564 SS GreenSmart ™ Fireplace
WARNING:
If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of
life.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This appliance may be installed as an OEM installation in a manufactured (mobile) home and must be
installed in accordance with the manufacturer's instructions and the manufactured home construction and
safety standard, Title 24 CFR, Part 3280.
This appliance is only for use with the type(s) of gas indicated on the rating plate. A conversion kit is
supplied with the appliance.
Owner's Manual
© Copyright 2009, T.I.
• Operation
• Maintenance
100‐01223_000
$10.00
Listed by
IAPMO-R&T OCEANA
Dragon Wholesaling Pty. Ltd.
Unit 2, 16 Lexington Drive
Bella Vista NSW 2153
4090709
AS 4553-2008
GMK10022
Australia

Advertisement

Table of Contents
loading

Summary of Contents for Travis Industries 564 SS GreenSmart

  • Page 1 564 SS GreenSmart ™ Fireplace Listed by AS 4553-2008 GMK10022 IAPMO-R&T OCEANA • Operation • Maintenance WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2: Introduction

    Introduction Introduction We welcome you as a new owner of a 564 SS GS gas fireplace. This manual details operation and maintenance of this fireplace. Please familiarize yourself with the Owner's Manual before operating your heater and save the manual for future reference.
  • Page 3: Table Of Contents

    Heating Specifications Natural Gas Propane Approximate Heating Capacity (in square meter)* Maximum Megajoules (MJ) Input Per Hour 21.6 21.6 Minimum Megajoules (MJ) Input on Low Heating capacity will vary with floor plan, insulation, and outside temperature. 4090709 © Travis Industries 100-01223_000...
  • Page 4: Safety Precautions

    Immediately call a qualified vicinity of this heater. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4090324 © Travis Industries 100-01223_000...
  • Page 5 If the fiber logs become damaged, replace with Travis Industries log set. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...
  • Page 6: Operation

    This switch turns the rear burner on and off. AA Battery Holder This holder contains 4 AA batteries that allow the fireplace to operate during power outages. This switch turns the fireplace burners on and off. Main Burner 4090324 © Travis Industries 100-01223_000...
  • Page 7: Starting The Fireplace For The First Time

    The rear portion of the burner may be shut off to lower the heat output and flame size from the burner (this is called the comfort control). Use the comfort control switch to adjust this as desired. COMFORT CONTROL 4090709 © Travis Industries 100-01223_000...
  • Page 8: Adjusting The Flame Height

    Accent Light This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. HIGH ACCENT LIGHT HIGH 4090324 © Travis Industries 100-01223_000...
  • Page 9: Adjusting The Blower Speed

    Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. CONTINUOUS PILOT GREEN SMART PILOT 4090709 © Travis Industries 100-01223_000...
  • Page 10: Normal Operating Sounds

    This appliance has several areas that reach high temperatures. Dust or other particles on these areas may burn and create an odor. This is normal during start-up. You may notice the smell is more acute if the appliance was left idle for a long period. 4090324 © Travis Industries 100-01223_000...
  • Page 11: Maintenance

    Panel Lights Lift up and swing the lower grill down to acces the area below the Swing the concealment cover firebox. up and slide it back to expose AA Battery the controls. Holder AA Battery Tray 4090709 © Travis Industries 100-01223_000...
  • Page 12: Accent Light Replacement

    If the pilot or main burners do not burn correctly, contact your dealer for service. Monitor blower operation. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or deterioration is found near the vent termination. 4090324 © Travis Industries 100-01223_000...
  • Page 13: Grill Installation And Removal

    (this prevents the it allows the grill to swing bushing. Once in place the grill is grill from accidentally falling off). forward. held in place by gravity. 4090709 © Travis Industries 100-01223_000...
  • Page 14: Face Installation And Removal

    Some fireplaces have a face that fits over the glass frame. The face can be removed following the directions below. Phillips Screwdriver Four screws hold the face in place. The screws are accessed through the grills on the face. 4090324 © Travis Industries 100-01223_000...
  • Page 15: Glass Frame Removal And Installation

    Lift the glass frame slightly and attach the lower latches. NOTE: Make sure the glass frame is all the way in place - it should be flush with the front of the fireplace when installed. 4090709 © Travis Industries 100-01223_000...
  • Page 16 Top of Firebox Glass Frame Anchor Note how the washer on the latch fits behind the flange on the glass frame anchor. Once fully inserted, turn the latch until it is upright. 4090324 © Travis Industries 100-01223_000...
  • Page 17: Log Set Installation

    Maintenance Log Set Installation Log Set Overview When installed, the logs should appear as shown below. Rear Log Right Twig Left Log Left Twig Right Log 4090709 © Travis Industries 100-01223_000...
  • Page 18 The rear log has a flat notch on both sides that center it on the grate. Place the rear log on the grate and slide it all the way back until the log contacts the end- brackets on the grate. 4090324 © Travis Industries 100-01223_000...
  • Page 19 Maintenance Right Log Installation The left log has a groove that fits over the grate. Note how the left side of the log rests on the burner but does not cover any burner holes. 4090709 © Travis Industries 100-01223_000...
  • Page 20 Maintenance Left Log Installation The left log has a groove that fits over the grate. Note how the right side of the log rests on the burner but does not cover any burner holes. 4090324 © Travis Industries 100-01223_000...
  • Page 21 Maintenance Left Twig Installation This hole fits over the pin on the rear log. The left twig should be positioned so the front edge contacts the grate as shown above. 4090709 © Travis Industries 100-01223_000...
  • Page 22 Maintenance Right Twig Installation The right twig has two holes for the pins on the rear and right log. When in place the right twig will appear as shown above. 4090324 © Travis Industries 100-01223_000...
  • Page 23 A bag of embers is provided to further enhance the firebox. Place the embers on the firebox floor and on the burner. Do not place embers over any of the burner holes or air channels. 4090709 © Travis Industries 100-01223_000...
  • Page 24: Glass Cleaning

    With the outer glass Inner glass frame frame and screen removed, the outer surface of the glass The optional screen is may be cleaned. sandwiched between the inner and outer glass frame. Outer glass frame 4090324 © Travis Industries 100-01223_000...
  • Page 25: Troubleshooting Table

    See "Adjusting the Flame Height" Short (Under 6") The logs or coals are placed incorrectly See "Log Set Installation" Thin Layer of Soot Improper air shutter adjustment Adjust Air Shutter - contact your dealer Covers the Glass 4090709 © Travis Industries 100-01223_000...
  • Page 26: Wiring Diagram

    Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person.
  • Page 27: Warranty Warranty

    The accessories listed below are available at your Travis dealer. To locate a dealer, visit: www.travisproducts.com Firebacks There are several styles of decorative firebacks that fit inside the firebox and enhance the area behind the flames. 4090709 © Travis Industries 100-01223_000...
  • Page 28: Index

    Safety Precautions .............. 4 Starting the Fireplace for the First Time ......7 Troubleshooting Table ............25 Turning the Fireplace On and Off ........7 Warranty ................27 Wiring Diagram ..............26 Yearly Service Procedure ........... 12 4090324 © Travis Industries 100-01223_000...
