ES HI/LO switch enables you to switch between full voltage and a lower voltage output. The lower voltage is factory set, but can be adjusted. 1. Set the ES HI/LO switch to LO. 2. -
Page 16: Maintenance
Maintenance Maintenance INSTRUCTIONS Flush the Spray Gun Flush the gun before changing colors, at the end of the day, before storing, and before repairing the gun. WARNING Fire, Explosion, and Electric Shock Hazard To reduce the risk of fire, explosion, or elec- tric shock, turn the ES ON/OFF valve OFF before flushing the gun. - Page 17 7. Hang the gun from its hook, with the nozzle pointing down. 309292L 8. When ready to spray again, reconnect the fluid sup- ply line. Follow the Setup procedure in the Opera- tion Manual. ti1288a Maintenance...
-
Page 18: Electrical Tests
Electrical Tests Electrical Tests Electrical components inside the gun affect performance and safety. The following procedures test the condition of the power supply (18) and electrode (29), and electri- cal continuity between components. Use megohmmeter Part No. 241079 (AA) and an applied voltage of 500 V. -
Page 19: Test Power Supply Resistance
Test Power Supply Resistance 1. Remove the power supply (18), page 30. 2. Remove the turbine alternator (19) from the power supply, page 31. 3. Measure resistance from the power supply's ground strips (EE) to the spring (18b). See F 4. -
Page 20: Test Electrode Resistance
Electrical Tests Test Electrode Resistance 1. Insert a conductive rod (B) into the gun barrel (removed for the power supply test) and against the metal contact (C) in the front of the barrel. 2. Measure the resistance between the conductive rod (B) and the electrode (29). -
Page 21: Troubleshooting
Troubleshooting WARNING Electric Shock Hazard Installing and servicing this equipment requires access to parts which may cause an electric shock or other serious injury if the work is not performed properly. Do not install or repair this equipment unless you are trained and qualified. -
Page 22: Gun Operation Troubleshooting
Troubleshooting Gun Operation Troubleshooting Problem Excessive spray fog. “Orange Peel” finish. Fluid leaks from the fluid packing area Air leaks from the front of the gun Fluid leakage from the front of the Gun does not spray Dirty air cap Cause Atomizing air pressure too high. -
Page 23: Electrical Troubleshooting
Electrical Troubleshooting Problem Poor wrap. ES indicator or voltage/current dis- play is not lit. Voltage/current display stays red (smart guns only). Operator gets mild shock. Operator gets shock from workpiece. Workpiece not grounded. * ES indicator light is off when the gun is triggered. 309292L Cause ES ON/OFF valve OFF (0).*... -
Page 24: Repair
Repair Repair Pressure Relief Procedure WARNING Pressurized Equipment Hazard The system pressure must be manually relieved to prevent the system from starting or spraying accidentally. To reduce the risk of an injury from electric shock, accidental spray from the gun, splashing fluid, or mov- ing parts, follow the Pressure Relief Pro- cedure whenever you: •... -
Page 25: Prepare The Gun For Service
Prepare the Gun for Service WARNING Electric Shock Hazard Installing and repairing this equipment requires access to parts that may cause electric shock or other serious injury if the work is not performed properly. Do not install or service this equipment unless you are trained and qualified. -
Page 26: Air Cap/Nozzle Replacement
Repair Air Cap/Nozzle Replacement CAUTION Hold the front end of the gun up and trigger the gun while removing the nozzle to help drain the gun and prevent any paint or solvent left in the gun from entering the air passages. 1. -
Page 27: Electrode Replacement
Electrode Replacement 1. Prepare the gun for service, page 25. 2. Remove the air cap and nozzle, page 26. 3. Unscrew the electrode (29) with the multi-tool (37). Hold the packing rod end (26h) to prevent it from turning, F . -
Page 28: Fluid Packing Removal
Repair Fluid Packing Removal 1. Prepare the gun for service, page 25. 2. Remove the air cap and fluid nozzle, page 26. 3. Remove the electrode, page 27. 4. Loosen the trigger screws (8) and trigger (30). See . 13.. 5. -
Page 29: Packing Rod Repair
Packing Rod Repair You may replace the packing rod as individual parts or as an assembly. The assembly is pre-adjusted at the factory. Before installing the fluid packing rod into the gun barrel, make sure the internal surfaces of the barrel are clean. Remove any residue with a soft brush or cloth. -
Page 30: Barrel Removal
Repair Barrel Removal 1. Prepare the gun for service, page 25. 2. Carefully loosen the nut (32 or 50d) from the bracket fluid fitting (13). Pull the tube (14 or 50a) out of the fitting. Make sure both ferrules and the nut stay with the tube. -
Page 31: Power Supply Removal And Replacement
Power Supply Removal and Replacement • Inspect the gun handle power supply cavity for dirt or moisture. Clean with a clean, dry rag. • Do not expose gasket (10) to solvents. 1. Prepare gun for service, page 25. 2. Remove the barrel (16), page 30. CAUTION Be careful when handling the power supply (18) to avoid damaging it. -
Page 32: Turbine Alternator Removal And Replacement
Repair Turbine Alternator Removal and Replacement Replace turbine alternator bearings after 2000 hours of operation. Order Part No. 223688 Bearing Kit. 1. Prepare gun for service, page 25. 2. Remove the power supply/alternator assembly, page 31. 3. Disconnect the alternator from the power supply, page 31. -
Page 33: Fan Air Adjustment Valve Repair
Fan Air Adjustment Valve Repair 1. Prepare the gun for service, page 25. 2. Place a wrench on the flats of the valve assembly (20) and unscrew it from the handle (17). You may replace the valve as an assembly (go to step 9) or as individual parts (steps 3-9). -
Page 34: Fluid Adjustment Valve Repair
Repair Fluid Adjustment Valve Repair 1. Prepare the gun for service, page 25. 2. Remove the fluid adjustment valve (25). It can only be replaced as a complete assembly. See F 3. Screw the valve (25) into the gun handle. Torque to 15-25 in-lb (1.7-2.8 N•m). -
Page 35: Atomizing Air Restrictor Valve Removal And Replacement
Atomizing Air Restrictor Valve Removal and Replacement 1. Prepare the gun for service, page 25. 2. Remove the atomizing air restrictor valve (23) . Inspect the o-ring (23c*). Replace if necessary. See . 22.. 3. Install a new atomizing air restrictor valve (23), or disassemble and replace parts individually. -
Page 36: Parts
Parts Parts Part No. 244400 60 kV Electrostatic Gun, Series C (items 1-48, 55) Part No. 244575 60 kV Electrostatic Gun, Series C (items 4-30, 35-55) Part No. 244401 85 kV Electrostatic Gun, Series C (items 1-48, 55) ti1266a *18a 25 (Ref) 27a* See page 37 for detail views of the fluid tube assemblies, alternator... - Page 37 Ref. No. 19: Alternator Ref. No. 22: ES ON/OFF Valve 22b* 22a* TI1488A Fluid Tube: Model 244400 31** ti1492a 309292L Ref. No. 20: Fan Adjustment Valve 19a* TI1481a Ref. No. 26: Packing Rod 26c** 26a** Fluid Tube: Model 244575 20b* 26b** 26g** 26d**...
- Page 38 Parts Part No. 244400 60 kV Electrostatic Gun, Series C (items 1-48, 55) Part No. 244575 60 kV Electrostatic Gun, Series C (items 4-30, 35-55) Part No. 244401 85 kV Electrostatic Gun, Series C (items 1-48, 55) Ref. Part No. Description 110078 FITTING, tube, fluid;...
- Page 39 Ref. Part No. Description 244559 VALVE, air, atomizing; includes 23a-23d 197594 . HOUSING, valve 197591 . SHAFT 23c* 168518 . O-RING; fluoroelastomer 101021 . RING, retaining 249323 VALVE, exhaust; includes 24a 24a* 112085 . O-RING; fluorocarbon 244593 VALVE, adjustment, fluid 244597 ROD, packing;...
- Page 40 Parts Part No. 244579 60 kV Electrostatic Gun, Series C (items 1-48, 51-59) Part No. 244576 60 kV Electrostatic Gun, Series C (items 1-30, 35-59) Part No. 244580 85 kV Electrostatic Gun, Series C (items 1-48, 51-59) 53 (Ref) 51 (Ref) ti1253a *18a 25 (Ref)
- Page 41 Ref. No. 19: Alternator Ref. No. 22: ES ON/OFF Valve 22b* 22a* TI1488A Fluid Tube: Model 244579 31** ti1492a 309292L Ref. No. 20: Fan Adjustment Valve 19a* TI1481a Ref. No. 26: Packing Rod 26c** 26a** Fluid Tube: Model 244576 20b* 26b** 26g** 26d**...
- Page 42 Parts Part No. 244579 60 kV Electrostatic Gun, Series C (items 1-48, 51-59) Part No. 244576 60 kV Electrostatic Gun, Series C (items 1-30, 35-59) Part No. 244580 85 kV Electrostatic Gun, Series C (items 1-48, 51-59) Ref. Part No. Description 110078 FITTING, tube, fluid;...
- Page 43 Ref. Part No. Description 185495 . HOUSING, packing 26g** 186069 . SPACER, packing; acetal 244695 . ROD, packing; used on 244579 and 244576 244696 . ROD, packing; used on 244580 244927 RING, retaining, air cap; includes item 27a* 198307 . PACKING, u-cup 276695 HOOK 29**** 276697...
-
Page 44: Accessories
Accessories Accessories Air Line Accessories ™ AirFlex Flexible Grounded Air Hose 100 psi (7 bar, 0.7 MPa) Maximum Working Pressure 0.315 in. (8 mm) ID; 1/4 npsm(f) x 1/4 npsm(f) left-hand thread 244963 6 ft (1.8 m) 244964 15 ft (4.6 m) 244965 25 ft (7.6 m) 244966... -
Page 45: Gun Accessories
Gun Accessories Gun Repair Kits 244781 Air Seal Repair Kit 244911 Fluid Seal Repair Kit Round Pattern Kits Consists of fluid tip, diffuser and air cap. 245217 4-6 in. (102-152 mm) diameter 245219 8-10 in. (203-254 mm) diameter Push/Pull Fan Air Valve 244912 For quick change of fan size. -
Page 46: Technical Data
Technical Data Technical Data Category Maximum Working Fluid Pressure Maximum Working Air Pressure Minimum Air Pressure at Gun Inlet Maximum Fluid Operating Temperature Paint Resistivity Range Short Circuit Current Output Voltage Output Sound Power (measured per ISO Standard 9216) Sound Pressure (measured 1 m from gun) Air inlet fitting, left-hand thread Fluid inlet fitting Gun Weight... - Page 47 Technical Data 309292L...
-
Page 48: Graco Standard Warranty
Graco Standard Warranty Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months or two thousand hours of operation from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
