Baby Lock Ellure Plus (BLR2) Quick Manual

Ellure Plus & Ellure Embroidery Features
Embroidery
Features
Ellure Plus (BLR2) Ellure (BLR)
Built-in designs 106 including one 106 including one script
script and 40 exclusives and 40 exclusives
Built-in 6 6
embroidery
alphabet styles
Frame patterns 120 120
Embroidery field 5" x 7" 5" x 7"
Rotation 1, 10, and 90 degree 1, 10, and 90 degree
Sizing 20% up, 10% down 20% up, 10% down
Data input USB (type B), Cards Cards
Embroidery Yes Yes
pattern memory
Embroidery speed 650 SPM 650 SPM
Format PES, PEC PES, PEC
Number of hoops 2 1
included
Built-in needle Yes Yes
threader
Mirror image Yes Yes
Low bobbin Yes Yes
indicator
Ellure Plus & Ellure Sewing Features
Sewing Features Ellure Plus (BLR2)
Total Built-in stitches 205
Utility 71
Decorative 51
Satin 18 satin, 11 decorative satin
Cross 15
Combinable Utility stitches 39
Built-in alphabet styles 3
Buttonholes; type 10; 1-step
Needle positions 15
Needle threader Built-in
Auto needle up/down Yes-programmable
Side feeding Yes
Bobbin loading Quick-Set, top-loading
Bobbin winding Quick-Set, bobbin winder
Knee lift Yes
Extension table Optional
Thread cutter Auto
Maximum stitch length in mm 5
Maximum stitch width in mm 7
Tension Automatic
Retractable feed dogs Yes
Variable speed control Yes
Free arm Yes
Number of feet included 11
Accessory storage Built-in
Warranty • 25-year limited manufacturer's warranty
• 10-year parts
• 5-year circuit board
• 5-year electrical
• 1-year labor
Optional Gold Standard Yes - see retailer for details
service and support program
800-422-2952
www.babylock.com
F
OR THE LOVE OF SEWING
LBSP-BLR2
Ellure (BLR)
187
67
51
16
ellure plus & ellure
14
39
0
10; 1-step
15
Built-in
Yes-programmable
No
Quick-Set, top-loading
Quick-Set, bobbin winder
No
Optional
Auto
5
7
Automatic
Yes
Yes
Yes
8
Built-in
No
