Mackie ONYX 4-BUS Series Specifications

ONYX 4-BUS SERIES
The Onyx 4-Bus Series mixing consoles set the new standard
in mid-format mixing. With improved Onyx mic preamps,
acclaimed 4-band Perkins EQ on every channel, and a
built-in assignable compressor/limiter, the Onyx 4-Bus is
packed with premium features and maximum flexibility.
The 6x2 matrix allows for two additional submixes, perfect for
zone outputs, IEM systems and more. A high-quality onboard
compression and limiting section features adjustable
threshold, ratio and fast/slow attack controls and dedicated
12-segment metering. The talkback section has separate
level controls for phones, monitor out, solo, mono out and
talkback. True 4-bus architecture means four accessible group
faders, each with 4-segment metering and mute, solo and AFL
functions for each group.
The mic/line channel strips each include a Mackie Onyx mic
preamp, individual 48V phantom power, a pad switch and a
100Hz high-pass filter. "British-style" 4-band Perkins EQ is
very effective and extremely musical, with frequency points
selected for optimum versatility. Six auxiliary sends may
be set individually to pre/post operation and each boasts
an AFL switch on their master. The fader itself is a 100mm
Panasonic fader for smooth, high-resolution control.
™
Oversized mute and PFL buttons are easy to access when
needed. The last two channels are specifically designed for
stereo devices such as effects returns, stereo synthesizers or
other two-track playback devices. These are full channel strips
with appropriate 4-band fixed EQ, all six Aux sends and
full routing.
With stunning sound quality and renowned Mackie
engineering — combined in a full-featured, portable, highly
affordable, mid-format mixing console — the Onyx 4-Bus is
certainly the new standard.
APPLICATIONS
Live sound mixing, houses of worship, small-to-medium-
sized clubs, theaters, banquet halls, conference rooms,
boardrooms, multitrack field recording, and many, many
more.
ONYX 4-BUS
FEATURES:
24-channel and 32-channel / 4-bus premium analog
■
live sound mixer
Onyx microphone preamps with class-leading fidelity
■
and dynamic range
4-band Perkins EQ for warm, musical sound
■
6x2 Matrix Mixer provides two additional mixes for
■
cry rooms, monitors, etc.
Assignable stereo compressor/limiter designed by
■
THAT ® corporation
12-segment LED ladders for Main output and
■
compressor/limiter
Six Aux sends with Pre/Post, Solo and Mute switches
■
Two dedicated stereo channels
■
100mm Panasonic faders on all channels, Groups,
■
™
and Mains
Compact and rugged
■
LIVE ANALOG
MIXING CONSOLES
1/8 PAGES
