Page 1 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 2 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 3 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 4 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 5: Before Driving
Turn the upper knob of each retaining hook (clip) to secure the floor mats in place. : Always align the marks. The shape of the retaining hooks (clips) may differ from that shown in the illustration. AVALON (U)_(OM41440U)
Page 6 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 7: For Safety Drive
Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. (→P. 28) Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. (→P. 51) AVALON (U)_(OM41440U)
Page 8 ● When driving over long distances, take regular breaks before you start to feel tired. Also, if you feel tired or sleepy while driving, do not force yourself to con- tinue driving and take a break immediately. AVALON (U)_(OM41440U)
Page 9: Seat Belts
● Do not twist the seat belt. Fastening and releasing the seat belt To fasten the seat belt, push the plate into the buckle until a click sound is heard. To release the seat belt, press the release button. Release button AVALON (U)_(OM41440U)
Page 10 Pre-collision seat belts (front seats of vehicles with pre-collision system) If the system determines that a collision is unavoidable, the front seat belts will retract before the collision. (→P. 216) AVALON (U)_(OM41440U)
Page 11 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. AVALON (U)_(OM41440U)
Page 12 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 13 The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (→P. 29) AVALON (U)_(OM41440U)
Page 14 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 15: Srs Airbags
Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the rear outer seats SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats AVALON (U)_(OM41440U)
Page 16 Front passenger’s seat belt Front side airbags buckle switch Curtain shield airbags Front passenger occupant classification system (ECU “AIR BAG ON” and “AIR BAG and sensors) OFF” indicator lights Airbag sensor assembly Side impact sensors (front) Rear side airbags AVALON (U)_(OM41440U)
Page 17 The seat should be adjusted as recommended by NHTSA above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls. AVALON (U)_(OM41440U)
Page 18 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 19 These items can become projectiles when the SRS driver, front passenger and knee airbags deploy. ● Do not attach anything to areas such as a door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip. AVALON (U)_(OM41440U)
Page 20 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes are damaged or cracked, have them replaced by your Toyota dealer. AVALON (U)_(OM41440U)
Page 21 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 22 The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ● Hitting a curb, edge of pavement or hard surface ● Falling into or jumping over a deep hole ● Landing hard or falling AVALON (U)_(OM41440U)
Page 23 ● Collision from the front ● Collision from the rear ● Vehicle rollover : Depending on the conditions and type of accident, the curtain shield airbags may deploy (inflate) upon frontal impact. AVALON (U)_(OM41440U)
Page 24 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 25: Front Passenger Occupant Classification System
This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. CTY11AX056 SRS warning light Seat belt reminder light “AIR BAG OFF” indicator light “AIR BAG ON” indicator light AVALON (U)_(OM41440U)
Page 26 Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices in the front passenger side Front passenger knee airbag Deactivated Front passenger’s seat belt pretensioner Activated AVALON (U)_(OM41440U)
Page 27 Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices in the front passenger side Front passenger knee airbag Deactivated Front passenger’s seat belt pretensioner Activated AVALON (U)_(OM41440U)
Page 28 A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 51) : In case the indicator light is not illuminated, consult this manual on how to install the child restraint system properly. (→P. 55) AVALON (U)_(OM41440U)
Page 29 ● Do not let a rear passenger lift the front passenger seat with their feet or press on the seatback with their legs. ● Do not put objects under the front passenger seat. AVALON (U)_(OM41440U)
Page 30 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 31: Safety Information For Children
There is also a danger that children may injure themselves by playing with the windows, the moon roof or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children. AVALON (U)_(OM41440U)
Page 32: Child Restraint Systems
● Choose a child restraint system that suits your vehicle and is appro- priate to the age and size of the child. ● For installation details, follow the instructions provided with the child restraint system. General installation instructions are provided in this manual. (→P. 55) AVALON (U)_(OM41440U)
Page 33 Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. ● If the child is too large for a child restraint system, sit the child on a rear seat and use the vehicle’s seat belt. (→P. 28) AVALON (U)_(OM41440U)
Page 34 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 35 If it is necessary to detach the child restraint system, remove it from the vehicle or store it securely in the trunk. This will prevent it from injuring passengers in the event of a sudden stop, sudden swerve or accident. AVALON (U)_(OM41440U)
Page 36: Installing Child Restraints
CTY11AX014 Seat belts equipped with a child restraint locking mechanism (ALR/ELR belts except driver’s seat belt) (→P. 30) Anchor brackets (for top tether strap) An anchor bracket is provided for each rear seat. AVALON (U)_(OM41440U)
Page 37 If the child restraint has a top tether strap, the top tether strap should latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the presence of a lower connec- tor system. Canada only AVALON (U)_(OM41440U)
Page 38 For owners in Canada: symbol child restraint system indicates the presence of a lower connec- tor system. Canada only AVALON (U)_(OM41440U)
Page 39 Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. AVALON (U)_(OM41440U)
Page 40 Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. AVALON (U)_(OM41440U)
Page 41 If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. (→P. 62) AVALON (U)_(OM41440U)
Page 42 (→P. 28) Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. AVALON (U)_(OM41440U)
Page 43 ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. AVALON (U)_(OM41440U)
Page 44 “AIR BAG OFF” indicator light is illuminated. Failure to do so may result in death or serious injury if the airbags deploy (inflate). AVALON (U)_(OM41440U)
Page 45 Make sure the child restraint system is securely attached, or it may cause death or serious injury to the child or other passengers in the event of a sudden braking or an accident. AVALON (U)_(OM41440U)
Page 46: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 47: Engine Immobilizer System
If the grip portion of the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle AVALON (U)_(OM41440U)
Page 48 NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. AVALON (U)_(OM41440U)
Page 49 Do one of the following to deactivate or stop the alarms: ● Unlock the doors or open the trunk. ● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine. (The alarm will be deactivated or stopped after a few seconds.) AVALON (U)_(OM41440U)
Page 50 NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. AVALON (U)_(OM41440U)
Page 51: Theft Prevention Labels (U.s.a.)
1-2. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law. AVALON (U)_(OM41440U)
Page 52: Warning Lights And Indicators
For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated. ◆ Instrument cluster The units used on the speedometer and some indicators may differ depending on where the vehicle is sold. ◆ Center panel AVALON (U)_(OM41440U)
Page 53 Electric power steering SRS warning light system warning light (→P. 388) (→P. 389) 1, 2 ABS warning light “PCS” warning light (→P. 388) (→P. 389) (U.S.A.) (if equipped) ABS warning light Master warning light (→P. 388) (→P. 390) (Canada) AVALON (U)_(OM41440U)
Page 54 There may be a mal- function in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate a malfunction.
Page 55 “AIR BAG ON/OFF” indi- AIR BAG Light (→P. 140) cator (→P. 44) “TRAC OFF” indicator Cruise control set indica- (→P. 212) tor (→P. 190, 194) Cruise control indicator Radar cruise control (→P. 190) indicator (→P. 194) (if equipped) (if equipped) AVALON (U)_(OM41440U)
Page 56 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 57: Gauges And Meters
Presents the driver with a variety of driving-related data (→P. 80) Speedometer Displays the vehicle speed Fuel gauge Displays the quantity of fuel remaining in the tank Trip meter reset knob/instrument panel light control knob →P. 78, 79 AVALON (U)_(OM41440U)
Page 58 Engine coolant temperature gauge Displays the engine coolant temperature Changing the trip meter display Switches between trip meter “A” and “B” displays. When the trip meter is displayed, pressing and holding the knob will reset the trip meter. AVALON (U)_(OM41440U)
Page 59 The engine may be overheating if the engine coolant temperature gauge is in the red zone (H). In this case, immediately stop the vehicle in a safe place, and check the engine after it has cooled completely. (→P. 422) AVALON (U)_(OM41440U)
Page 60: Multi-Information Display
The display returns to the previous screen by pressing the “DISP” button. (→P. 81) ● Cruise control display equipped) (→P. 190) ● Dynamic radar cruise control display (if equipped) (→P. 194) AVALON (U)_(OM41440U)
Page 61 Displays the average fuel con- sumption since the function was reset. • The function can be reset by pressing and holding the “DISP” button when the average fuel consumption is displayed. • Use the displayed average fuel consumption as a reference. AVALON (U)_(OM41440U)
Page 62 All green suggests the status of the most Eco-friendly driv- ing. All blue suggests the status of the least Eco-friendly driv- ing. ■ Digital speedometer Displays the current vehicle speed. This screen can be disabled in the “Settings” screen. (→P. 83) AVALON (U)_(OM41440U)
Page 63 Changing the settings While the vehicle is stopped, press the “DISP” button until the “Settings” screen appears. Press and hold the “DISP” but- ton while the “Settings” screen is displayed. Press the “DISP” button to select the desired setting item. AVALON (U)_(OM41440U)
Page 64 When the vehicle begins to move while the setting display is displayed ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display. AVALON (U)_(OM41440U)
Page 65 This may lead to death or a serious health hazard. NOTICE ■ During setting up the display To prevent battery discharge, ensure that the engine is running while setting up the display features. AVALON (U)_(OM41440U)
Page 66 2. Instrument cluster AVALON (U)_(OM41440U)
Page 67 Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (→P. 415) AVALON (U)_(OM41440U)
Page 68 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 69 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. AVALON (U)_(OM41440U)
Page 70: Smart Key System
A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) ■ Security feature If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. AVALON (U)_(OM41440U)
Page 71 : The door unlock settings can be changed. (→P. 98) Touch the lock sensor (the inden- tation on the upper part of the door handle) to lock all the doors. Unlocking the trunk Press the button to unlock the trunk. AVALON (U)_(OM41440U)
Page 72 3-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Right side antenna outside the cabin (if equipped) Antennas inside the cabin Antenna outside the trunk Antenna inside the trunk Left side antenna outside the cabin AVALON (U)_(OM41440U)
Page 73 When the door cannot be locked by the lock sensor on the upper part of the door handle If the door will not lock even when the top- side sensor area is touched, try touching both the topside and underside sensor areas at the same time. AVALON (U)_(OM41440U)
Page 74 5 sec- and lock the doors position, then closing onds again. the door with the elec- tronic key still inside the vehicle. AVALON (U)_(OM41440U)
Page 75 Indicates that a door other than the driver’s door has been opened and closed with the Confirm Once 3 times engine switch in any mode location of the other than off and the electronic electronic key. key outside of the detection area. AVALON (U)_(OM41440U)
Page 76 ⎯ Once detected in the vehicle. switch while • The electronic key could not depressing the be detected in the vehicle brake pedal. even after the engine switch was pressed two consecu- tive times. AVALON (U)_(OM41440U)
Page 77 (If a door is not opened within 60 seconds after pressed, the doors will be locked again and the alarm will automatically be set.) In case that the alarm is triggered, immediately stop the alarm. (→P. 68) AVALON (U)_(OM41440U)
Page 78 . Confirm that the electronic key indicator flashes 4 times. While the battery-saving mode is set, the smart key system cannot be used. To cancel the function, press any of the elec- tronic key buttons. AVALON (U)_(OM41440U)
Page 79 • Another vehicle’s electronic key or a wireless key that emits radio waves • Personal computers or personal digital assistants (PDAs) • Digital audio players • Portable game systems ● If window tint with a metallic content or metallic objects are attached to the rear window AVALON (U)_(OM41440U)
Page 80 If the wireless remote control is used to lock the doors when the electronic key is near the vehicle, there is a possibility that the door may not be unlocked by the entry function. (Use the wireless remote control to unlock the doors.) AVALON (U)_(OM41440U)
Page 81 ● Fingernails may scrape against the door during operation of the door han- dle. Be careful not to injure fingernails or damage the surface of the door. AVALON (U)_(OM41440U)
Page 82 (→P. 113) ■ If the smart key system does not operate properly ● Locking and unlocking the doors: Use the mechanical key. (→P. 415) Unlocking the trunk: →P. 114 ● Starting the engine: →P. 416 ● AVALON (U)_(OM41440U)
Page 83 If the smart key system has been deactivated in a customized setting Locking and unlocking the doors: →P. 106, 415 ● Unlocking the trunk: →P. 106, 114 ● Starting the engine and changing engine switch modes: →P. 416 ● Stopping the engine: →P. 156 ● AVALON (U)_(OM41440U)
Page 84 (→P. 93) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 85: Wireless Remote Control
Locks all the doors Unlocks all the doors Pressing the button unlocks the driver’s door. Pressing the button again within 5 seconds unlocks the other doors. Unlocks the trunk (press and hold) Sounds the alarm (press and hold) (→P. 107) AVALON (U)_(OM41440U)
Page 86 To stop the alarm, press any button on the electronic key. ■ Security feature →P. 91 ■ Alarm Using the wireless remote control to lock the doors will set the alarm system. (→P. 68) ■ Conditions affecting operation →P. 100 AVALON (U)_(OM41440U)
Page 87 →P. 350 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization Settings (e.g. wireless remote control system) can be changed. (Customizable features: →P. 453) ■...
Page 88 Locks all the doors Unlocks all the doors ◆ Inside lock buttons Unlocks the door Locks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position. AVALON (U)_(OM41440U)
Page 89 The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors. AVALON (U)_(OM41440U)
Page 90 Be especially careful for the front doors, as the doors may be opened even if the inside lock buttons are in locked position. ● Set the rear door child-protector locks when children are seated in the rear seats. AVALON (U)_(OM41440U)
Page 91 Entry function →P. 91 ■ Wireless remote control →P. 106 When closing the trunk Using the trunk grip, lower the trunk without applying force to the side and push the trunk down from the outside to close it. AVALON (U)_(OM41440U)
Page 92 Internal trunk release lever The trunk lid can be opened by pulling the glow-in-the-dark lever located on the inside of the trunk lid. The lever will continue to glow for some time after the trunk lid is closed. AVALON (U)_(OM41440U)
Page 93 ■ Important points while driving Never let anyone sit in the trunk. In the event of sudden braking or a colli- sion, they are susceptible to death or serious injury. AVALON (U)_(OM41440U)
Page 94 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 95: Front Seats
(if equipped for passen- Seatback angle adjustment ger’s seat) switch Seat cushion length adjust- Seat cushion (front) angle ment switch (if equipped) adjustment switch (if equipped for passenger’s seat) Vertical height adjustment switch (if equipped for passen- ger’s seat) AVALON (U)_(OM41440U)
Page 96 Adjustments should not be made while driving as the seat may unexpect- edly move and cause the driver to lose control of the vehicle. ■ When adjusting the seat positions Make sure to leave enough space around the feet so they do not get stuck. AVALON (U)_(OM41440U)
Page 97: Driving Position Memory
Recalling the memorized position Check that the shift lever is in P. Turn the engine switch to IGNITION ON mode. Press button “1” or “2” to recall the desired position. ∗ : If equipped AVALON (U)_(OM41440U)
Page 98 (either lock or unlock) until the signal beeps. The driving position is recalled when driver’s door unlocked using the entry func- tion or wireless remote control and the driver’s door is opened. AVALON (U)_(OM41440U)
Page 99 The operation will stop. To reactivate the system, push the desired button (“1” or “2”) again. CAUTION ■ Seat adjustment caution Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel. AVALON (U)_(OM41440U)
Page 100: Head Restraints
Down Push the head restraint down while pressing the lock release button. Lock release button ■ Removing the head restraints (except rear center seat) Pull the head restraint up while pressing the lock release button. Lock release button AVALON (U)_(OM41440U)
Page 101 ■ Adjusting the rear seat head restraint (except center seat) Always raise the head restraint one level from the stowed position when using. AVALON (U)_(OM41440U)
Page 102 Adjust the head restraints to the correct position at all times. ● After adjusting the head restraints, push down on them and make sure they are locked in position. ● Do not drive with the head restraints removed. AVALON (U)_(OM41440U)
Page 103: Steering Wheel
■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident, and resulting in death or serious injury. AVALON (U)_(OM41440U)
Page 104: Inside Rear View Mirror
The height of the rear view mirror can be adjusted to suit your driving posture. Adjust the height of the rear view mirror by moving it up and down. Anti-glare function Manual anti-glare inside rear view mirror Normal position Anti-glare position AVALON (U)_(OM41440U)
Page 105 To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury. AVALON (U)_(OM41440U)
Page 106: Outside Rear View Mirrors
Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear. AVALON (U)_(OM41440U)
Page 107 Auto anti-glare function (vehicles with outer foot lights) When the anti-glare inside rear view mirror is set to automatic mode, the out- side rear view mirrors will activate in conjunction with the anti-glare inside rear view mirror to reduce reflected light. (→P. 125) AVALON (U)_(OM41440U)
Page 108 To avoid personal injury and mirror malfunction, be careful not to get your hand caught by the moving mirror. ■ When the mirror defoggers are operating Do not touch the rear view mirror surfaces, as they can become very hot and burn you. AVALON (U)_(OM41440U)
Page 109: Power Windows
: To stop the window partway, oper- ate the switch in the opposite direc- tion. Window lock switch Press the switch to lock the pas- senger window switches. Use this switch to prevent children from accidentally opening or clos- ing a passenger window. AVALON (U)_(OM41440U)
Page 110 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 111 ■ Jam protection function ● Never use any part of your body to intentionally activate the jam protection function. ● The jam protection function may not work if something gets caught just before the window fully closes. AVALON (U)_(OM41440U)
Page 112 Tilting up and down Tilts the moon roof up Tilts the moon roof down : Lightly press either way of the moon roof switch to stop the moon roof partway. ∗ : If equipped AVALON (U)_(OM41440U)
Page 113 If an object is detected between the moon roof and the frame while the moon roof is closing or tilting down, travel is stopped and the moon roof opens slightly. ■ Sunshade The sunshade can be opened and closed manually. However, the sunshade will open automatically when the moon roof is opened. AVALON (U)_(OM41440U)
Page 114 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41440U)
Page 115 ■ Jam protection function ● Never use any part of your body to intentionally activate the jam protection function. ● The jam protection function may not work if something gets caught just before the moon roof fully closes. AVALON (U)_(OM41440U)
Page 116: Driving The Vehicle
Shift the shift lever to P. (→P. 161) If parking on a hill, block the wheels as needed. Press the engine switch to stop the engine. Lock the door, making sure that you have the electronic key on your person. AVALON (U)_(OM41440U)
Page 117 It does not indicate sudden acceleration. ● The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ● When the brake pedal is depressed while sport mode is selected (→P. 209) AVALON (U)_(OM41440U)
Page 118 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 119 ● Do not drive the vehicle over or stop the vehicle near flammable materials. The exhaust system and exhaust gases can be extremely hot. These hot parts may cause a fire if there is any flammable material nearby. AVALON (U)_(OM41440U)
Page 120 Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible injury. Be sure to consult a tire dealer to determine whether the tires on your vehicle are high-speed capability tires or not before driving at such speeds. AVALON (U)_(OM41440U)
Page 121 Be careful not to shift the shift lever with the accelerator pedal depressed. Shifting the shift lever to a gear other than P or N may lead to unexpected rapid acceleration of the vehicle that may cause an accident and result in death or serious injury. AVALON (U)_(OM41440U)
Page 122 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 123 Do not leave the vehicle unattended while the engine is running. ● Do not touch the exhaust pipes while the engine is running or immediately after turning the engine off. Doing so may cause burns. AVALON (U)_(OM41440U)
Page 124 In this case, the brake pedal should be depressed more firmly than usual and the braking distance will increase. If this happens, do not continue to drive the vehicle. Have your brakes fixed immediately. AVALON (U)_(OM41440U)
Page 125 ● It may be difficult to control your vehicle. ● The vehicle will make abnormal sounds or vibrations. ● The vehicle will behave abnormally. Information on what to do in case of a flat tire (→P. 399) AVALON (U)_(OM41440U)
Page 126 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 127: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 152) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. AVALON (U)_(OM41440U)
Page 128 In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle. AVALON (U)_(OM41440U)
Page 129 Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury. AVALON (U)_(OM41440U)
Page 130: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 131: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 132: Dinghy Towing
Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. AVALON (U)_(OM41440U)
Page 133: Engine (Ignition) Switch
Press the engine switch. The engine will crank until it starts or for up to 30 seconds, whichever is less. Continue depressing the brake pedal until the engine is completely started. The engine can be started from any engine switch mode. AVALON (U)_(OM41440U)
Page 134 IGNITION ON mode All electrical components can be used. : If the shift lever is in a position other than P when turning off the engine, the engine switch will be turned to ACCESSORY mode, not to off. AVALON (U)_(OM41440U)
Page 135 Check that the parking brake is set. Shift the shift lever to P. Check that “Turn Power OFF” is displayed on the multi-information display and then press the engine switch once. Check that “Turn Power OFF” on the multi-information display is turned off. AVALON (U)_(OM41440U)
Page 136 If the engine does not start ● The engine immobilizer system may not have been deactivated. (→P. 66) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 137 When a message requesting the smart key system be inspected is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted →P. 350 ■...
Page 138 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 139: Automatic Transmission
: To improve fuel efficiency and reduce noises, set the shift lever in the D position for normal driving. : Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges, controls engine braking force, and prevents upshifting above the selected range. AVALON (U)_(OM41440U)
Page 140 A lower shift range will provide greater engine braking force than a higher shift range, and the engine speed will also increase. ● You can choose the gear range you want for different levels of acceleration. (e.g. uphill, sporty driving, etc.) AVALON (U)_(OM41440U)
Page 141 When a shift range higher than “5” is selected, the shift range will return to the normal D position. When the vehicle comes to a stop, the shift range will return to the normal D position. AVALON (U)_(OM41440U)
Page 142 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 143: Turn Signal Lever
Turn signals can be operated when The engine switch is in IGNITION ON mode. ■ If the indicator flashes faster than usual Check that a light bulb in the front or rear turn signal lights has not burned out. AVALON (U)_(OM41440U)
Page 144: Parking Brake
Usage in winter time →P. 233 NOTICE ■ Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear. AVALON (U)_(OM41440U)
Page 145 To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P. 124) AVALON (U)_(OM41440U)
Page 146: Headlight Switch
(when the engine switch IGNITION mode). The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on. The headlights and all the lights listed above (except daytime running lights) turn on. daytime running lights turn off. AVALON (U)_(OM41440U)
Page 147 Pull the lever toward you to the center position to turn the high beams off. Pull the lever toward you and release it to flash the high beams once. You can flash the high beams with the headlights on or off. AVALON (U)_(OM41440U)
Page 148 Automatic headlight leveling system (if equipped) The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. AVALON (U)_(OM41440U)
Page 149 4-3. Operating the lights and wipers ■ Customization Settings (e.g. light sensor sensitivity) can be changed. (Customizable features: →P. 453) NOTICE ■ To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not running. AVALON (U)_(OM41440U)
Page 150: Automatic High Beam
Put the headlight switch in the “AUTO” position. Push the lever away from you. The Automatic High Beam indica- tor will come on when the head- lights are turned on automatically to indicate that the system is active. ∗ : If equipped AVALON (U)_(OM41440U)
Page 151 Switching to high beam Turn the light switch to position. The Automatic High Beam indi- cator will turn off and the high beam indicator will turn on. Press the switch to activate the Automatic High Beam system again. AVALON (U)_(OM41440U)
Page 152 • The condition of the road (gradient, curve, condition of the road surface etc.) • The number of passengers and amount of luggage ● High beam may be turned on or off when unexpected by the driver. AVALON (U)_(OM41440U)
Page 153 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. ■ If the Automatic High Beam indicator flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The automatic high beam can be deactivated.
Page 154 Do not install a parking tag or any other accessories near or around the inside rear view mirror and the camera sensor. ● Do not overload the vehicle. ● Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. Contact your Toyota dealer. AVALON (U)_(OM41440U)
Page 155: Fog Light Switch
4-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Type A Turns the front fog lights Turns the front fog lights ∗ : If equipped AVALON (U)_(OM41440U)
Page 156 4-3. Operating the lights and wipers Type B Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam. AVALON (U)_(OM41440U)
Page 157: Windshield Wipers And Washer
Type A Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper opera- tion Temporary operation Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency AVALON (U)_(OM41440U)
Page 158 Low speed wiper operation High speed wiper operation Temporary operation Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency ■ Washer/wiper dual operation Wipers will automatically oper- ate a couple of times after the washer squirts. AVALON (U)_(OM41440U)
Page 159 With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the sensitivity Decreases the sensitivity AVALON (U)_(OM41440U)
Page 160 Rain-sensing wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the sensitivity Decreases the sensitivity ■ Washer/wiper dual operation Wipers will automatically oper- ate a couple of times after the washer squirts. AVALON (U)_(OM41440U)
Page 161 14°F (-10°C) or lower, automatic operation may not occur. In this case, operate the wipers in any mode other than AUTO mode. ■ If no windshield washer fluid sprays Check that the washer nozzles are not blocked if there is washer fluid in the windshield washer fluid reservoir. AVALON (U)_(OM41440U)
Page 162 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. AVALON (U)_(OM41440U)
Page 163: Opening The Fuel Tank Cap
Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch off. ● Confirm the type of fuel. ■ Fuel types Use unleaded gasoline (Octane rating 87 [Research Octane Number 91] or higher) AVALON (U)_(OM41440U)
Page 164 Do not top off the fuel tank. NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface. AVALON (U)_(OM41440U)
Page 165 Then open the door fully by hand. Turn the fuel tank cap slowly to open. Hang the fuel tank cap on the back of the fuel filler door. AVALON (U)_(OM41440U)
Page 166 If the fuel filler door cannot be opened Remove the cover inside the trunk and pull the lever to open the fuel filler door if the fuel filler door cannot be opened by pressing the rear edge of the fuel filler door. AVALON (U)_(OM41440U)
Page 167 CAUTION ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 168: Cruise Control
Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set the speed. “SET” indicator will be displayed. The vehicle speed at the moment the lever is released becomes the set speed. ∗ : If equipped AVALON (U)_(OM41440U)
Page 169 The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the constant speed control. Resuming is available when the vehicle speed is more than approx- imately 25 mph (40 km/h). AVALON (U)_(OM41440U)
Page 170 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41440U)
Page 171 ● On winding roads ● On slippery roads, such as those covered with rain, ice or snow ● On steep hills Vehicle speed may exceed the set speed when driving down a steep hill. ● During emergency towing AVALON (U)_(OM41440U)
Page 172: Dynamic Radar Cruise Control
In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Vehicle-to-vehicle distance but- Display Indicators Set speed Cruise control switch ∗ : If equipped AVALON (U)_(OM41440U)
Page 173 Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set the speed. “SET” indicator will be displayed. The vehicle speed at the moment the lever is released becomes the set speed. AVALON (U)_(OM41440U)
Page 174 In the constant speed control mode (→P. 201), the set speed will be increased or decreased as follows: Fine adjustment: By approximately 1 mph (1.6 km/h) each time the lever is operated Large adjustment: The set speed can be increased or decreased continu- ally until the lever is released. AVALON (U)_(OM41440U)
Page 175 50 mph (80 km/h). Vehicle-to-vehicle distance increases/decreases in accordance with vehicle speed. Distance options Vehicle-to-vehicle distance Long Approximately 160 ft. (50 m) Medium Approximately 130 ft. (40 m) Short Approximately 100 ft. (30 m) AVALON (U)_(OM41440U)
Page 176 The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed. Resuming is available when the vehicle speed is more than approx- imately 25 mph (40 km/h). AVALON (U)_(OM41440U)
Page 177 When a greater reduction in vehicle speed is necessary, the system applies the brakes. A warning tone warns you when the system cannot decelerate sufficiently to prevent your vehicle from clos- ing in on the vehicle ahead. AVALON (U)_(OM41440U)
Page 178 ● When the speed of the vehicle ahead matches or exceeds your vehicle speed ● When the vehicle ahead is traveling at an extremely slow speed ● Immediately after the cruise control speed was set ● At the instant the accelerator is applied AVALON (U)_(OM41440U)
Page 179 If the engine switch is turned off and then turned to IGNITION ON mode again, the vehicle will auto- matically return to vehicle-to-vehi- cle distance control mode. Adjusting the speed setting: →P. 191 Canceling and resuming the speed setting: →P. 191 AVALON (U)_(OM41440U)
Page 180 The windshield wipers are operating at high speed (when the wipers are in AUTO mode [rain-sensing windshield wipers] or the high speed wiper oper- ation). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. AVALON (U)_(OM41440U)
Page 181 If the warning message remains on even after the above actions have been performed, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41440U)
Page 182 For vehicles sold in Canada Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any inter ference, includ- ing interference that may cause undesired operation of the device. AVALON (U)_(OM41440U)
Page 183 The dynamic radar cruise control has no capability to prevent or avoid a collision with a vehicle traveling ahead. Therefore, if there is ever any dan- ger, the driver must take immediate and direct control of the vehicle and act appropriately in order to ensure the safety of all involved. AVALON (U)_(OM41440U)
Page 184 Vehicle speed may exceed the set speed when driving down a steep hill. ● At entrances to expressways ● When weather conditions are bad enough that they may prevent the sen- sors from functioning correctly (fog, snow, sandstorm, heavy rain, etc.) ● When an approach warning buzzer is heard often AVALON (U)_(OM41440U)
Page 185 When your vehicle is pointing upwards (caused by a heavy load in the trunk etc.) ● When the road curves or when the lanes are narrow ● When steering wheel operation or your position in the lane is unstable ● When the vehicle ahead of you decelerates suddenly AVALON (U)_(OM41440U)
Page 186 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by a Toyota dealer. ● Do not disassemble the sensor.
Page 187: Driving Mode Select Switches
Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. When the “ECO” switch is pressed, the “ECO MODE” indicator comes on in the instrument cluster. ∗ : If equipped AVALON (U)_(OM41440U)
Page 188 (→P. 238). To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode. ■ Sport mode automatic deactivation Sport mode is automatically deactivated if the engine switch is turned off after driving in sport mode. AVALON (U)_(OM41440U)
Page 189: Driving Assist Systems
◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆ PCS (Pre-Collision System) (if equipped) →P. 216 ◆ BSM (Blind Spot Monitor) (if equipped) →P. 223 AVALON (U)_(OM41440U)
Page 190 To turn the TRAC system off, quickly press and release the switch. The “TRAC OFF” indicator light should come on and message will be shown on the multi-information display. Press the switch again to turn the system back on. AVALON (U)_(OM41440U)
Page 191 TRAC has been disabled and “TRAC OFF” indicator light comes on even if the TRAC/VSC OFF switch has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC and TRAC systems ●...
Page 192 When the TRAC/VSC systems are turned off Be especially careful and drive at a speed appropriate to the road condi- tions. As these are the systems to ensure vehicle stability and driving force, do not turn the TRAC/VSC systems off unless necessary. AVALON (U)_(OM41440U)
Page 193 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 194 When there is a high possibility of a frontal collision, the system warns the driver using a warning light, warning display and buzzer. If the system determines that a collision is unavoidable, the brakes are automatically applied to reduce the collision speed. ∗ : If equipped AVALON (U)_(OM41440U)
Page 195 Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and determines whether a collision is imminent based on the position, speed, and heading of the obstacles. AVALON (U)_(OM41440U)
Page 196 • Vehicle speed is greater than about 10 mph (15 km/h). • The speed at which your vehicle is approaching the obstacle or the vehi- cle running ahead of you is greater than about 10 mph (15 km/h). AVALON (U)_(OM41440U)
Page 197 In inclement weather such as heavy rain, fog, snow or sand storms ● When your vehicle is skidding such as the VSC system off ● When your vehicle is steeply inclined ● When the axis of the radar is out of adjustment AVALON (U)_(OM41440U)
Page 198 ■ When there is a malfunction in the system “PCS” warning light will flash and warning messages will be displayed. (→P. 389) Have the vehicle inspected by your Toyota dealer immediately. ■ Certification For vehicles sold in the U.S.A.
Page 199 Do not disassemble the sensor. ● Do not attach accessories or stickers to the sensor, grille cover or sur- rounding area. ● Do not modify or paint the sensor and grille cover. ● Do not replace them with non-genuine parts. AVALON (U)_(OM41440U)
Page 200 For this reason, when encountering a dangerous situation the driver must take direct and immediate action in order to ensure the safety of all involved. AVALON (U)_(OM41440U)
Page 201 Rear Cross Traffic Alert function: When a vehicle approaching from the right or left rear of the vehicle is detected, the outside rear view mirror indicators flash. ∗ : If equipped AVALON (U)_(OM41440U)
Page 202 (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. AVALON (U)_(OM41440U)
Page 203 If the sensor moves even slightly off position, the system may mal- function and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. ● Do not disassemble the sensor.
Page 204 Blind Spot Monitor function. The function cannot judge if it is safe to change lanes, therefore over reliance could cause an accident resulting in death or serious injury. According to conditions, the system may not function correctly. Therefore the driver’s own visual confirmation of safety is necessary. AVALON (U)_(OM41440U)
Page 205 Guardrails, walls, signs, parked vehicles and similar stationary objects ● Following vehicles that are in the same lane ● Vehicles driving 2 lanes across from your vehicle : Depending on conditions, detection of a vehicle and/or object may occur. AVALON (U)_(OM41440U)
Page 206 • When there is only a short distance between your vehicle and a following vehicle • When vehicle lanes are narrow and a vehicle driving 2 lanes across from your vehicle enters the detection area • When items such as a bicycle carrier are installed on the rear of the vehi- AVALON (U)_(OM41440U)
Page 207 Failure to do so could cause death or serious injury. According to conditions, the system may not function correctly. Therefore the driver’s own visual confirmation of safety is necessary. AVALON (U)_(OM41440U)
Page 208 The BSM main switch is set to on. ● The shift lever is in R. ● Vehicle speed is less than approximately 5 mph (8 km/h). ● Approaching vehicle speed is between approximately 5 mph (8 km/h) and 18 mph (28 km/h). AVALON (U)_(OM41440U)
Page 209 When a vehicle is approaching at high speed ● When parking on a steep incline, such as hills, a dip in the road etc. ● Directly after the BSM main switch is set to on ● Vehicles that the sensors cannot detect because of obstacles AVALON (U)_(OM41440U)
Page 210: Winter Driving Tips
● Have the vehicle fitted with four snow tires or purchase a set of tire chains for the front tires. Ensure that all tires are the specified size and brand, and that chains match the size of the tires. AVALON (U)_(OM41440U)
Page 211 Park the vehicle and move the shift lever to P without setting the park- ing brake. The parking brake may freeze up, preventing it from being released. If necessary, block the wheels to prevent inadvertent sliding or creeping. AVALON (U)_(OM41440U)
Page 212 Install tire chains on the front tires. Do not install tire chains on the rear tires. ● Install tire chains on front tires as tightly as possible. Retighten chains after driving 1/4 ⎯ 1/2 mile (0.5 ⎯ 1.0 km). ● Install tire chains following the instructions provided with the tire chains. AVALON (U)_(OM41440U)
Page 213 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 214 4-6. Driving tips AVALON (U)_(OM41440U)
Page 215: Automatic Air Conditioning System
5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Front control panel (type A) Front control panel (type B) AVALON (U)_(OM41440U)
Page 216 Air outlet display Front passenger’s side tem- Automatic mode perature display Air outlet selector Front passenger’s side tem- Rear passenger’s temperature perature control setting display (if equipped) Rear control panel (if equipped) Rear control switch Rear passenger’s temperature control AVALON (U)_(OM41440U)
Page 217 The air conditioning system switches between individual and synchro- nized modes each time is touched. Vehicles with a rear control switch: The rear passenger’s temperature setting switches between individual and synchronized modes each time is pressed. AVALON (U)_(OM41440U)
Page 218 To adjust the fan speed, touch and slide your finger toward “+” to increase the fan speed or “-” to decrease the fan speed. The fan speed can also be adjusted by touching “+” or “-” on Touch to turn the fan off. AVALON (U)_(OM41440U)
Page 219 To change the air outlets, press The air outlets used are switched each time is pressed. ■ Changing the rear seat temperature settings (vehicles with a rear control switch) →P. 241 AVALON (U)_(OM41440U)
Page 220 To return to the previous mode, press again when the wind- shield is defogged. Air outlets and air flow Air flows to the upper body. Air flows to the upper body and feet. AVALON (U)_(OM41440U)
Page 221 Adjusting the position of and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. AVALON (U)_(OM41440U)
Page 222 ● If you turn off, the windows may fog up more easily. ● The windows may fog up if the recirculated air mode is used. AVALON (U)_(OM41440U)
Page 223 • The start timing of the blower may be delayed for a short period of time immediately after the air conditioning system is started in automatic mode. ■ Air conditioning filter →P. 348 AVALON (U)_(OM41440U)
Page 224 NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is stopped. AVALON (U)_(OM41440U)
Page 225: Rear Window And Outside Rear View Mirror Defoggers
When the outside rear view mirror defoggers are on Do not touch the rear view mirror surfaces, as they can become very hot and burn you. NOTICE ■ To prevent battery discharge Turn the defoggers off when the engine is off. AVALON (U)_(OM41440U)
Page 226: Audio System Types
Owners of models equipped with a Display Audio system should refer to the “Display Audio System Owner's Manual”. Type A Type B With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. U.S.A. Canada AVALON (U)_(OM41440U)
Page 227 L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appa- reil doit accepter tout brouillage radioélectrique subi, même si le brouil- lage est susceptible d’en compromettre le fonctionnement. AVALON (U)_(OM41440U)
Page 228 Canada. Dans le but de réduire les risques de brouillage radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. AVALON (U)_(OM41440U)
Page 229 • This product utilizes a laser. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD. AVALON (U)_(OM41440U)
Page 230: Using The Usb/Aux Port
The volume can be adjusted using the vehicle's audio controls. All other adjustments must be made on the portable audio device itself. ■ When using a portable audio device connected to the power outlet Noise may occur during playback. Use the power source of the portable audio device. AVALON (U)_(OM41440U)
Page 231: Interior Lights List
5-3. Using the interior lights Interior lights list Outer foot lights (if equipped) Ambient lights (if equipped) (→P. 256) Rear personal/interior lights (→P. 255) Front door courtesy lights Front personal/interior lights (→P. 255) AVALON (U)_(OM41440U)
Page 232 Turns the lights on/off linked to door position Personal/interior lights ■ Front Turns the light on/off ■ Rear Turns the light on/off If the lights are turned on by the personal/interior light main switch, the lights cannot turn off by pressing the switch. AVALON (U)_(OM41440U)
Page 233 Customization Setting (e.g. the time elapsed before lights turn off) can be changed. (Customizable features: →P. 453) NOTICE ■ To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not running. AVALON (U)_(OM41440U)
Page 234: List Of Storage Features
When driving or when the storage compartments are not in use Keep the lids closed. In the event of sudden braking or sudden swerving, an accident may occur due to an occupant being struck by an open lid or the items stored inside. AVALON (U)_(OM41440U)
Page 235 Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside. AVALON (U)_(OM41440U)
Page 236 Slide the console box lid forward as needed. Slide the lid forward while pulling up the lever. The lid can also be opened from the for- wardmost position. ■ Tray in the console box The tray slides forward/backward and can be removed. AVALON (U)_(OM41440U)
Page 237 Cup holders Front Rear (type A) Pull down the armrest. Rear (type B) Pull down the armrest and open the lid. AVALON (U)_(OM41440U)
Page 238 Keep the cup holders closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open cup holders or the items stored inside. Auxiliary boxes Type A Press in the button. Type B Push the lid. AVALON (U)_(OM41440U)
Page 239 An electronic device on the tray can be recharged by running a charging cable through the clearance of the tray and con- necting it to the AUX/USB port or power outlet underneath the tray. AVALON (U)_(OM41440U)
Page 240 If the LED indicators flash even though the surface of the tray is not hot, the wireless charger may be malfunctioning. Consult your Toyota dealer. ■ When charging of the wireless charger stops temporarily If any of the following operations are performed with the electronic key present, charging may stop temporarily.
Page 241 ■ Certification for the wireless charger For vehicles sold in the U.S.A. This device complies with Part 18 of the FCC Rules. Toyota Motor Sales, U.S.A., Inc. 19001 S. Western Avenue Torrance, CA 90501 For vehicles sold in Canada This ISM device complies with Canadian ICES-001.
Page 242 Do not pull down the tray to close it. Doing so may damage the tray. ■ When on a steep downward incline The tray can be closed slowly. In this case, the tray can be pulled down to close it. However, make sure the lock has been released before doing so. AVALON (U)_(OM41440U)
Page 243: Trunk Features
5-4. Using the storage features Trunk features Grocery bag hooks Cargo net (if equipped) AVALON (U)_(OM41440U)
Page 244 5-4. Using the storage features NOTICE ■ To prevent damage to the hooks Do not apply too much load to the hooks. AVALON (U)_(OM41440U)
Page 245: Sun Visors And Vanity Mirrors
Vanity mirrors Open the cover to use. The light turns on when the cover is opened. NOTICE ■ To prevent battery discharge Do not leave the vanity lights on for extended periods while the engine is off. AVALON (U)_(OM41440U)
Page 246 Pressing and holding the button adjusts the minutes forward quickly by 1 minute at a time. If the button is pressed and held for 5 seconds or more, the min- utes move forward by 5 minutes at a time. AVALON (U)_(OM41440U)
Page 247 The time display will automatically be set to 12:00. ■ Time display (Type B) After pressing “H” or “M” to show the setting screen, press “H” and “M” at the same time to change between the analog and digital displays. AVALON (U)_(OM41440U)
Page 248: Outside Temperature Display
When the vehicle is stopped, or moving at low speeds (less than 16 mph [25 km/h]). ● When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) ■ When “---°F” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. AVALON (U)_(OM41440U)
Page 249: Power Outlets
5-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. ■ Console box AVALON (U)_(OM41440U)
Page 250 ■ To prevent blown fuse Do not use an accessory that uses more than 12 V 10 A. ■ To prevent battery discharge Do not use the power outlets longer than necessary when the engine is off. AVALON (U)_(OM41440U)
Page 251: Seat Heaters
The further you turn the knob clockwise, the warmer the seat temperature becomes. Turn the knob counterclockwise all the way to turn the system off. Press the knob again to lock it when not in use. ∗ : If equipped AVALON (U)_(OM41440U)
Page 252 If the passenger returns to the seat, it automatically turns on again. ■ Operation display illumination (if equipped) Illuminates when the ventilator is operating. Illuminates when the front seat heater is operating. AVALON (U)_(OM41440U)
Page 253 Do not put heavy objects that have an uneven surface on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. ■ To prevent battery discharge Turn the seat heaters/seat ventilators off when the engine is off. AVALON (U)_(OM41440U)
Page 254 5-5. Other interior features Armrest Fold down the armrest for use. NOTICE ■ To prevent damage to the armrest Do not apply too much load on the armrest. AVALON (U)_(OM41440U)
Page 255: Rear Sunshade
The rear sunshade can be operated for approximately 1 minute even after the engine switch is turned off. ■ Customization Settings (e.g. time elapsed before the reverse operation feature activates) can be changed. (Customizable features: →P. 453) ∗ : If equipped AVALON (U)_(OM41440U)
Page 256 Do not place objects where they may hinder opening and closing opera- tions. ● Do not attach items to the rear sunshade. ● Keep the opening clean and clear of obstructions. ● Do not operate the rear sunshade continuously for long periods of time. AVALON (U)_(OM41440U)
Page 257: Trunk Storage Extension
Lock Unlock CAUTION ■ When not in use Ensure that the armrest door is closed. In the event of sudden braking, items stored in the trunk may be thrown for- ward into the cabin, resulting in injury. AVALON (U)_(OM41440U)
Page 258: Coat Hooks
Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury. AVALON (U)_(OM41440U)
Page 259: Assist Grips
Do not use the assist grip when getting in or out of the vehicle or rising from your seat. NOTICE ■ To prevent damage to the assist grip Do not hang any heavy object or put a heavy load on the assist grip. AVALON (U)_(OM41440U)
Page 260: Garage Door Opener
(for U.S.A. owners) ® The HomeLink compatible transceiver in your vehicle has 3 buttons which can be programmed to operate 3 different devices. Refer to the programming method below appropriate for the device. Indicator light Buttons ∗ : If equipped AVALON (U)_(OM41440U)
Page 261 If the HomeLink indicator light comes on but does not flash, or flashes rapidly for 2 seconds ® and remains lit, the HomeLink button is already programmed. Use the other buttons or follow “Reprogramming ® HomeLink button” instructions. (→P. 288) AVALON (U)_(OM41440U)
Page 262 2 seconds and then remains lit. If your transmitter is the Rolling Code type, proceed to the heading “Programming a rolling code system”. Repeat the steps above to program another device for each of ® the remaining HomeLink buttons. AVALON (U)_(OM41440U)
Page 263 The ceiling mounted garage door opener motor should now recognize ® the HomeLink transceiver and operate the garage door. Repeat the steps above to program another rolling code system ® for any of the remaining HomeLink buttons. AVALON (U)_(OM41440U)
Page 264 ® the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 265 (all three programs) Press and hold down the 2 out- side buttons for 10 seconds until the indicator light flashes. If you sell your vehicle, be sure to erase the programs stored in the ® HomeLink memory. AVALON (U)_(OM41440U)
Page 266 This includes any garage door that cannot detect an obstruction object. A door or device without these features increases the risk of death or serious injury. AVALON (U)_(OM41440U)
Page 267: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 268 After you have signed the Telematics Subscription Service Agree- ment and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” button in your vehicle for further subscription details. AVALON (U)_(OM41440U)
Page 269 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 270 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 271 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 272 (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. AVALON (U)_(OM41440U)
Page 273 ■ Operation To turn the compass on or off, press the switch for more than 3 seconds. ■ Displays and directions Display Direction North Northeast East Southeast South Southwest West Northwest ∗ : If equipped AVALON (U)_(OM41440U)
Page 274 A number (1 to 15) appears on the compass display. Referring to the map above, press the switch to select the num- ber of the zone you are in. If the direction is displayed several seconds after adjustment, the cali- bration is complete. AVALON (U)_(OM41440U)
Page 275 Be sure to adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood. Do not violate any local traffic rules while performing cir- cling calibration. AVALON (U)_(OM41440U)
Page 276 Do not perform circling calibration of the compass in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields. ● During calibration, do not operate electric systems (moon roof, power win- dows, etc.) as they may interfere with the calibration. AVALON (U)_(OM41440U)
Page 277 5-5. Other interior features AVALON (U)_(OM41440U)
Page 278: Cleaning And Protecting The Vehicle Exterior
High pressure car washes ● Do not allow the nozzles of the car wash to come within close proximity of the windows. ● Before using the car wash, check that the fuel filler door on your vehicle is closed properly. AVALON (U)_(OM41440U)
Page 279 Do not use detergent on the wheels when they are hot, for example after driving for long distance in the hot weather. ● Wash detergent from the wheels immediately after use. ■ Bumpers Do not scrub with abrasive cleaners. AVALON (U)_(OM41440U)
Page 280 ■ Precaution regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. AVALON (U)_(OM41440U)
Page 281 ■ When using an automatic car wash (vehicles with rain-sensing wind- shield wipers) Set the wipers switch to off. If AUTO mode is selected, the wipers may operate and the wiper blades may be damaged. AVALON (U)_(OM41440U)
Page 282: Cleaning And Protecting The Vehicle Interior
● Apply a mild soap solution to the synthetic leather using a sponge or soft cloth. ● Allow the solution to soak in for a few minutes. Remove the dirt and wipe off the solution with a clean, damp cloth. AVALON (U)_(OM41440U)
Page 283 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 284 Use a cloth dampened with lukewarm water to gently wipe the window clean. Wipe the window in strokes running parallel to the heater wires or antenna. ● Be careful not to scratch or damage the heater wires or antenna. AVALON (U)_(OM41440U)
Page 285: Maintenance Requirements
Toyota recommends performing the fol- lowing maintenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 286 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 287: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 288 • The brakes should work effec- tively. Brakes • The brake pedal should not feel spongy. • The brake pedal should not get too close to the floor when the brakes are applied. AVALON (U)_(OM41440U)
Page 289 • Do the seat controls operate prop- Seats erly? • Does the steering wheel rotate smoothly? • Does the steering wheel have the Steering wheel correct amount of free play? • There should not be any strange sounds coming from the steering wheel. AVALON (U)_(OM41440U)
Page 290 • Have the tires been rotated according to the maintenance schedule? • The wheel nuts should not be loose. CAUTION ■ If the engine is running Turn the engine off and ensure that there is adequate ventilation before per- forming maintenance checks. AVALON (U)_(OM41440U)
Page 291: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 292: Do-It-Yourself Service Precautions
“Toyota Super Long Life Coolant” is pre-mixed with 55% coolant and 45% deionized water. • Funnel (used only for adding cool- ant) • “Toyota Genuine Motor Oil” or equivalent Engine oil level (→P. 323) • Rag or paper towel • Funnel (used only for adding...
Page 293 Radiator and condenser (→P. 328) • Tire pressure gauge Tire inflation pressure (→P. 342) • Compressed air source • Water or washer fluid containing antifreeze (for winter use) Washer fluid (→P. 333) • Funnel (used only for adding water or washer fluid) AVALON (U)_(OM41440U)
Page 294 Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting in your eyes. NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. AVALON (U)_(OM41440U)
Page 295 Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. AVALON (U)_(OM41440U)
Page 296: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ◆ Front ◆ Rear AVALON (U)_(OM41440U)
Page 297 ● Do not raise the vehicle while someone is in the vehicle. ● When raising the vehicle, do not place any object on top of or underneath the floor jack. AVALON (U)_(OM41440U)
Page 298: Engine Compartment
Engine oil filler cap (→P. 324) Radiator (→P. 328) Engine oil level dipstick Electric cooling fans (→P. 323) Condenser (→P. 328) Brake fluid reservoir Engine coolant reservoir (→P. 329) (→P. 326) Fuse box (→P. 352) Washer fluid tank (→P. 333) Battery (→P. 330) AVALON (U)_(OM41440U)
Page 299 Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive The shape of the dipstick may differ depending on the type of vehicle or engine. Wipe the dipstick and reinsert it fully. AVALON (U)_(OM41440U)
Page 300 If low quality oil or oil of an inappropriate viscosity is used ● When driving at high engine speeds or with a heavy load, or when driving while accelerating or decelerating frequently ● When leaving the engine idling for a long time, or when driving frequently through heavy traffic AVALON (U)_(OM41440U)
Page 301 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 302 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. AVALON (U)_(OM41440U)
Page 303 Be sure to read the antifreeze or coolant label. ■ If you spill coolant Be sure to wash it off with water to prevent it from damaging parts or paint. AVALON (U)_(OM41440U)
Page 304 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■...
Page 305 It is normal for the brake fluid level to go down slightly as the brake pads wear out or when the fluid level in the accumulator is high. If the reservoir needs frequent refilling, there may be a serious problem. AVALON (U)_(OM41440U)
Page 306 If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable. ● Make sure the power switch on the charger is off when connecting and dis- connecting the charger cables to the battery. AVALON (U)_(OM41440U)
Page 307 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. CAUTION ■...
Page 308 If you accidentally swallow electrolyte Drink a large quantity of water or milk. Get emergency medical attention immediately. NOTICE ■ When recharging the battery Never recharge the battery while the engine is operating. Also, be sure all accessories are turned off. AVALON (U)_(OM41440U)
Page 309 Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. ■ Diluting washer fluid Dilute washer fluid with water as necessary. Refer to the freezing temperatures listed on the label of the washer fluid bot- tle. AVALON (U)_(OM41440U)
Page 310 Check spare tire condition and pressure if not rotated. Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. AVALON (U)_(OM41440U)
Page 311 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 337) ◆ Initializing the tire pressure warning system ■...
Page 312 Press and hold the tire pres- sure warning reset switch until the tire pressure warn- ing light blinks slowly 3 times. Wait for a few minutes with the engine switch in IGNITION ON mode and then turn the engine switch off. AVALON (U)_(OM41440U)
Page 313 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 314 Do not install studded tires without first checking local regulations for possible restrictions. Snow tires should be installed on all wheels. (→P. 232) AVALON (U)_(OM41440U)
Page 315 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 316 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 317 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 318: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 435) AVALON (U)_(OM41440U)
Page 319 Driving with incorrect tire inflation pressure may result in the following: ● Reduced fuel efficiency ● Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. AVALON (U)_(OM41440U)
Page 320 Be sure to put the tire valve caps back on. Without the valve caps, dirt or moisture could get into the valve and cause air leakage, which could result in an accident. If the caps are lost, replace them as soon as possible. AVALON (U)_(OM41440U)
Page 321 ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 322 In addition, the oil or grease can cause the wheel nuts to loosen and the wheel may fall off, causing an accident and resulting in death or serious injury. Remove any oil or grease from the wheel bolts or wheel nuts. AVALON (U)_(OM41440U)
Page 323 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 324: Air Conditioning Filter
Turn the engine switch off. Open the glove box. (→P. 258) Lift up the side with the stay, disconnect the stay tabs and remove the partition by pulling horizontally. Remove the glove box cover. Press the tabs and remove the filter cover. AVALON (U)_(OM41440U)
Page 325 The filter may be clogged. Check the filter and replace if necessary. NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system. AVALON (U)_(OM41440U)
Page 326: Electronic Key Battery
Replacing the battery Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. Insert a new battery with the “+” terminal facing up. AVALON (U)_(OM41440U)
Page 327 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 328: Checking And Replacing Fuses
Open the Fuse box cover. Engine compartment Push the tab in and lift the lid off. Driver’s side instrument panel Remove the lid. Remove the fuse with the pull- out tool. Only type A fuse can be removed using the pullout tool. AVALON (U)_(OM41440U)
Page 329 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer. Type A Type B Type C...
Page 330 Fuse block on the back of the cover Fuse Ampere Circuit METER-IG2 Gauge and meters 50 A Electric cooling fans H-LP CLN 30 A No circuit 50 A Air conditioning system 140 A Charging system 120 A ABS NO.2 30 A Vehicle stability control system AVALON (U)_(OM41440U)
Page 331 23 STRG LOCK 10 A Steering lock system 24 AMP 15 A Audio system 20 A 25 H-LP LH-LO Left-hand headlight (low beam) 15 A 20 A 26 H-LP RH-LO Right-hand headlight (low beam) 15 A AVALON (U)_(OM41440U)
Page 332 10 A system, steering sensor, air conditioning system, outside rear view mirror, front power seats 37 SPARE 25 A Spare fuse 38 SPARE 30 A Spare fuse Vehicles with discharge headlight low beam Vehicles with halogen headlight low beam AVALON (U)_(OM41440U)
Page 333 Multiplex communication system, power D/L-AM1 20 A door lock, trunk opener switch 10 PSB 30 A Pre-collision system 11 P/SEAT FR 30 A Power seats 12 S/ROOF 10 A Moon roof 13 A/C-B 7.5 A Air conditioning system AVALON (U)_(OM41440U)
Page 334 20 A Rear left-hand power windows Power windows, outside rear view mir- 30 DOOR F/L 20 A rors 31 DOOR R/R 20 A Rear right-hand power windows Power windows, outside rear view mir- 32 DOOR F/R 20 A rors AVALON (U)_(OM41440U)
Page 335 36 ECU-IG1 NO.2 10 A anti-glare inside rear view mirror, outside rear view mirrors, pre-collision system, air conditioning controls, rain-sensing windshield wipers, starting system, dynamic radar cruise control AVALON (U)_(OM41440U)
Page 336 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 361) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 337: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 436) AVALON (U)_(OM41440U)
Page 338 Front Headlight low beam (halogen bulb) Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams) Headlight high beam (vehicles with discharge bulbs for low beams) Fog light (if equipped) Front turn signal/parking light AVALON (U)_(OM41440U)
Page 339 6-3. Do-it-yourself maintenance ■ Rear Rear turn signal light Back-up light License plate light AVALON (U)_(OM41440U)
Page 340 Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. AVALON (U)_(OM41440U)
Page 341 Turn it clockwise to set. Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. AVALON (U)_(OM41440U)
Page 342 Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb. Remove the fender liner bolt and partly remove the fender liner. AVALON (U)_(OM41440U)
Page 343 Set the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting. AVALON (U)_(OM41440U)
Page 344 6-3. Do-it-yourself maintenance Reinstall the fender liner and the fender liner bolt. Reinstall the fender liner clips. AVALON (U)_(OM41440U)
Page 345 Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb. Remove the fender liner bolt and partly remove the fender liner. AVALON (U)_(OM41440U)
Page 346 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41440U)
Page 347 6-3. Do-it-yourself maintenance ■ Rear turn signal light Open trunk remove the luggage trim cover clip. Pull the hook while depress- ing the button. Partly remove the luggage trim cover. AVALON (U)_(OM41440U)
Page 348 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41440U)
Page 349 6-3. Do-it-yourself maintenance ■ Back-up light Open trunk remove the clips. Then partly remove trunk panel cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41440U)
Page 350 To prevent damaging the vehi- cle, wrap the screwdriver with a tape. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41440U)
Page 351 ■ Replacing the following bulbs If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (discharge bulb) ● Daytime running lights (vehicles with discharge headlights) ● Side marker lights ●...
Page 352 The daytime running lights (vehicles with discharge headlights), stop/tail lights, high mounted stoplight and outer foot lights each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 353 To pre- vent burns, do not touch these metal components until you are certain they have cooled down. AVALON (U)_(OM41440U)
Page 354 6-3. Do-it-yourself maintenance CAUTION ■ Discharge headlights (if equipped) ● Contact your Toyota dealer before replacing the discharge headlights (including light bulbs). ● Do not touch the discharge headlight’s high voltage socket when the head- lights are turned on. An extremely high voltage of 30000 V will be discharged and could result in death or serious injury by electric shock.
Page 355: Emergency Flashers
All the turn signals will flash. To turn them off, press the switch once again. ■ Emergency flashers If the emergency flashers are used for a long time while the engine is not operating, the battery may discharge. AVALON (U)_(OM41440U)
Page 356 If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine. AVALON (U)_(OM41440U)
Page 357: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 358 Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front From the rear Release the parking brake. Use a towing dolly under the front wheels. AVALON (U)_(OM41440U)
Page 359 Without adequate clearance, the vehicle could be damaged while being towed. ■ To prevent body damage when towing with a sling-type truck Do not tow with a sling-type truck, either from the front or rear. AVALON (U)_(OM41440U)
Page 360: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 361: Fuel Pump Shut Off System
■ Before starting the engine Inspect the ground under the vehicle. If you find that fuel has leaked onto the ground, the fuel system has been damaged and is in need of repair. Do not restart the engine. AVALON (U)_(OM41440U)
Page 362: If A Warning Light Turns On Or A Warning Buzzer Sounds
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 363 Low engine oil pressure warning light Indicates that the engine oil pressure is too low. Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
Page 364 • The VSC system; or • The TRAC system The light will flash when the VSC or the TRAC system is operating. Automatic High Beam indicator light Indicates a malfunction in the Automatic high beam sys- (Flashes) tem. (If equipped) AVALON (U)_(OM41440U)
Page 365 (warning buzzer) off. Master warning light A buzzer sounds and the warning light comes on →P. 398 and flashes to indicate that the master warning system has detected a malfunc- tion. AVALON (U)_(OM41440U)
Page 366 • Flat tire (→P. 399) pressure adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire pres- by your Toyota dealer.
Page 367 12 mph (20 km/h). If the seat belt is still unfas- tened after 30 seconds, the buzzer will sound intermittently for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in a different tone for 20 more seconds. AVALON (U)_(OM41440U)
Page 368 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 369 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 370 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 371 This sequence will continue upon subsequent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illu- minated, the system may not be able to detect or signal low tire pres- sure as intended. AVALON (U)_(OM41440U)
Page 372 TPMS (tire pressure warning system) to continue to function properly. NOTICE ■ Precaution when installing a different tire When differently constructed tires or tires of different makers, models or tread patterns are installed, the tire pressure warning system may not operate properly. AVALON (U)_(OM41440U)
Page 373: If A Warning Message Is Displayed
Multi-information display If any of the warning message is shown again after its correction pro- cedure has been performed, contact your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 374: If You Have A Flat Tire
Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ● Shift the shift lever to P. ● Stop the engine. ● Turn on the emergency flashers. (→P. 380) AVALON (U)_(OM41440U)
Page 375 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Luggage floor cover Jack Jack handle Spare tire Tool tray Wheel nut wrench AVALON (U)_(OM41440U)
Page 376 ● Use a jack stand if it is necessary to get under the vehicle. ● When lowering the vehicle, make sure that there is no-one near the vehicle. If there are people nearby, warn them vocally before lowering. AVALON (U)_(OM41440U)
Page 377 7-2. Steps to take in an emergency Taking out the jack and jack handle Remove luggage floor cover. Remove the jack. AVALON (U)_(OM41440U)
Page 378 Remove the tool tray. Loosen the center fastener that secures the spare tire. CAUTION ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle. AVALON (U)_(OM41440U)
Page 379 (one turn). Turn the tire jack portion “A” by hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions. AVALON (U)_(OM41440U)
Page 380 Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. AVALON (U)_(OM41440U)
Page 381 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 382 Install the spare tire and loosely Tapered portion tighten each wheel nut by hand by approximately the same amount. Tighten the wheel nuts until the tapered portion comes into loose Disc wheel contact with the disc wheel seat. seat AVALON (U)_(OM41440U)
Page 383 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. AVALON (U)_(OM41440U)
Page 384 Perform the following steps and fit tire chains to the front tires: Replace a rear tire with the compact spare tire. Replace the flat front tire with the tire removed from the rear of the vehi- cle. Fit tire chains to the front tires. AVALON (U)_(OM41440U)
Page 385 • ABS & Brake assist • Rear view monitor system (if • VSC equipped) • TRAC • Navigation system (if equipped) • Cruise control (if equipped) • Dynamic radar cruise control (if equipped) • PCS (if equipped) • EPS AVALON (U)_(OM41440U)
Page 386 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. AVALON (U)_(OM41440U)
Page 387: If The Engine Will Not Start
The starter motor does not turn over The engine starting system may be malfunctioning due to an electrical problem such as electronic key battery depletion or a blown fuse. However, an interim measure is available to start the engine. (→P. 413) AVALON (U)_(OM41440U)
Page 388 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 418) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 389: If The Shift Lever Cannot Be Shifted From P
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 390: If The Electronic Key Does Not Operate Properly
(→P. 88) in order to perform the following operations: Locks all the doors Unlocks the door Turning rearward unlocks the driver’s door. Turn- ing the key once again within 5 seconds unlocks other doors. ■ Trunk →P. 114 AVALON (U)_(OM41440U)
Page 391 Firmly depress the brake pedal. A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. AVALON (U)_(OM41440U)
Page 392 Make sure that the smart key system has not been deactivated in the cus- tomization setting. If it is off, turn the function on. (Customizable features →P. 453) ● Check if battery-saving mode is set. If it is set, cancel the function. (→P. 99) AVALON (U)_(OM41440U)
Page 393: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 394 ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. AVALON (U)_(OM41440U)
Page 395 ● Make sure that the key is not inside the vehicle when recharging or replac- ing the battery. The key may be locked in the vehicle if the alarm is acti- vated. (→P. 69) AVALON (U)_(OM41440U)
Page 396 ● Do not allow children near the battery. NOTICE ■ When handling jumper cables When connecting the jumper cables, ensure that they do not become entan- gled in the cooling fans or engine drive belt. AVALON (U)_(OM41440U)
Page 397: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 398 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 399 ■ To prevent damage to the cooling system Observe the following precautions: ● Avoid contaminating the coolant with foreign matter (such as sand or dust etc.). ● Do not use commercially available coolant additives. AVALON (U)_(OM41440U)
Page 400: If The Vehicle Becomes Stuck
When shifting the shift lever Be careful not to shift the shift lever with the accelerator pedal depressed. This may lead to unexpected rapid acceleration of the vehicle that may cause an accident resulting in death or serious injury. AVALON (U)_(OM41440U)
Page 401 To avoid damaging the transmission and other components ● Avoid spinning the front wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed. AVALON (U)_(OM41440U)
Page 402: Maintenance Data (Fuel, Oil Level, Etc.)
72.2 in. (1835 mm) Overall height 57.5 in. (1460 mm) Wheelbase 111.0 in. (2820 mm) Front 62.6 in. (1590 mm) Tread Rear 62.2 in. (1580 mm) Vehicle capacity weight 930 lb. (420 kg) (Occupants + luggage) : Unladen vehicle AVALON (U)_(OM41440U)
Page 403 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is located on the top left of the instrument panel.
Page 404 6.0 qt. (5.7 L, 5.0 Imp. qt.) : The engine oil capacity is a reference quantity to be used when changing the engine oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level on the dipstick. AVALON (U)_(OM41440U)
Page 405 8-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 406 8-1. Specifications Cooling system Capacity 9.7 qt. (9.2 L, 8.1 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 407 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. AVALON (U)_(OM41440U)
Page 408 : Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while the engine is running : Parking brake pedal travel when depressed with a force of 67 lbf (300 N, 30.6 kgf). Steering Free play Less than 1.2 in. (30 mm) AVALON (U)_(OM41440U)
Page 409 76 ft•lbf (103 N•m, 10.5 kgf•m) Compact spare tire Tire size T155/70D17 110M Tire inflation pressure (Recommended cold 60 psi (420 kPa, 4.2 kgf/cm or bar) tire inflation pressure) 17 × 4T Wheel size Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m) AVALON (U)_(OM41440U)
Page 410 Door courtesy lights Trunk light A: D4S discharge bulbs B: HB3L+ halogen bulbs C: HB3 halogen bulbs D: H11 halogen bulbs E: Wedge base bulbs (amber) F: Wedge base bulbs (clear) G: Double end bulbs : If equipped AVALON (U)_(OM41440U)
Page 411: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 412 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA's lowest additives concen- tration program.
Page 413 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 414: Tire Information
8-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire AVALON (U)_(OM41440U)
Page 415 An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire. “TEMPORARY USE ONLY” A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded on its sidewall. This tire is designed for temporary emergency use only. AVALON (U)_(OM41440U)
Page 416 Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards. AVALON (U)_(OM41440U)
Page 417 (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter) ■ Tire dimensions Section width Tire height Wheel diameter AVALON (U)_(OM41440U)
Page 418 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer AVALON (U)_(OM41440U)
Page 419 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 420 Warning: The temperature grades of a tire assume that it is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire failure. AVALON (U)_(OM41440U)
Page 421 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 weight that follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below AVALON (U)_(OM41440U)
Page 422 The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between compo- Bead separation nents in the bead AVALON (U)_(OM41440U)
Page 423 Intended outboard molding on the other sidewall of the tire, or sidewall (b) The outward facing sidewall of an asym- metrical tire that has a particular side that must always face outward when mounted on a vehicle AVALON (U)_(OM41440U)
Page 424 Radial ply tire extend to the beads are laid at substantially 90 degrees to the centerline of the tread A tire designed to operate at higher loads and Reinforced tire at higher inflation pressures than the corre- sponding standard tire AVALON (U)_(OM41440U)
Page 425 (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing Table 1 ⎯ Occupant loading and distribution for vehicle normal load for various designated seating capacities AVALON (U)_(OM41440U)
Page 426 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat 2 in front, 2 in second 16 through 20 seat, 2 in third seat, 1 in fourth seat AVALON (U)_(OM41440U)
Page 427: Customizable Features
Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizable features Vehicles with a Display Audio system: Settings that can be changed...
Page 428 106) being unlocked 120 sec- onds Open door warning — — O buzzer Smart key system — — O Smart key sys- Number of permissible → P. 91) times continuous Twice Unlimited — — O smart lock AVALON (U)_(OM41440U)
Page 429 O O O matic door lock function Opening driver's door — O O unlocks all doors Shifting gears O O O unlocks all doors. Shifting gears to posi- tion other than P locks all O O O doors. AVALON (U)_(OM41440U)
Page 430 30 sec- O O O → P. 168) onds turn off after doors are onds closed 90 sec- onds Daytime running light Lights O O O → P. 168, system (except Canada) 172) Automatic high beam — — O AVALON (U)_(OM41440U)
Page 431 — — O approach vehicle with the electronic key on your person Enable/disable opera- tion of the outer foot lights when the doors are — — O unlocked with the power door lock switch AVALON (U)_(OM41440U)
Page 432 In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This may lead to death or a serious health hazard. AVALON (U)_(OM41440U)
Page 433 8-2. Customization NOTICE ■ During customization To prevent battery discharge, ensure that the engine is running while cus- tomizing features. AVALON (U)_(OM41440U)
Page 434: Items To Initialize
• After the maintenance is per- Maintenance data P. 310 formed • When changing the tire size • When changing the tire infla- Tire pressure warning sys- tion pressure by changing P. 336 traveling speed load weight, etc. AVALON (U)_(OM41440U)
Page 435: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 436: Seat Belt Instructions For Canadian Owners (In French)
● Ne vrillez pas la ceinture de sécurité. Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d’eau savon- neuse tiède. Vérifiez régulièrement que les ceintures ne sont pas effilochées, entaillées ou exagérément usées. AVALON (U)_(OM41440U)
Page 437 N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée. Une ceinture de sécurité défectueuse n’apporte aucune garan- tie de protection de l’occupant en cas d’accident. AVALON (U)_(OM41440U)
Page 438: Srs Airbag Instructions For Canadian Owners (In French)
Participent à la protection de la tête et du thorax du conducteur et du passager avant contre les chocs avec les éléments de l’habita- Airbags SRS de genoux Participent à la protection du conducteur et du passager avant AVALON (U)_(OM41440U)
Page 439 Participent à la protection du haut du corps des occupants assis dans les sièges des places arrière extérieures Airbags SRS rideaux Participent principalement à la protection de la tête des occupants assis dans les sièges des places extérieures AVALON (U)_(OM41440U)
Page 440 Airbags rideaux avant Témoins indicateurs “AIR Système de classification de BAG ON” et “AIR BAG OFF” l’occupant du siège passager Capteurs d’impact latéral avant (ECU et capteurs) (avant) Boîtier électronique d’airbags Airbags latéraux arrière AVALON (U)_(OM41440U)
Page 441 Le déploiement rapide des airbags est obtenu au moyen d’une réaction chimique dans les dispositifs pyrotechniques, qui produit un gaz inof- fensif permettant d’amortir le mouvement des occupants. AVALON (U)_(OM41440U)
Page 442 Réglez votre siège selon ces recommandations de la NHTSA, tout en conservant le contrôle des pédales, du volant et la vue des commandes du tableau de bord. AVALON (U)_(OM41440U)
Page 443 être grièvement blessés ou tués par le déploiement d’un airbag. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 444 Ne fixez ni ne posez aucun objet sur la planche de bord, la garniture du volant de direction et la partie inférieure du tableau de bord. Au déploiement des airbags SRS con- ducteur, passager avant et genoux, tout objet risque de se transformer en pro- jectile. AVALON (U)_(OM41440U)
Page 445 ● Si les parties renfermant les airbags SRS, telles que la garniture du volant et les garnitures de montants avant et arrière, sont abîmées ou craque- lées, faites-les remplacer par votre concessionnaire Toyota. AVALON (U)_(OM41440U)
Page 446 ■ Modification et mise au rebut des éléments du système d’airbags SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d’intervenir sur votre véhicule ou de procéder à l’une des modifica- tions suivantes. Les airbags SRS risquent de ne pas fonctionner correcte- ment ou de se déployer (gonfler) accidentellement, provoquant ainsi des...
Page 447 AVALON (U)_(OM41440U)
Page 448 You lose your keys ● If you lose your mechanical keys, new genuine mechanical keys can be made by your Toyota dealer. (→P. 89) ● If you lose your electronic keys, the risk of vehicle theft increases significantly. Contact your Toyota dealer immediately. (→P. 90) The doors cannot be locked or unlocked ●...
Page 449 The trunk lid is closed with the electronic key left inside ● The function to prevent the electronic key from being left inside the trunk will operate and you can open the trunk as usual. Take the key out from the trunk. (→P. 92) AVALON (U)_(OM41440U)
Page 450 If you cannot release the shift lever by depressing the brake pedal with the engine switch in IGNITION ON mode (→P. 414) The steering wheel cannot be turned after the engine is stopped ● It is locked automatically to prevent theft of the vehicle. (→P. 158) AVALON (U)_(OM41440U)
Page 451 Are the driver and the front passenger wearing the seat belts? (→P. 390) ● The brake system warning light is on Is the parking brake released? (→P. 166) Depending on the situation, other types of warning buzzer may also sound. (→P. 387, 398) AVALON (U)_(OM41440U)
Page 452 A warning light turns on or a warning message is dis- played ● When a warning light turns on, refer to P. 387. ● When a warning message is displayed, perform the correction pro- cedure appropriate to the message. AVALON (U)_(OM41440U)
Page 453 Stop the vehicle in a safe place and replace the flat tire with the spare tire. (→P. 399) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow. (→P. 425) AVALON (U)_(OM41440U)
Page 454 S mode ......... 162 conditions ......41 AUX port........253 Side airbag precautions ..36 Auxiliary boxes......261 Side and curtain shield airbags operating conditions ..... 41 Side and curtain shield airbags precautions ....36 SRS airbags......34 AVALON (U)_(OM41440U)
Page 455 Infant seats, definition..... 52 Instrument panel light Infant seats, installation ..58 control........79 Installing CRS BSM (Blind Spot Monitor) ..223 with LATCH anchors .... 56 Installing CRS with seat belts........58 Installing CRS with top tether strap....62 AVALON (U)_(OM41440U)
Page 456 Correct driving posture ... 26 Dynamic radar cruise Driving mode select switch ... 209 control......... 194 Procedures ......138 Cup holders......260 Winter drive tips....232 Curtain shield airbags....34 Dynamic radar cruise Customizable features .... 453 control........194 AVALON (U)_(OM41440U)
Page 457 Event data recorder (EDR)..10 is wrong ......385 If your vehicle becomes stuck ........425 If your vehicle has to be stopped in an emergency ... 381 If your vehicle needs to be towed......382 If your vehicle overheats..422 AVALON (U)_(OM41440U)
Page 458 ........ 117 Gauges ........77 Seat heaters ......274 Glove box ......... 258 Seat position memory ... 118 Grocery bag hooks....266 Seat ventilators ..... 274 Front side marker lights..168 Light switch ......168 Replacing light bulbs..... 375 AVALON (U)_(OM41440U)
Page 459 Coat hooks......281 Interior lights ......254 Grocery bag hooks ....266 Retaining hooks (floor mat)..24 Jack Positioning a floor jack..320 Vehicle-equipped jack ..400 Jack handle......400 Jam protection function Moon roof ......134 Power windows..... 131 AVALON (U)_(OM41440U)
Page 460 LATCH anchors ......56 Luggage net ......266 Lever Luggage security system ..113 Auxiliary catch lever....319 Hood lock release lever ..319 Internal trunk release lever ... 113 Shift lever......161 Turn signal lever ....165 Wiper lever......179 AVALON (U)_(OM41440U)
Page 461 Multi-information display..80 Cruise control......190 Dynamic radar cruise control......... 194 Language........ 83 Switching the display ....81 Trip information....... 81 Warning message....398 : For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”. AVALON (U)_(OM41440U)
Page 462 Electronic key battery ... 350 Pre-Collision System (PCS)..216 Fuses........352 Function ........ 216 Light bulbs ......361 PCS OFF switch ....217 Tires........399 Warning light......389 Reporting safety defects for U.S. owners...... 462 Reset the maintenance data... 310 AVALON (U)_(OM41440U)
Page 463 Automatic transmission ..161 Seating capacity ...... 152 If the shift lever cannot be shifted from P ..414 Shift lock system..... 414 Side airbags ....... 34 Side marker lights ....168 Light switch......168 Replacing light bulbs .... 375 AVALON (U)_(OM41440U)
Page 464 Storage feature ......257 Light switches ....... 168 Moon roof switches....133 Outside rear view mirror switches ......127 Paddle shift switches .... 162 PCS OFF switch ....217 Power door lock switch..109 Power window switches..130 AVALON (U)_(OM41440U)
Page 465 179 Grading ......445 Tire pressure warning system........335 Function........ 335 Initializing......335 Installing tire pressure warning valves and transmitters ..335 Registering ID codes .... 337 Tire pressure warning reset switch ......... 336 Warning light......391 AVALON (U)_(OM41440U)
Page 466 Paddle shift switches .... 162 Vehicle data recording....9 S mode ......... 162 Vehicle identification Trip information ......81 number........429 Trip meters ......... 77 Vehicle Stability Control (VSC) ........211 Ventilators (seat ventilators) ....274 (Vehicle Stability Control) ..211 AVALON (U)_(OM41440U)
Page 467 .......... 106 Tire pressure......391 Battery-Saving Function ..99 Warning messages....398 Locking/Unlocking ....106 Washer........179 Replacing the battery.... 350 Checking....... 333 Preparing and checking before winter....... 232 Switch ........179 Washing and waxing ....302 AVALON (U)_(OM41440U)
Page 468: Gas Station Information
Fuel tank capacity 17.0 gal. (64.35 L, 14.2 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P. 185, 430 Cold tire inflation P. 435 pressure Engine oil capacity (Drain and refill — P. 430 reference) Engine oil type P. 430 AVALON (U)_(OM41440U)
