PANCAKE AND HOT DOG
AIR COMPRESSORS
MODEL H4517/H4518
INSTRUCTION MANUAL
COPYRIGHT © AUGUST, 2003 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN CHINA
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE
AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION CAN CHANGE AS
PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF
THE MACHINE, THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUS-
TOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT DIFFERENCES. PREVIOUS VER-
SIONS ARE NOT AVAILABLE ONLINE.
Advertisement
Table of Contents
Related Manuals for Grizzly H4517
Summary of Contents for Grizzly H4517
-
Page 1: Air Compressors
INSTRUCTION MANUAL COPYRIGHT © AUGUST, 2003 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN CHINA ONLINE MANUAL DISCLAIMER THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. - Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Safety Instructions For Pneumatic Tools
Keep work area well lighted. Model H4517/H4518 Air Compressors SAFETY Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. - Page 4 USERS TO USE THIS TOOL WHILE UNSUPERVISED. 23. IF YOU ARE UNSURE OF THE INTENDED OPERATION, STOP USING THE TOOL. Seek formal training or research books or maga- zines that specialize in pneumatic tools. Model H4517/H4518 Air Compressors RECOMMENDED Consult DAMAGED PARTS. ALLOW UNTRAINED...
- Page 5 Be sure to use a compressor capable of handling the air demand of connected tools. Model H4517/H4518 Air Compressors DRAIN TANK DAILY OR AT THE END OF EACH USE to avoid tank corrosion and possible tank rupture.
-
Page 6: Introduction And Set Up
Grizzly’s commit- ment to customer satisfaction. The Model H4517 features a 2.5 HP motor, a cast-iron direct-drive pump, a 4 gallon tank capacity that delivers 4.6 CFM @90 PSI and 5.9 CFM @40 PSI, and is oil lubri- cated. - Page 7 Customer Service at (570) 546-9663. The Model H4517/H4518 represents a heavy load at 60 pounds. Seek assistance before moving. Long term exposure to this machine...
-
Page 8: Circuit Requirements
CIRCUIT REQUIREMENTS 110V Operation The Model H4517/H4518 Air Compressor is wired for 110V, single-phase operation only. The maximum amperage draw for the machine is 17 amps, with a fusing level rat- ing of 20 amps. It is best to operate a compressor on a dedicated circuit, i.e. -
Page 9: Preparing For Use
3 months. Know and understand the duty cycle of the compressor before operating. The Model H4517/H4518 Air Compressor should NOT be operated on more than a 50% duty cycle. (This means an air com- pressor that pumps air for over 30 minutes in one hour is considered misuse. - Page 10 Everyday glasses or reading glasses only have impact resistant lenses, they are not safety glasses. Be certain the safety glasses you wear meet the appropriate standards of the American National Standards Institute (ANSI). Model H4517/H4518 Air Compressors...
-
Page 11: Air Control
Understand the duty cycle of the air compressor. Model H4517/H4518 Air Compressors AIR CONTROL There are two ways to release air from the compressor tank other than through your... - Page 12 Connect the compressor to the power supply and start compressor. If the PSI level still needs adjustment, repeat steps 1 through 6. Replace the cover when the proper adjustments have been made. Figure 9. Pressure Regulator Model H4517/H4518 Air Compressors...
-
Page 13: Connecting Tools
Model H4517/H4518 Air Compressors Consideration should also be given to the type of usage. A nailer or staple gun uses air in short bursts and it is easier for the compressor to maintain pressure. -
Page 14: Maintenance
Always drain the air from the tank before performing any maintenance or transporting your air compressor. Damage to the air compressor while under pressure could cause burst- ing or explosion and injury or prop- erty damage could occur. Model H4517/H4518 Air Compressors... - Page 15 Figure 11. Air filter foam element Blow out any dirt that has accumulat- ed between the cylinder cooling fans. Model H4517/H4518 Air Compressors Weekly If the compressor is used on a daily basis, perform the following checks each week.
-
Page 16: Every 300 Hours
Water will condense in the air com- pressor tank. Water left in the tank can cause the tank to weaken and corrode, increasing the risk of tank rupture Model H4517/H4518 Air Compressors Storage... -
Page 17: Troubleshooting
3. Piston loose. 1. Cooling fins dirty. Motor runs hot 2. Air filter clogged. Model H4517/H4518Air Compressors CAUSE 1. Check power line for proper voltage. circuit 2. Inspect all lead connections on motor, switch and cord for loose or open connec- tions. - Page 18 2. Repair or replace pressure switch. 1. Open drain cocks on both tanks and make certain all condensation water is drained out. 2. Remove delivery pipes, clean out and replace. ACTION Model H4517/H4518Air Compressors...
- Page 19 Model H4517 Pancake Air Compressor Model H4517/H4518 Air Compressors...
- Page 20 FLANGE BOLT M5-.8 X 15 CRANK SHAFT WRIST PIN INT RETAINING RING 12MM BREATHER CRANK CASE COVER HEX BOLT M6-1 X 18 SHAFT SEAL OIL SIGHT GLASS CONNECTING ROD PISTON RING SET PISTON RING SET PISTON RING SET FILTER ELEMENT Model H4517/H4518 Air Compressors...
- Page 21 PH4517049 PH4517050 PH4517051 PH4517052 PW01M PH4517054 PW01M PB09M PH4517057 Model H4517/H4518 Air Compressors Model H4517 DESCRIPTION ELBOW 90˚ 3/8 NPT X 3/4-16UNF CRANKCASE CAP SCREW M8-1.25 X 25 LOCK WASHER 8MM HEX BOLT M8-1.25 X 35 FLAT WASHER 8MM HEX NUT M8-1.25...
- Page 22 Model H4518 Hot Dog Air Compressor Model H4517/H4518 Air Compressors...
- Page 23 PH4517017 PR49M PH4517019 PH4517020 PB91M PH4517021 PH4517022 PH4517023 PH4517024 PH4517025 PH4517026 PH4517027 PH4517028 Model H4517/H4518 Air Compressors Model H4518 DESCRIPTION CYLINDER PISTON GASKET VALVE ASSEMBLY CYLINDER HEAD FLANGE BOLT M6-1 X 55 CAPACITOR 250VAC, 120MFD STATOR OVERLOAD PROTECTOR ROTATOR BALL BEARING 6202 CAP SCREW M8-1.25 X 22LH...
- Page 24 UNLOADING SCREW UNLOADING PIPE MOTOR CORD POWER CORD W/PLUG TANK CHECK VALVE ELBOW 90˚ 1/8 X 1/8 NPT HANDLE DRAIN VALVE 14MM FLAT WASHER 8MM RUBBER FOOT FLAT WASHER 8MM HEX BOLT M8-1.25 X 20 EXHAUST PIPE Model H4517/H4518 Air Compressors...
- Page 25 NOTES Model H4517/H4518 Air Compressors...
-
Page 26: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of main- tenance. - Page 27 ___Yes 15. Would you recommend Grizzly to a friend? ___Yes 16. Would you allow us to use your name as a refer- ence for Grizzly customers in your area? Note: We never use names more than three times. ___Yes 17.Comments:________________________________...
- Page 28 Send a Grizzly Catalog to a friend: Name________________________________ Street________________________________ City______________State______Zip_______ FOLD ALONG DOTTED LINE GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
