AMD Socket F Dual Processor Motherboard
USER'S MANUAL
AMD Opteron
*
The WEEE marking on the product indicates this product must not be disposed of with
user's other household waste and must be handed over to a designated collection point
for the recycling of waste electrical and electronic equipment!!
*
The WEEE marking applies only in European Union's member states.
GA-3CCWV-RH
GA-3CCWL-RH
Socket F Dual Processor Motherboard
™
Rev. 1001
12ME-3CCWVRH-1001R
Advertisement
Table of Contents
Related Manuals for Gigabyte GA-3CCWV-RH
Summary of Contents for Gigabyte GA-3CCWV-RH
- Page 1 GA-3CCWV-RH GA-3CCWL-RH AMD Socket F Dual Processor Motherboard USER’S MANUAL AMD Opteron Socket F Dual Processor Motherboard ™ Rev. 1001 12ME-3CCWVRH-1001R The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!! The WEEE marking applies only in European Union's member states.
-
Page 2: Table Of Contents
WARNING! ....................4 Chapter 1 Introduction ................5 1.1 Features Summary ................5 1.2 GA-3CCWV-RH Motherboard Components.......... 8 1.3 GA-3CCWL-RH Motherboard Components ........10 Chapter 2 Hardware Installation Process ..........12 2-1: Installing Processor and CPU Haet Sink ........... 12 2-1-1: Installing CPU ....................... - Page 3 Table of Content Exit ......................62 Chapter 4 Application Driver Installation ..........67 A.NVDIA Chipset Driver Installation ................67 B.Audio Hot Fix Driver Installation ................. 72 (For Windows 64-bit operating system) ................ 72 C.Realtek ALC883 Audio Driver Installation ..............76 D.DirectX 9.0 Driver Installation ..................
-
Page 4: Item Checklist
IDE (ATA133 ) cable x 1 / Floppy cable x 1 SATA Power cable x 3 CD for motherboard driver & utility GA-3CCWV-RH/GA-3CCWL-RH user’s manual WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. -
Page 5: Chapter 1 Introduction
400, 800, 1200, and 1600 MT/s. Supports L2/3 Cache with 1MB/2MB Chipset NVIDIA NFP3600 Chipset ® UDP 702404 (For GA-3CCWV-RH Only) ® Memory 8 x DDRII DIMM sockets Supports up to 32GB 533/667 memory Dual Channel memory bus... - Page 6 GA-3CCWV-RH/GA-3CCWL-RH Motherboard Hardware Monitor Enhanced features with CPU Vcore, 1.5V reference, VCC3 (3.3V) , VBAT3V, +5VSB, CPUA/B Temperature, and System Temperature Values viewing CPU/Power/System Fan Revolution Detect CPU shutdown when overheat System Voltage Detect On-Board LAN Dual Marvell 88E1116 GbE PHY ®...
-
Page 8: 1.2 Ga-3Ccwv-Rh Motherboard Components
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 1.2 GA-3CCWV-RH Motherboard Components Primary CPU SATA5 Connector Secondary CPU SATA6 Connector NVIDIA Front Fan Connector BIOS Flash Rear Fan Connector ITE IT8716F CPU0 Fan Connector Realtek ALC 883 CPU1 Fan Connector Marvell 88E1116 PCI-E x4 Slot IDE Connector... - Page 9 Introduction...
-
Page 10: 1.3 Ga-3Ccwl-Rh Motherboard Components
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 1.3 GA-3CCWL-RH Motherboard Components Primary CPU SATA5 Connector Secondary CPU SATA6 Connector NVIDIA BIOS Flash Front Fan Connector Battery Rear Fan Connector ITE IT8716F CPU0 Fan Connector Realtek ALC 883 CPU1 Fan Connector Marvell 88E1116 PCI-E x8 Slot... - Page 11 Introduction...
-
Page 12: Chapter 2 Hardware Installation Process
GA-3CCWV-RH/GA-3CCWL-RH Motherboard Chapter 2 Hardware Installation Process 2-1: Installing Processor and CPU Haet Sink Before installing the processor and cooling fan, adhere to the following cautions: 1. The processor will overheat without the heatsink and/or fan, resulting in permanent irreparable damage. - Page 13 Hardware Installation Process Step 4. When the processor installation is completed, apply thermal grease to the processor(as prior to installing the heatsink. AMD recommends using a high thermal conductivity grease for the thermal interface material rather than a phase change material. Phase change materials develop strong adhesive forces between the heatsink and processor.
-
Page 14: 2-1-2: Installing Heat Sink
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 2-1-2: Installing Heat Sink Step 1. Attach th cooling fan clip to the processor scoket. Align the heatsink assembly with the support frame mating with the backer plate standoffs as shown in Figure 5&6. Step 2. Coonect the processor fan cable to the processor fan connector. -
Page 15: 2-2: Install Memory Modules
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 2-2: Install Memory Modules Before installing the processor and heatsink, adhere to the following warning: When DIMM LED is ON, do not install/remove DIMM from socket. The motherboard has 8 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. -
Page 16: Installation Step
Hardware Installation Process Installation Step: 1. Unlock a DIMM socket by pressing the retaining clips outwards. 2. Aling a DIMM on the socket such that the notch on the DIMM exactly match the notches in the socket. Firmly insert the DIMMinto the socket until the retaining clips snap back in place. 3. - Page 17 Hardware Installation Process Table 1. Vaild DIMM Configuration for 64 bit Mode DIMM 0 (MB) DIMM 2 (MB) 1024 1024 1024 2048 2048 2048 4096 4096 4096 Note: X = Do not populate Table 2. Vaild DIMM Configuration for 128 bit Mode Logical DIMM 0 Ligical DIMM1 DIMM 0 (MB)
-
Page 18: 2-3: Connect Ribbon Cables, Cabinet Wires, And Power Supply
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 2-3: Connect ribbon cables, cabinet wires, and power supply 2-3-1 : I/O Back Panel Introduction... - Page 19 Hardware Installation Process PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. COAXIAL (SPDIF Out) The SPDIF coaxial output port is capable for providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder via a coaxial cable.
- Page 20 Hardware Installation Process LAN LED Description LED2 (Green/Yellow) LED1 (Green) Name Color Condition Description LED1 Green LAN Link / no Access Green BLINK LAN Access Idle LED2 10Mbps connection Green BLINK Port identification with 10 Mbps connection Green 100Mbps connection Green BLINK Port identification with 100Mbps connection...
-
Page 21: 2-4: Connectors Introduction
GA-3CCWV-RH/GA-3CCWL-RH Motherboard 2-4: Connectors Introduction 1. ATX1 15. F1_1394 (IEEE 1394 connector) 2. ATX2 16. F2_1394 (IEEE 1394 connector) 3. IDE 17. F_Audio (Front Audio Connector) 4. FDD (Floppy Connector) 18. CD_IN 5. SATA 1 (SATA Connector) 19. SPDIF_IN 6. SATA 2 (SATA Connector) 20. - Page 22 Connector Introduction 1) ATX1 (Auxukiary Power Connector) PIN No. Definition +3.3V +3.3V 5VSB +12V +12V +3.3V +3.3V -12V AC power cord should only be connected to PSON your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
- Page 23 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 3 ) IDE (IDE Connector) Please connect first harddisk to IDE1. The red stripe of the ribbon cable must be the same side with the Pin1. 4 ) FDD (Floppy Connector) Please connect the floppy drive ribbon cables to FDD. It supports 720K,1.2M,1.44M and 2.88Mbytes floppy disk types.
- Page 24 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 5/ 6/ 7/ 8/9/10 ) SATA 1~6 (Serial ATA Connectors) You can connect the Serial ATA device to this connector, it provides you high speed transfer rates (3.0 Gb/sec). Pin No. Definition SATA1 SATA4 SATA6 SATA5 SATA3 SATA2 11/ 12/13 ) F_USB1/2/3 (Front USB Connectors) Be careful with the polarity of the front USB connector.
- Page 25 Connector Introduction 14 ) F_Panel (2X10 Pins Front Panel connector) Please connect the power LED, PC speaker, reset switch and power switch of your chassis front panel to the F_PANEL connector according to the pin assignment above. Message LED/Power/Sleep MSG+ IDE Hard Disk MSG- Active LED...
- Page 26 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 15/16 ) F1_1394/F2_1394 (IEEE 1394 connectors) Pin No. Definition FTPA1+ FTPA1- FTPB1+ FTPB1- BUSVCC0 BUSVCC0 No Pin 17) F_AUDIO (Front AUDIO Connector) If you want to use Front Audio connector, you must remove 5-6, 9-10 Jumper. In order to utilize the front audio header, your chassis must have front audio connector.
- Page 27 Connector Introduction 18) CD_IN (CD IN,Blank) Connect CD-ROM or DVD-ROM audio out to the connector. Pin No. Definition CD-L CD_R 19) SPDIF_IN Use this device only when your hardware system has digital output function. Pin No. Definition SPDIF IN...
- Page 28 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 20/21 ) CPU0_FAN/CPU1_FAN (CPU0/1 Fan Connectors) Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.The CPU fan connector supports Max. current up to 1A .
- Page 29 Connector Introduction 23/24 ) FRONT_FAN/REAR_FAN (System Fan Connectors) This connector allows you to link with the cooling fan on the system case to lower the system temperature. These connectors are for system use only. REAR_FAN Pin No. Definition Sense Control FRONT_FAN 25) BATTERY CAUTION...
- Page 30 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 26) CI (CASE OPEN) This 2 pin connector allows your system to enable or disable the “case open” item in BIOS if the system case begin remove. Pin No. Definition Signal...
-
Page 31: 2-5: Jumper Setting
Jumper Setting 2-5: Jumper Setting 1. BIOS_RECOVERY 2. CLR_CMOS 3. SLI_EN... - Page 32 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 1 ) BIOS_RECCOVERY ( BIOS Recovery Function) 1-2 Close: Enable BIOS Recovery function. 2-3 Close: Disable BIOS Revocery function (Default value) 2 ) CLR_CMOS1 (Clear CMOS Function) You may clear the CMOS data to restore its default values by this jumper.
- Page 33 Jumper Setting 3 ) SLI_EN (Support SLI Function) 1-2 Close: Enable SLI function 2-3 Close: Disable SLI function...
-
Page 34: 2-7: Block Diagram
PCI-E x8 CONN 1394 TSB43AB23 PCI-E x4 CONN PCI-E x4 ALC883 (GA-3CCWL-RH) Audio Jack x 6 PCI-X Bridge uPD720404 SPDIF Out (GA-3CCWV-RH) IDE x1 Dual Stacked LAN0 USB2 PCI-X 133MHz Dual Stacked LAN1 PCI-X 64 SLOTx1 SATA CONN x6 USB2 USB Ports... -
Page 35: Chapter 3 Bios Setup
BIOS Setup Chapter 3 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. -
Page 36: Getting Help
GA-3CCWV-RH Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. -
Page 37: Main
BIOS Setup Main Once you enter Phoenix BIOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. Figure 1: Main System Time The time is calculated based on the 24-hour military time clock. -
Page 38: Legacy Diskette A
GA-3CCWV-RH Motherboard Legacy Diskette A This category identifies the type of floppy disk drive A that has been installed in the computer. Disabled Disable this device. 360KB, 5 inch AT-type high-density drive; 360K byte capacity 1.2MB, 3 inch AT-type high-density drive; 1.2M byte capacity 720K, 3 inch double-sided drive;... - Page 39 BIOS Setup Multi-Sector Transfer This field displays the information of Multi-Sector Transfer Mode. Disabled: The data transfer from and to the device occurs one sector at a time. Auto: The data transfer from and to the device occurs multiple sectors at a time if the device supports it.
-
Page 40: Advanced Processor Options
GA-3CCWV-RH Motherboard Advanced Processor Options Figure 1-1: Advanced Processor Option Advanced Processor Option This category displays the information of current CPU Type, CPU Speed, CPU ID, and CPU Path ID. These category is display-only which is determined by POST (Power On Self... -
Page 41: Advanced
BIOS Setup Advanced About This Section: Advanced With this section, allowing user to configure your system for basic operation. User can change the processor options, chipset configuration, PCI configuration and chipset control. Figure 2: Advanced... -
Page 42: Memory Configuration
GA-3CCWV-RH Motherboard Memory Configuration Figure 2-1: Memory Configuration Syetem Memory/Extended Memory/ P0_DIMMA1/B1, A2/B2/ P1_DIMMA1/B1, A2/B2Status These category is display-only which is determined by POST (Power On Self Test) of the BIOS. -
Page 43: Pci Configuration
BIOS Setup PCI Configuration Figure 2-2: PCI Configuration Figure 2-2-1: Embedded NIC... - Page 44 GA-3CCWV-RH Motherboard Embedded NIC Onboard LAN1 Control Enabled Enable onboard LAN1 device. (Default setting) Disabled Disable this function. Option ROM Scan Enabled Enableing this item to initialize device expansion ROM. Disabled Disable this function. (Defualt setting) Onboard LAN2 Control Enabled Enable onboard LAN2 device.
- Page 45 BIOS Setup PCI /PNP ISA UMB Region Exclusion Reserve specific upper memory blocks for use by legacy ISA devices. C800-CBFF/ CC00-CFFF/ D000-D3FF/ D400 -D7FF/ D800-DBFF/ DC00-DFFF PCI /PNP ISA IRQ Resource Exclusion Reserve specific IRQs for use by legacy ISA devices. IRQ3/ IRQ4/ IRQ5/ IRQ7/ IRQ9/ IRQ10/ IRQ11/ IRQ15 SLI Support Enabled...
-
Page 46: I/O Device Configuration
GA-3CCWV-RH Motherboard I/O Device Configuration Figure 2-3: I/O Device Configuration Serial Port A This allows users to configure serial prot A by using this option. Auto BIOS or OS choosed configuration automatically. (Default setting) Enabled Enable the configuration. Disabled Disable the configuration. -
Page 47: Parallel Port
BIOS Setup Parallel Port This allows users to configure parallel port by using this option. Auto BIOS or OS choosed configuration automatically. (Default setting) Enabled Enable the configuration. Disabled Disable the configuration. Mode This option allows user to set Parallel Port transfer mode. Bi-directional Use this setting to support bi-directional transfers on the parallel port. - Page 48 GA-3CCWV-RH Motherboard SATA0/SATA1/SATA2 Controller Enabled Enables on-board Serial ATA controller. (Default setting) Disabled Disables on-board Serial ATA controller. NV RAID Configuration Enabled Enable NVIDA RAID Control. Disabled Disable NVIDA RAID Control. (Default setting) Note!! To function NV RAID Configuration properly, you must enable SATA Controller items.
-
Page 49: Advanced Chipset Control
BIOS Setup Advanced Chipset Control Figure 2-4: Advanced Chipset Control Wake on Keyboard/Mouse This item allows you to set the enable/disable for powering-on the system by keyboard and mouse. Enabled Wake on Keyboard/Mouse. Disabled Disable this function. (Default setting) Note: This item must enabled if you’re running under Windows operating system. Wake On Ring This item allow user to determine the action of the system power is off and the modem is ringing. -
Page 50: Wake On Ring
GA-3CCWV-RH Motherboard Wake On Ring This item allow user to determine the action of the system power is off and the modem is ringing. Enabled Enable Wake On Ring. Disabled Disable this function. (Default setting) Note: This item must enabled if you’re running under Windows operating system. -
Page 51: Hardware Monitor
BIOS Setup Hardware Monitor Figure 2-5: Hardware Monitor Voltage Monitor: VCORE0/1, 3.3V, 5V, 12V, DDRP0/P1, 5 Dual, VBAT Detect system's voltage status automatically. Temperature Monitor: CPU0/1 Temperature, System Temperature Display the current CPU1/2 temperature, and System temperature. FAN Monitor: CPU0/1, MCP55, Front and Rear Fan (RPM) Display the current CPU1/2 and System FAN 1/2/3 speed. -
Page 52: Reset Configuration Data
GA-3CCWV-RH Motherboard Boot -time Diagnostic Screen When this item is enabled, system will shows Diagnostic status when system boot. Enabled Enable Boot-time Diagnostic.(Default setting) Disabled Disable this function. Reset Configuration Data Reset all configuration data. Do not make any changes. (Default setting) NumLock This option allows user to select power-on state for NumLock. - Page 53 BIOS Setup Multiprocessor Specification This option allows user to configure the multiprocessor(MP) specification revision level. Some operating system will require 1.1 for compatibility reasons. Support MPS Version 1.4 . (Default setting) Support M PS Version 1.1.
-
Page 54: Security
GA-3CCWV-RH Motherboard Security About This Section: Security In this section, user can set either supervisor or user passwords, or both for different level of password securities. In addition, user also can set the virus protection for boot sector. Figure 3: Security Set User Password You can only enter but do not have the right to change the options of the setup menus. -
Page 55: Set Supervisor Password
BIOS Setup Set Supervisor Password You can install and change this options for the setup menus. Type the password up to 6 characters in lengh and press <Enter>. The password typed now will clear any previously entered password from the CMOS memory. You will be asked to confirm the entered password. -
Page 56: Server
GA-3CCWV-RH Motherboard Server Figure 4: Server... -
Page 57: System Management
BIOS Setup System Management Figure 4-1: System Management Server Management This category allows user to view the server management features. Including information of BIOS Version. All items in this menu cannot be modified in user’s mode. If any items require changes, please consult your system supervisor. -
Page 58: Console Redirection
GA-3CCWV-RH Motherboard Console Redirection Figure 4-2: Console Redirection COM Port Address If this item allows user to determine which port to use for console reidrection. On-board COMA Use COMA as he COM port address. On-board COMB Use COMB as he COM port address. -
Page 59: Flow Control
BIOS Setup Flow Control This option provide user to enable the flow control function. None Not supported. XON/OFF Software control. CTS/RTS Hardware control. (Default setting) Console connection This field indicates whether the console is connected directly to the system or a modem is used to connect. -
Page 60: After Power Failure
GA-3CCWV-RH Motherboard After Power Failure This option provides user to set the mode of operation if an AC / power loss occurs. Power On System power state when AC cord is re-plugged. Stay Off Do not power on system when AC power is back. -
Page 61: Boot
BIOS Setup Boot Figure 5: Boot Boot Priority Order This field determines which type of device the system attempt to boot from after PhoenixBIOS Post completed. Specifies the boot sequence from the available devices. If the first device is not a bootable device, the system will seek for next available device. Key used to view ot configure devices: Up and Down arrows select a device. -
Page 62: Exit
GA-3CCWV-RH Motherboard Exit Figure 6: Exit About This Section: Exit Once you have changed all of the set values in the BIOS setup, you should save your changes and exit BIOS setup program. Select “Exit” from the menu bar, to display the following sub-menu. -
Page 63: Exit Saving Changes
BIOS Setup Exit Saving Changes This option allows user to exit system setup with saving the changes. Press <Enter> on this item to ask for the following confirmation message: Pressing ‘Y’ to store all the present setting values tha user made in this time into CMOS. Therefore, whenyou boot up your computer next time, the BIOS will re-configure your system according data in CMOS. - Page 64 GA-3CCWV-RH Motherboard Load Settup Default This option allows user to load default values for all setup items. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below:...
-
Page 65: Discard Changes
BIOS Setup Discard Changes This option allows user to load previos values from CMOS for all setup item. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below:... -
Page 66: Save Changes
GA-3CCWV-RH Motherboard Save Changes This option allows user to save setup dat ato CMOS. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below: Press [Yes] to save setup daya to CMOS. -
Page 67: Chapter 4 Application Driver Installation
Driver Installation Revision History Chapter 4 Application Driver Installation NVDIA Chipset Driver Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. - Page 68 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 2. InstallShield Wizard Welcome Window 2. Click "Next" to start the installation 3. Select Features 3. Select the feature setup that you want to install. And click "Next".
- Page 69 Driver Installation 4. NVDIA IDE SW Driver Information 4. Click "Next" to process the installation. 5. IDE SW Driver Installation Confirmation Dialog 5. Click “Yes”.
- Page 70 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 6. Firewall and ForceWare Network Access Manager Installation Confirmation Dialog 6. Click “Yes”. 7. Network Access Manager Installation 7. Click “Next”.
- Page 71 Driver Installation 8. Network Access Manager Setup Type Selection 8. Select the setup type and determine the driver destination folder. Click “Next” 9. Installation Complete. Restart Computer 10. Select ‘Yes, I want to restart my computer now’ and click “Finish”.
-
Page 72: B.audio Hot Fix Driver Installation
GA-3CCWV-RH/GA-3CCWL-RH Motherboard Audio Hot Fix Driver Installation (For Windows 64-bit operating system) Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. - Page 73 Driver Installation 2. Select “Realtek” Folder 2. Click "Realtek" folder. 3. Execute the file 3. Double click the self-execute file to start installation.
- Page 74 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 4. InstallShield Wizard Welcome Window 4. Click "Next" to start the installation 5. License Agreement 5. Select “I Agree” and click "Next" to process the installation.
- Page 75 Driver Installation 6. Installation Complete 6. Installation complete. Click “Finish”.
-
Page 76: C.realtek Alc883 Audio Driver Installation
GA-3CCWV-RH/GA-3CCWL-RH Motherboard Realtek ALC883 Audio Driver Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. - Page 77 Driver Installation 2. InstallShield Wizard Welcome Window 2. Click "Next" to start the installation 3. Installaiton Wizard Complete 3. Select ‘Yes, I want to restart my computer now’ and click “Finish”.
-
Page 78: D.directx 9.0 Driver Installation
GA-3CCWV-RH/GA-3CCWL-RH Motherboard DirectX 9.0 Driver Installation Insert the driver CD-title that came with your motherboard into your CD-ROM driver, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. - Page 79 Driver Installation 2. License Agreement 2. Select “I accept the agreement andclick "Next" to process the installation. 3. Start Installaiton 3. Click “Next” to start the installation .
- Page 80 GA-3CCWV-RH/GA-3CCWL-RH Motherboard 4. Installaiton Wizard completed 4. Click "Finish". Installation complete.
-
Page 81: Chapter 5 Appendix
Appendix Revision History Chapter 5 Appendix Appexdix: PCI-X Card QVL... - Page 82 GA-3CCWV-RH/GA-3CCWL-RH Motherboard...
- Page 83 Appendix Appendix : Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Boot Specification BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser...
- Page 84 GA-3CCWV-RH/GA-3CCWL-RH Motherboard Local Area Network Logical Block Addressing Light Emitting Diode Megahertz MIDI Musical Instrument Digital Interface Memory Translator Hub Memory Protocol Translator Network Interface Card Operating System Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect...
