Alpine TUE-T152 Owner's Manual

Tv tuner/diversity unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-8501, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
Sankei Kikaku Co., Ltd.
1-13-38, Hinodai, Hino, Tokyo, Japan
TUE-T152
TV TUNER/DIVERSITY UNIT
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare
l'attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7-11 40878 Ratingen, Germany
Tel.: 02102-45 50
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul Naviglio
Tel.: 02-48 47 81
B.P. 50016 F-95945, Roissy, Charles De Gaulle
13 Tanners Drive, Blakelands, Milton Keynes
MI, Italy
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Tel.: 34-45-283588
Designed by ALPINE Japan
Printed in Japan (S)
68P41262Y88-0
EN
DE
FR
ES
IT
SE

Advertisement

Table of Contents
loading

Related Manuals for Alpine TUE-T152

Summary of Contents for Alpine TUE-T152

  • Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. Tokyo office: 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)

  • Page 3: Table Of Contents

    ENGLISH Contents Operating Instructions WARNING WARNING ..........2 CAUTION ........... 2 PRECAUTIONS ......... 3 Controls on remote control ......4 Battery Replacement ........5 Basic Operations Turning Power On and Off ........ 6 Switching the TV Band ........6 TV Area Setting ..........6 Automatic Memory of Channel Presets ....

  • Page 4: Warning

    DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or YOUR VEHICLE. the nearest Alpine Service Center for repairing.

  • Page 5: Precautions

    Maintenance If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. Installation Location Make sure the TUE-T152 will not be exposed to: •...

  • Page 6: Controls On Remote Control

    Controls on remote control button Press the button to automatically seek for a channel downward. MANUAL button Press the button to automatically seek for a channel upward. BAND button CALL Preset channel is called each time the button is A.MEMO pressed.

  • Page 7: Battery Replacement

    Battery Replacement Applicable battery: Use two “AAA” sized dry batteries or equivalent. Opening the battery cover Slide out the battery cover while firmly pressing outward. Replacing the battery Put the batteries in the case observing the polarities as illustrated. Closing the cover Push the cover as illustrated until a click is heard.

  • Page 8: Basic Operations

    AUX1 or AUX2. The TV area setup menu appears. The source to be selected is changed by the connector to which TUE-T152 was connected. Press the PWR (Power) button of the remote control unit. The TV Tuner power is turned on.

  • Page 9: Automatic Memory Of Channel Presets

    Automatic Memory of Channel Tuning to Preset Channel Presets Call a TV broadcast station memorized by the auto memory. Broadcasting stations that can be received within the present TV area and all the channels Press the BAND button. receivable are automatically memorized. The band is switched each time the button is Refer to page 6 for channels of each TV area.

  • Page 10: Manual Storing Of Channel Presets

    Basic Operations Confirming Channel (Channel Call) Press the CALL button. Channel No. being received is displayed for approx. 5 seconds. CALL Channel selection mode WRITE P.SCAN Manual Storing of Channel Presets Press the CALL button again during a channel selection mode. The channel searched by “Manual Channel The channel memorization list is displayed for Selection”...

  • Page 11: Information De

    • Poor connection of guide control input cord. the rest of your system is properly connected or consult - Connect guide control cord of navigation securely. your authorized Alpine dealer. Channel display is incorrect. No power supplied. • The field strength is low.

  • Page 12: Installation And Connections

    Installation and Connections Before installing or connecting the unit, please Caution read the following and pages 2 and 3 of this manual thoroughly for proper use. HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS. Warning The wiring and installation of this unit requires special technical skill and experience.

  • Page 13: Precautions

    (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When connecting the TUE-T152 to the fuse box, make sure the fuse for the intended circuit of the TUE-T152 has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle.

  • Page 14: Preparation

    Installation and Connections Preparation Installation Park the vehicle in a flat, safe place. Apply the Installing TV TUNER parking brake, then remove the ignition key. This TV TUNER can be placed inside the trunk, on the kick panel of the front passenger's seat or Check the included parts and organize the tools and installation instructions.
  • Page 15 • Your Alpine dealer knows best about noise prevention measures so consult your dealer for Remote Control Sensor Unit Mounting further information.

  • Page 16: Connections

    NOTE Caution - when connecting the Rear Monitor Make sure to use the Remote Control Eye r , when operating TUE-T152 from the rear monitor. In this case, the signal of the Remote Control Input Lead 5 becomes ineffective. 1 Switched Power Lead (Ignition) (Red)
  • Page 17 Händlerstemple Tipps der Polizei: Stellen Sie Ihr Fahrzeug stets gut sichtbar ab. Verschließen Sie Türen, Fenster, Schiebedach und Kofferraum immer, auch bei nur kurzer Abwesenheit. Lassen Sie keine Wertsachen sichtbar im Auto liegen. Wird Ihr Fahrzeug aufgebrochen, wenden Sie sich sofort an die nächste Polizeidienststelle. Belassen Sie Ihr Fahrzeug nach einem Aufbruch im Originalzustand.
  • Page 18 Car Audio and Navigation Systems GERÄTE-PASS AUDIO SYSTEME Fahrzeugmarke: Typ: Amtl. Kennzeichen: Name des Halters: Straße: Wohnort: Bitte füllen Sie diesen Pass vollständig aus und bewahren Sie ihn außerhalb des Fahrzeugs auf: Im Falle eines Diebstahls wird für Sie die Schadensabwicklung mit der Versicherung einfacher, und Sie erleichtern der Polizei die Fahndung nach den Tätern.
