- Page 1 USER’S MANUAL PSB-601LF Intel Core 2 Duo ® Full Size CPU Card With VGA/Sound/2LAN PSB-601LF M1...
- Page 2 Copyright Notice PSB-601LF Intel® Core 2 Duo Full Size CPU Card With VGA/ Sound/ 2LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.
- Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Table Of Contents
Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ……..…………………………... RS232/422/485(COM2) Selection ........ - Page 5 Contents 2-34 CF Card Master/ Slave Selection ……………………… 2-26 2-35 PCI Slot 3.3V Voltage Selection ……………………… 2-27 2-36 LVDS Connector ……………………………………… 2-28 2-37 LVDS Panel Voltage Selection ……………………….. 2-29 CHAPTER 3 SOFTWARE UTILITIES Introduction …………..........…..VGA Driver Utility ……………………………….…… Flash BIOS Update ..........…..LAN Driver Utility …...........…..
- Page 6 Contents APPENDIX A EXPANSION BUS ISA Bus Pin Assignment ……………………………………… PCI Bus Pin Assignment ..........…..Compact Flash Card Pin Assignment …………………………. APPENDIX B TECHNICAL SUMMARY Block Diagram ................Interrupt Map ................RTC & CMOS RAM Map ............Timer & DMA Channels Map ..........I/O &...
-
Page 7: Chapter 1 Introduction
CHAPTER INTRODUCTION This chapter gives you the information for PSB-601LF. It also outlines the System specifications. Section includes: About This Manual System Specifications Safety Precautions Experienced users can skip to chapter 2 on page 2-1 for a Quick Start. Page:1-1... -
Page 8: About This Manual
Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our PSB-601LF Intel® Core 2 Duo Full Size CPU Card enhanced with VGA/Sound/2LAN, which is fully PC / AT compatible. The PSB-601LF provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system. -
Page 9: System Specification
Support S/IO Setup. KEYBOARD CONNECTOR : Mini DIN connector. Selectable for keyboard, PS/2 Mouse, or Y-cable. One additional 5-pin external keyboard connector. BUS SUPPORT : One ISA/PCI Bus One Compact Flash Bus One MXM Bus ′ Page: 1-3 PSB-601LF USER S MANUAL... - Page 10 Fully Compliant HD Analog I/O Component 16-Bit Stereo Full-Duplex Codec Four Analog Line-level Stereo Inputs for Connection. High Quality CD Input with Ground Sense Stereo Line-Level Output Interface: Line-In, Line-Out, Microphone, and CD Audio-In. ′ Page: 1-4 PSB-601LF USER S MANUAL...
- Page 11 0 to 60°C. INPUT POWER REQUIREMENT : ATX power: +5V, +12V, -12V, 5VSB. AT power: +5V, +12V, -12V. BOARD DIMENSIONS : 338.5mm x 122mm, 13.33” x 4.8” BOARD NET WEIGHT : 370 gram. (0.82lb) ′ Page: 1-5 PSB-601LF USER S MANUAL...
-
Page 12: Safety Precautions
3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 PSB-601LF USER S MANUAL... -
Page 13: Chapter 2 Hardware Configuration
CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1... -
Page 14: Jumper & Connector Quick Reference Table
Reset/ NMI Selection ………………………………….. AUDIO1 Sound Connector ………………………….…………… CD_IN1 CD Audio-In Connector ……………………………….. Compact Flash Card Master/ Slave Selection …………. PCI Slot 3.3V Voltage Selection ………………………. LVDS1 LVDS Connector ………………………………………. LVDS Voltage Selection ………………………………. ′ Page: 2-2 PSB-601LF USER S MANUAL... -
Page 15: Component Locations
Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS PSB-601LF Connector, Jumper and Component locations ′ Page: 2-3 PSB-601LF USER S MANUAL... -
Page 16: How To Set The Jumpers
You can connect PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 PSB-601LF USER S MANUAL... - Page 17 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 PSB-601LF USER S MANUAL...
-
Page 18: Com Port Connector
COM2 : COM2 Connector The COM2 is selectable as RS-232/422/485. The pin assignment is as follows : ASSIGNMENT RS-232 RS-422 RS-485 COM2_DCD# COM2_RX COM2_TX COM2_DTR# COM2_DSR# RTS- COM2_RTS# RTS+ COM2_CTS# CTS+ COM2_RI# CTS- ′ Page: 2-6 PSB-601LF USER S MANUAL... -
Page 19: Rs232/422/485(Com2) Selection
This connector is used to set the COM2 function. The jumper settings are as follows : COM 2 Jumper Settings Jumper Function (pin closed) Illustrations RS-232 All Open RS-422 1-2, 3-4, 9-10 RS-485 1-2, 5-6, 7-8 *** Manufacturing default -- RS-232. ′ Page: 2-7 PSB-601LF USER S MANUAL... -
Page 20: Keyboard And Ps/2 Mouse Connector
For Y-Cable user, please set the jumper same as AT keyboard. The jumper settings are as follows: JUMPER SETTING JUMPER DEVICE TYPE (pin closed) ILLUSTRATION AT KEYBOARD PS/2 MOUSE *** Manufactory default -- AT Keyboard ′ Page: 2-8 PSB-601LF USER S MANUAL... -
Page 21: External Keyboard Connector
The pin assignment is as follows : ASSIGNMENT RST_BTN 2-10. HARD DISK DRIVE LED CONNECTOR JP3 (1, 3) : Hard Disk Drive LED Connector The pin assignment is as follows : ASSIGNMENT HD_LED+ HD_LED- ′ Page: 2-9 PSB-601LF USER S MANUAL... -
Page 22: Atx Power Button
The pin assignment is as follows : ASSIGNMENT SPK_VCC SPEAKER SIGNAL SPEAKER SIGNAL SPEAKER SIGNAL 2-13. POWER LED CONNECTOR JP3 (2, 4) : Power LED Connector The pin assignment is as follows: ASSIGNMENT PW_LED+ PW_LED- ′ Page: 2-10 PSB-601LF USER S MANUAL... -
Page 23: Keylock Connector
2-14. KEYLOCK CONNECTOR JP3 (13, 15) : Keylock Connector The pin assignment is as follows: ASSIGNMENT KEYLOCK 2-15. EXTERNAL SMI CONNECTOR JP3 (17,19) : External SMI Connector The pin assignment is as follows: ASSIGNMENT SLP_BTN ′ Page: 2-11 PSB-601LF USER S MANUAL... -
Page 24: Clear Cmos Data Selection
“Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-17. CPU FAN CONNECTOR CPU_FAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT VCC12 LPC1_FANIO1 LPC1_FANPWM1 ′ Page: 2-12 PSB-601LF USER S MANUAL... -
Page 25: System Fan Connector
SYS_FAN1 : System Fan connector The pin assignment is as follows: ASSIGNMENT VCC12 LPC1_FANIO2 2-19. INVERTER CONNECTOR INV1 : Inverter Connector The pin assignment is as follows: ASSIGNMENT +12V ENABKL(Inverter backlight ON/OFF control signal) ′ Page: 2-13 PSB-601LF USER S MANUAL... -
Page 26: Hard Disk Drive Connector
IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDREQ PDIOW# PDIOR# PIORDY PULL LOW PDDACK# IRQ14 PDA1 P66 DETECT PDA0 PDA2 PDCS#1 PDCS#3 IDEACTP# ′ Page: 2-14 PSB-601LF USER S MANUAL... -
Page 27: Vga Connector
Chapter 2 Hardware Configuration 2-21. VGA CONNECTOR VGA1: VGA Connector ASSIGNMENT GMCH_CRTRED GMCH_GRTGREEN GMCH_CRTBLUE GMCH_CRTVCC_L GMCH_CRTDATA GMCH_HSYNC GMCH_VSYNC GMCH_CRTCLK ′ Page: 2-15 PSB-601LF USER S MANUAL... -
Page 28: Serial Ata Connector
Chapter 2 Hardware Configuration 2-22. SERIAL ATA CONNECTOR SATA1, SATA2, SATA3, SATA4 : The PSB-601LF possesses four Serial ATA Connector. The pin assignments are as follows: SATA1: ASSIGNMENT SATAHDR_TXP0 SATAHDR_TXN0 SATAHDR_RXN0 SATAHDR_RXP0 SATA2: ASSIGNMENT SATAHDR_TXP1 SATAHDR_TXN1 SATAHDR_RXN1 SATAHDR_RXP1 ′ Page: 2-16... - Page 29 Chapter 2 Hardware Configuration SATA3: ASSIGNMENT SATAHDR_TXP2 SATAHDR_TXN2 SATAHDR_RXN2 SATAHDR_RXP2 SATA4: ASSIGNMENT SATAHDR_TXP3 SATAHDR_TXN3 SATAHDR_RXN3 SATAHDR_RXP3 ′ Page: 2-17 PSB-601LF USER S MANUAL...
-
Page 30: Floppy Disk Drive Connector
34-pin flat cable to attach the FDD on the board, and the other side is attaches two FDDs. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT RWC# INDEX MOA# DSB# DSA# MOB# DIR# STEP# TRK0# RDATA# HEAD# DSKCHG ′ Page: 2-18 PSB-601LF USER S MANUAL... -
Page 31: Universal Serial Bus Connector
USB1: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB1_VCC5 USBN0_L USBP0_L USB1_VCC5 USBN1_L USBP1_L USB2: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB2_VCC5 USBN2_L USBP2_L USB2_VCC5 USBN3_L USBP3_L ′ Page: 2-19 PSB-601LF USER S MANUAL... -
Page 32: Irda Connector
Left Side LED Green Color On 10/100 LAN Speed Indicator Orange Color On Giga LAN Speed Indicator No LAN switch/ hub connected. Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active ′ Page: 2-20 PSB-601LF USER S MANUAL... -
Page 33: 5Vsb Connector
No LAN switch/ hub connected. Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active 2-27. 5VSB CONNECTOR JP12 : ATX Power Signal Connector The pin assignments are as follows: ASSIGNMENT 5VSB PS_ON ′ Page: 2-21 PSB-601LF USER S MANUAL... -
Page 34: Atx/At Power Selection
Chapter 2 Hardware Configuration 2-28. ATX / AT POWER SELECTION JP13 : AT / ATX Power Selection The selections are as follows: JUMPER JUMPER SETTING ILLUSTRATION (pin closed) Open Closed *** Manufacturing Default: ATX. ′ Page: 2-22 PSB-601LF USER S MANUAL... -
Page 35: Atx Power Connector
2-29. ATX POWER CONNECTOR ATX_PW1 : ATX 12V Connector The pin assignments are as follows: ASSIGNMENT +12V +12V CONN1 : Power Connector The pin assignments are as follows : ASSIGNMENT ASSIGNMENT 5VSB PS-ON +12V -12V ′ Page: 2-23 PSB-601LF USER S MANUAL... -
Page 36: Memory Installation
Chapter 2 Hardware Configuration 2-30. MEMORY INSTALLATION PSB-601LF CPU Card can support up to 4GB in two DIMM sockets. DRAM BANK CONFIGURATION DIMM 1 DIMM 2 TOTAL MEMORY 256MB 256MB 512MB 512MB 512MB 2-31. RESET/NMI SELECTION JP10 : Reset/NMI Watchdog Selection... -
Page 37: Sound Connector
ASSIGNMENT AC97_MIC-IN AUDIO_GND AUDIO_GND AUDIO_GND AC97_LINE-L AC97_LINE-R AUDIO_GND AUDIO_GND AC97_SPK-L AC97_SPK-R 2-33. CD AUDIO-IN CONNECTOR CD_IN1 : CD Audio-In Connector The pin assignments are as follows: ASSIGNMENT CD L CDGND CDGND CD R ′ Page: 2-25 PSB-601LF USER S MANUAL... -
Page 38: Cf Card Master/ Slave Selection
CF card and other devices are using IDE 1 channel at the same time, the ATA66/100 cable will make the device detecting time expand. Thus, it is suggested to use ATA33 cable to avoid the problem. ′ Page: 2-26 PSB-601LF USER S MANUAL... -
Page 39: Pci Slot 3.3V Voltage Selection
2-35. PCI SLOT 3.3V VOLTAGE SELECTION JP9 : PCI Slot 3.3V Voltage Selection. The selections are as follows: JUMPER SETTING JUMPER FUNCTION (pin closed) ILLUSTRATION 3.3V from Mainboard OPEN 3.3V from Backplane *** Manufacturing Default: 3.3V from Backplane. ′ Page: 2-27 PSB-601LF USER S MANUAL... -
Page 40: Lvds Connector
LVDS1 : LVDS Connector. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LVDS_VCC CLKBM CLKBP YBM2 YBP2 YBM1 YBP1 YBP3 YBM3 YBP0 YBM0 CLKAP CLKAM YAP2 YAM2 YAP1 YAM1 YAP0 YAM0 YAP3 YAM3 LVDS_VCC LVDS_VCC ′ Page: 2-28 PSB-601LF USER S MANUAL... -
Page 41: Lvds Panel Voltage Selection
Chapter 2 Hardware Configuration 2-37. LVDS PANEL VOLTAGE SELECTION JP1 : LVDS Panel Voltage Selection. The selections are as follows: JUMPER SETTING JUMPER FUNCTION (pin closed) ILLUSTRATION LVDS_VCC3 LVDS_VCC5 *** Manufactory default --- LVDS_VCC3. ′ Page: 2-29 PSB-601LF USER S MANUAL... - Page 42 CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, Sound driver, and flash BIOS update. It also describes on how to configuration the watchdog timer. Section includes: Introduction. VGA Driver Utility Flash BIOS Update LAN Driver Utility Sound Driver Utility Intel®...
-
Page 43: Introduction
Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our PSB-601LF package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc,... -
Page 44: Vga Driver Utility
Chapter 3 Software Configuration 3-2. VGA DRIVER UTILITY The VGA interface embedded with our PSB-601LF can support a wide range of display. You can display CRT, PCI-E (SDVO) simultaneously with the same mode. 3-2-1. Installation of VGA Driver: To install the VGA Driver, simply follow the following steps: 1. -
Page 45: Flash Bios Update
Chapter 3 Software Configuration 3-3. FLASH BIOS UPDATE 3-3-1. System BIOS Update: Users of PSB-601LF can use the program “Awdflash.exe” contained in CD ROM for BIOS update. This is found in D:\flash\Awdflash.exe. 3-3-2. To update BIOS : (1) Install “Awdflash.exe” from the CD ROM Disk into your system. - Page 46 BIOS. After you have completed all the programming, you will see the line: “Reset System or power off to accomplish update process!”. Please turn off or reset the system. Then the Flash BIOS is fully implemented. ′ Page:3-5 PSB-601LF USER S MANUAL...
-
Page 47: Lan Driver Utility
Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction PSB-601LF is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: For more details on Installation procedure, please refer to Readme.txt file found on LAN DRIVER UTILITY. -
Page 48: Sound Driver Utility
“D:\Sound\pathname” refers to the full path to the source files. 3. Click on the OK button or press the ENTER key. 4. Click on the “Next” and OK prompts as they appear. 5. Reboot the system to complete the driver installation. ′ Page:3-7 PSB-601LF USER S MANUAL... -
Page 49: Intel Chipset Software Installation Utility
3. Click Setup.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-8 PSB-601LF USER S MANUAL... -
Page 50: Usb2.0 Software Installation Utility
5. Double Click “USB Root Hub”. 6. Select “Driver”. 7. Click “Install” to install the driver. 8. Follow the instructions on the screen to complete the installation. 9. Click “Finish” after the driver installation is complete. ′ Page:3-9 PSB-601LF USER S MANUAL... -
Page 51: Watchdog Timer Configuration
I/O port 441H, the system will run the command to stop the Watchdog function. In PSB-601LF watchdog function, You must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog. - Page 52 CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency Control Load Fail-Safe Defaults Load Optimized Defaults...
-
Page 53: Introduction
4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The PSB-601LF Intel Core 2 Duo Full Size CPU Card is equipped with the BIOS for system chipset from Phoenix -Award Software Inc. -
Page 54: Entering Setup
You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 PSB-601LF USER S MANUAL... -
Page 55: The Standard Cmos Features
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 PSB-601LF USER S MANUAL... - Page 56 Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more than 1024 cylinders. LBA (Logical Block Addressing): During drive accesses, the ′ Page: 4-5 PSB-601LF USER S MANUAL...
- Page 57 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 PSB-601LF USER S MANUAL...
-
Page 58: Chapter 4 Award Bios Setup
1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 PSB-601LF USER S MANUAL... -
Page 59: The Advanced Bios Features
BIOS Features Setup Screen The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s boot-up sequence and security. A brief introduction of each setting is given below. ′ Page: 4-8 PSB-601LF USER S MANUAL... - Page 60 3.If you are using Windows operating system. Please disable this feature. 2. EXECUTE DISABLE BIT To select enable or disable the No-Execution Page Protection Technology. 3. VITRUALIZATION TECHNOLOGY To select enable or disable Virtualization Technology. ′ Page: 4-9 PSB-601LF USER S MANUAL...
- Page 61 For example, if you press and hold down the "A" key, the letter "a" will repeatedly appear on your screen on your screen until you release the key. When enabled, the typematic rate and typematic delay can be selected. ′ Page: 4-10 PSB-601LF USER S MANUAL...
- Page 62 This option is only valid for multiprocessor motherboards as it specifies the version of the Multiprocessor Specification (MPS) that the motherboard will use. The MPS is a specification by which PC manufacturers design and build Intel architecture systems with two or more processors. ′ Page: 4-11 PSB-601LF USER S MANUAL...
-
Page 63: Advanced Chipset Features
The value in this field depends on performance parameters of the installed memory chips (DRAM). Do not change the value from the factory setting unless you install new memory that has a different performance rating than the original DRAMs. ′ Page: 4-12 PSB-601LF USER S MANUAL... - Page 64 To select the PCI-Express Graphics or onchip VGA Graphics. ON-CHIP FRAME BUFFER SIZE: The On-Chip Frame Buffer Size can be set as 32MB. This memory is shared with the system memory. DVMT MODE: Intel Dynamic Video Memory Technology Mode. ′ Page: 4-13 PSB-601LF USER S MANUAL...
-
Page 65: Integrated Peripherals
If bios setup menu item supports USB device boot, it will cause Win9x detects the same storages twice when the system is rebooted, and USB HDD will fail. Note: this cause just happen under Win9x, the phenomenon is a limitation. ′ Page: 4-14 PSB-601LF USER S MANUAL... - Page 66 The four IDE PIO fields allow you to set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device. ′ Page: 4-15 PSB-601LF USER S MANUAL...
- Page 67 Disabled. 2. ONBOARD SERIAL PORT 1/2 Select an address and corresponding interrupt for the first and second serial ports. 3. UART MODE SELECT This item allows you to select UART mode. ′ Page: 4-16 PSB-601LF USER S MANUAL...
- Page 68 This should be enabled if your system has a USB installed on the system board and you want to use it. Even when so equipped, if you add a higher performance controller, you will need to disable this feature. ′ Page: 4-17 PSB-601LF USER S MANUAL...
- Page 69 USB Mouse. 5. USB STORAGE FUNCTION Enable the USB Storage Function 6. USB FLASH DISK 2.00 Select USB Flash Disk Type. ONBOARD LAN 1/2 CONTROLLER: Enable the LAN controller. ′ Page: 4-18 PSB-601LF USER S MANUAL...
-
Page 70: Power Management Setup
ACPI FUNCTION: Users are allowed to enable or disable the Advanced Configuration and Power Management (ACPI). ′ Page: 4-19 PSB-601LF USER S MANUAL... - Page 71 RESUME BY ALARM: When enabled, you can set the date and time at which the RTC alarm awakens the system from Suspend mode. ′ Page: 4-20 PSB-601LF USER S MANUAL...
-
Page 72: Pnp/Pci Configuration
This section covers technical items, which is strongly recommended for experienced users only. INIT DISPLAY FIRST: This item allows you to decide to active whether PCI Slot or on-chip VGA first. ′ Page: 4-21 PSB-601LF USER S MANUAL... - Page 73 You may assign each system interrupt a type, depending on the type of device using the interrupt. PCI/VGA PALETTE SNOOP: Leave this field at disabled. MAXIMUM PAYLOAD SIZE: To select the maximum payload size of PCI Express devices. ′ Page: 4-22 PSB-601LF USER S MANUAL...
-
Page 74: Pc Health Status
1.8V/3.3V/12V / 5V : Show you the voltage of 1.8V/3.3V/12V/5V. SYSTEM/CPU TEMPERATURE: This item shows you the current System/CPU temperature. CPU/SYSTEM/POWER FAN: This item shows you the current CPU/ SYSTEM /Power FAN speed. ′ Page: 4-23 PSB-601LF USER S MANUAL... -
Page 75: Frequency Control
Frequency / Voltage Control Setup Screen AUTO DETECT DIMM/PCI CLK: This item allows you to enable or disable auto detect DIMM/PCI Clock. SPREAD SPECTRUM: This item allows you to enable or disable the spread spectrum modulate. ′ Page: 4-24 PSB-601LF USER S MANUAL... -
Page 76: Load Fail-Safe Defaults
When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-25 PSB-601LF USER S MANUAL... -
Page 77: Password Setting
PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-26 PSB-601LF USER S MANUAL... -
Page 78: Save & Exit Setup
You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-27 PSB-601LF USER S MANUAL... -
Page 79: Exit Without Saving
►Integrated Peripherals word Quit Without Saving (Y/N)? N ►Power Management etup ►PnP/PCI Configura Saving ►PC Health Status Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Datas ′ Page: 4-28 PSB-601LF USER S MANUAL... -
Page 80: Appendix A Expansion Bus
APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: ISA BUS Pin Assignment PCI BUS Pin Assignment Compact Flash Card Pin Assignment Page: A-1... - Page 81 SA16 DRQ7 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 SA05 SA04 BALE SA03 SA02 SA01 SA00 ′ Page: A-2 PSB-601LF USER S MANUAL...
-
Page 82: Pci Bus Pin Assignment
AD30 AD08 C/BE0# AD29 +3.3V AD07 +3.3V AD28 +3.3V AD06 AD27 AD26 AD05 AD04 AD25 AD03 +3.3V AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +3.3V +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 ′ Page: A-3 PSB-601LF USER S MANUAL... -
Page 83: Compact Flash Card Pin Assignment
Appendix A Expansion Bus COMPACT FLASH CARD PIN ASSIGNMENT You will find a Compact Flash connector in our PSB-601LF. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT -CD1 D111 D121 D131 D141 D151 -CS0 -CS11 A102 -VS1 -ATASEL -IORD... - Page 84 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...
-
Page 85: Appendix B Technical Summary Block Diagram
Appendix B Technical Summary BLOCK DIAGRAM ′ Page: B-2 PSB-601LF USER S MANUAL... -
Page 86: Interrupt Map
Appendix B Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 ′ Page: B-3 PSB-601LF USER S MANUAL... -
Page 87: Rtc & Cmos Ram Map
Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 PSB-601LF USER S MANUAL... -
Page 88: Timer & Dma Channels Map
TIMER & DMA CHANNELS MAP Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available Floppy Available Cascade Available Available Available ′ Page: B-5 PSB-601LF USER S MANUAL... -
Page 89: I/O & Memory Map
Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: B-6 PSB-601LF USER S MANUAL...
