- Page 1 USER’S MANUAL ISA-382LF VIA Mark Half-size Embedded Card With VGA/LAN/SOUND ISA-382LF M1...
- Page 2 Copyright Notice ISA-382LF Half-size CPU Board With VGA / Sound / LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end-users in installing and setting up the system. The information contained in this document is subject to change without any prior notice.
- Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Table Of Contents
Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specifications ........... Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ........... How to Set the Jumpers ..........COM Port Connector ............ RS232/422/485 (COM2) Selection ....... - Page 5 Contents 2-33 SSD Memory Mapping Selection ……………………. 2-23 2-34 IRQ12 Release Selection ……………………………... 2-23 2-35 LVDS LCD Connector ……………………………….. 2-24 2-36 LVDS Panel Power Selection ………………………... 2-25 CHAPTER 3 SOFTWARE UTILITIES Introduction ..............VGA Driver Utility ............Flash BIOS Update ............LAN Driver Utility …...........
-
Page 6: Chapter 1 Introduction
CHAPTER INTRODUCTION This chapter gives you the information for ISA-382LF. It also outlines the System specifications. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for a Quick Start. Page:1-1... -
Page 7: About This Manual
Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our ISA-382LF, Half Size CPU Board enhanced with VGA/Sound/LAN, is fully PC / AT/ATX compatible. The ISA- 382LF provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system. -
Page 8: System Specifications
PS/2 keyboard with mini DIN connector or one external 5-pin boxheader connector with mini DIN cable Supports Y-Cable. MOUSE CONNECTOR : PS/2 mouse connector with min DIN cable Selectable with keyboard DIN connector BUS SUPPORT : PC/104 Bus ISA Bus ′ Page: 1-3 ISA-382LF USER S MANUAL... - Page 9 Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte FIFOs; COM1 for RS-232; COM2 for RS-232/422/485 COM1 with 9-pin D-SUB connector on board COM2 with two 5-pin boxheader connector on board Infrared Communications port option on the COM2. ′ Page: 1-4 ISA-382LF USER S MANUAL...
- Page 10 Monitor CPU Voltage, CPU temperature, and Cooling Fan. LED INDICATOR : HDD LED: one 2-pin headpin on board power LED: one 2-pin headpin on board DMA CONTROLLER : 82C37 x 2 DMA CHANNELS : INTERRUPT CONTROLLERS : 82C59 x 2 ′ Page: 1-5 ISA-382LF USER S MANUAL...
-
Page 11: Safety Precautions
3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-6 ISA-382LF USER S MANUAL... -
Page 12: Chapter 2 Hardware Configuration
CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. This section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector‘s Pin Assignments Page 2-1... -
Page 13: Jumper & Connector Quick Reference Table
..…………………………. Sound Connector …….………………………….……... CD Audio-in Connector ……………………………….. CD_IN1 Solid-State Disk Socket ……………………………….. SSD Memory Mapping Selection ……………………… IRQ12 Release Selection ………………………………. LVDS LCD Connector ………………………………… LVDS1 LVDS/ LCD2 Panel Power Selection ………………… ′ Page: 2-2 ISA-382LF USER S MANUAL... -
Page 14: Component Locations
Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS ISA-382LF Connector, Jumper and Component locations ′ Page: 2-3 ISA-382LF USER S MANUAL... -
Page 15: How To Set The Jumpers
PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagram looks like and what they represent. ′ Page: 2-4 ISA-382LF USER S MANUAL... - Page 16 Chapter 2 Hardware Configuration JUMPER DIAGRAMS JUMPER SETTINGS ′ Page: 2-5 ISA-382LF USER S MANUAL...
-
Page 17: Com Port Connector
COM1 : COM1 Connector The COM1 Connector assignments are as follows : ASSIGNMENT COM1 COM2 : COM2 Connector The COM2 Connector assignments are as follows : ASSIGNMENT RS-232 RS-422 RS-485 RTS- RTS+ CTS+ CTS- ′ Page: 2-6 ISA-382LF USER S MANUAL... -
Page 18: Rs232/422/485 (Com2) Selection
JUMPER SETTING JUMPER FUNCTION (pin closed) ILLUSTRATION RS-232 Open 1-2, 5-6, 7-8, 9-10 11-12, 13-14, 15-16 17-18, 19-20 RS-422 1-3, 4-6, 7-8, 9-10 11-12, 13-14, 15-16 17-18, 19-20 RS-485 *** Manufactory default --- RS-232. ′ Page: 2-7 ISA-382LF USER S MANUAL... -
Page 19: Keyboard/Mouse Connector
If User select to use Y-Cable, please set the jumper same as AT Keyboard. The selections are as follows : DEVICE JUMPER SETTING JUMPER TYPE (pin closed) ILLUSTRATION KEYBOARD/Y-Cable JP10 PS/2 MOUSE JP10 *** Manufactory default -- AT Keyboard ′ Page: 2-8 ISA-382LF USER S MANUAL... -
Page 20: Inverter Connector
The pin assignment is as follows: ASSIGNMENT +12V +12V ENABKL (Inverter backlight ON/OFF control signal) 2-10. POWER LED CONNECTOR JP4 (1-3) : Power LED Connector The pin assignment is as follows: ASSIGNMENT PW_LED ′ Page: 2-9 ISA-382LF USER S MANUAL... -
Page 21: Reset Connector
JP4 (2-4) : Hard Disk Drive LED Connector The pin assignments are as follows : ASSIGNMENT HDD Active Signal 2-13. POWER BUTTON JP4 (5-6) : Power Button for ATX power. The pin assignments are as follows: ASSIGNMENT GROUND PW_BN ′ Page: 2-10 ISA-382LF USER S MANUAL... -
Page 22: External Buzzer Connector
2-15. SLPBTN CONNECTOR JP4 (11-12) : SLPBTN Connector The pin assignments are as follows: ASSIGNMENT -EXTSMI 2-16. FAN CONNECTOR FAN1 : FAN Connector The pin assignments are as follows: FAN1 ASSIGNMENT +12V FAN speed monitor ′ Page: 2-11 ISA-382LF USER S MANUAL... -
Page 23: Irda Connector
IR1 : IrDA (SIR) Connector The pin assignments are as follows: PIN ASSIGNMENT IRRX IRTX 2-18. VGA CONNECTOR VGA1 : VGA Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE I2CCK HSYNC VSYNC I2CDA ′ Page: 2-12 ISA-382LF USER S MANUAL... -
Page 24: Lcd Connector
Chapter 2 Hardware Configuration 2-19. LCD CONNECTOR LCD1 : LCD Connector The pin assignments are as follows : ASSIGNMEN ASSIGNMENT LCD_VCC5 LCD_VCC5 FPVS FPDEN FPHS FPCLLK LCD_VCC3 LCD_VCC3 ENABKL ENVDD +12V +12V ′ Page: 2-13 ISA-382LF USER S MANUAL... - Page 25 Chapter 2 Hardware Configuration LCD2 : LCD Connector The pin assignments are as follows : ASSIGNMEN ASSIGNMENT -12V +12V LCD_VCC LCD_VCC ENVDD FPCCLK FPVS FPDEN FDHS ENABKL LCD_VCC LCD_VCC ′ Page: 2-14 ISA-382LF USER S MANUAL...
-
Page 26: Universal Serial Bus Connector
USBDT0+ 5V_SB USBDT1− USBDT1+ 2-21. CLEAR CMOS SELECTION JP7 : Clear CMOS Selection The selections are as follows: JUMPER JUMPER SETTING FUNCTION ILLUSTRATION (pin closed) Normal Clear CMOS *** Manufacturing Default – Normal. ′ Page: 2-15 ISA-382LF USER S MANUAL... -
Page 27: Floppy Disk Drive Connector
34-pin flat cable to attach the FDD on the board, the other side attaches to two FDDs. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT DRVDEN0 DRVDEN1 INDEX MTR0 DRV1 DRV0 MTR1 STEP WDATA WGATE TRK0 WRPRT RDATA DSKCHG ′ Page: 2-16 ISA-382LF USER S MANUAL... -
Page 28: Hard Disk Drive Connector
ASSIGNMENT IDERST PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 DDREQA -DIOWA -DIORA HDRDYA PULL LOW -DDACKA IRQ14 PDA1 PD_80P PDA0 PDA2 -PDCS1 -PDCS3 HDLED1 ′ Page: 2-17 ISA-382LF USER S MANUAL... -
Page 29: Printer Connector
As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AUTFE ERROR INIT SLCTIN BUSY SLCT ′ Page: 2-18 ISA-382LF USER S MANUAL... -
Page 30: Reset/Nmi/Clear Watchdog Selection
Chapter 2 Hardware Configuration 2-25. RESET/NMI/CLEAR WATCHDOG SELECTION JP8 : Reset/NMI/Clear Watchdog Selection The selections are as follows: FUNCTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION RESET CLEAR WATCHDOG ***Manufacturing Default is set as Reset. ′ Page: 2-19 ISA-382LF USER S MANUAL... -
Page 31: Lan Connector
Left side LED: Yellow Color Blinking LAN Message Active No LAN Message Active 2-27. ATX POWER CONNECTOR PW1 : Power Connector The pin assignments are as follows : ASSIGNMENT ASSIGNMENT 5VSB PS-ON +12V -12V ′ Page: 2-20 ISA-382LF USER S MANUAL... -
Page 32: Atx Backplane Connector
As a reminder, when you choose to use the ATX function, please be sure to set the corresponding configuration found in BIOS setup such 1. Inside the “POWER MANAGEMENT” setting, set the ACPI function to enable. ′ Page: 2-21 ISA-382LF USER S MANUAL... -
Page 33: Sound Connector
GND_AUD LINE-R GND_LOUT SPK-R Please refer our Appendix A for more information about installation. 2-31. CD AUDIO-IN CONNECTOR CD_IN1 : CD Audio-in Connector The pin assignments are as follows: ASSIGNMENT CD_IN1 CD_L CD_R ′ Page: 2-22 ISA-382LF USER S MANUAL... -
Page 34: Solid-State Disk Socket
Chapter 2 Hardware Configuration 2-32. SOLID-STATE DISK SOCKET SSD: 32pin Disk-on-chip Socket The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SA12 SA10 SA11 ′ Page: 2-23 ISA-382LF USER S MANUAL... -
Page 35: Ssd Memory Mapping Selection
*** Manufactory default --- D0000h-D1FFFh. 2-34. IRQ12 RELEASE SELECTION J1 : IRQ12 Release Selection. The selections are as follows: JUMPER SELECTION JUMPER SETTING ILLUSTRATION IRQ12 Release Closed PS/2 Mouse Open *** Manufactory default --- PS/2 Mouse. ′ Page: 2-24 ISA-382LF USER S MANUAL... -
Page 36: Lvds Lcd Connector
Chapter 2 Hardware Configuration 2-35. LVDS CONNECTOR LVDS1 : LVDS Connector. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LCD_VCC LCD_VCC LCD_VCC ′ Page: 2-25 ISA-382LF USER S MANUAL... -
Page 37: Lvds Panel Power Selection
Chapter 2 Hardware Configuration 2-36. LVDS/ LCD2 PANEL POWER SELECTION JP3 : LCD_VCC Power Selection. The selections are as follows: JUMPER SELECTION JUMPER SETTING ILLUSTRATION LCD_VCC3 LCD_VCC5 *** Manufactory default --- LVDS_VCC3. ′ Page: 2-26 ISA-382LF USER S MANUAL... -
Page 38: Chapter 3 Software Utilities
CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, sound driver, and Flash BIOS update. It also describes how to install the watchdog timer configuration. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility Sound Driver Utility Watchdog Timer Configuration Page: 3-1... -
Page 39: Introduction
Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our ISA-382LF package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc,... -
Page 40: Flash Bios Update
Utility Disk for system BIOS and VGA BIOS update. 3-3-2. To update VGA BIOS for LCD Flat Panel Display: As ISA-382LF user, you have to update the VGA BIOS for your specific LCD flat panel you are going to use. For doing this, you need two files. - Page 41 File Name to Program: C30bxxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-4 ISA-382LF USER S MANUAL...
-
Page 42: Lan Driver Utility
Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction ISA-382LF Embedded Board is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 95/98/2000/XP program 2. Win NT program 3. - Page 43 Last step to select OK and close NETWORK SETUP. Select SKIP if only one adapter is installed on this computer. For more information on installation procedure, please refer to TXT directory found on LAN DRIVER UTILITY. ′ Page:3-6 ISA-382LF USER S MANUAL...
-
Page 44: Sound Driver Utility
(5) Change the “Install Driver” directory to the “VIA Audio Driver directory”. Then press “OK” button. (6) If it correct, you will see a pop window, which shows “VIA PCI Audio Controller”. Press “OK” button to process installing. (7) Restart the computer. ′ Page:3-7 ISA-382LF USER S MANUAL... -
Page 45: Watchdog Timer Configuration
I/O port 441H, the system will run the command to stop the Watchdog function. In ISA-382LF watchdog function, you must write your program so when it writes I/O port address 443 for enable watchdog and write I/O port address 441 for disable watchdog. -
Page 46: Chapter 4 Award Bios Setup
CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults... -
Page 47: Introduction
4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The ISA-382LF half size Embedded Board is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system. -
Page 48: Entering Setup
You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 ISA-382LF USER S MANUAL... -
Page 49: The Standard Cmos Features
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 ISA-382LF USER S MANUAL... - Page 50 Auto: The BIOS automatically determines the optimal mode. Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more than 1024 cylinders. ′ Page: 4-5 ISA-382LF USER S MANUAL...
- Page 51 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 ISA-382LF USER S MANUAL...
- Page 52 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 1024 65535 1023 65535 1023 65535 1024 65535 1023 1024 65535 1023 65535 65535 65335 AUTO Award Hard Disk Type Table ′ Page: 4-7 ISA-382LF USER S MANUAL...
-
Page 53: The Advanced Bios Features
F7:Optimized Defaults BIOS Features Setup Menu The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. ′ Page: 4-8 ISA-382LF USER S MANUAL... - Page 54 SWAP FLOOPY DRIVE: This field is effective only in systems with two floppy drives. Selecting Enabled assigns physical drive B to logical drive A, and physical drive A to logical drive B. ′ Page: 4-9 ISA-382LF USER S MANUAL...
- Page 55 To disable security, select PASSWORD SETTING at Main Menu and then you will be asked to enter password. Do not type anything and just ′ Page: 4-10 ISA-382LF USER S MANUAL...
- Page 56 Video Shadow will increase the video speed. C8000-CBFFF SHADOW ~ DC000-DFFFF SHADOW: These categories determine whether option ROMs will be copied to RAM. An example of such option ROM would be support of on-board SCSI. ′ Page: 4-11 ISA-382LF USER S MANUAL...
-
Page 57: Advanced Chipset Features
The parameter allows you to configure the system based on the specific features of the installed chipset. The chipset manages bus speed and access to system memory resources, such as DRAM and the external cache. ′ Page: 4-12 ISA-382LF USER S MANUAL... - Page 58 This allows you to adjust the graphics aperture size. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation. ′ Page: 4-13 ISA-382LF USER S MANUAL...
- Page 59 When Enabled, writes to the PCI bus are executed with zero wait states. PCI DELAY TRANSACTION: The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1. ′ Page: 4-14 ISA-382LF USER S MANUAL...
- Page 60 IO CHANNEL CHECK NMI: This field enables or disables IO channel check NMI. Before selecting this function, the user should check first that NMI function is enabled as described in chapter 2 (Reset/NMI/Clear Watchdog Selection). ′ Page: 4-15 ISA-382LF USER S MANUAL...
-
Page 61: Integrated Peripherals
The onboard IDE drive interfaces supports IDE pre-fetching for faster drive accesses. If you install a primary and or secondary add-in IDE interface, set this field to Disabled if the interface does not support pre-fetching. ′ Page: 4-16 ISA-382LF USER S MANUAL... - Page 62 UART 2 MODE: This item allows you to select which mode for the Onboard Serial Port 2. IR FUNCTION DUPLEX: This item allows you to select the IR half/full duplex function. ′ Page: 4-17 ISA-382LF USER S MANUAL...
- Page 63 ECP MODE USE DMA: Select a DMA channel for the parallel port for use during ECP mode. PARALLEL PORT EPP TYPE: Select EPP port type 1.7 or 1.9 as required by your parallel peripheral. ′ Page: 4-18 ISA-382LF USER S MANUAL...
-
Page 64: Power Management Setup
This item allows the user to select the type or degree of power saving and is directly related to HDD Power Down, Doze Mode and Suspend Mode. PM CONTROL BY APM: If Advanced Power Management (APM) is installed on your system, selecting Yes gives better power savings. ′ Page: 4-19 ISA-382LF USER S MANUAL... - Page 65 SOFT-OFF BY PWRBTN: Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung”. The choices are Delay 4 Sec and Instant-Off. ′ Page: 4-20 ISA-382LF USER S MANUAL...
- Page 66 When Enabled, you can set the date and the time at which the RTC alarm awakens the system from Suspend mode. PRIMARY INTR: When set to Off, IRQ Activity Monitoring is set to BIOS default. When set to On, user may select the desired setting. ′ Page: 4-21 ISA-382LF USER S MANUAL...
-
Page 67: Pnp/Pci Configuration
This section covers technical items, which is strongly recommended for experienced users only. PNP OS INSTALLED: This item allows you to determine install PnP OS or not. ′ Page: 4-22 ISA-382LF USER S MANUAL... - Page 68 DMA channel. PCI/VGA PALETTE SNOOP: Leave this field at disabled. ASSIGN IRQ FOR USB: Enable or Disable to assign IRQ for USB. ASSIGN IRQ FOR VGA: Enable or Disable to assign IRQ for VGA. ′ Page: 4-23 ISA-382LF USER S MANUAL...
-
Page 69: Pc Health Status
CURRENT CPU TEMPERATURE: This item shows you the current CPU temperature. CURRENT CPUFAN SPEED: This item shows you the current CPUFAN speed. VCORE: This item shows you the current system voltage. ′ Page: 4-24 ISA-382LF USER S MANUAL... -
Page 70: Frequency/Voltage Control
This setup menu allows you to specify your settings for frequency/voltage control. AUTO DETECT DIMM/PCI CLK: This item allows you to enable or disable auto detect DIMM/PCI Clock. SPREAD SPECTRUM: This item allows you to enable or disable the spread spectrum modulate. ′ Page: 4-25 ISA-382LF USER S MANUAL... -
Page 71: Load Fail-Safe Defaults
When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-26 ISA-382LF USER S MANUAL... -
Page 72: Password Setting
PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-27 ISA-382LF USER S MANUAL... -
Page 73: Save & Exit Setup
You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-28 ISA-382LF USER S MANUAL... -
Page 74: Exit Without Saving
►Integrated Peripherals Set Password ►Power Management Setup Quit Without Saving (Y/N)? N ►PnP/PCI Configura Saving ►PC Health Status Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Data ′ Page: 4-29 ISA-382LF USER S MANUAL... -
Page 75: Appendix A Expansion Bus
APPENDIX EXPANSION BUS This appendix indicates you the pin assignments. Section includes: PC-104 Connector Pin Assignment ISA BUS Pin Assignment Page: A-1... - Page 76 -12V LA19 IRQ15 LA18 IRQ14 +12V LA17 DACK0 IOCHRDY MEMR DRQ0 SMEMW MEMW DACK5 SMEMR DRQ5 DACK6 DRQ6 DACK3 DACK7 DRQ3 DRQ7 DACK1 DRQ1 MASTER REFRESH KEY PIN IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2 BALE Page: A-2 ISA-382LF USER‘S MANUAL...
- Page 77 SA16 DRQ7 SD12 -DRQ3 SA15 SD13 -DACK1 SA14 -MASTER SD14 -DRQ1 SA13 SD15 -REFRESH SA12 BCLK SA11 IRQ7 SA10 IRQ6 SA09 IRQ5 SA08 IRQ4 SA07 IRQ3 SA06 -DACK2 SA05 SA04 BALE SA03 SA02 SA01 SA00 Page: A-3 ISA-382LF USER‘S MANUAL...
- Page 78 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...
-
Page 79: Appendix B Technical Summary
Appendix B Technical Summary BLOCK DIAGRAM ′ Page: B-2 ISA-382LF USER S MANUAL... -
Page 80: Interrupt Map
Cascade for IRQ 8-15 Serial port 2 / Modem Serial port 1 Parallel port 2 / Sound Blaster Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 Available ′ Page: B-3 ISA-382LF USER S MANUAL... -
Page 81: Rtc & Cmos Ram Map
Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 ISA-382LF USER S MANUAL... -
Page 82: Timer & Dma Channels Map
System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available / Sound Blaster Floppy Available / ECP Cascade for DMA controller 1 Available Available Available ′ Page: B-5 ISA-382LF USER S MANUAL... -
Page 83: I/O & Memory Map
Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: B-6 ISA-382LF USER S MANUAL...
