Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated DMX 512 Master/Slave Autoswitching Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual... -
Page 2: Table Of Contents
ECHNICAL PECIFICATIONS CHAUVET®, 2010, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Rev01b Mega Moon™ User Manual... -
Page 3: Before You Begin
1. B EFORE EGIN What is included 1 x Mega Moon™ 1 x Power Cord 1 x Warranty Card 1 x User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have arrived in good condition. -
Page 4: Safety Instructions
Adjustable strobe speed Built-in automated programs via DMX Built-in sound activated programs via master/slave or DMX Additional Features Razor-sharp rotating beams Additional power output: max 37 units @ 120V Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 5: Dmx Channel Summary
Module 2 Module 3 Module 4 Strobe Function Product Overview Hanging bracket Bracket adjustment DMX out knob (1 of 2) DMX in Power out Safety eyebolt Fuse holder Microphone Power in switches Microphone sensitivity Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 6: Setup
To link two or more fixtures together you must use DMX compliant data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable, please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 7: Cable Connectors
If you use a controller with a 5-pin DMX output connector, you will need to use a 5- pin to 3-pin adapter. You may use the CHAUVET Model number DMX5M, or DMX5F. The chart below details the proper cable conversion:... -
Page 8: Master/Slave Fixture Linking
Always use safety cables. Never mount the fixture in places where it may be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Hanging Clamp The clamp is sold separately Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 9: Operating Instructions
Master setting of your choice. Turn the DIP switches to the Slave position on the Slave fixture, and they will react the same as the Master. Mode DIP switches Slave 1, 10 = On Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 10: Dmx Mode
089 114 Program 4 115 130 Program 5 131 156 Program 6 157 182 Program 7 183 208 Program 8 209 250 Auto mode 251 255 Sound mode Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 11: Setting The Starting Address
Remote does not work Make sure connector is firmly attached to device If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support at the location on the next page. Mega Moon™ User Manual... -
Page 12: Contact Us
3-pin XLR female connector on the other end. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). See page 6 for details on this type of cable. Mega Moon™ User Manual 9/16/2010 4:11 PM... -
Page 13: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request an RMA #, prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 14: Technical Specifications
Data pin configuration ................pin 1 shield, pin 2 (-), pin 3 (+) Protocols ........................DMX-512 USITT DMX Channels ............................ 6 ORDERING INFORMATION Mega Moon™ ......................... MEGAMOON WARRANTY INFORMATION Warranty ......................2-year limited warranty Mega Moon™ User Manual 9/16/2010 4:11 PM...
