Summary of Contents for Fujitsu Siemens Computers D1544
- Page 1 Technisches Handbuch / Technical Manual Mainboard D1544 Deutsch / English...
- Page 2 • Ihre Verkaufsstelle Weitere Informationen finden Sie im Handbuch "Sicherheit" und "Ergonomie". Aktuelle Informationen und Updates zu unseren Mainboards finden Sie im Internet: http://www.fujitsu-siemens.com Are there ..any technical problems or other questions you need clarified? Please contact: •...
- Page 4 Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-D1544-Z120-1-7419 Bestell-Nr./Order No.: Printed in the Federal Republic of Germany AG 0403...
- Page 5 Deutsch English Mainboard D1544 Technisches Handbuch Technical Manual Ausgabe April 2003 April 2003 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright Fujitsu Siemens Computers GmbH 2003 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
- Page 8 Übersicht/Overview Mainboard D1544 Interne Anschlüsse und Steckplätze / Internal connectors and slots Pentium 4 10 = Stromversorgung Prozessor / Power supply USB E/F 11 = processor Batterie / Battery 12 = Lüfter Prozessor / Fan processor Steckbrücke J4 / Jumper J4...
-
Page 9: Table Of Contents
Contents Übersicht/Overview Mainboard D1544 Mainboard D1544 ..........................1 Notational conventions ......................1 Important notes..........................2 Information about boards ......................2 List of features...........................3 Special features.........................4 Interfaces and connectors ......................6 External ports ............................6 LAN connector...........................6 Graphics port - Supported screen resolutions ................7 Internal ports and connectors ......................7 Hard disk connection .........................7... -
Page 11: Mainboard D1544
Mainboard D1544 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Further information Additional descriptions (e. g. of the drivers) are contained: •... -
Page 12: Important Notes
The equipment and tools you use must be free of static charges. • Remove the power plug from the mains supply before inserting or removing boards containing ESDs. • Always hold boards with ESDs by their edges. • Never touch pins or conductors on boards fitted with ESDs. A26361-D1544-Z120-1-7419 English -... -
Page 13: List Of Features
HI-SPEED USB 2.0 SmartCard Reader Support (USB / serial) Temperature monitoring System Monitoring Fujitsu Siemens Computers Keyboard Power Button Support Internal ports DIMM slots (DDR 266 SDRAM) AGP Slot (4/8x, 32 bit, 66 MHz, 1.5 V) PCI slot (32-bit, 33 MHz, 5 V and 3.3 V) CNR Slot (Type A, AC‘97 only) -
Page 14: Special Features
List of features External ports D1544 Audio Mic. in / Line in / Line out / Speaker out 1 / 1 / 1 / 1 Game/MIDI LAN (RJ-45) PS/2 mouse/keyboard 1 / 1 USB Ports (2.0, ~480 MB/s) Serial Ports (FIFO, 16550 compatible) - Page 15 Within just a few seconds the PC is in exactly the same state it was in when it was switched off without time-consuming booting. Depending on the operating system, the PC can be switched into an energy-saving mode with applications open by pressing the ON/OFF switch. 5 - English A26361-D1544-Z120-1-7419...
-
Page 16: Interfaces And Connectors
Magic Packet. The LAN RJ45 connector has two LEDs (light emitting diodes). 1 = a connection exists (e.g. to a hub). 2 = Link Mode: the LAN connection is active. WOL mode: a Magic Packet is being received. A26361-D1544-Z120-1-7419 English -... -
Page 17: Graphics Port - Supported Screen Resolutions
An ultra ATA/66 or ultra ATA/100 hard disk must be connected with a cable especially designed for the ultra ATA/66 or ultra ATA/100 mode. Ê Connect the end of the cable marked with blue to the mainboard. 7 - English A26361-D1544-Z120-1-7419... -
Page 18: Add-On Modules / Upgrading
(A) with regard to the position (4). The angled corner of the processor can also be at a different location than shown in the illustration. Ê Push the lever back down until it clicks into place (5). 8 - English A26361-D1544-Z120-1-7419... -
Page 19: Mounting Heat Sink
Depending on the processor variant, clips may also be supplied for mounting the heat sink that fix it in place. Ê When you have mounted the optional fan, connect the fan plug to the corresponding connection on the mainboard. 9 - English A26361-D1544-Z120-1-7419... -
Page 20: Upgrading Main Memory
Push the holders on each side of the memory compartment outwards. Ê Insert the memory module into the location (1). Ê At the same time flip the lateral holders upwards until the memory module snaps in place (2). A26361-D1544-Z120-1-7419 English -... -
Page 21: Adding Pci Cards
PCI IRQ Lines connect AGP slots, PCI slots and onboard components to the interrupt controller. PCI IRQ Lines are permanently wired on the mainboard. Which ISA IRQs are assigned to the PCI IRQ Lines is normally automatically specified by the BIOS. 11 - English A26361-D1544-Z120-1-7419... - Page 22 PCI slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. A26361-D1544-Z120-1-7419 English -...
-
Page 23: Replacing The Lithium Battery
Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). Ê Remove the battery (2). Ê Push the new lithium battery of the identical type into the holder (3) and press it downward until it engages (4). 13 - English A26361-D1544-Z120-1-7419... -
Page 24: Glossary
Universal Serial Bus GMCH Graphics and Memory Controller Video Graphic Adapter Graphics Performance Wake On LAN Accelerator Inter Integrated Circuit IAPC Instantly Available Power Managed Desktop PC Design I/O Controller Hub Intelligent Drive Electronics IPSEC Internet Protocol Security A26361-D1544-Z120-1-7419 English -...
