Page 1: User Manual
Snapshot ™ Hurricane 1300 OK on Dimmer F-1300 Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin .................................. 3 ..................................3 What is included ................................3 Unpacking Instructions ....................................3 AC Power ..................................4 Safety Instructions 2. Introduction ................................... 5 ...................................... 5 Features Product Dimensions ..................................5 ..................................6 Product Overview Fuse Replacement .................................. -
Page 3: Before You Begin
1. B EFORE EGIN What is included 1 x Hurricane™ 1300 1 x FC-T wired timer remote 1 x Warranty Card 1 x User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. -
Page 4: Safety Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Hurricane™ 1300 User Manual 3/26/2009 3:18 PM... -
Page 5: Introduction
2. I NTRODUCTION Features Output: 20,000cfm 3.3L tank capacity Uses 1L every 8min (continuous use at full output) 5 minute heat up Manual fog button Low fluid indicator and auto shut down Wired timer remote included Water-based fogger Product Dimensions Hurricane™... -
Page 6: Product Overview
Product Overview Hanging bracket Safety eyebolt Fluid container Handle Tilt Heater Adjustment Nozzle knob Low Fluid indicator Manual Fluid level controller Power indicator switch Fuse holder Power input (hardwired) Manual Fog Wireless button Controller Hurricane™ 1300 User Manual 3/26/2009 3:18 PM... -
Page 7: Fuse Replacement
Disconnect the power cord before replacing a fuse and always replace with the same type fuse. Fuse Replacement With a flat head screwdriver wedge the fuse holder out of its housing. Remove the damaged The fuse is located fuse from its holder and replace with exact inside this same type fuse. -
Page 8: Operating Instructions
3. O PERATING NSTRUCTIONS Operation Manual Remote Operation (FC-M) (Optional) Plug in the fog machine to power and turn the power switch to the fixture on. Plug in the wired manual remote to the Manual Controller socket on the rear of the fog machine. Press the single button located on the remote to trigger the fog output. -
Page 9: Wireless Controller (Fc-W) (Optional)
Wireless Controller (FC-W) (Optional) This mode will allow you to control the fogger using the optional wireless controller. This consists of the transmitter and the receiver. You may control up to 4 independent fog machines or many more if you run them simultaneously. -
Page 10: Hurricane™ 1300 General Troubleshooting
Possible bad part. Contact Chauvet or a Chauvet Dealer/distributor for further container if full. instruction. If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location listed below. Contact Us Wor l d Wi de... -
Page 11: Appendix
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without a RMA # will be refused. Call CHAUVET and request a RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Blow-Out Diagram
Blow-out Diagram. Description Part Number 1 Master PCB P170-F3MSPCB 2 Heater P120-HT13 3 Pump P200-F3PUMP 4 Fluid container P170-F3FLC 5 Fluid sensor (not shown) P170-F1FLOS 6 Thermal switch 115° Celsius P170-THEF11 7 Bracket Knob P111-F3BKNOB 8 Fuse holder P170-FUSEHOL 9 Manual fog button P111-F3FOGB 10 Fuse 13A 250V (not shown) P170-FUSE013... -
Page 13: Connections Drawing
Connections Drawing In the event that any part(s) may need to be replaced/repaired, you may use the below diagram to assist in this operation. Warning: All repairs should only be performed by Authorized Service Personnel. Hurricane™ 1300 User Manual 3/26/2009 3:18 PM... -
Page 14: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length ..........................16.5 in (419 mm) Width ..........................12.3 in (313 mm) Height ..........................12.1 in (306 mm) Weight ........................... 21 lbs (9.5 kg) POWER AC Power ..................... 120V 60Hz AC or 230V 50Hz Fuse ............................. 13A 250V Power Consumption ..................
