- Page 1 PL1500M LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product ............................4 Rear View of the Product ..............................5 Quick Installation ................................6 Basic Operation.................................7 Advanced Operation—OSD Menu..........................9 Supporting Timing Modes ............................12 Technical Information ..............................13 Wall-mount instruction .............................. 14 Care and Maintenance..............................15 Troubleshooting................................15 Planar Support ................................16... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing this TFT LCD Monitor, a high-resolution multi-scan color TFT LCD Monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This TFT LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Safety Precautions
Safety Precautions This TFT LCD Monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the TFT LCD Monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. -
Page 5: First Setup
First Setup Congratulations on your purchase of this high performance TFT LCD monitor. This TFT LCD Monitor comes with the following accessories : LCD Monitor User's Guide Power Cable Base VGA Cable (15 pin) Audio Cable Install the stand base 1. -
Page 6: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤ ⑥ ① OSD Turn On/ Off ② Volume Adjust/ Scroll Down/ Adjust Decrease ③ Preset Mode/ Scroll UP/ Adjust Increase ④ Auto adjust/ Confirm Selection ⑤ Power On/ Off ⑥ LED Indicator... -
Page 7: Rear View Of The Product
Rear View of the Product ① ② ③ ① Power Input ② Audio Input ③ VGA Input (D-Sub 15 pin) -
Page 8: Quick Installation
Quick Installation 1. Connect either VGA Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. Connect the audio cable from audio output of computer to the audio input of the monitor. 3. -
Page 9: Basic Operation
Basic Operation Before using the TFT LCD Monitor: Connect external equipments properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the TFT LCD Monitor on/off: Press POWER button on the front of TFT LCD Monitor. The power LED indicator lights green when the TFT LCD Monitor is on. - Page 10 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The TFT LCD Monitor will show an “Lock Out” message for 5~10 seconds and the message will disappear automatically.
-
Page 11: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your TFT LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 12 6500K: Adds red to screen image for warmer white and richer red. 5400K: Adds green to screen image for a darker color. User Color: Individual adjustments for red (R), green (G), blue (B). 1. Press button 2 to select the desired color. 2.
- Page 13 ▲: move OSD up, ▼: move OSD down. OSD Time Out: To automatically turn off On Screen Display (OSD) after a preset period of time. OSD Background: Allows the user to turn the OSD background On or Off. Memory Recall: To recall factory settings for Video &...
-
Page 14: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 15: Technical Information
Technical Information LCD Panel 15” TFT Power Management On: 16 Watts (typical), 20 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution XGA 1024 x 768 max. Vertical Frequency 75 Hz max. Pixel Dimension 0.297 x 0.297 mm LCD Display Color 16.7M Tilt... -
Page 16: Wall-Mount Instruction
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD monitor before performing the procedure below. -
Page 17: Care And Maintenance
Care and Maintenance Care Avoid exposing your TFT LCD Monitor directly to sunlight or other heat source. Place your TFT LCD Monitor away from the sun to reduce glare. Put your TFT LCD Monitor in a well ventilated area. ... -
Page 18: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touch screen drivers, warranty information and access to Planar's Technical Library for online troubleshooting. - Page 19 2013 P/N:2001171429T...
