- Page 1 Wireless Keypad and Mouse Combo USER GUIDE Visit our Website at www.targus.com Features and specifications subject to change without notice. © 2006 Targus Group International, Inc. and Targus, Inc. PAKP003U v.2 / 410-0486-001C...
-
Page 2: System Requirements
KEYPAD AND MOUSE COMBO Introduction Congratulations on your purchase of the Targus wireless keypad and mouse combo. This combo set offers wireless freedom with 27 MHz wireless connection. Both keypad and mouse feature an on/off switch and recharging capability for effective power management. -
Page 3: Installing The Batteries
Targus Wireless Keypad and Mouse Combo Installing the Batteries Optical Mouse Remove the battery cover from the top of the mouse by pressing the battery cover release button and sliding the cover backwards. Battery cover release button Removing the battery cover... - Page 4 Targus Wireless Keypad and Mouse Combo Wireless Keypad 1 Remove the battery cover located on the bottom of the keypad. 2 Insert the supplied batteries , making sure that the positive (+) and negative (-) ends of each battery match the polarity indicators inside the battery housing.
- Page 5 Targus Wireless Keypad and Mouse Combo Operating Notes for Wireless Mice with Recharging Feature via USB Cable 1. Charge the mouse for at least 8 hours before using it. And please make sure only rechargeable batteries (the ones that come with your product) are used.
-
Page 6: Charging The Batteries
Targus Wireless Keypad and Mouse Combo Charging the Batteries Connect the USB charge cable into the mouse and plug the other USB tip into an available USB port on your computer. Notebook Desktop Recharge cable connector Opitcal Mouse Connect the USB charge cable into the keypad and plug the other USB tip into an available USB port on your computer. - Page 7 Targus Wireless Keypad and Mouse Combo Setting the Identification Code After your computer detects the USB receiver you must set the ID code between the receiver and the mouse as well as between the receiver and the keypad BEFORE you can use them.
-
Page 8: Using The Keypad
Targus Wireless Keypad and Mouse Combo Wireless Keypad 1 Press and release the connect button on the receiver again. 2 Press the connection button located on the back of the keypad. When the light emitter diode (LED) on the receiver is lit, the keypad is set up with an ID and the receiver is locked. - Page 9 Targus Wireless Keypad and Mouse Combo Internet / Media Hot Keys Switch between Internet mode and media mode by sliding the button located at the top of the number pad. Internet Mode Media Mode Function Function Back Previous Track Next Track...
- Page 10 Targus Wireless Keypad and Mouse Combo Mouse and keypad Power Management • To power the mouse on and off, slide the on/off switch on the bottom of the mouse to the desired position. • To power the keypad on and off, slide the on/off switch on the side of the keypad to the desired position.
-
Page 11: Things To Remember
Targus Wireless Keypad and Mouse Combo Comfortable Usage Research suggests that physical discomfort and injury to nerves, tendons, and muscles may be related to repetitive motion, an improperly set up work area, incorrect body posture, and poor work habits. To reduce the risk of injury, follow these precautions: •... -
Page 12: Troubleshooting
Targus Wireless Keypad and Mouse Combo Troubleshooting What do I do if the mouse does not work? • Make sure that the polarity of the batteries is correct. The positive (+) and negative (- ) ends of each battery must match the positive (+) and negative (-) connections in the battery housing. - Page 13 Targus Wireless Keypad and Mouse Combo What do I do if the response time of the mouse is slow or the mouse intermittently stops working? Try one or more of the following: • Increase the distance between the mouse’s receiver and the rest of your computer equipment by using the extension cable provided.
-
Page 14: Technical Support
This warranty does not cover accidental damage, wear and tear, or consequential or incidental loss. Under no conditions is Targus liable for loss of, or damage to a devices nor loss of, or damage to, programs, records, or data; nor any consequential or incidental damages, even if Targus has been informed of their possibility. -
Page 15: Declaration Of Conformity
Changes or modifications not authorized by the party responsible for compliance could void the user’s authority to operate this product. Declaration of Conformity Hereby, Targus, declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
