Page 1 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 2 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 3 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 4 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 5: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 319 P. 112 P. 187 Hood lock release Tire inflation lever pressure P. 319 P. 435 Fuel tank capacity 17.0 gal. (64.35 L, 14.2 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P.
Page 6: Before Driving
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 7 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 8: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 9 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 125, 127) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 10: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 11 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 12 ■ Seat belt extender If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. AVALON (U)_(OM41452U)
Page 13 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 14 Seat belt pretensioners If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 15 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 16: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 17 1-1. For safe use SRS airbag system components Front impact sensors Side impact sensors (rear) Knee airbags Driver airbag Side impact sensors (front Driver’s seat belt buckle doors) switch Seat belt pretensioners and Driver’s seat position sensor force limiters SRS warning light Front passenger airbag Front passenger’s seat belt Front side airbags...
Page 18 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 19 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 20 1-1. For safe use CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 21 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes are damaged or cracked, have them replaced by your Toyota dealer. AVALON (U)_(OM41452U)
Page 22 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 23 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 24 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 25 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 26: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. CTY11AX056 SRS warning light Seat belt reminder light...
Page 27 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat...
Page 28 1-1. For safe use ■ Child restraint system with infant “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
Page 29 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 30 1-1. For safe use CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 31 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 32: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 33: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 34 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/con- Forward facing ⎯ Convertible vertible seat seat Booster seat ■...
Page 35 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 36 1-1. For safe use CAUTION ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 37: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 38 1-1. For safe use Installation with LATCH system Adjust the head restraint to the downmost position. (→P. 121) Widen the gap between the seat cushion and seatback slightly. Rear left seat only: Slide the rear center seat belt to the side to prevent it from getting pinched in the lower anchor- age.
Page 39 1-1. For safe use Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the presence of a lower connec-...
Page 40 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 41 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 42 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 43 1-1. For safe use ■ Booster seat Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 44 1-1. For safe use Child restraint systems with a top tether strap Adjust the head restraint to the downmost position. (→P. 121) Secure the child restraint sys- tem using the seat belt or LATCH anchors. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 45 1-1. For safe use CAUTION ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 30) ■...
Page 46 1-1. For safe use CAUTION ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 47: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 48: Engine Immobilizer System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 49 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 50 1-2. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 51 1-2. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 52: Theft Prevention Labels (U.s.a.)
1-2. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law. AVALON (U)_(OM41452U)
Page 53: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 54 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Slip indicator (→P. 389) light (→P. 387) (U.S.A.) Brake system warning Open door warning light light (→P. 387) (→P. 390) (Canada) Charging system warn- Low fuel level warning...
Page 55 There may be a mal- function in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate a malfunction.
Page 56 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Automatic high beam (→P. 165) indicator (→P. 172) (if equipped) Headlight indicator Eco drive mode indicator (→P. 168) (→P. 209) (U.S.A.) (if equipped) Tail light indicator...
Page 57 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 58: Gauges And Meters
2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on where the vehicle is sold. Tachometer Displays the engine speed in revolutions per minute Multi-information display Presents the driver with a variety of driving-related data (→P. 80) Speedometer Displays the vehicle speed Fuel gauge...
Page 59 2. Instrument cluster Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances independently.
Page 60 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter ■ The meters and display illuminate when The engine switch is in IGNITION ON mode. ■ The brightness of the instrument panel lights ●...
Page 61: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of driv- ing-related data. ● Distance to empty (→P. 81) ● Average fuel economy (→P. 81) ● Current fuel economy (→P. 82) ● ECO Drive Level (→P. 82) ●...
Page 62 2. Instrument cluster Trip information ■ Switching the display Items displayed switched pressing “DISP” button. ■ Distance to empty Displays the estimated maxi- mum distance that can be driven with the quantity of fuel remaining. • This distance computed based on your average fuel con- sumption.
Page 63 2. Instrument cluster ■ Current fuel economy Displays the current rate of fuel consumption. ■ ECO Drive Level Suggests driving level based on acceleration. All green suggests the status of the most Eco-friendly driv- ing. All blue suggests the status of the least Eco-friendly driv- ing.
Page 64 2. Instrument cluster Setting up the displays ■ Customizable items Item Default setting Customized setting Digital speedometer Units (vehicles without English Metric a navigation system) Turn-by-turn naviga- tion (vehicles with a navigation system) Eco Driving Indicator Light ■ Changing the settings While the vehicle is stopped, press the “DISP”...
Page 65 2. Instrument cluster Press and hold the “DISP” but- ton to select the desired setting. Press and hold the “DISP” but- ton after selecting the “EXIT” by pressing the “DISP” button. The display goes back to step ■ System check display After turning the engine switch to IGNITION ON mode, “SYSTEM CHECK”...
Page 66 2. Instrument cluster CAUTION ■ The information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display.
Page 67 2. Instrument cluster AVALON (U)_(OM41452U)
Page 68 3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (→P. 91) • Operating the wireless remote control function (→P. 106) Mechanical keys Key number plate Using the mechanical key To take out the mechanical key, push the release button and take the key out.
Page 69 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 70 Toyota dealer. ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. AVALON (U)_(OM41452U)
Page 71: Smart Key System
3-2. Opening, closing and locking the doors Smart key system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (→P.
Page 72 3-2. Opening, closing and locking the doors Unlocking and locking the doors Grip the driver’s door handle to unlock the door. Some models, grip the passenger’s door handle to unlock all the doors. Make sure to touch the sensor on the back of the handle.
Page 73 3-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Right side antenna outside the cabin (if equipped) Antennas inside the cabin Antenna outside the trunk Antenna inside the trunk Left side antenna outside the cabin AVALON (U)_(OM41452U)
Page 74 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) Type A Type B When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft.
Page 75 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators An alarm sounds and warning message displays shown on the multi-informa- tion display are used to protect against unexpected accidents or theft of the vehicle resulting from erroneous operation. When a warning message is dis- played, take appropriate measures based on the displayed message.
Page 76 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure The engine switch was turned to ACCESSORY mode while the driver's Turn the engine switch door was open (The close driver's door driver’s door. opened when engine switch was in Interior alarm sounds ACCESSORY mode.) continuously...
Page 77 3-2. Opening, closing and locking the doors Interior Exterior Correction Situation buzzer buzzer procedure An attempt was made to exit Turn the vehicle with the electronic Continuous engine switch Once key and lock the doors without (5 seconds) off and lock the first turning the engine switch doors again.
Page 78 3-2. Opening, closing and locking the doors ■ Switching the door unlock function (some models) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 79 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 80 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
Page 81 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 82 3-2. Opening, closing and locking the doors ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly.
Page 83 3-2. Opening, closing and locking the doors ■ When the vehicle is not driven for extended periods ● To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. (→P. 453) ■...
Page 84 3-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● If the battery becomes low, an alarm will sound in the cabin when the engine stops. (→P. 95) ●...
Page 85 (→P. 93) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 86: Wireless Remote Control
3-2. Opening, closing and locking the doors Wireless remote control Function summary The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Unlocks all the doors Pressing the button unlocks the driver’s door. Pressing the button again within 5 seconds unlocks the other doors.
Page 87 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Trunk: A buzzer sounds to indicate that the trunk has been opened. ■...
Page 88 →P. 350 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization Settings (e.g. wireless remote control system) can be changed. (Customizable features: →P. 453) ■...
Page 89 3-2. Opening, closing and locking the doors Doors Unlocking and locking the doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switches. ◆ Entry function →P. 91 ◆ Wireless remote control →P.
Page 90 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door. The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 91 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 453. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- mately 12 mph (20 km/h) or higher.
Page 92 3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. Opening the trunk from inside the vehicle Press the opener switch. Opening the trunk from outside the vehicle ■...
Page 93 3-2. Opening, closing and locking the doors Luggage security system The trunk opener switch can be temporarily disabled to protect lug- gage stored in the trunk against theft. Turn the main switch in the glove box off to disable the trunk opener.
Page 94 3-2. Opening, closing and locking the doors ■ In case the trunk opener is not actuated Pull down the rear armrest and open the door behind it. Pull the loop of wire to unlock the trunk lid. This is used in case the trunk lid cannot be unlocked due to a discharged battery or other trouble.
Page 95 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 96: Front Seats
3-3. Adjusting the seats Front seats Adjustment procedure Driver’s seat Passenger’s seat Seat position adjustment switch Lumbar support adjustment switch (if equipped for passen- Seatback angle adjustment ger’s seat) switch Seat cushion length adjust- Seat cushion (front) angle ment switch (if equipped) adjustment switch (if equipped for passenger’s seat) Vertical...
Page 97 3-3. Adjusting the seats ■ Power easy access system (vehicles with driving position memory) The auto away/return function enables easy access by activating when the driver attempts to enter or exit the vehicle. ● When the engine switch has been turned to IGNITION ON mode or the driver’s seat belt has been fastened, the driver’s seat will move forward.
Page 98: Driving Position Memory
3-3. Adjusting the seats ∗ Driving position memory Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be memorized and recalled by pressing a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 99 3-3. Adjusting the seats ■ When you want to stop the position recall operation part-way through Perform any of the following operations: ● Press the “SET” button. ● Press button “1” or “2”. ● Adjust the seat using the switches (only cancels seat position recall). Linking driving position memory with door unlock operation A desired driving position can be recalled linked with the unlocking of the door.
Page 100 3-3. Adjusting the seats ◆ Cancelation procedure Carry only the key for which you want to cancel the linked door unlock operation. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
Page 101: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats (except center seat) Pull the head restraints up.
Page 102 3-3. Adjusting the seats ■ Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. Lock release button Rear seats (except center seat) Align the head restraint with the installa-...
Page 103 3-3. Adjusting the seats CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 104: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 105: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 106 3-4. Adjusting the steering wheel and mirrors Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in on mode, the indica- tor illuminates.
Page 107: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 108 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The engine switch is in ACCESSORY or IGNITION ON mode. ■ Linked mirror function when reversing (vehicles with driving position memory) ● When the mirror select switch is either in the “L” or “R” position, the outside rear view mirrors will automatically angle down when the vehicle is in reverse to give a better view of the ground.
Page 109 3-4. Adjusting the steering wheel and mirrors CAUTION ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 110: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 111 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 112 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 113 3-5. Opening, closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 114 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when The engine switch is in IGNITION ON mode. ■ Operating the moon roof after turning the engine off The moon roof can be operated for approximately 45 seconds after the engine switch is turned to ACCESSORY mode or turned off.
Page 115 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41452U)
Page 116 3-5. Opening, closing the windows and moon roof ■ Moon roof open warning buzzer The buzzer sounds and a message is shown on the multi-information display when the engine switch is turned off and the driver’s door is opened with the moon roof open.
Page 117: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine →P. 155 Driving With the brake pedal depressed, shift the shift lever to D. (→P. 161) Release the parking brake. (→P. 166) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 118 4-1. Before driving Starting off on a steep uphill Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. ■ Driving in the rain ● Drive carefully when it is raining, because visibility will be reduced, the win- dows may become fogged-up, and the road will be slippery.
Page 119 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 120 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
Page 121 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 122 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 123 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 124 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 125 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 126 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 127 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 128: Cargo And Luggage
Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 152) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. AVALON (U)_(OM41452U)
Page 129 4-1. Before driving Calculation formula for on your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (→P. 428) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 130 4-1. Before driving CAUTION ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 131: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 132: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 133: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. AVALON (U)_(OM41452U)
Page 134: Engine (Ignition) Switch
4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal.
Page 135 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P. Set the parking brake. (→P. 166) Press the engine switch. Driving-related data will be displayed on the multi-information display. (→P. 84) Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal released.
Page 136 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P, a message indicating to shift the shift lever to P will be displayed on the multi-information display.
Page 137 If the engine does not start ● The engine immobilizer system may not have been deactivated. (→P. 66) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 138 When a message requesting the smart key system be inspected is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted →P. 350 ■...
Page 139 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 140: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in IGNITION ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 141 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever or paddle shift switches can be operated as follows: Shift lever Upshifting Downshifting Paddle shift switches (if equipped) Upshifting Downshifting The initial shift range in S mode is set automatically to “4”...
Page 142 4-2. Driving procedures Selecting shift ranges in the D position (vehicles with paddle shift switches) To drive using temporary shift range selection, operate the “-” paddle shift switch. The shift range can then be selected by operating the “-” and “+” paddle shift switches. Changing the shift range allows restric- tion of the highest gear, preventing upshifting and enabling the level of engine braking force to be selected.
Page 143 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 144: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 145: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully U.S.A. Canada depress the parking brake pedal with your left foot while depress- ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Usage in winter time →P.
Page 146 4-2. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 147: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: Type A The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION...
Page 148 4-3. Operating the lights and wipers Type B The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION mode). The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on.
Page 149 4-3. Operating the lights and wipers ■ Daytime running light system ● Vehicles with halogen headlights: To make your vehicle more visible to other drivers, the headlight high beam turn on automatically (at a decreased inten- sity) whenever the engine is started and the parking brake is released. Day- time running lights are not designed for use at night.
Page 150 4-3. Operating the lights and wipers ■ Automatic headlight leveling system (if equipped) The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. ■...
Page 151: Automatic High Beam
4-3. Operating the lights and wipers ∗ Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Put the headlight switch in the “AUTO”...
Page 152 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on (after approximately 1 second): ● Vehicle speed is above approximately 25 mph (40 km/h). ●...
Page 153 4-3. Operating the lights and wipers ■ The Automatic High Beam can be operated when The engine switch is in IGNITION ON mode. ■ Camera sensor detection information ● High beam may not be automatically turned off in the following situations: •...
Page 154 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. ■ If the Automatic High Beam indicator flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The automatic high beam can be deactivated.
Page 155 Do not install a parking tag or any other accessories near or around the inside rear view mirror and the camera sensor. ● Do not overload the vehicle. ● Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. Contact your Toyota dealer. AVALON (U)_(OM41452U)
Page 156: Fog Light Switch
4-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Type A Turns the front fog lights Turns the front fog lights ∗ : If equipped AVALON (U)_(OM41452U)
Page 157 4-3. Operating the lights and wipers Type B Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam. AVALON (U)_(OM41452U)
Page 158: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper with interval adjuster (if equipped) Type A Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper opera- tion Temporary operation Increases the intermittent wind-...
Page 159 4-3. Operating the lights and wipers Type B Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency ■...
Page 160 4-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped) Type A With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper...
Page 161 4-3. Operating the lights and wipers Type B With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper operation High speed wiper operation...
Page 162 4-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The engine switch is in IGNITION ON mode. ■ Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wipers) With low speed windshield wiper operation selected, wiper operation will be switched from low speed to intermittent wiper operation only when the vehicle is stationary.
Page 163 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. AVALON (U)_(OM41452U)
Page 164: Opening The Fuel Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch off. ● Confirm the type of fuel. ■...
Page 165 4-4. Refueling CAUTION ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 166 4-4. Refueling Opening the fuel tank cap With the doors unlocked, press the center of the rear edge of the fuel filler door. Push until you hear a click and take your hand away to slightly open the fuel filler door. Then open the door fully by hand.
Page 167 4-4. Refueling ■ If the fuel filler door cannot be opened Remove the cover inside the trunk and pull the lever to unlock the fuel filler door. Then press the center of the rear edge of the fuel filler door to open it. AVALON (U)_(OM41452U)
Page 168 CAUTION ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 169: Cruise Control
4-5. Using the driving support systems ∗ Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Display Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control.
Page 170 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 171 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41452U)
Page 172 4-5. Using the driving support systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 173: Dynamic Radar Cruise Control
4-5. Using the driving support systems ∗ Dynamic radar cruise control Summary of functions Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Vehicle-to-vehicle distance but- Display Indicators...
Page 174 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will be displayed. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set...
Page 175 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 176 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance Pressing the button changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short Preceding vehicle mark The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 177 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 178 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 179 4-5. Using the driving support systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 180 4-5. Using the driving support systems Selecting conventional constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to dirt etc.
Page 181 The windshield wipers are operating at high speed (when the wipers are in AUTO mode [rain-sensing windshield wipers] or the high speed wiper oper- ation). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. AVALON (U)_(OM41452U)
Page 182 If the warning message remains on even after the above actions have been performed, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41452U)
Page 183 4-5. Using the driving support systems ■ Certification For vehicles sold in the U.S.A. FCC ID: HYQDNMWR004 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 184 4-5. Using the driving support systems CAUTION ■ Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 185 4-5. Using the driving support systems CAUTION ■ To avoid inadvertent cruise control activation Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 186 4-5. Using the driving support systems CAUTION ■ When the sensor may not be correctly detecting the vehicle ahead Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (→P.
Page 187 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 188: Driving Mode Select Switches
4-5. Using the driving support systems ∗ Driving mode select switches The driving modes can be selected to suit driving condition. Normal mode Use for normal driving. While in Eco drive mode or sport mode, press the switch to change the driving mode to normal mode.
Page 189 4-5. Using the driving support systems Sport mode Use sport mode when increased acceleration response and precise handling is desired, for example, when driving on mountain roads. When the “SPORT” switch is pressed, the “SPORT” indicator comes on in the instrument cluster. ■...
Page 190: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 191 4-5. Using the driving support systems When the TRAC/VSC systems are operating The slip indicator light will flash while the TRAC/VSC systems are operating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels.
Page 192 TRAC has been disabled and “TRAC OFF” indicator light comes on even if the TRAC/VSC OFF switch has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC and TRAC systems ●...
Page 193 4-5. Using the driving support systems CAUTION ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 194 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 195 4-5. Using the driving support systems ∗ PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, the pre-collision system such as the brakes and seat belts are automatically engaged to lessen impact as well as vehicle dam- age.
Page 196 4-5. Using the driving support systems Disabling pre-collision system Enabled Disabled The “PCS” warning light turns on when pre-collision system is dis- abled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and determines whether a collision is imminent based on the position, speed, and heading of the obstacles.
Page 197 4-5. Using the driving support systems ■ The pre-collision system is operational when The pre-collision system off switch is not pressed and the following conditions are met: ● Pre-collision seat belts (operating conditions A): • Vehicle speed is greater than about 19 mph (30 km/h). •...
Page 198 4-5. Using the driving support systems ■ Conditions that may trigger the system even if there is no possibility of a collision ● When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 199 ■ When there is a malfunction in the system “PCS” warning light will flash and warning messages will be displayed. (→P. 389) Have the vehicle inspected by your Toyota dealer immediately. ■ Certification For vehicles sold in the U.S.A.
Page 200 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 201 4-5. Using the driving support systems CAUTION ■ Cautions regarding the assist contents of the system By means of alarms and brake control, the pre-collision system is intended to assist the driver in avoiding collisions through the process of LOOK- JUDGE-ACT.
Page 202 4-5. Using the driving support systems ∗ BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 203 The outside temperature is extremely high or low ● The sensor voltage has become abnormal If a message continues to be displayed, have the vehicle inspected by your Toyota dealer. ■ Certification for the Blind Spot Monitor system For vehicles sold in the U.S.A.
Page 204 If the sensor moves even slightly off position, the system may mal- function and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. ● Do not disassemble the sensor.
Page 205 4-5. Using the driving support systems The Blind Spot Monitor function detection areas The areas that vehicles can be detected in are outlined below. The range of the detection area extends to: Approximately 11.5 ft. (3.5 m) from the side of the vehicle The first 1.6 ft.
Page 206 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The BSM main switch is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ■ The Blind Spot Monitor function will detect a vehicle when ●...
Page 207 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow etc. •...
Page 208 4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 209 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 210 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians etc.
Page 211: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 212 4-6. Driving tips Before driving the vehicle Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 213 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3 mm) in diameter 0.39 in. (10 mm) in width 1.18 in. (30 mm) in length Cross chain: 0.16 in.
Page 214 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 215 4-6. Driving tips AVALON (U)_(OM41452U)
Page 216: Automatic Air Conditioning System
5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Front control panel (type A) Front control panel (type B) AVALON (U)_(OM41452U)
Page 217 5-1. Using the air conditioning system and defogger Driver’s side temperature con- Outside air or recirculated trol mode Windshield defogger SYNC mode Driver’s side temperature dis- Cooling and dehumidification play function on/off Fan speed display Fan speed control Air outlet display Front passenger’s side tem- Automatic mode perature display...
Page 218 5-1. Using the air conditioning system and defogger Using the automatic air conditioning system ■ Using automatic operation Touch The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Touch (driver’s side) to increase the temperature and touch (driver’s side) to decrease the temperature.
Page 219 5-1. Using the air conditioning system and defogger ■ Changing the rear seat temperature settings (vehicles with a rear control switch) Turn clockwise to increase the temperature and turn counterclockwise to decrease the temperature. ■ Confirming automatic operation status During automatic operation, the operation status of fan speed, air outlet mode, outside/recirculated air mode and whether the A/C is on or off can be confirmed on the display by touching The display will return to its previous state after a few seconds.
Page 220 5-1. Using the air conditioning system and defogger To adjust the temperature setting, touch (driver’s side) to increase the temperature and touch (driver’s side) to decrease the temperature. The temperature for the driver’s, front passenger’s and rear seats (vehi- cles with a rear control switch) can be adjusted separately when: •...
Page 221 5-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to the outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 222 5-1. Using the air conditioning system and defogger Air flows mainly to the feet. Air flows to the feet and the wind- shield defogger operates. Switching between outside air and recirculated air modes Press The mode switches between (outside air mode) and (recircu- lated air mode) each time the button is pressed.
Page 223 5-1. Using the air conditioning system and defogger Front side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Rear outlets Direct air flow to the left or right, up or down.
Page 224 5-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode ● When driving on dusty roads such as tunnels or in heavy traffic, set the out- side/recirculated air mode to the recirculated air mode. This is effective in preventing outside air from entering the vehicle interior.
Page 225 5-1. Using the air conditioning system and defogger ■ Handling of the air conditioning panel The operating section of the air conditioning panel uses capacitive touch sen- sors. In the following cases, incorrect operation or non-response may occur. ● If the operating section is dirty or has liquid attached to it, incorrect operation or non-response may occur.
Page 226: Rear Window And Outside Rear View Mirror Defoggers
5-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mir- rors. On/off The defoggers will automatically turn off after 15 to 60 minutes.
Page 227: Audio System Types
5-2. Using the audio system Audio system types With Display Audio system Owners of models equipped with a Display Audio system should refer to the “Display Audio System Owner's Manual”. Type A Type B With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”.
Page 228 5-2. Using the audio system ■ ® About Bluetooth (with Display Audio system) The Bluetooth wordmark and logo are owned by Bluetooth SIG. and permis- sion has been granted to use the trademark of the licensee Panasonic Corpo- ration. Other trademarks and trade names are owned by various different owners.
Page 229 5-2. Using the audio system CAUTION • This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum per- missive exposure evaluation (MPE).
Page 230 5-2. Using the audio system CAUTION ● Laser products • Do not take this unit apart or attempt to make any changes yourself. This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs. The laser is carefully shielded so that its rays remain inside the cabinet.
Page 231: Using The Usb/Aux Port
5-2. Using the audio system Using the USB/AUX port This port can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Push the tray forward until it locks. Open the cover and connect the portable audio device.
Page 232: Interior Lights List
5-3. Using the interior lights Interior lights list Outer foot lights (if equipped) Ambient lights (if equipped) (→P. 256) Rear personal/interior lights (→P. 255) Front door courtesy lights Front personal/interior lights (→P. 255) AVALON (U)_(OM41452U)
Page 233 5-3. Using the interior lights Personal/interior light main switch Turns the lights on/off Turns the lights on/off linked to door position Personal/interior lights ■ Front Turns the light on/off ■ Rear Turns the light on/off If the lights are turned on by the personal/interior light main...
Page 234 5-3. Using the interior lights Ambient lights (if equipped) Each time the “MOOD” switch is pressed, brightness level changes. ■ Illuminated entry system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.
Page 235: List Of Storage Features
5-4. Using the storage features List of storage features Auxiliary boxes (→P. 261) Cup holders (→P. 260) Glove box (→P. 258) Console box (→P. 259) CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 236 5-4. Using the storage features Glove box Open (pull up the lever) Lock with the mechanical key Unlock with the mechanical key ■ Removing the insert The insert inside the glove box can be removed. CAUTION ■ Caution while driving Keep the glove box closed.
Page 237 5-4. Using the storage features Console box Lift the lid while pulling up the lever to release the lock. ■ When using the console box lid as an armrest Slide the console box lid forward as needed. Slide the lid forward while pulling up the lever.
Page 238 5-4. Using the storage features CAUTION ■ Caution while driving Keep the console box closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open console box or the items stored inside. Cup holders Front Rear (type A)
Page 239 5-4. Using the storage features CAUTION ■ Items unsuitable for the cup holders Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 240 5-4. Using the storage features Type C Opening Push the tray forward until it locks. Closing Push the tray forward to release the lock and the tray will automati- cally close. ■ When placing small items on top of the tray The tray can be opened while small items are placed on it.
Page 241 The LED indicators will be illuminated if the surface of the tray cools down. If the LED indicators flash even though the surface of the tray is not hot, the wireless charger may be malfunctioning. Consult your Toyota dealer. AVALON (U)_(OM41452U)
Page 242 ■ Certification for the wireless charger For vehicles sold in the U.S.A. This device complies with Part 18 of the FCC Rules. Toyota Motor Sales, U.S.A., Inc. 19001 S. Western Avenue Torrance, CA 90501 For vehicles sold in Canada This ISM device complies with Canadian ICES-001.
Page 243 5-4. Using the storage features CAUTION ■ Caution regarding interference with electronic devices (vehicles with a wireless charger) ● People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators should main- tain a reasonable distance between themselves and the wireless charger. The radio waves may affect the operation of such devices.
Page 244: Trunk Features
5-4. Using the storage features Trunk features Grocery bag hooks Cargo net (if equipped) AVALON (U)_(OM41452U)
Page 245 5-4. Using the storage features NOTICE ■ To prevent damage to the hooks Do not apply too much load to the hooks. AVALON (U)_(OM41452U)
Page 246: Sun Visors And Vanity Mirrors
5-5. Other interior features Sun visors and vanity mirrors Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 247 5-5. Other interior features Clock The clock can be adjusted by pressing the buttons. Type A Adjusts the hours Pressing and holding the button adjusts hours forward quickly 1 hour at a time. Adjusts the minutes Pressing and holding the button adjusts the minutes forward quickly by 1 minute at a time.
Page 248 5-5. Other interior features ■ The clock is displayed when The engine switch is in ACCESSORY or IGNITION ON mode. ■ When disconnecting and reconnecting battery terminals Type A The time display will automatically be set to 12:00 AM. Type B The time display will automatically be set to 12:00.
Page 249: Outside Temperature Display
When the vehicle is stopped, or moving at low speeds (less than 16 mph [25 km/h]). ● When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) ■ When “---°F” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. AVALON (U)_(OM41452U)
Page 250: Power Outlets
5-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. ■ Console box AVALON (U)_(OM41452U)
Page 251 5-5. Other interior features ■ Instrument panel Type A Type B ■ The power outlets can be used when The engine switch is in ACCESSORY or IGNITION ON mode. NOTICE ■ To avoid damaging the power outlets Close the power outlet lids when the power outlets are not in use. Foreign objects or liquids that enter the power outlets may cause a short cir- cuit.
Page 252: Seat Heaters
5-5. Other interior features ∗ ∗ Seat heaters /seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. Seat heaters/ventilators ■ Front seats Vehicles with ventilator Press the knob to release it, and turn the knob to the desired temperature setting.
Page 253 5-5. Other interior features ■ Rear seats ON/OFF The indicator illuminates when the seat heater is turned on. ■ The seat heaters/seat ventilators can be used when The engine switch is in IGNITION ON mode. ■ Automatic operation of the seat ventilator for the passenger's seat When a passenger leaves the passenger seat while the seat ventilation turns on, the seat ventilator automatically turns off.
Page 254 5-5. Other interior features CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 255 5-5. Other interior features Armrest Fold down the armrest for use. NOTICE ■ To prevent damage to the armrest Do not apply too much load on the armrest. AVALON (U)_(OM41452U)
Page 256: Rear Sunshade
5-5. Other interior features ∗ Rear sunshade The rear sunshade can be raised and lowered by pressing the switch shown below. Extends/retracts the rear sun- shade ■ The rear sunshade can be used when The engine switch is in IGNITION ON mode. ■...
Page 257 5-5. Other interior features CAUTION ■ When the rear sunshade is being raised or lowered Do not place fingers or other objects in the fastener section or in the open- ing. They may get caught, causing injury. NOTICE ■ To prevent battery discharge Do not operate the rear sunshade when the engine is not running.
Page 258: Trunk Storage Extension
5-5. Other interior features Trunk storage extension Long objects can be loaded into the vehicle by utilizing the trunk space and rear seat area. Fold down the armrest. Push down the handle and open the armrest door. The armrest door can be locked unlocked using mechanical key.
Page 259: Coat Hooks
5-5. Other interior features Coat hooks The coat hooks are provided with the rear assist grips. CAUTION ■ Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 260: Assist Grips
5-5. Other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. CAUTION ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 261: Garage Door Opener
5-5. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manu- ®...
Page 262 5-5. Other interior features ® ■ Programming the HomeLink Point the remote control for the device 1 to 3 in. (25 to 75 ® mm) from the HomeLink control buttons. Keep the indicator light on the ® HomeLink in view while pro- gramming.
Page 263 5-5. Other interior features Test the operation of the ® HomeLink by pressing the newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 264 5-5. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 265 ® the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 266 5-5. Other interior features ® Operating the HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator ® light on the HomeLink transceiver should turn on. ® The HomeLink continues to send a signal for up to 20 seconds as long as the button is pressed.
Page 267 5-5. Other interior features ■ Before programming ● Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ® HomeLink ■ Certification for the garage door opener For vehicles sold in U.S.A. FCC ID: NZLWZLHL4 NOTE: This device complies with Part 15 of the FCC Rules.
Page 268: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 269 After you have signed the Telematics Subscription Service Agree- ment and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” button in your vehicle for further subscription details. AVALON (U)_(OM41452U)
Page 270 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 271 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 272 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 273 5-5. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 274 5-5. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. ■ Operation To turn the compass on or off, press the switch for more than 3 seconds.
Page 275 5-5. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 276 5-5. Other interior features ■ Circling calibration When “C” appears on the dis- play, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 277 5-5. Other interior features NOTICE ■ To avoid the compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass ●...
Page 278 5-5. Other interior features AVALON (U)_(OM41452U)
Page 279: Cleaning And Protecting The Vehicle Exterior
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 280 6-1. Maintenance and care ■ When using a car wash If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In that case, follow the fol- lowing correction procedures to wash the vehicle: ●...
Page 281 ■ Precaution regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. AVALON (U)_(OM41452U)
Page 282 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 283: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 284 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 285 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 286: Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 287 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 288: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 289 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Automatic transmission “Park” shift lever is in P, is the vehicle mechanism securely stopped? •...
Page 290 6-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Moves smoothly? • When parked on a slope and the Parking brake parking brake is on, is the vehicle securely stopped?
Page 291 6-2. Maintenance Vehicle exterior Items Check points • Do doors/trunk operate Doors/trunk smoothly? • Does the engine hood lock system Engine hood work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 292: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 293: Do-It-Yourself Service Precautions
“Toyota Super Long Life Coolant” is pre-mixed with 55% coolant and 45% deionized water. • Funnel (used only for adding cool- ant) • “Toyota Genuine Motor Oil” or equivalent Engine oil level (→P. 323) • Rag or paper towel • Funnel (used only for adding...
Page 294 6-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 352) as original • Bulb with same number and watt- age rating as original Light bulbs (→P. 361) • Phillips-head screwdriver • Flathead screwdriver • Wrench ⎯...
Page 295 6-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 296 6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. CAUTION ■...
Page 297: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ◆ Front ◆ Rear AVALON (U)_(OM41452U)
Page 298 6-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 299: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Engine oil filler cap (→P. 324) Radiator (→P. 328) Engine oil level dipstick Electric cooling fans (→P. 323) Condenser (→P. 328) Brake fluid reservoir Engine coolant reservoir (→P. 329) (→P. 326) Fuse box (→P. 352) Washer fluid tank (→P.
Page 300 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 301 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 302 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 303 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. AVALON (U)_(OM41452U)
Page 304 6-3. Do-it-yourself maintenance CAUTION ■ When the engine is hot Do not remove the engine coolant reservoir cap or the radiator cap. (→P. 424) The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. NOTICE ■...
Page 305 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■...
Page 306 6-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” line “MIN” line ■ Adding fluid Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 307 6-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 308 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. CAUTION ■...
Page 309 6-3. Do-it-yourself maintenance CAUTION ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5 A or less).
Page 310 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. CAUTION ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 311 Check spare tire condition and pressure if not rotated. Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. AVALON (U)_(OM41452U)
Page 312 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 337) ◆ Initializing the tire pressure warning system ■...
Page 313 6-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the engine switch off. Initialization cannot be performed while the vehicle is moving. Adjust the tire inflation pressure to the specified cold tire inflation pressure level.
Page 314 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 315 6-3. Do-it-yourself maintenance ■ Low profile tires (18-inch tires) Generally, low profile tires will wear more rapidly and tire grip perfor- mance will be reduced on snowy and/or icy roads when compared to standard tires. Be sure to use snow tires or tire chains on snowy and/or icy roads and drive carefully at a speed appropriate for road and weather conditions.
Page 316 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 317 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 318 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 319: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (→P. 435) AVALON (U)_(OM41452U)
Page 320 Driving with incorrect tire inflation pressure may result in the following: ● Reduced fuel efficiency ● Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. AVALON (U)_(OM41452U)
Page 321 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 322 ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 323 6-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 324 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 325: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box. (→P. 258) Lift up the side with the stay, disconnect the stay tabs and remove the partition by pulling horizontally.
Page 326 6-3. Do-it-yourself maintenance Remove the air conditioning fil- ter and replace it with a new one. The “↑UP” marks shown on the fil- ter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 327: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover.
Page 328 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 329: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. After a system failure, see “Fuse layout and amperage ratings” for details about which fuse to check.
Page 330 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer. Type A Type B Type C...
Page 331 6-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse block Fuse block on the back of the cover Fuse Ampere Circuit METER-IG2 Gauge and meters 50 A Electric cooling fans H-LP CLN 30 A No circuit 50 A Air conditioning system 140 A Charging system...
Page 332 6-3. Do-it-yourself maintenance Fuse Ampere Circuit ST/AM2 30 A Starter system H-LP LH-LO, H-LP RH-LO, headlights H-LP-MAIN 30 A (low beam) ABS NO.1 50 A Vehicle stability control system 10 EPS 80 A Electric power steering 11 S-HORN 7.5 A S-HORN 12 HORN 10 A...
Page 333 6-3. Do-it-yourself maintenance Fuse Ampere Circuit 27 EFI-MAIN NO.1 30 A EFI NO.2, EFI NO.3, A/F sensor 28 SMART No circuit 29 ETCS 10 A Electronic throttle control system 30 TOWING 20 A No circuit Multiport fuel injection system/sequential 31 EFI NO.1 7.5 A multiport fuel injection system, electronic controlled transmission...
Page 334 6-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit H-LP LVL 7.5 A Automatic headlight leveling system S/HTR RR 20 A Rear seat heater Outside rear view mirrors, glove box light, ECU-ACC air conditioning system, multiplex com- munication system RR P/OUTLET 15 A Power outlet...
Page 335 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Stop/tail lights, multiport fuel injection system/sequential multiport fuel injection system, vehicle stability control system, 14 STOP 7.5 A anti-lock brake system, electronic con- trolled transmission, high mounted stop- light, smart key system, shift lock control system 15 AM1 7.5 A...
Page 336 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Parking lights, side marker lights, stop/tail 33 TAIL 10 A lights, rear turn signal lights, back up lights, license plate lights, fog lights Switch illumination, air conditioning sys- tem, glove box light, interior lights, per- sonal lights, audio system, navigation system, rear sunshade, seat heater, 34 PANEL...
Page 337 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 361) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 338: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (→P. 436) AVALON (U)_(OM41452U)
Page 339 6-3. Do-it-yourself maintenance Bulb locations ■ Front Headlight low beam (halogen bulb) Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams) Headlight high beam (vehicles with discharge bulbs for low beams) Fog light (if equipped) Front turn signal/parking light AVALON (U)_(OM41452U)
Page 340 6-3. Do-it-yourself maintenance ■ Rear Rear turn signal light Back-up light License plate light AVALON (U)_(OM41452U)
Page 341 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beam (halogen bulb) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set.
Page 342 6-3. Do-it-yourself maintenance ■ Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams)/Headlight high beam (vehicles with discharge bulbs for low beams) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise.
Page 343 6-3. Do-it-yourself maintenance ■ Fog light (if equipped) To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
Page 344 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector.
Page 345 6-3. Do-it-yourself maintenance Reinstall the fender liner and the fender liner bolt. Reinstall the fender liner clips. AVALON (U)_(OM41452U)
Page 346 6-3. Do-it-yourself maintenance ■ Front turn signal/parking light To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
Page 347 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41452U)
Page 348 6-3. Do-it-yourself maintenance ■ Rear turn signal light Open trunk remove the luggage trim cover clip. Pull the hook while depress- ing the button. Partly remove the luggage trim cover. AVALON (U)_(OM41452U)
Page 349 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41452U)
Page 350 6-3. Do-it-yourself maintenance ■ Back-up light Open trunk remove the clips. Then partly remove trunk panel cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41452U)
Page 351 6-3. Do-it-yourself maintenance ■ License plate light Remove the cover. To prevent damaging the vehi- cle, wrap the flathead screw- driver with a tape. Remove the lens. Insert a properly sized screw- driver into the hole of the lens, and pry off the lens as shown in the illustration.
Page 352 ■ Replacing the following bulbs If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (discharge bulb) ● Daytime running lights (vehicles with discharge headlights) ● Side marker lights ●...
Page 353 The daytime running lights (vehicles with discharge headlights), stop/tail lights, high mounted stoplight and outer foot lights each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 354 6-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 355 6-3. Do-it-yourself maintenance CAUTION ■ Discharge headlights (if equipped) ● Contact your Toyota dealer before replacing the discharge headlights (including light bulbs). ● Do not touch the discharge headlight’s high voltage socket when the head- lights are turned on. An extremely high voltage of 30000 V will be discharged and could result in death or serious injury by electric shock.
Page 356: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 357 7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 358: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 359 7-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front From the rear Release the parking brake. Use a towing dolly under the front wheels.
Page 360 7-2. Steps to take in an emergency Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be dam- aged.
Page 361: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 362: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 363: If A Warning Light Turns On Or A Warning Buzzer Sounds
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 364 Low engine oil pressure warning light Indicates that the engine oil pressure is too low. Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
Page 365 7-2. Steps to take in an emergency Warning light Warning light/Details Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steer- ing) system “PCS” warning light Indicates a malfunction in the pre-collision system The warning light will operate as follows, even when the system is not malfunctioning: •...
Page 366 7-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure Open door warning light (warning buzzer) Check that all the doors and Indicates that a door or the the trunk are closed.
Page 367 • Flat tire (→P. 399) pressure adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire pres- by your Toyota dealer.
Page 368 7-2. Steps to take in an emergency : Open door warning buzzer: A buzzer will sound if the vehicle reaches a speed of 3 mph (5 km/h) or more with any door open. : Driver’s seat belt buzzer: The driver’s seat belt buzzer sounds to alert the driver that his or her seat belt is not fastened.
Page 369 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 370 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 371 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 372 7-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 373 7-2. Steps to take in an emergency CAUTION TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 374: If A Warning Message Is Displayed
Multi-information display If any of the warning message is shown again after its correction pro- cedure has been performed, contact your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 375: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare tire provided. For details about tires: →P. 334 CAUTION ■ If you have a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair, which could result in an accident.
Page 376 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Luggage floor cover Jack Jack handle Spare tire Tool tray Wheel nut wrench AVALON (U)_(OM41452U)
Page 377 7-2. Steps to take in an emergency CAUTION ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 378 7-2. Steps to take in an emergency Taking out the jack and jack handle Remove luggage floor cover. Remove the jack. AVALON (U)_(OM41452U)
Page 379 7-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. (→P. 402) Remove the tool tray. Loosen the center fastener that secures the spare tire. CAUTION ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 380 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 381 7-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 382 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 383 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 384 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. AVALON (U)_(OM41452U)
Page 385 7-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 386 7-2. Steps to take in an emergency CAUTION ■ When using the compact spare tire ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. ●...
Page 387 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. AVALON (U)_(OM41452U)
Page 388: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (→P. 155), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
Page 389 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 418) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 390: If The Shift Lever Cannot Be Shifted From P
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 391: If The Electronic Key Does Not Operate Properly
7-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (→P. 100) or the electronic key cannot be used because the battery is depleted, the smart key system and wire- less remote control cannot be used.
Page 392 Firmly depress the brake pedal. A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. AVALON (U)_(OM41452U)
Page 393 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 394: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 395 ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. AVALON (U)_(OM41452U)
Page 396 7-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. ●...
Page 397 7-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 398: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 399 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 400 7-2. Steps to take in an emergency CAUTION ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 401: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the front wheels.
Page 402 7-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the front wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 403: Maintenance Data (Fuel, Oil Level, Etc.)
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 195.3 in. (4960 mm) Overall width 72.2 in. (1835 mm) Overall height 57.5 in. (1460 mm) Wheelbase 111.0 in. (2820 mm) Front 62.6 in. (1590 mm) Tread Rear 62.2 in.
Page 404 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is located on the top left of the instrument panel.
Page 405 8-1. Specifications Engine Model 3.5L 6-cylinder (2GR-FE) Type 6-cylinder V type, 4-cycle, gasoline 3.70 × 3.27 in. (94.0 × 83.0 mm) Bore and stroke Displacement 210.9 cu.in. (3456 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only...
Page 406 8-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 407 8-1. Specifications Cooling system Capacity 9.7 qt. (9.2 L, 8.1 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 408 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. AVALON (U)_(OM41452U)
Page 409 8-1. Specifications Brakes Pedal clearance 1.43 in. (36.4 mm) Min. 0.04 ⎯ 0.24 in. (1.0 ⎯ 6.0 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) ⎯ 10 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.116 DOT 3...
Page 410 8-1. Specifications Tires and wheels Type A Tire size P215/55R17 93V Front Tire inflation pressure 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold Rear tire inflation pressure) 35 psi (240 kPa, 2.4 kgf/cm or bar) 17 × 7J Wheel size Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Page 411 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights ⎯ Low beam (discharge bulbs) Low beam (halogen bulbs) 9005 High beam 9005 ⎯ Fog lights Front turn signal/parking lights 7444NA 28/8 Exterior Side marker lights Side turn signal lights WY5W Rear turn signal lights Back-up lights...
Page 412: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 413 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA's lowest additives concen- tration program.
Page 414 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 415: Tire Information
8-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire AVALON (U)_(OM41452U)
Page 416 8-1. Specifications Tire size (→P. 443) DOT and Tire Identification Number (TIN)(→P. 442) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators(→P. 334) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 417 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 418 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits)
Page 419 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer AVALON (U)_(OM41452U)
Page 420 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 421 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 422 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 423 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 424 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 425 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 426 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 427 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 428: Customizable Features
Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizable features Vehicles with a Display Audio system: Settings that can be changed...
Page 429 8-2. Customization Custom- Default Item Function ized setting setting Operation signal — O O (Emergency flashers) Operation signal — — O (Buzzer) Operation buzzer vol- Off to level Smart key Level 5 O O O system wire- less Time elapsed before remote automatic...
Page 430 8-2. Customization Custom- Default Item Function ized setting setting Wireless remote control — — O Driver's door unlocked All doors in one unlocked Unlocking operation step, all — O O in one doors step. unlocked Wireless in two remote steps control Panic function —...
Page 431 8-2. Customization Custom- Default Item Function ized setting setting Trunk Trunk opener main Deacti- Activated — — O → P. 112) switch vated Driver’s seat movement when exiting the vehi- Full O O O Partial Front seats Seats operated by the Driver’s (→P.
Page 432 8-2. Customization Custom- Default Item Function ized setting setting Interior lights illumina- — — O tion control 7.5 sec- Time elapsed before 15 sec- onds — O O lights turn off onds 30 sec- onds Center console spot light — — O Operation when —...
Page 433 8-2. Customization Custom- Default Item Function ized setting setting Instrument Instrument panel light Level 1 to panel Level 3 — — O auto dimmer control → P. 79) Automatic condi- A/C auto switch opera- tioning sys- Auto Manual — O O tion →...
Page 434 8-2. Customization NOTICE ■ During customization To prevent battery discharge, ensure that the engine is running while cus- tomizing features. AVALON (U)_(OM41452U)
Page 435: Items To Initialize
8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the maintenance being performed on the vehicle: Item When to initialize Reference • After the maintenance is per- Maintenance data P.
Page 436: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 437: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 438 ATTENTION ■ Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité périodiquement. Contrôlez qu’elles ne sont pas entaillées, effilochées et que leurs ancrages ne sont pas desser- rés. N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée.
Page 439: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 440 ◆ Coussins gonflables latéraux et rideau SRS Coussins gonflables avant latéraux SRS Peuvent aider à protéger le torse des passagers avant Coussins gonflables arrière SRS latéraux Participent à la protection du haut du corps des occupants assis aux places arrière extérieures Coussins gonflables rideau SRS Participent principalement à...
Page 441 Composants du système de coussins gonflables SRS Capteurs d’impact avant Capteurs d’impact latéral (arrière) Coussins gonflables genoux Coussin gonflable conducteur Capteurs d’impact latéral (por- Contacteur de boucle de cein- tes avant) ture de sécurité conducteur Prétensionneurs de ceintures Capteur de position du siège de sécurité...
Page 442 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des coussins gonflables régule le déploiement de ces derniers sur la base des informations qu’il reçoit des capteurs, etc., indiqués ci-des- sus dans le schéma illustrant les composants du système.
Page 443 ATTENTION ■ Précautions concernant les coussins gonflables SRS Respectez les précautions suivantes avec les coussins gonflables SRS. Autrement, des blessures graves, voire mortelles, pourraient s’ensuivre. ● Le conducteur et les passagers du véhicule doivent porter correctement leur ceinture de sécurité. Les coussins gonflables SRS sont des dispositifs supplémentaires à...
Page 444 Installez dans un siège de sécurité enfant les nourris- sons et les enfants trop petits pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement atta- chés.
Page 445 ATTENTION ■ Précautions concernant les coussins gonflables SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas contre le tableau de bord. ● Ne laissez pas un enfant rester debout devant le coussin gonflable SRS passa- ger avant ou bien s’asseoir sur les genoux du passager avant.
Page 446 Essuyez tout résidu dès que possible afin d’éviter d’éventuelles irritations de la peau. ● Si les parties renfermant les coussins gonflables SRS, telles que la garni- ture du volant et les garnitures de montants avant et arrière, sont abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota. AVALON (U)_(OM41452U)
Page 447 Modification et mise au rebut des éléments du système de coussins gonflables SRS Consultez impérativement votre concessionnaire Toyota avant de mettre votre véhicule au rebut ou de procéder à l'une des modifications suivantes. Les coussins gonflables SRS peuvent être défaillants ou se déployer (se gonfler) accidentellement, provoquant la mort ou de graves blessures.
Page 448 AVALON (U)_(OM41452U)
Page 449 You lose your keys ● If you lose your mechanical keys, new genuine mechanical keys can be made by your Toyota dealer. (→P. 89) ● If you lose your electronic keys, the risk of vehicle theft increases significantly. Contact your Toyota dealer immediately. (→P. 90) The doors cannot be locked or unlocked ●...
Page 450 What to do if... (Troubleshooting) The rear door cannot be opened ● Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock.
Page 451 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the brake pedal? (→P. 155) ● Is the shift lever in P? (→P. 158) ●...
Page 452 What to do if... (Troubleshooting) The windows do not open or close by operating the power window switches ● Is the window lock switch pressed? The power window except for the one at the driver’s seat cannot be operated if the window lock switch is pressed. (→P. 130) The engine switch is turned off automatically ●...
Page 453 What to do if... (Troubleshooting) An alarm is activated and the horn sounds ● Did anyone inside the vehicle open a door during setting the alarm? The sensor detects it and the alarm sounds. (→P. 68) To stop the alarm, turn the engine switch to IGNITION ON mode or start the engine.
Page 454 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (→P. 399) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 455 Alphabetical index Alphabetical index Alarm .......... 68 A/C ..........238 Alarm ........68 Air conditioning filter ..... 348 Warning buzzer ....387 Automatic air conditioning Anchor brackets ......55 system ........ 238 Antennas (smart key system) ....93 (Anti-lock Brake System)..211 Anti-lock Brake System Function ........
Page 456 Alphabetical index Back-up lights Care ........302, 306 Replacing light bulbs..... 373 Aluminum wheels ....303 Wattage ........ 436 Exterior ......... 302 Battery ........330 Interior ........306 Battery checking ....330 Seat belts......307 If the vehicle battery Cargo capacity......152 is discharged ......
Page 457 Alphabetical index Child safety ........ 50 Airbag precautions....36 Daytime running light Battery precautions..331, 421 system........170 Child restraint system ..... 51 Defogger How your child should Front windshield ....243 wear the seat belt ....30 Outside rear view mirrors ..248 Installing child restraints ..
Page 458 Alphabetical index Emergency flashers ....380 Eco drive mode......209 Engine Eco Drive Indicator....140 Accessory mode ....156 EDR (Event data recorder)..10 Compartment......322 Electric Power Steering Engine switch ....... 155 (EPS)........211 Hood ........319 Function ........ 211 How to start the engine..
Page 459 Alphabetical index Front turn signal lights ... 165 Flat tire........399 Replacing light bulbs .... 369 Floor mats ........24 Turn signal lever ....165 Fluid Wattage ........ 436 Automatic transmission..433 Fuel ........... 430 Brake ........434 Capacity........ 430 Washer .........
Page 460 Alphabetical index Head restraints ......121 I/M test ........315 Headlights ........ 168 Identification Automatic high beam .... 172 Engine ........429 Discharge headlights Vehicle........429 precautions......378 Ignition switch Light switch ......168 (engine switch)...... 155 Replacing light Illuminated entry system ..256 bulbs....
Page 461 Alphabetical index License plate lights ....168 Keyless entry ......91 Light switch......168 Smart key system ....91 Replacing light bulbs .... 374 Wireless remote control ..106 Wattage ........ 436 Keys ..........88 Lights Battery-saving function ... 99 Automatic high beam....
Page 462 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 316 Noise from under vehicle ... 8 General maintenance ... 311 Maintenance data ....428 Maintenance requirements ... 309 Odometer ........77 Reset the maintenance data ........310 Engine oil......430 Malfunction indicator lamp..388 Opener Master warning light....
Page 463 Alphabetical index Paddle shift switches ....162 Radar cruise control (dynamic Parking brake......166 radar cruise control) ..... 194 Operation ......166 Radiator........328 Parking brake engaged Rear personal lights....255 warning buzzer ....387 Rear seat heaters ....275 Parking lights......
Page 464 Alphabetical index Seats......... 116 Safety Connect ......290 Adjustment......116 Seat belts........28 Adjustment precautions ..117 Adjusting the seat belt .... 29 Child seats/child restraint Automatic Locking system installation....55 Retractor....... 30 Cleaning ....... 306 Child restraint system Driving position memory ..118 installation ......
Page 465 Alphabetical index Side mirrors ......127 Stuck Adjusting and folding .... 127 If the vehicle becomes Blind Spot Monitor ....223 stuck........425 Linked mirror function Sun shade when reversing ....128 Rear........278 Mirror position memory ..118 Roof ........134 Side turn signal lights .....
Page 466 Alphabetical index Rear sunshade switch ..278 Rear window and outside Tachometer ........ 77 rear view mirror defoggers Tail lights........168 switch ......... 248 Light switch......168 Seat heater switches .... 274 Replacing light bulbs .... 375 Seat ventilator switches ..274 Theft deterrent system “SOS”...
Page 467 Alphabetical index Tires .......... 334 Trunk ........112 Chains........234 Internal trunk release lever ... 113 Checking....... 334 Luggage security system..113 If you have a flat tire ..... 399 Smart key system ....92 Inflation pressure ....435 Trunk features ...... 266 Information......
Page 468 Alphabetical index Weight Warning buzzers Cargo capacity...... 152 Approach warning....200 Load limits ......152 Brake system ......387 Weight ........428 Downshifting ......164 Wheels........345 Seat belt reminder ....390 Replacing wheels ....345 Warning lights......73 Size........435 ABS........

Toyota 2014 Avalon Owner's Manual

Quick Links

Related Manuals for Toyota 2014 Avalon

Summary of Contents for Toyota 2014 Avalon

Table of Contents
