Model
1
E5-2620
E5-2620 v2
1
E5-2609
E5-2609 v2
E5-2603
E5-2603 v2
1
Model available for the life of the system.
For information on processor installation and configuration, see the
Manual
on Dell.com/Support/Manuals.

GPU support

The T620 supports GPU technology, providing accelerated performance for a variety of applications
including virtual desktop infrastructure (VDI) medical imaging and graphical rendering
implementations.
The T620 supports up to four 300W, full-length, single- or double-wide GPU cards. Each GPU card
can support up to 6GB of dedicated GDDR5 memory and is actively cooled. Each GPU card has one
or two power connectors to meet the high demand for power delivery. The power connectors are
located on the back of the card. See Table 7 for a list of supported GPU cards.
GPU card Model
C2075
K4000
®
NVIDIA
Q6000
K20A
ATI™ FirePro™ V7800
AMD FirePro W7000
GPU configuration options
GPU cards are installed in the PCIe x16 2.0 interfaces, which are slots 2, 4, 5 and 7; slots 5 and 7 only
work with two processors.
Note: You must select the GPU enablement kit at point of sale to install GPU or keep the system's
GPGPU capability. GPU enablement kit is not upgradable after point of sales.
With one processor installed, two GPU cards are supported with the following restrictions:

Slots 1, 2, 3 and 4 are available, therefore only two GPUs can be installed in slots 2 and 4

Since double-wide GPU cards occupy two slots, only two can be installed and slots 1 and 3 are
not available

RAID cards cannot be installed with two double-wide GPU cards
20
PowerEdge T620 Technical Guide
Speed Cache QPI
2.0GHz 15M 7.2GT/s
2.1GHz 15M 7.2GT/s
2.4GHz 10M 6.4GT/s
2.5GHz 10M 6.4GT/s
1.8GHz 10M 6.4GT/s
1.8GHz 10M 6.4GT/s
Table 7. GPU cards supported
Length Height
247.65mm 111mm
241.3mm 111mm
247.65mm 111mm
266.7mm 111mm
242mm 111mm
243.3mm 111mm
Cores Turbo
6 Yes
6 Yes
4 No
4 No
4 No
4 No
Dell PowerEdge T620 Owner's
Width Heatsink
Double Active
Single Active
Double Active
Double Active
Single Active
Single Active
TDP
95W
80W
80W
80W
80W
80W
Power
consumption
215W
80W
204W
225W
150W
127.7W
