Page 3 Search by illustration Pictorial index For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of warning lights and indicators, etc. cluster Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 4 TABLE OF CONTENTS For your information .......6 Operation of each Reading this manual.....10 component How to search ......11 Pictorial index .......12 3-1. Key information Keys ........106 For safety and security 3-2. Opening, closing and locking the doors Doors......... 110 1-1.
Page 5 4-5. Using the driving Driving support systems Toyota Safety Sense..198 4-1. Before driving (Pre-Collision System) ..204 Driving the vehicle .....154 Cargo and luggage ....162 (Lane Departure Alert Trailer towing .....163 with steering control)..217 4-2. Driving procedures Dynamic radar cruise Engine (ignition) switch..164...
Page 6 TABLE OF CONTENTS Interior features Maintenance and care 5-1. Using the 6-1. Maintenance and care Cleaning and protecting air conditioning the vehicle exterior..332 system and defogger Automatic air conditioning Cleaning and protecting system ......296 the vehicle interior... 335 Seat heaters/ 6-2.
Page 7 ........430 For vehicles with a multimedia system or navigation system, refer to the “Navigation and Multimedia System Owner’s Manual” for infor- mation regarding the equipment listed below. • Navigation system • Toyota parking assist monitor • Audio/visual system AVALON_GE AVALON_OM_General_OM41476E...
Page 8 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and acces-...
Page 9 ●Anti-lock brake system ●SRS airbag system ●Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail- able on request at your Toyota dealer.
Page 10 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 11 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 12 Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 13 How to search ■ Searching by name • Alphabetical index ..P. 460 ■ Searching installation position • Pictorial index....P. 12 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 456 ■ Searching by title •...
Page 14 Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 110 Locking/unlocking .
Page 15 Pictorial index Windshield wipers ....... . . P. 190 Precautions for winter season ......P. 287 Fuel filler door .
Page 16 Pictorial index ■ Instrument panel Engine switch ........P. 164 Starting the engine/changing the positions or modes .
Page 17 Pictorial index Parking brake switch....... P. 175 Applying/releasing ......P. 175, 176 Precautions for winter season .
Page 18 Pictorial index ■ Switches Automatic High Beam switch ..... . . P. 185 VSC OFF switch........P. 282 Trunk opener switch .
Page 19 Pictorial index Driving position memory switches ....P. 131 Driving position memory ......P. 131 Outside rear view mirror switch.
Page 20 Pictorial index Meter control switches ......P. 79 Vehicle-to-vehicle distance switch .
Page 21 Pictorial index ■ Interior SRS airbags ........P. 32 Floor mats .
Page 22 Pictorial index Interior lights/personal lights ..... . P. 306 Moon roof switches ......P. 149 Vanity mirrors .
Page 23 For safety and security 1-1. For safe use Before driving.......22 For safe driving ....24 Seat belts......26 SRS airbags......32 Front passenger occupant classification system .......44 Safety information for children ......49 Child restraint systems ..50 Installing child restraints ..54 Exhaust gas precautions ..62 1-2.
Page 24 1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 25 When installing the driver’s floor mat Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver’s seat. ● Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 26 1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust angle seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 27 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’s seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback.
Page 28 1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 29 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 30 ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation. ■ Rear seat belt Use the seat belt after passing it through the guide if the seat belt comes free from the guide.
Page 31 Each seat belt should be used by one person only. Do not use a seat belt ● for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always ● use a seat belt and/or an appropriate child restraint system.
Page 32 If the pretensioner has activated, the SRS warning light will come on. In ● that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 33 Ensure that the belt and plate are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 34 1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 35 1-1. For safe use ◆ SRS side and curtain shield airbags SRS front side airbags Can help protect the torso of the front seat occupants SRS rear side airbags Can help protect the torso of occupants in the rear outer seats SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats...
Page 36 1-1. For safe use SRS airbag system components Front impact sensors “AIR BAG ON” and “AIR BAG OFF” indicator lights Front passenger occupant classification system (ECU SRS warning light and sensors) Airbag sensor assembly Knee airbags Side impact sensors (rear) Side impact sensors (front Driver airbag doors)
Page 37 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 38 1-1. For safe use WARNING ■ SRS airbag precautions Do not sit on the edge of the seat or ● lean against the dashboard. Do not allow a child to stand in front of ● the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 39 1-1. For safe use WARNING ■ SRS airbag precautions Do not attach anything to or lean any- ● thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Page 40 If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. Do not place anything, such as a cushion, on the front passenger’s seat. ●...
Page 41 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 42 1-1. For safe use ■ If the SRS airbags deploy (inflate) ●Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ●A loud noise and white powder will be emitted. ●Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes.
Page 43 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 44 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 45 When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ●Any of the SRS airbags have been inflated. ●The front of the vehicle is damaged or...
Page 46 1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag and front passenger knee airbag. Driver’s and front passenger’s seat belt reminder light SRS warning light...
Page 47 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Driver’s and front passenger’s seat belt reminder light flashing Front passenger airbag...
Page 48 1-1. For safe use ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Driver’s and front passenger’s seat belt reminder light Front passenger airbag Devices Deactivated Front passenger knee airbag ■...
Page 49 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted ●...
Page 50 SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the ●...
Page 51 1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 52 ● For installation details, follow the instructions provided with the child restraint system. General installation instructions are provided in this manual. (P. 54) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. AVALON_GE AVALON_OM_General_OM41476E...
Page 53 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Baby seat (infant seat) Child seat (convertible seat)   Junior seat (booster seat) ...
Page 54 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 55 1-1. For safe use WARNING ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 56 1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mechanism...
Page 57 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the...
Page 58 1-1. For safe use Place the child restraint sys- tem on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and allow it to retract to put it in lock mode.
Page 59 1-1. For safe use ■ Junior seat (booster seat) Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions...
Page 60 1-1. For safe use Installation with ISOFIX rigid anchor Install the child restraint system in accordance to the operation man- ual enclosed with the child restraint system. If the head restraint interferes with the child restraint sys- tem installation and the head restraint can be removed, remove the head restraint.
Page 61 1-1. For safe use If the child restraint has a top tether strap, follow the child restraint manufacturer’s operation manual regarding the installa- tion, using the top tether strap to latch onto the top tether strap anchor. (P. 59) After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
Page 62 1-1. For safe use WARNING ■ When installing a junior seat (booster seat) To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child.
Page 63 When installing a child restraint system If child restraint system regulations exist in the country where you reside, ● please contact your Toyota dealer for the child restraint system installation. When a junior (booster) seat is installed, always ensure that the shoulder ●...
Page 64 Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, ● open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking If the vehicle is in a poorly ventilated area or a closed area, such as a ●...
Page 65 1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 66 1-2. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 67 1-2. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ●Nobody is in the vehicle. ●The windows and moon roof (if equipped) are closed before the alarm is set.
Page 68 1-2. Theft deterrent system ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ●When a person remaining in the vehicle unlocks the door and the alarm is activated.
Page 69 Instrument cluster Instrument cluster Warning lights and indicators ......68 Gauges and meters .....74 Multi-information display ..77 Head-up display....94 Fuel consumption information.......101 AVALON_GE AVALON_OM_General_OM41476E...
Page 70 2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster, cen- ter panel and outside rear view mirrors inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 71 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Parking brake indicator light (P. 394) (P. 395) (Red) 1, 3 Brake system warning Brake hold operated light (P. 394) indicator (P.
Page 72 There may be a mal- function in a system if a light does not come on, or turn off. Have the vehi- cle inspected by your Toyota dealer. : This light illuminates on the multi-information display.
Page 73 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Brake hold standby (P. 174) indicator (P. 179) Tail light indicator Cruise control indicator (P. 181) (P. 228, 255) Dynamic radar cruise Headlight high beam control indicator...
Page 74 2. Instrument cluster 1, 5 Slip indicator Security indicator (P. 282) (P. 63, 64) Toyota parking assist- 1, 4 VSC OFF indicator sensor indicator (P. 283) (P. 271) (if equipped) “BSM” indicator Smart entry & start sys- (P. 260) tem indicator (P. 164) (if equipped) “RCTA”...
Page 75 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 76 2. Instrument cluster Gauges and meters Tachometer Displays the engine speed in revolutions per minute Shift position (P. 169) Outside temperature Displays the outside temperature within the range of -40°C (-40°F) to 50°C (122°F). Low outside temperature indicator comes on when the ambient temperature is 3°C (37°F) or lower.
Page 77 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. The brightness of some of the interior lights will be changed when the brightness of the instrument panel lights is adjusted. (P. 306) Darker Brighter •...
Page 78 ●When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) ●When “” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. NOTICE ■ To prevent damage to the engine and its components Do not let the indicator needle of the tachometer enter the red zone, which ●...
Page 79 2. Instrument cluster Multi-information display Summary of functions The multi-information display presents the driver with a variety of driv- ing-related data, such as the current outside temperature. The multi- information display can also be used to change the display settings and other settings.
Page 80 2. Instrument cluster Content display area A variety of information can be displayed by selecting a menu icon. Addi- tionally, warning or suggestion/advice pop-up displays will be displayed in some situations. • Menu icon content (P. 80) • Suggestion function (P. 91) •...
Page 81 2. Instrument cluster Using the multi-information display ◆ Using the content display area The content display area is operated using the meter control switches. Scroll screens , change the displayed content and move the cursor Press: Enter/Set Press and hold: Reset/Dis- play the next screen Return previous...
Page 82 Select to perform the following: Enable/Disable the following systems: • Parking assist (Toyota parking assist-sensor) (if equipped) (P. 271) • BSM (Blind Spot Monitor) function (if equipped) (P. 260) • RCTA (Rear Cross Traffic Alert) function (if equipped) (P. 260) These functions can also be enabled/disabled on Settings display (P.
Page 83 2. Instrument cluster Warning message display (P. 402) Select to display warning messages and measures to be taken if a mal- function is detected. AVALON_GE AVALON_OM_General_OM41476E...
Page 84 2. Instrument cluster Driving information ( ■ Speedometer/driving range • Speedometer • Driving range Displays the driving range with remaining fuel. When only a small amount of fuel is added to the tank, the display may not be updated. When refueling, turn the engine switch off. If the vehicle is refueled with- out turning the engine switch off, the display may not be updated.
Page 85 2. Instrument cluster Gadget The following items can be displayed by changing the settings for gad- get content and fuel economy type on . (P. 85) Displayable item Content Gadget Fuel economy content type Trip Displays the average vehicle speed since Average (after start) engine start.
Page 86 2. Instrument cluster : Use the displayed fuel consumption as a reference only. : When only a small amount of fuel is added to the tank, the display may not be updated. When refueling, turn the engine switch off. If the vehicle is refueled with- out turning the engine switch off, the display may not be updated.
Page 87 2. Instrument cluster Settings display ( ◆ Changing settings Use the meter control switches on the steering wheel to change settings. Press to select Operate the switches to select a desired item. Press or press and hold The available settings will differ depending on if is pressed or pressed and held.
Page 88 2. Instrument cluster ■ PCS (Pre-Collision System) (if equipped) (P. 204) Press to enable/disable the pre-collision system. Item Settings Details Select to enable/disable the pre- collision system. Press and hold to change the settings of the following item: Item Settings Details (Far) Warning sensitivity...
Page 89 Settings Details (Low) RCTA buzzer vol- Select to change the volume of (Medium) the RCTA buzzer. (Loud) ■ Parking assist (Toyota parking assist-sensor) (if equipped) (P. 271) Press to enable/disable the Toyota parking assist-sensor. Item Settings Details Toyota parking Select...
Page 90 2. Instrument cluster ■ HUD (Head-up display) (if equipped) (P. 94) Press to enable/disable the head-up display. Item Settings Details Select enable/disable head-up display. Press and hold to change the settings of the following items: Item Settings Details Select to adjust the brightness/ position of the head-up display.
Page 91 ID code tem sensor ID codes must be set) registered by a Toyota dealer. For information regarding chang- ing the registered ID code set, contact your Toyota dealer. (P. 367)
Page 92 2. Instrument cluster ■ Meter settings Press and hold to change the settings of the following items: Item Settings Details Select to change the language Language displayed. Select to change the units of Units measure displayed. Select to enable/disable the Eco (Eco Driving Driving Indicator Light.
Page 93 2. Instrument cluster Odometer/trip meter ■ Odometer Displays the total distance the vehicle has been driven. ■ Trip meter A/trip meter B Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and dis- play different distances independently.
Page 94 2. Instrument cluster ■ Suggestion to close the power windows (linked to vehicle speed) If the vehicle is driven at high speeds for a certain amount of time with a power window open, a suggestion message will be displayed asking if you wish to close the power windows. To close all of the power windows, select “Yes”.
Page 95 2. Instrument cluster ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal displays, and there is no problem continuing to use the display. ■ Customization Some functions can be customized. (P. 85, 445) WARNING ■...
Page 96 2. Instrument cluster  Head-up display Summary of functions The head-up display is linked to the meters and navigation system and projects a variety of information in front of the driver, such as the current vehicle speed. Driving assist system status/navigation system-linked display area (P.
Page 97 2. Instrument cluster Using the head-up display Select on the multi-information display (P. 85) and then ◆ Enabling/disabling the head-up display Press to enable/disable the head-up display. ◆ Changing the head-up display settings Press and hold to change the following settings: ■...
Page 98 • Dynamic radar cruise control (if equipped) (P. 242) • LDA (Lane Departure Alert with steering control) (if equipped) (P. 217) • Toyota parking assist-sensor (if equipped) (P. 271) ◆ Navigation system-linked display area Displays the following items, which are linked to the navigation sys- tem: ■...
Page 99 2. Instrument cluster Eco Driving Indicator/Tachometer ■ Eco Driving Indicator Eco Driving Indicator Zone Display Eco driving ratio based on acceleration Zone of Eco driving Displayed content is the same as that displayed on the multi- information display (Eco Driving Indicator).
Page 100 2. Instrument cluster Information display area Displays the following items in the appropriate situation: ■ Warning/Message ● Alert from the LDA (Lane Departure Alert with steering control) (if equipped) ● Dynamic radar cruise control with full-speed range (if equipped) ● Dynamic radar cruise control (if equipped) message ●...
Page 101 2. Instrument cluster ■ Head-up display The head-up display may seem dark or hard to see when viewed through sunglasses, especially polarized sunglasses. Adjust the brightness of the head-up display or remove your sunglasses. ■ Display brightness The brightness of the head-up display can be adjusted on of the multi- information display.
Page 102 2. Instrument cluster NOTICE ■ To prevent damage to components Do not place any drinks near the head- ● up display projector. If the projector gets wet, electrical malfunctions may result. Do not place anything on or put stickers ● onto the head-up display projector.
Page 103 2. Instrument cluster Fuel consumption information Fuel consumption information can be displayed on the audio system screen. Trip information Without navigation function  Press the “INFO” button. If the “History” screen is displayed, select “Trip information”. AVALON_GE AVALON_OM_General_OM41476E...
Page 104 2. Instrument cluster With navigation function  Press the “MENU” button. Select “Information” on the “Menu” screen. If the “History” screen is displayed, select “Trip information”. Resetting the consumption data Average vehicle speed since the engine was started Elapsed time since engine was started Fuel consumption in the past...
Page 105 2. Instrument cluster History Without navigation function  Press the “INFO” button. If the “History” screen is displayed, select “Trip information”. With navigation function  Press the “MENU” button. Select “Information” on the “Menu” screen. If the “Trip information” screen is displayed, select “History”. Resetting the past record data Best recorded fuel consump-...
Page 106 2. Instrument cluster ■ Updating the past record data Update the average fuel consumption by selecting “Clip” to measure the cur- rent fuel consumption again. ■ Resetting the data The fuel consumption data can be deleted by selecting “Clear”. ■ Cruising range Displays the estimated maximum distance that can be driven with the quan- tity of fuel remaining.
Page 107 Operation of each component 3-1. Key information Keys........106 3-2. Opening, closing and locking the doors Doors .........110 Trunk........116 Smart entry & start system .....120 3-3. Adjusting the seats Front seats......127 Rear seats ......129 Driving position memory ..131 Head restraints ....136 3-4.
Page 108 3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (P. 120) • Operating the wireless remote control function (P. 106) Mechanical keys Key number plate Wireless remote control Locks all the doors (P.
Page 109 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 110 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
Page 111 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. AVALON_GE AVALON_OM_General_OM41476E...
Page 112 3-2. Opening, closing and locking the doors Doors Unlocking and locking the doors from the outside ◆ Smart entry & start system Carry the electronic key to enable this function. Grip the front door handle to unlock all the doors. Make sure to touch the sensor on the back of the handle.
Page 113 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Windows and moon roof: A buzzer sounds to indicate that the windows and moon roof are operating. ■...
Page 114 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switches Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 115 3-2. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 116 3-2. Opening, closing and locking the doors ■ Switching the door unlock function It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 117 3-2. Opening, closing and locking the doors ■ Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (P. 419) ■ Conditions affecting the operation of the smart entry & start system or wireless remote control P.
Page 118 3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener switch, entry function or wireless remote control. Opening the trunk from inside the vehicle Press the trunk opener switch. Opening the trunk from outside the vehicle ◆...
Page 119 3-2. Opening, closing and locking the doors ◆ Wireless remote control Press and hold the switch. A buzzer sounds. ■ Trunk light The trunk light turns on when the trunk is opened. ■ Function to prevent the trunk being locked with the electronic key inside ●When all doors are locked, closing the trunk lid with the electronic key left inside the trunk will sound an alarm.
Page 120 3-2. Opening, closing and locking the doors ■ Using the mechanical key The trunk can be also opened using the mechanical key. (P. 419) ■ If the smart entry & start system or the wireless remote control does not operate properly Use the mechanical key to unlock the trunk.
Page 121 When closing the trunk lid, make sure to ● press it lightly on its outer surface. Do not attach any accessories other than genuine Toyota parts to the trunk ● lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 122 3-2. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 123 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate mea- sures in response to any warning message on the multi-information display.
Page 124 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ●In the following situations, the smart entry &...
Page 125 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system, wireless remote control and engine immobi- lizer system use weak radio waves. In the following situations, the communi- cation between the electronic key and the vehicle may be affected, preventing the smart entry &...
Page 126 3-2. Opening, closing and locking the doors ■ Note for the entry function ●Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 127 ●Fingernails may scrape against the door during operation of the door han- dle. Be careful not to injure fingernails or damage the surface of the door. : This setting can be customized at your Toyota dealer. ■ When the vehicle is not driven for extended periods ●To prevent theft of the vehicle, do not leave the electronic key within 2 m (6...
Page 128 & start system antennas. (P. 120) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 129 3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Lumbar support firmness adjustment switch (if equipped) Lumbar support height adjust- ment switch (if equipped) ■...
Page 130 3-3. Adjusting the seats WARNING ■ When adjusting the seat position Take care when adjusting the seat position to ensure that other passen- ● gers are not injured by the moving seat. Do not put your hands under the seat or near the moving parts to avoid ●...
Page 131 3-3. Adjusting the seats Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Pull the seatback lever in the trunk for the seatback you wish to fold down and then fold the seatback down.
Page 132 3-3. Adjusting the seats WARNING ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift ●...
Page 133 3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat, steering wheel and outside rear view mirrors to make entering and exit- ing the vehicle easier or to suit your preferences. Power easy access system The seat and steering wheel are automatically adjusted to allow the driver to enter and exit the vehicle easily.
Page 134 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory. ■...
Page 135 3-3. Adjusting the seats ■ To stop the position recall operation part-way through Perform any of the following operations: ●Press the “SET” button. ●Press button “1” or “2”. ●Operate any of the seat adjustment switches (only cancels seat position recall). ●Operate the tilt and telescopic steering control switch (only cancels steering wheel position recall).
Page 136 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. ■ Registering procedure Record your driving position to button 1 or 2 before performing the following: Carry only the key you want to register, and then close the driver’s door.
Page 137 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
Page 138 3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats and rear outboard seats  Pull the head restraint up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear center seat ...
Page 139 3-3. Adjusting the seats ■ Installing the head restraints Front seats  Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. Lock release button Rear outboard seats...
Page 140 3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Manual type  Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 141 3-4. Adjusting the steering wheel and mirrors Horn To sound the horn, press on or close to the mark. ■ The steering wheel can be adjusted when (power type) The engine switch is in ACCESSORY or IGNITION ON mode. ■ Automatic adjustment of the steering position (vehicles with driving position memory) A desired steering position can be entered to memory and recalled automati-...
Page 142 3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 143 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 144 3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, operate the switch. Right Down Left Folding and extending the mirrors Folds the mirrors Extends the mirrors Putting the outside rear view mirror folding switch in the neutral posi-...
Page 145 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (vehicles with driving position memory) When the mirror select switch is in the “L” or “R” position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 146 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 147 3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 148 1 second or more. If you release the switch while the window is moving, start again from the beginning. If the window reverses and cannot be fully closed or opened, have the vehicle inspected by your Toyota dealer. AVALON_GE AVALON_OM_General_OM41476E...
Page 149 Door lock linked window operation The power windows can be opened and closed using the mechanical key. (P. 419) : This setting must be customized at your Toyota dealer. ■ Alarm The alarm may be triggered if the alarm is set and a power window is closed using the door lock linked power window operation function.
Page 150 3-5. Opening and closing the windows WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Opening and closing the windows The driver is responsible for all the power window operations, including the ●...
Page 151 3-5. Opening and closing the windows  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 152 ■ Door lock linked moon roof operation The moon roof can be opened and closed using the mechanical key. (P. 419) : This setting must be customized at your Toyota dealer. AVALON_GE AVALON_OM_General_OM41476E...
Page 153 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. ■ Alarm The alarm may be triggered if the alarm is set and the moon roof is closed using the door lock linked moon roof operation function.
Page 154 3-5. Opening and closing the windows WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 155 Driving 4-1. Before driving 4-5. Using the driving Driving the vehicle .....154 support systems Toyota Safety Sense ..198 Cargo and luggage ....162 Trailer towing .....163 (Pre-Collision System)..204 4-2. Driving procedures Engine (ignition) switch..164 (Lane Departure Alert Automatic transmission ..169 with steering control) ..217 Turn signal lever ....174...
Page 156 4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 164 Driving With the brake pedal depressed, shift the shift lever to D. (P. 169) Release the parking brake. (P. 175) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 157 4-1. Before driving Starting off on a steep uphill Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. ■ When starting off on a uphill The hill-start assist control will activate.
Page 158 4-1. Before driving ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●For the first 300 km (186 miles): Avoid sudden stops. ●For the first 1000 km (621 miles): •...
Page 159 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
Page 160 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 161 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is stopped Do not race the engine. ● If the shift lever is any position other than P or N, the vehicle may acceler- ate suddenly and unexpectedly, causing an accident.
Page 162 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked Always apply the parking brake, shift the shift lever to P, stop the engine ● and lock the vehicle.
Page 163 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: Brake function ● Changes in quantity and quality of oil and fluid used for the engine, ●...
Page 164 4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: WARNING ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: Receptacles containing gasoline ●...
Page 165 Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 166 4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 167 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. The multi-information display will not be displayed.
Page 168 If the engine does not start ●The engine immobilizer system may not have been deactivated. (P. 63) Contact your Toyota dealer. ●Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 169 4-2. Driving procedures ■ If the electronic key battery is depleted P. 379 ■ Operation of the engine switch ●It the switch is not pressed shortly and firmly, the engine switch mode may not change or the engine may not start. ●If attempting to restart the engine immediately after turning the engine switch off, the engine may not start in some cases.
Page 170 ● If the engine becomes difficult to start or stalls frequently, have your vehi- ● cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 171 4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in IGNITION ON mode and the brake pedal depressed , shift the shift lever while pushing the shift release button on the shift knob. Shift the shift lever while pushing the shift release button on the shift knob.
Page 172 4-2. Driving procedures Shift position purpose Shift position Objective or function Parking the vehicle/starting the engine Reversing Neutral Normal driving S mode driving (P. 170) : Shifting to the D position allows the system to select a gear suitable for the driving conditions.
Page 173 4-2. Driving procedures ■ S mode ●When the shift range is 7 or lower, holding the shift lever toward “+” sets the shift range to 8. ●To prevent the engine from over-revving, upshifting may automatically occur. ●To protect the automatic transmission, a function is adopted that automati- cally selects a higher shift range when the fluid temperature is high.
Page 174 If the shift lever cannot be shifted even though the brake pedal is depressed and the shift release button is pushed, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 175 4-2. Driving procedures WARNING ■ When driving on slippery road surfaces Do not accelerate or shift gears suddenly. Sudden changes in engine braking may cause the vehicle to spin or skid, resulting in an accident. ■ To prevent an accident when releasing the shift lock Before pressing the shift lock override button, make sure to set the parking brake and depress the brake pedal.
Page 176 4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 177 4-2. Driving procedures Parking brake A mode can be selected from the following modes. Automatic mode The parking brake is set or released automatically according to the shift lever operation. Even when in automatic mode, the parking brake can be set and released manually.
Page 178 4-2. Driving procedures Manual mode The parking brake can be set and released manually. Sets the parking brake The parking brake indicator light and parking brake light will turn on. Pull and hold the parking brake switch if an emergency occurs and it is necessary to operate the park- ing brake while driving.
Page 179 Operate the parking brake switch. If the message does not disappear after operating the switch several times, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Parking brake operation sound When the parking brake operates, a motor sound (whirring sound) may be heard.
Page 180 When the parking brake cannot be released due to a malfunction Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear. Contact your Toyota dealer immediately if this occurs. AVALON_GE AVALON_OM_General_OM41476E...
Page 181 4-2. Driving procedures Brake Hold The brake hold system keeps the brake applied when the shift lever is in D, S or N with the system on and the brake pedal has been depressed to stop the vehicle. The system releases the brake when the accelerator pedal is depressed with the shift lever in D or S to allow smooth start off.
Page 182 Make sure that the parking brake indicator light goes off. (P. 175) ■ When an inspection at your Toyota dealer is necessary When the brake hold standby indicator (green) does not illuminate even when the brake hold switch is pressed with the brake hold system operating condi- tions met, the system may be malfunctioning.
Page 183 4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows: The headlights, day- time running lights (  183) and all the lights listed below turn on and off automatically.
Page 184 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 185 4-3. Operating the lights and wipers ■ Daytime running light system ●Type A: To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the engine is started and the parking brake is released with the headlight switch off or in the position.
Page 186 4-3. Operating the lights and wipers ■ Welcome lighting If the headlight switch is turned to and the surrounding area is dark, unlocking the doors using the smart entry & start system or wireless remote control will turn the front position lights and tail lights on automatically. ■...
Page 187 4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses a camera sensor located behind the upper portion of the windshield to assess the brightness of the lights of vehicles ahead, streetlights, etc., and automatically turns the high beams on or off as necessary.
Page 188 4-3. Operating the lights and wipers Turning the high beams on/off manually ■ Switching to the low beams Pull the lever to its original posi- tion. The Automatic High Beam indi- cator will turn off. Push the lever away from you to activate the Automatic High...
Page 189 4-3. Operating the lights and wipers ■ Conditions to turn the high beams on/off automatically ●When all of the following conditions are met, the high beams will be turned on automatically (after approximately 1 second): • The vehicle speed is approximately 30 km/h (25 mph) or more. •...
Page 190 4-3. Operating the lights and wipers ●In the following situations the system may not be able to correctly detect the surrounding brightness level. This may cause the low beams to remain on or the high beams to flash or dazzle pedestrians or vehicles ahead. In such a case, it is necessary to manually switch between the high and low beams.
Page 191 4-3. Operating the lights and wipers Fog light switch A fog light secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Turns the rear fog light Turns the rear fog light ■ Rear fog light can be used when The headlights or front position lights are turned on.
Page 192 4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows: When intermittent windshield wiper operation is selected, wiper inter- val can be also adjusted. Intermittent windshield wiper operation The intermittent wind- shield wiper operates...
Page 193 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. AVALON_GE AVALON_OM_General_OM41476E...
Page 194 4-3. Operating the lights and wipers Changing the windshield wiper rest position/Lifting the wind- shield wipers When the windshield wipers are not being used, they retract to below the hood. To enable the windshield wipers to be lifted when parking in cold conditions or when replacing a windshield wiper insert, change the rest position of the windshield wipers to the service position using the wiper lever.
Page 195 4-3. Operating the lights and wipers ■ Lowering the windshield wipers to the retracted position With the windshield wipers placed on the windshield, turn the engine switch to IGNITION ON mode and then move the wiper lever to an operating posi- tion.
Page 196 ● Confirm the type of fuel. ■ Fuel types P. 436, 444 ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. AVALON_GE AVALON_OM_General_OM41476E...
Page 197 4-4. Refueling WARNING ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. After exiting the vehicle and before opening the fuel door, touch an ● unpainted metal surface to discharge any static electricity.
Page 198 4-4. Refueling Opening the fuel tank cap Press the opener to open the fuel filler door. Turn the fuel tank cap slowly to remove it and hang it on the back of the fuel filler door. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click.
Page 199 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 200 ■ Toyota Safety Sense The Toyota Safety Sense is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 201 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 202 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor AVALON_GE AVALON_OM_General_OM41476E...
Page 203 Do not subject the radar sensor or surrounding area to a strong impact. ● If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. Do not disassemble the radar sensor. ●...
Page 204 ● Replace the windshield if it is damaged or cracked. ● If the windshield needs to be replaced, contact your Toyota dealer. Do not get the camera sensor wet. ● Do not allow bright lights to shine into the camera sensor.
Page 205 Do not attach any accessories that may obstruct the camera sensor to the ● hood, front grille or front bumper. Contact your Toyota dealer for details. If a surfboard or other long object is to be mounted on the roof, make sure ●...
Page 206 The countries and areas for each region listed in the table are cur- rent as of August 2019. However, depending on when the vehicle was sold, the countries and areas of each region may be different. Contact your Toyota dealer for details.  : If equipped...
Page 207 4-5. Using the driving support systems ◆ Pre-collision warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 208 4-5. Using the driving support systems WARNING ■ Limitations of the pre-collision system The driver is solely responsible for safe driving. Always drive safely, taking ● care to observe your surroundings. Do not use the pre-collision system instead of normal braking operations under any circumstances.
Page 209 4-5. Using the driving support systems WARNING ■ When to disable the pre-collision system In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: When the vehicle is being towed ●...
Page 210 4-5. Using the driving support systems Changing settings of the pre-collision system ■ Enabling/disabling the pre-collision system The pre-collision system can be enabled/disabled on (P. 85) of the multi-information display. The system is automatically enabled each time the engine switch is turned to IGNITION ON mode.
Page 211 4-5. Using the driving support systems ■ Operational conditions Availability of the pedestrian detection function depends on the region in which the vehicle was sold. (For specific countries/areas: P. 204) Read the following for details: Region A  (The pedestrian detection function is available) The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle or pedestrian is high.
Page 212 4-5. Using the driving support systems Region B  (The pedestrian detection function is not available) The pre-collision system is enabled and the system determines that the pos- sibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: ●Pre-collision warning: •...
Page 213 4-5. Using the driving support systems ■ Conditions under which the system may operate even if there is no pos- sibility of a collision ●In some situations such as the following, the system may determine that there is a possibility of a frontal collision and operate. •...
Page 214 4-5. Using the driving support systems • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge • When there is a metal object (manhole cover, steel plate, etc.), steps, or a protrusion on the road surface or roadside •...
Page 215 4-5. Using the driving support systems • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead • When driving through steam or smoke • When there are patterns or paint on the road or a wall that may be mis- taken for a vehicle or pedestrian •...
Page 216 4-5. Using the driving support systems • When a vehicle ahead is not directly in front of your vehicle • When driving in inclement weather such as heavy rain, fog, snow or a sandstorm • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead •...
Page 217 4-5. Using the driving support systems ●Some pedestrians such as the following may not be detected by the radar sensor and camera sensor, preventing the system from operating prop- erly • Pedestrians shorter than approximately 1 m (3.2 ft.) or taller than approx- imately 2 m (6.5 ft.) •...
Page 218 ●If the PCS warning light continues to flash or remains illuminated or the warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled ●If VSC is disabled (P.
Page 219 4-5. Using the driving support systems LDA (Lane Departure Alert with steering  control) Summary of functions When driving on highways and freeways with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane and provides assistance by operating the steering wheel to keep the vehicle in its lane.
Page 220 4-5. Using the driving support systems Functions included in LDA system ◆ Lane departure alert function When the system determines that the vehicle might depart from its lane, a warning is dis- played on the multi-information display and the warning buzzer sounds to alert the driver.
Page 221 4-5. Using the driving support systems ◆ Steering control function When the system determines that the vehicle might depart from its lane, the system pro- vides assistance as necessary by operating the steering wheel in small amounts for a short period of time to keep the vehi- cle in its lane.
Page 222 4-5. Using the driving support systems ◆ Vehicle sway warning function When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 223 Toyota dealer. Do not install or place anything on the hood or grille. Also, do not install a ● grille guard (bull bars, kangaroo bar, etc.). If your windshield needs repairs, contact your Toyota dealer. ● AVALON_GE AVALON_OM_General_OM41476E...
Page 224 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates and a message is displayed on the multi-information display. Press the LDA switch again to turn the LDA system off.
Page 225 4-5. Using the driving support systems Indications on multi-information display The illustration used is intended as an example, and may differ from the image that is actually displayed on the multi-information display. LDA indicator The illumination condition of the indicator informs the driver of the system operation status.
Page 226 4-5. Using the driving support systems ■ Operation conditions of each function ●Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 50 km/h (32 mph) or more. •...
Page 227 4-5. Using the driving support systems ■ Temporary cancellation of functions When the operation conditions are no longer met, a function may be tempo- rarily canceled. However, when the operation conditions are met again, oper- ation of the function is automatically restored. (P. 224) ■...
Page 228 4-5. Using the driving support systems ■ White (yellow) lines are only on one side of road The LDA system will not operate for the side on which white (yellow) lines could not be recognized. ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally.
Page 229 The system may not be operating “LDA Malfunction Visit Your properly. Dealer”  Have the vehicle inspected at your Toyota dealer. The operation conditions of the cam- era sensor (temperature, etc.) are not met.  When the operation conditions of the camera sensor (temperature, “Front Camera Unavailable”...
Page 230 4-5. Using the driving support systems Dynamic radar cruise controlwith full-  speed range Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates, decelerates and stops to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 231 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control with full-speed range Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings.
Page 232 4-5. Using the driving support systems WARNING ■ To avoid inadvertent dynamic radar cruise control with full-speed range activation Switch the dynamic radar cruise control with full-speed range off using the cruise control main switch when not in use. ■ Situations unsuitable for dynamic radar cruise control with full-speed range Do not use dynamic radar cruise control with full-speed range in any of the...
Page 233 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 234 4-5. Using the driving support systems Example of acceleration When there are no longer any preceding vehicles driving slower than the set speed The system accelerates until the set speed is reached. The system then returns to constant speed cruising. Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the cruise control main...
Page 235 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the “+ RES” or “- SET” switch until the desired set speed is displayed. Increases the speed (Except when the vehicle has been stopped by system control in vehi- cle-to-vehicle distance control...
Page 236 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 237 4-5. Using the driving support systems Resuming follow-up cruising when the vehicle has been stopped by system control (vehicle-to-vehicle distance control mode) After the vehicle ahead of you starts off, press the “+ RES” switch. Your vehicle will also resume fol- low-up cruising if the accelerator pedal is depressed after the vehi- cle ahead of you starts off.
Page 238 4-5. Using the driving support systems Approach warning (vehicle-to-vehicle distance control mode) When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the display will flash and the buzzer will sound to alert the driver.
Page 239 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 240 • The driver’s door is opened. • The vehicle has been stopped for about 3 minutes If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. AVALON_GE...
Page 241 ●When the VSC or TRC system is turned off. ●Pre-collision braking is activated. If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 242 4-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 243 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 244 4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 245 4-5. Using the driving support systems WARNING ■ Before using dynamic radar cruise control Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings.
Page 246 4-5. Using the driving support systems WARNING ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 247 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 248 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the cruise control main switch to activate the cruise control. Dynamic radar cruise control indi- cator will come on and a message will be displayed on the multi-infor- mation display.
Page 249 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the “+ RES” or “- SET” switch until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Press the switch. Large adjustment: Press and hold the switch to change the speed, and release when the desired...
Page 250 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 251 4-5. Using the driving support systems Canceling and resuming the speed control Pressing the cancel switch can- cels the speed control. The speed control is also canceled when brake pedal depressed. Pressing the “+ RES” switch resumes the cruise control and returns vehicle speed to the set speed.
Page 252 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 253 ●The sensor cannot detect correctly because it is covered in some way. ●Pre-collision braking is activated. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. AVALON_GE...
Page 254 ●When the VSC or TRC system is turned off. ●Pre-collision braking is activated. If constant speed control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Toyota dealer. ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard.
Page 255 4-5. Using the driving support systems ■ When the sensor may not be correctly detecting the vehicle ahead In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 256 4-5. Using the driving support systems ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 257 4-5. Using the driving support systems  Cruise control Use the cruise control to maintain a set speed without depress- ing the accelerator pedal. System Components ■ Meter display Set speed Indicators ■ Operation switches “+ RES” switch Cruise control main switch Cancel switch “- SET”...
Page 258 4-5. Using the driving support systems Setting the vehicle speed Press the cruise control main switch to activate the cruise control. Cruise control indicator will be dis- played. Press the switch again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and press the “- SET”...
Page 259 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the “+ RES” or “- SET” switch until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Press the switch. Large adjustment: Press and hold the switch to change the speed, and release when the desired...
Page 260 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. AVALON_GE AVALON_OM_General_OM41476E...
Page 261 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the cruise control main switch when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 262 4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The BSM (Blind Spot Monitor) function Assists the driver in making a decision when changing lanes ●...
Page 263 4-5. Using the driving support systems Audio system screen (RCTA function only) If a vehicle approaching from the right or left at the rear of the vehicle is detected, the RCTA icon (P. 266) for the detected side will be displayed. buzzer ( function only) RCTA...
Page 264 Do not attach accessories or stickers to the sensor or surrounding area on ● the bumper. Do not modify the sensor or surrounding area on the bumper. ● Do not paint the rear bumper any color other than an official Toyota color. ● AVALON_GE AVALON_OM_General_OM41476E...
Page 265 4-5. Using the driving support systems BSM function The BSM function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is usually not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 266 4-5. Using the driving support systems ■ The BSM function is operational when ●The BSM function is turned on ●Vehicle speed is greater than approximately 16 km/h (10 mph). ■ The BSM function will detect a vehicle when ●A vehicle in an adjacent lane overtakes your vehicle. ●You overtake a vehicle in adjacent lane slowly.
Page 267 4-5. Using the driving support systems • When there is a significant difference in height between your vehicle and the vehicle that enters the detection area • Immediately after the BSM function is turned on ●Instances of the BSM function unnecessarily detecting a vehicle and/or object may increase under the following conditions: •...
Page 268 When a vehicle approaching from the right or left at the rear of the vehicle is detected, the following will be displayed on the audio sys- tem screen. Toyota parking assist Content monitor A vehicle is approaching from the left or right at the rear of the vehicle : The RCTA function is malfunctioning (P.
Page 269 4-5. Using the driving support systems WARNING ■ Cautions regarding the use of the system The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. The RCTA function is only an assist and is not a replacement for careful driving.
Page 270 4-5. Using the driving support systems RCTA function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 271 4-5. Using the driving support systems ●Guardrails, walls, signs, parked vehicles and similar stationary objects ●Vehicles moving away from your vehicle ●Vehicles approaching from the parking spaces next to your vehicle ●Vehicles backing up in the parking space next to your vehicle : Depending on the conditions, detection of a vehicle and/or object may occur.
Page 272 4-5. Using the driving support systems • When the distance between your vehicle and metal objects, such as a guardrail, wall, sign, or parked vehicle, which may reflect electrical waves toward the rear of the vehicle, is short ●When there are spinning objects near your vehicle such as the fan of an air conditioning unit ■...
Page 273 Types of sensors Front corner sensors Front center sensors Rear corner sensors Rear center sensors Turning the Toyota parking assist-sensor on/off Press of the meter con- trol switches, select Press of the meter con-...
Page 274 • When the vehicle speed has reached or exceeded approximately 10 km/h (6 mph) with the shift lever in D • When the Toyota parking assist-sensor is turned off once and turned on again • When the engine switch is turned off once and turned to IGNITION ON mode again •...
Page 275 4-5. Using the driving support systems Sensor detection display, object distance ■ Distance display Sensors that detect an object will illuminate continuously or blink. Approximate distance to object Multi-infor- mation Insert display Front and rear Front and rear display center sensor corner sensor Front center sen- sor:...
Page 276 4-5. Using the driving support systems ■ Buzzer operation and distance to an object A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an object. When the vehicle comes within the following distance of the object, the buzzer sounds continuously: Approximately 35 cm (1.2 ft.).
Page 277 ■ Toyota parking assist-sensor display When an object is detected while the Toyota parking assist monitor is in use, the warning indicator will appear in the upper part of the screen even if the display setting has been set to off.
Page 278 Some functions can be customized. (P. 85, 446) WARNING ■ When using the Toyota parking assist-sensor Observe the following precautions. Failing to do so may result in the vehicle being unable to be driven safely and possibly cause an accident.
Page 279 The area directly under the bumpers is not detected. ● If objects draw too close to the sensor. ● A non-genuine Toyota suspension (lowered suspension, etc.) is installed. ● A backlit license plate is installed. ● In addition to the examples above, there are instances in which, because of their shape, signs and other objects may be judged by a sensor to be closer than they are.
Page 280 When using Toyota parking assist-sensor In the following situations, the system may not function correctly due to a sensor malfunction, etc. Have the vehicle checked by your Toyota dealer. The Toyota parking assist-sensor operation display flashes, and a buzzer ●...
Page 281 4-5. Using the driving support systems Driving mode select switches The driving modes can be selected to suit driving condition. Normal mode Use for normal driving. While in Eco drive mode or Sport mode, press the “NORMAL” switch to change the driving mode to normal mode. Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating.
Page 282 4-5. Using the driving support systems ■ Operation of the air conditioning system in Eco drive mode Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency (P. 296). To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode.
Page 283 4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 284 4-5. Using the driving support systems ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel ◆ The Secondary Collision Brake (if equipped) When the SRS airbag sensor detects a collision and the system operates, the brakes and stop lights are automatically controlled to reduce the vehicle speed and help reduce the possibility of further damage due to a secondary collision.
Page 285 TRC has been disabled even if has not been pressed TRC is temporary deactivated. If the information continues to show, contact your Toyota dealer. ■ Operating conditions of hill-start assist control When the following four conditions are met, the hill-start assist control will operate: ●The shift lever is in a position other than P or N (when starting off forward/...
Page 286 4-5. Using the driving support systems ■ Sounds and vibrations caused by the ABS, brake assist, VSC, TRC and hill-start assist control systems ●A sound may be heard from the engine compartment when the brake pedal is depressed repeatedly, when the engine is started or just after the vehicle begins to move.
Page 287 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when The limits of tire gripping performance have been exceeded (such as ● excessively worn tires on a snow covered road). The vehicle hydroplanes while driving at high speed on wet or slick roads. ●...
Page 288 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 289 4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 290 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Vehicles with 17-inch tires ...
Page 291 4-6. Driving tips Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road. Always check local regulations before installing chains. ■ Tire chain installation Observe the following precautions when installing and removing chains: ●Install and remove tire chains in a safe location.
Page 292 Repairing or replacing snow tires (vehicles with a tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valve and transmitters.
Page 293 4-6. Driving tips Eco-friendly driving tips For improved fuel economy and reduced CO emissions, pay attention to the following points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accel- erator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 294 4-6. Driving tips ◆ Highway driving Control and maintain the vehicle at a constant speed. Before stop- ping at a toll booth or similar, allow plenty of time to release the accelerator pedal and gently apply the brakes. ◆ Air conditioning Use the air conditioning only when necessary.
Page 295 4-6. Driving tips ◆ Regular maintenance ● Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel economy. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel economy. Use tires that are appropriate for the season and road conditions.
Page 296 4-6. Driving tips AVALON_GE AVALON_OM_General_OM41476E...
Page 297 Interior features 5-1. Using the 5-4. Other interior features Other interior features..317 air conditioning system and defogger • Sun visors......317 Automatic air conditioning • Vanity mirrors ....317 system ......296 • Ashtray ......318 Seat heaters/ • Power outlet ....319 seat ventilators ....303 •...
Page 298 5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls ■ Adjusting the temperature setting To adjust the temperature setting, press “ ”...
Page 299 5-1. Using the air conditioning system and defogger Individual mode (indicator off): The temperature for the driver’s and front passenger’s side can be adjusted separately. ■ Fan speed setting To adjust the fan speed, press to increase the fan speed to decrease the fan speed.
Page 300 5-1. Using the air conditioning system and defogger Using automatic mode Press The dehumidification function begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. Adjust the temperature setting. To stop the operation, press ■...
Page 301 5-1. Using the air conditioning system and defogger Other functions ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time is pressed. ■...
Page 302 5-1. Using the air conditioning system and defogger Air outlets ■ Location of air outlets The air outlets and air volume change according selected airflow mode. ■ Adjusting the position of and opening and closing the air out- lets Front Rear ...
Page 303 5-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 304 5-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors ●To let fresh air in, set the air conditioning system to the outside air mode. ●During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 305 5-1. Using the air conditioning system and defogger  Seat heaters/seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good ventilation by pulling air through the seat upholstery. WARNING Care should be taken to prevent injury if anyone in the following categories ●...
Page 306 5-1. Using the air conditioning system and defogger Seat heaters ■ Front Without seat ventilators With seat ventilators   Each time the switch is pressed, the operation condition changes as follows. Hi (3 segments lit)  Mid (2 segments lit)  Lo (1 segment lit)  Off The level indicator lights up during operation.
Page 307 5-1. Using the air conditioning system and defogger Seat ventilators Each time the switch is pressed, the operation condition changes as follows. Hi (3 segments lit)  Mid (2 seg- ments lit)  Lo (1 segment lit)  The level indicator lights up during operation.
Page 308 5-2. Using the interior lights Interior lights list Front interior/personal lights (P. 307) Shift lever light Ambient lights (if equipped) (P. 308) Door courtesy lights Rear personal lights (P. 307) Footwell lights Front center console light AVALON_GE AVALON_OM_General_OM41476E...
Page 309 5-2. Using the interior lights Interior light The rear personal lights turn on/off together with the interior light. Turns the lights on/off linked to door positions Turns the lights on/off Personal lights ■ Front Turns the lights on/off ■ Rear Turns the lights on/off AVALON_GE AVALON_OM_General_OM41476E...
Page 310 5-2. Using the interior lights Ambient lights (if equipped) Each time the “MOOD” switch is pressed, brightness level changes. ●Illuminated entry system: The lights automatically turn on/off according to the engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are open/closed.
Page 311 5-3. Using the storage features List of storage features Cup holders (P. 312) Auxiliary boxes (P. 313) Console box (P. 310) Glove box (P. 310) Bottle holders/door pockets Auxiliary box/open tray (P. 311) (P. 313, 315) WARNING Do not leave glasses, lighters or spray cans in the storage spaces, as this ●...
Page 312 5-3. Using the storage features Glove box Push the button to open the glove box. The glove box light turns on when the engine switch is in ACCESSORY or IGNITION ON mode. Console box Push the knob. ■ Console box tray The tray can be removed.
Page 313 5-3. Using the storage features Bottle holders Front Rear   ●When storing a bottle, close the cap. ●The bottle may not be stored depending on its size or shape. WARNING Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 314 5-3. Using the storage features Cup holders Front Rear   Pull the armrest down. WARNING Do not place any objects that fit loosely or are very tall in the cup holders, ● otherwise they may fall out while driving, possibly leading to an accident. To prevent burns, cover hot drinks when placed in the cup holders.
Page 315 5-3. Using the storage features Auxiliary boxes Type A (if equipped) Type B   Push the lid. Pull the armrest down. Type C  Opening: Push the tray forward until it locks. Closing: Push the tray forward to release the lock and the tray will automati- cally close.
Page 316 5-3. Using the storage features WARNING ■ Items unsuitable for storing (type A) Do not store items heavier than 0.2 kg (0.4 lb.). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident. NOTICE ■...
Page 317 5-3. Using the storage features Open tray WARNING Do not store items in the tray that can easily shift or roll out. Failure to do so may cause items to be thrown out of the tray in the event of sudden braking or steering.
Page 318 5-3. Using the storage features Trunk features Grocery bag hooks NOTICE To prevent damage to the hooks, do not apply too much load to the hooks. Cargo net AVALON_GE AVALON_OM_General_OM41476E...
Page 319 5-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 320 5-4. Other interior features Ashtray The ashtray can be installed in the cup holder. (P. 312) WARNING ■ When not in use Keep the ashtray closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open ashtray or ash flying out. ■...
Page 321 5-4. Other interior features Power outlet Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). Open the lid. ■ The power outlet can be used when The engine switch is in ACCESSORY or IGNITION ON mode. ■...
Page 322 5-4. Other interior features USB charging ports The USB charging ports are used to supply 2.1 A of electricity at 5 V to external devices (power consumption of 10.5 W). The USB charging ports are for charging only. They are not designed for data transfer or other purposes.
Page 323 5-4. Other interior features ■ Cable pass through ●The cutouts on the console box rim allow power cables to be passed through when the console box lid is closed. ●An electronic device on the console box tray can be recharged by running power cables through the clearance of the tray and connecting it to the USB charging ports underneath the tray.
Page 324 5-4. Other interior features Wireless charger (if equipped) A portable device, such as a smartphone or mobile battery, can be charged by just placing it on the charging area, provided the device is compatible with the Qi wireless charging standard created by the Wireless Power Consortium.
Page 325 5-4. Other interior features ■ Using the wireless charger Push the open tray forward until it locks. (P. 313) Press power supply switch of the wireless char- ger. Pressing the switch again turns the wireless charger off. When turned on, the operation indicator light (green) comes on.
Page 326 (orange). Take the appropriate measures according to the table below. Operation indicator light Suspected causes Measure Blinks (orange) at a Vehicle to charger com- Contact your Toyota second interval munication failure. dealer. continuously A foreign object exists between the portable...
Page 327 5-4. Other interior features ■ The wireless charger can be operated when The engine switch is in ACCESSORY or IGNITION ON mode. ■ Portable devices that can be charged ●Portable devices compatible with the Qi wireless charging standard can be charged by the wireless charger.
Page 328 5-4. Other interior features WARNING ■ Caution while driving When charging a portable device while driving, for safety reasons, the driver should not operate the portable device. ■ Caution regarding interference with electronic devices People with implantable cardiac pacemakers, cardiac resynchronization therapy pacemakers or implantable cardioverter defibrillators, as well as any other electrical medical device, should consult their physician about the usage of the wireless charger.
Page 329 If in situations other than above the wireless charger does not operate prop- erly or the operation indicator light is blinking, the wireless charger may be malfunctioning. Contact your Toyota dealer. ■ To prevent failure or damage to data Do not bring magnetic cards, such as a credit card, or magnetic recording ●...
Page 330 5-4. Other interior features Armrest Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat.
Page 331 5-4. Other interior features Coat hooks Coat hooks are provided on the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 332 5-4. Other interior features AVALON_GE AVALON_OM_General_OM41476E...
Page 333 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior ..332 Cleaning and protecting the vehicle interior ...335 6-2. Maintenance Maintenance requirements....338 Scheduled maintenance ....341 6-3. Do-it-yourself maintenance Do-it-yourself service precautions ......348 Hood ........351 Positioning a floor jack..352 Engine compartment..353 Tires........365 Tire inflation pressure ..373...
Page 334 6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 335 Precaution regarding the rear bumper with Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, avoid using the system and consult your Toyota dealer. AVALON_GE...
Page 336 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels, etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
Page 337 6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 338 ● Wring out any excess water from the cloth and thoroughly wipe off remaining traces of detergent and water. ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available.
Page 339 Water may also cause the body to rust. ■ When cleaning the inside of the windshield (vehicles with Toyota Safety Sense) Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
Page 340 ● Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for maintenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips and in-dealership train- ing programs.
Page 341 ●Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair.
Page 342 6-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Important health and safety information Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 343 6-2. Maintenance Scheduled maintenance Perform maintenance by the schedule as follows: Maintenance schedule requirements Your vehicle needs to be serviced according to the normal maintenance schedule. (See “Maintenance schedule”.) If you mainly operate your vehicle under one or more of the spe- cial operating conditions below, some of the maintenance sched- ule items need to be serviced more frequently in order to keep your vehicle in good condition.
Page 344 6-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: MONTHS x1000 km 10 20 30 40 50 60 70 80 (Odometer reading or months, which- x1000 ever comes first.) 6 12 18 24 30 36 42 48...
Page 345 6-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: MONTHS x1000 km 10 20 30 40 50 60 70 80 (Odometer reading or months, which- x1000 ever comes first.) 6 12 18 24 30 36 42 48 miles CHASSIS AND BODY...
Page 346 2. First replace at 160000 km (100000 miles), then replace every 80000 km (50000 miles). 3. Including the filter in fuel tank. 4. For Bahrain, Yemen, and Saudi Arabia only. 5. Toyota genuine fuel injector cleaner or equivalent. AVALON_GE AVALON_OM_General_OM41476E...
Page 347 6-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe condi- tions. (For outline, see “Maintenance schedule requirements”.) A-1: Operating on rough or muddy roads, or roads with melted snow ...
Page 348 6-2. Maintenance A-2: Operating on dusty roads (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.) Every 5000 km (3000 miles) or 6  Replacement of engine oil months Every 5000 km (3000 miles) or 6 ...
Page 349 6-2. Maintenance B-2: Repeated short trips less than 8 km (5 miles) and outside tempera- tures remain below freezing (Engine temperature will not reach to nor- mal temperature) Every 5000 km (3000 miles) or 6  Replacement of engine oil months Every 5000 km (3000 miles) or 6 ...
Page 350 • Baking soda • Grease Battery condition (P. 359) • Conventional wrench (for terminal clamp bolts) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology level (P.
Page 351 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment Keep hands, clothing and tools away from the moving fan and engine ●...
Page 352 6-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. ■ If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 353 6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. ■ Open hood warning buzzer If the vehicle reaches a speed of 5 km/h (3 mph), the master warning light flashes and a buzzer sounds to indicate that the hood is not fully closed.
Page 354 6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 355 6-3. Do-it-yourself maintenance Engine compartment Fuse boxes (P. 381) Battery (P. 359) Engine oil filler cap Radiator (P. 358) (P. 355) Electric cooling fan Engine oil level dipstick Condenser (P. 358) (P. 354) Engine coolant reservoir Air cleaner (P. 363) (P.
Page 356 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 357 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 358 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 359 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. AVALON_GE...
Page 360 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 361 6-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Caution symbols The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating Shield eyes instructions Keep away from chil- Explosive gas...
Page 362 Make sure to turn off the engine before disconnecting the battery. Take extra care when connecting the bat- tery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. AVALON_GE...
Page 363 6-3. Do-it-yourself maintenance WARNING ■ Chemicals in the battery Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: Do not cause sparks by touching the battery terminals with tools.
Page 364 6-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations: ● A washer does not work. ● “Windshield Washer Fluid Low” is displayed on the multi-infor- mation display. WARNING ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine, etc.
Page 365 6-3. Do-it-yourself maintenance Air cleaner filter Check the air cleaner filter as follows: Disengage each clamp. While pulling the claw, pull the clamp to disengage it. Release the clips. Lift the cover and take out the air cleaner filter. Inspect the outer surface of the filter, and replace the filter if it is extremely dirty.
Page 366 6-3. Do-it-yourself maintenance After checking, make sure the filter is set properly. Fully engage the claws and then secure the upper cover of the air cleaner case using the clips. Engage each clamp. Make sure to push each clamp until it is securely engaged. WARNING ■...
Page 367 Replace the tires if the treadwear indicators are showing on a tire. Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that tire rotation is carried Front out approximately every 10000 km (6000 miles).
Page 368 6-3. Do-it-yourself maintenance Tire pressure warning system Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning valve and transmitters to detect low tire inflation pressure before serious problems arise. If the tire pressure drops below a predetermined level, the driver is warned by a warning light.
Page 369 ID codes initially registered to the vehicle, a second set of ID codes can be registered. A second set of tire pressure warning system sensor ID codes can be registered at your Toyota dealer. When 2 sets of ID codes have been registered, either ID code set can be selected. ■...
Page 370 ●A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID codes of the tire pressure warning valve and transmitters are not reg- istered, the tire pressure warning system will not work properly.
Page 371 ●In the following situations, the tire pressure warning system may not operate properly. • If non-genuine Toyota wheels are used. • If a tire has been replaced with a tire that is not an OE (Original Equip- ment) tire.
Page 372 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●If initialization is attempted and the tire pressure warning light does not blink 3 times.
Page 373 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply ●...
Page 374 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 375 ●Reduced tire life due to wear ●Reduced safety ●Damage to the drivetrain If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●Check only when the tires are cold.
Page 376 6-3. Do-it-yourself maintenance WARNING ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: Excessive wear ●...
Page 377 ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 378 Because tire repair or replacement may affect the tire pressure warning ● valve and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valve and transmitters at your Toyota dealer.
Page 379 6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open glove remove the glove box cover inside the glove box. Remove the filter cover. Unlock the filter cover.
Page 380 6-3. Do-it-yourself maintenance Remove the air conditioning fil- ter from the filter case and replace it with a new one. The “UP” marks shown on the fil- ter and the filter case should be pointing up. ■ Checking interval Replace the air conditioning filter according to the maintenance schedule. (P.
Page 381 6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Release the lock and remove the mechanical key.
Page 382 Be careful not to lose the battery or any other small parts. ■ Use a CR2032 lithium battery ●Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ●Replace only with the same or equivalent type recommended by the manu- facturer.
Page 383 6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. Open the fuse box cover. Engine compartment (type A) Engine compartment (type B) ...
Page 384 6-3. Do-it-yourself maintenance Check if the fuse is blown. Type A Type B   Type C  Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. AVALON_GE AVALON_OM_General_OM41476E...
Page 385 After a fuse is replaced ●If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 384) ●If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■...
Page 386 6-3. Do-it-yourself maintenance Light bulbs If any lights burn out, have it replaced by your Toyota dealer. ■ LED lights The lights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 387 When trouble arises 7-1. Essential information Emergency flashers ...386 If your vehicle has to be stopped in an emergency....387 If the vehicle is trapped in rising water ......388 7-2. Steps to take in an emergency If your vehicle needs to be towed ......389 If you think something is wrong.......392...
Page 388 7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped on the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 389 7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 390 : Contact your Toyota dealer or aftermarket accessory manufacturer for further information about an emergency hammer. ■...
Page 391 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 392 7-2. Steps to take in an emergency Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. Covers are installed to the tie-down holes. After transporting the vehi- cle, make sure to reinstall the cov- ers to the holes.
Page 393 7-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck Do not tow the vehicle from the rear when the engine switch is off. The ● steering lock mechanism is not strong enough to hold the front wheels straight.
Page 394 7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 395 7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 396 • The brake system is malfunctioning  Immediately stop the vehicle in a safe place and con- (Red) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Brake system warning light (warning buzzer) Indicates a malfunction in the electric parking brake ...
Page 397 Indicates a malfunction in: • The electronic engine control system; • The electronic throttle control system; or • The electronic automatic transmission control system  Have the vehicle inspected by your Toyota dealer immediately. SRS warning light (warning buzzer) Indicates a malfunction in: •...
Page 398 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Brake hold operated indicator Indicates a malfunction in the brake hold system  Have the vehicle inspected by your Toyota dealer (Flashes) immediately. Electric power steering system warning light (warning buzzer)
Page 399 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Driver’s and front passenger’s seat belt reminder light (warning buzzer) Warns the driver and/or front passenger to fasten their seat belts  Fasten the seat belt. If the front passenger’s seat is occupied, the front passenger’s seat belt also needs to be fastened to make the warning light (warning buzzer) turn off.
Page 400 7-2. Steps to take in an emergency : This light illuminates on the multi-information display. : Parking brake engaged warning buzzer: A buzzer will sound if the vehicle is driven at a speed of approximately 5 km/h (3 mph) or more. : Driver’s and front passenger’s seat belt warning buzzer: Except for Lebanon ...
Page 401 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
Page 402 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 403 7-2. Steps to take in an emergency NOTICE ■ To ensure the tire pressure warning system operates properly Do not install tires with different specifications or makers, as the tire pres- sure warning system may not operate properly. AVALON_GE AVALON_OM_General_OM41476E...
Page 404 Multi-information display Handling method Follow the instructions of the mes- sage on the multi-information dis- play. If any of the warning messages are shown again after the appropriate actions have been performed, contact your Toyota dealer. AVALON_GE AVALON_OM_General_OM41476E...
Page 405 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 406 If a message instructing to refer to the Owner’s Manual is displayed ●If the following messages are shown, there may be a malfunction. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous.
Page 407 If this message is displayed but you have not had a new electronic key regis- tered, ask your Toyota dealer to check if an unknown electronic key (other than those in your possession) has been registered.
Page 408 7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 365 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 409 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Screwdriver Luggage floor cover Jack Jack handle Wheel nut wrench Spare tire cover Tools Spare tire AVALON_GE AVALON_OM_General_OM41476E...
Page 410 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Do not use the tire jack for any purpose other than replacing tires or install- ●...
Page 411 7-2. Steps to take in an emergency Taking out the jack Lift up the hook of the luggage floor cover on the trunk floor. Secure the luggage floor cover using the hook provided. Remove the jack. AVALON_GE AVALON_OM_General_OM41476E...
Page 412 7-2. Steps to take in an emergency Taking out the spare tire Lift up the hook of the luggage floor cover on the trunk floor. Secure the luggage floor cover using the hook provided. Remove the tool tray. AVALON_GE AVALON_OM_General_OM41476E...
Page 413 7-2. Steps to take in an emergency Remove the spare tire cover. Loosen the center fastener that secures the spare tire. When taking out or stowing the spare tire, make sure to firmly hold opposite end of the tire. WARNING ■...
Page 414 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 415 7-2. Steps to take in an emergency Assemble the jack handle. Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 416 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 417 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 418 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 419 7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 164), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
Page 420 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 422) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 421 (turn and hold) Unlocks all the door Opens the windows and the moon roof (turn and hold) : If equipped : This setting must be customized at your Toyota dealer. ■ Trunk Turn the mechanical key clock- wise to open.
Page 422 ACCESSORY mode. Firmly depress the brake pedal and check that is displayed on the multi-information display. Press the engine switch shortly and firmly. In the event that the engine still cannot be started, contact your Toyota dealer. AVALON_GE AVALON_OM_General_OM41476E...
Page 423 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 424 The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 425 7-2. Steps to take in an emergency Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 426 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 427 • If the 20 hour rate capacity is low, even if the time period where the vehi- cle is not used is a short time, the battery may discharge and the engine may not be able to start. ●For details, consult your Toyota dealer. WARNING ■...
Page 428 7-2. Steps to take in an emergency WARNING ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: When working with the battery, always wear safety glasses and take care ●...
Page 429 (radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 430 (The fan may not operate in freezing tem- peratures.) If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 431 7-2. Steps to take in an emergency WARNING ■ To prevent an accident or injury when inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until ●...
Page 432 7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the front wheels.
Page 433 7-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components Avoid spinning the front wheels and depressing the accelerator pedal ● more than necessary. If the vehicle remains stuck even after these procedures are performed, ●...
Page 434 7-2. Steps to take in an emergency AVALON_GE AVALON_OM_General_OM41476E...
Page 435 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)...434 Fuel information ....444 8-2. Customization Customizable features ..445 8-3. Items to initialize Items to initialize ....453 AVALON_GE AVALON_OM_General_OM41476E...
Page 436 8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 4975 mm (195.9 in.) Overall width 1850 mm (72.8 in.) Overall height 1435 mm (56.5 in.) Wheelbase 2870 mm (113.0 in.) 1600 mm (63.0 in.) Front 1590 mm (62.6 in.) Tread 1615 mm (63.6 in.) Rear...
Page 437 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 438 8-1. Specifications ■ Year of manufacture and country of origin The year of the manufacture and country of origin are shown on the Certification Regulation label. ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 2GR-FKS...
Page 439 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 440 8-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 441 Capacity 9.4 L (9.9 qt., 8.3 Imp. qt.) (Reference) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate cool- ant with long-life hybrid organic acid technology Do not use plain water alone.
Page 442 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of the transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission. AVALON_GE...
Page 443 8-1. Specifications Brakes Pedal clearance 81 mm (3.2 in.) Pedal free play 1  6 mm (0.04  0.24 in.) Brake pad wear limit 1.0 mm (0.04 in.) SAE J1703 or FMVSS No.116 DOT 3 Fluid type SAE J1704 or FMVSS No.116 DOT 4 : Minimum pedal clearance when depressed with a force of 300 N (31 kgf, 67 lbf) while the engine is running.
Page 444 8-1. Specifications Tires and wheels 17-inch tires  Tire size 215/55R17 94V Driving under normal conditions Front: 240 kPa (2.4 kgf/cm or bar, 35 psi) Rear: 240 kPa (2.4 kgf/cm or bar, 35 psi) Tire inflation pressure Driving at high speeds (above 160 km/h (Recommended cold tire [100 mph]) (in countries where such inflation pressure)
Page 445 8-1. Specifications Light bulbs Light bulbs Type Door courtesy lights Interior Vanity lights Trunk light A: Wedge base bulbs B: Double end bulbs : Light bulbs not listed in this table are LED bulbs. AVALON_GE AVALON_OM_General_OM41476E...
Page 446 ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 447 The settings of these fea- tures can be changed using the multi-information display, on the audio system screen, or at your Toyota dealer. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in P and the parking brake set.
Page 448 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed on the audio system screen Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, —...
Page 449 8-2. Customization ■ Door lock (P. 110116, 419) Function Default setting Customized setting Driver’s door All doors Unlocking using unlocked in one step, unlocked in one mechanical key all doors unlocked in step two steps Speed linked door lock- ing function Shift position linked door locking function Shift position linked door...
Page 450 8-2. Customization ■ Smart entry & start system (P. 110, 116, 120) Function Default setting Customized setting Smart entry & start sys- — O Smart door unlocking All the doors Driver’s door Time elapsed before unlocking all the door when gripping and hold- 2 seconds —...
Page 451 8-2. Customization ■ Power windows and moon roof (P. 145, 149) Function Default setting Customized setting Mechanical key linked — O operation Wireless remote control linked operation signal — O (buzzer) : If equipped ■ Moon roof (P. 149) Function Default setting Customized setting Linked operation of com-...
Page 452 8-2. Customization ■ Outside rear view mirrors (P. 142) Function Default setting Customized setting Linked to the Automatic mirror folding locking/unlock- — O Linked to operation of and extending operation ing of the doors the engine switch ■ Automatic light control system (P. 181) Function Default setting Customized setting...
Page 453 8-2. Customization ■ Toyota parking assist-sensor (P. 271) Function Default setting Customized setting Detection distance of the Near — O front center sensor Detection distance of the Near — O rear center sensor : If equipped ■ BSM (Blind Spot Monitor) (P.
Page 454 8-2. Customization ■ Illumination (P. 306) Function Default setting Customized setting Time elapsed before 15 seconds 7.5 seconds lights turn off 30 seconds Operation after — O engine switch turned off Operation when — O doors are unlocked Operation when approach vehicle —...
Page 455 8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference • When the tire inflation pres- sure is changed such as when changing traveling speed or load weight...
Page 456 8-3. Items to initialize AVALON_GE AVALON_OM_General_OM41476E...
Page 457 Alphabetical index ......460 For vehicles with a multimedia system or navigation system, refer to the “Navigation and Multimedia System Owner’s Manual” for information regarding the equipment listed below. • Navigation system • Audio/visual system • Toyota parking assist monitor AVALON_GE AVALON_OM_General_OM41476E...
Page 458 Toyota dealer. (P. 107) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly. Contact your Toyota dealer immediately. (P. 109) The doors cannot be locked or unlocked ● Is the key battery weak or depleted? (P. 379) ●...
Page 459 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the brake pedal? (P. 164) ● Is the shift lever in P? (P. 166) ●...
Page 460 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Are the driver and the front passenger wearing the seat belts? (P. 397) ● The parking brake indicator is on Is the parking brake released? (P. 175) Depending on the situation, other types of warning buzzer may also sound.
Page 461 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 406) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 462 Alphabetical index Alphabetical index Alarm .......... 64 Ambient lights......308 A/C..........296 Air conditioning filter....377 Anchor brackets ......54 Automatic air Antennas conditioning system .... 296 (smart entry & start system)........120 Anti-lock Brake System (Anti-lock Brake System)..281 Warning light ......
Page 463 Alphabetical index Back-up lights Care Replacing light bulb....384 Aluminum wheels....333 Exterior ......... 332 Battery ........359 Battery checking ....359 Interior........335 If the battery is discharged..422 Seat belts......336 Preparing and checking Cargo net........316 before winter....... 287 Chains........
Page 464 Alphabetical index Child safety ........49 Coat hooks ....... 329 Airbag precautions ....35 Condenser........ 358 Battery precautions ..361, 426 Console box ......310 Child restraint system .....50 Consumption How your child should wear screen....... 82, 101 the seat belt ......28 Coolant Installing child restraints..54 Capacity........
Page 465 Alphabetical index Doors ........110 Automatic door locking Daytime running light and unlocking systems ..113 system ........183 Door lock....... 112 Defogger Outside rear view mirrors..142 Rear window ......299 Rear door child-protector ..113 Windshield ......299 Side doors......
Page 466 Alphabetical index Engine ACCESSORY mode ..... 165 Eco drive mode ......279 Compartment ......353 Eco Driving Indicator....92 Engine switch......164 Hood ........351 (Event data recorder) ....8 How to start the engine..164 Electric Power Steering Identification number .... 436 (EPS)........
Page 467 Alphabetical index Front turn signal lights Replacing light bulbs..... 384 Flat tire........406 Turn signal lever ....174 Floor mats ........22 Fuel Fluid Capacity........ 436 Automatic transaxle ....440 Fuel gauge......74 Brake........441 Fuel pump shut off system..393 Washer........
Page 468 Alphabetical index Head restraints......136 Identification Engine........436 Head-up display ......94 Vehicle ........435 Headlights ........ 181 Automatic High Beam ... 185 Ignition switch Light switch ......181 (engine switch) ...... 164 Replacing light bulbs..... 384 Illuminated entry system ..308 Heaters Immobilizer system ....
Page 469 Alphabetical index Keyless entry Lane Departure Alert with Smart entry & start steering control (LDA) ..217 system ......110, 116 Language (multi- Wireless remote information display)....90 control......110, 117 LDA (Lane Departure Alert Keys .......... 106 with steering control).... 217 Battery-saving function ..
Page 470 Alphabetical index Multi-information display ..77 Driving information....82 Maintenance Dynamic radar Do-it-yourself maintenance ... 348 cruise control ...... 242 Maintenance data ....434 Dynamic radar Maintenance cruise control with requirements....... 338 full-speed range....228 Scheduled maintenance ..341 Language........ 90 Malfunction indicator lamp ..
Page 471 Alphabetical index Panic mode....... 107 Radar cruise control Parking brake ......175 (dynamic radar Parking brake engaged cruise control) ....... 242 warning buzzer/ Radar cruise control message ......178 (dynamic radar cruise Warning light ......395 control with full-speed range) ........228 (Pre-Collision System) ..
Page 472 ........ 185 Seat ventilators ......303 Camera sensor ..... 200 Inside rear view mirror ..141 LDA (Lane Departure Alert with steering control) ..217 Radar sensor ......200 Toyota parking assist-sensor ...... 271 Service reminder indicators ..68 AVALON_GE AVALON_OM_General_OM41476E...
Page 473 Alphabetical index Shift lever ......... 169 Stoplights Automatic transmission..169 Replacing light bulbs..... 384 If the shift lever cannot Storage feature ......309 be shifted from P ....172 Storage precautions....309 S mode........170 Stuck If the vehicle becomes Shift lock system .....
Page 474 Alphabetical index LDA (Lane Departure Alert with steering control) Tachometer ........ 74 switch........222 Tail lights Light switch ......181 Light switch ......181 Meter control switches ....79 Replacing light bulbs..... 384 “MOOD” switch ..... 308 Theft deterrent system Moon roof switches ....149 Alarm ........
Page 475 Trunk light ......117 Toyota parking Trunk opener ......116 assist-sensor ......271 Wireless remote control ..117 Toyota Safety Sense....198 Automatic High Beam ... 185 Trunk light Dynamic radar Trunk light ......117 cruise control ...... 242 Wattage ........
Page 476 Low engine oil pressure..394 Pre-collision warning..... 205 Low fuel level ......396 Seat belt reminder....397 Malfunction indicator lamp ..395 Toyota parking Master warning light....397 assist-sensor ...... 274 Parking brake indicator ..395 Vehicle sway warning ... 220 PCS warning light ....
Page 477 Alphabetical index Warning messages ....402 Washer........190 Checking ....... 362 Preparing and checking before winter....... 287 Switch ........190 Washing and waxing ....332 Wheels ........375 Replacing ......375 Size ........442 Window glasses....... 145 Window lock switch....145 Windows Power windows .....
Page 478 60 L (15.9 gal., 13.2 Imp. gal.) (Reference) Fuel type P. 436, 444 Cold tire inflation P. 442 pressure Engine oil capacity (Drain and refill — P. 437 reference) “Toyota Genuine Motor Oil” or equivalent Engine oil type P. 437 AVALON_GE AVALON_OM_General_OM41476E...

Toyota Avalon Owner's Manual

1-1. for Safe Use

Theft Deterrent System

Instrument Cluster

Instrument Cluster Warning Lights and Indicators

Operation of each Component

3-1. Key Information

3-2. Opening, Closing and

Adjusting the Seats

3-4. Adjusting the Steering

Driving

4-1. before Driving

Quick Links

Summary of Contents for Toyota Avalon

Toyota Avalon Owner's Manual

1-1. for Safe Use

Theft Deterrent System

Instrument Cluster

Instrument Cluster Warning Lights and Indicators

Operation of each Component

3-1. Key Information

3-2. Opening, Closing and

Adjusting the Seats

3-4. Adjusting the Steering

Driving

4-1. before Driving

Quick Links

Related Manuals for Toyota Avalon

Summary of Contents for Toyota Avalon

Table of Contents
