MULTI-GPU MOSAIC CONFIGURATION
MOSAIC OVERVIEW
Mosaic is a technology that combines multiple displays or projectors into a single virtual
display. It's cable of creating a projector overlap region or subtracting the area behind
screen bezels to create a single unified display surface. With Quadro Sync and
supported Quadro GPUs up to 16 displays can appear as one to the operating systems
and any application that runs on them. The image in Figure 3 is an example of a 3 × 3
display wall connected to 3 Quadro K5000 graphics boards.
A
D
G
Figure 3.
3 x 3 Mosaic with Quadro Sync
When working with multi-GPU Mosaic, Quadro Sync automatically keeps all the
displays that are part of the Mosaic synchronized.
For more information on Mosaic refer to the NVIDIA Web site at www.nvidia.com/svs.
Quadro Sync
B
C
E
F
H
I
I
F
C
H
E
B
G
D
A
DU-06574-001_v01 | 6
