- Page 1 Internet Telephony Gateway User’s manual VIP-110/VIP-210 release 1.0 February 10, 2004...
- Page 2 Copyright (C) 2004 PLANET Technology Corp. All rights reserved. The products and programs described in this User ’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
-
Page 3: Table Of Contents
Procedure ....................9 LAN/WAN Interface quick configurations .............12 LAN IP configuration via command line interface (CLI)........12 Preparation before beginning web administration on VIP-110/VIP-210 ....14 Checking TCP/IP settings on Windows 95/98 ..........14 Checking TCP/IP settings on Windows NT............16 Checking TCP/IP Settings - Windows 2000: ..........20 Checking TCP/IP Settings - Windows XP............22... - Page 4 PBX system. PLANET VoIP (Voice over IP) system – VIP-110/VIP-210 offers toll quality voice and real-time fax data over IP networks. With optimized H323 architecture, PLANET VIP...
-
Page 5: Vip-110/Vip-210 Features
PBX system, in a heterogeneous signal-switching environment. Domain name call & DDNS supports Either IP or URL addressing, the VIP-110/VIP-210 is able to locate and communicate with destination H.323 gateways and terminals. The DDNS service is supported for those VoIP gateways deployed in a dynamic IP environment. -
Page 6: Package Content
Power adapter Quick Installation Guide User’s Manual CD Physical Details The front panel of VIP-110/VIP-210 contains a push button and 5/6 LED indicators. The following figure illustrates the front/rear panel of VIP-110/VIP-210. VIP-110 Front Panel VIP-110 Rear Panel - 6 -... -
Page 7: Led Display & Button
VIP-110/VIP-210 is equipped with a WAN interface with 10/100 Mbps auto-negotiation capability, 1 LAN Ethernet ports with 10/100 Mbps auto-negotiation capability. In addition to the LAN/WAN Ethernet interface ports, One (VIP-110) / two (VIP-210) RJ-11 telephony interface ports on the rear panel. Their functions are described below:... -
Page 8: Reset Button
PLANET VIP-110/VIP-210 Web Configuration Guide Port Label Function RJ-45 Connecting VIP to a 10/100 Mbps Ethernet network RJ-45 Connecting VIP to a 10/100 Mbps Ethernet network / xDSL /Cable modem for Internet access RJ-11 Telephony Connect PBX Extension line/Telephone to VIP... -
Page 9: Physical Installation Requirement
PLANET VIP-110/VIP-210 Web Configuration Guide Physical Installation and IP Configuration This chapter illustrates basic installation of VIP-110/VIP-210 Physical Installation Requirement Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors. TCP/IP protocol must be installed on all PCs. For Internet Access, an Internet Access account with an ISP, and either of a DSL or Cable modem... - Page 10 Netscape Communicator 4.03 or higher Microsoft Internet Explorer 4.01 or higher with Java support Default LAN interface IP address of VIP-110/VIP-210 is 192.168.0.1. You may now open your web browser, and insert 192.168.0.1 in the address bar of your web browser to logon VIP-110/VIP-210 web configuration page.
- Page 11 CD or consult your network administrator for proper network configurations. CLI configuration access You can connect the VIP-110/VIP-210 via telnet terminal program Start up your terminal program, here, we use Hyper Terminal as the example. Set up the parameters as below for Telnet connection Host Address: 192.168.0.1...
-
Page 12: Lan/Wan Interface Quick Configurations
Nature of PLANET VIP-110/VIP-210 is an IP Sharing (NAT) device, it comes with two default IP addresses, and default LAN side IP address is “192.168.0.1”, default WAN side IP address is “172.16.0.1”. You may use any PC to connect to the LAN port of VIP-110/VIP-210 to start machine administration.,... - Page 13 PLANET VIP-110/VIP-210 Web Configuration Guide The command “net set lan mask” is used to set the network mask of VIP. If you would like to set up the network mask to “255.255.255.0”, for example. You can have the command as below and press the <Enter> key: ITG>net set lan mask 255.255.255.0...
-
Page 14: Preparation Before Beginning Web Administration On Vip-110/Vip-210
Preparation before beginning web administration on VIP-110/VIP-210 In this section, we’ll introduce steps of how to setup a PC to communicate with VIP-110/VIP-210 and Internet access related parameters through TCP/IP protocol configuration. Before starting web browser to connect to VIP-110/VIP-210, please check TCP/IP configurations on PC: the PC must be configured either as a DHCP client and or fixed IP allocation on the intranet or Internet. - Page 15 PLANET VIP-110/VIP-210 Web Configuration Guide e. Click OK, and the Network window appears. Step 3.1 Change the TCP/IP settings to use DHCP as follows (DHCP environment): a. Double-click the first TCP/IP cable icon. The TCP/IP Properties window appears. b. Verify that the IP Address tab has Obtain an IP address automatically selected and that the IP Address and Subnet Mask fields are grayed out.
-
Page 16: Checking Tcp/Ip Settings On Windows Nt
PLANET VIP-110/VIP-210 Web Configuration Guide d. Enter your domain name in the Domain field. e. Enter the IP address of the DNS server in the DNS Server Search Order field. f. Click Add. The IP address displays in the window below the field. - Page 17 PLANET VIP-110/VIP-210 Web Configuration Guide Windows NT4.0 - TCP/IP Click the Properties button to see a screen like the one below. Windows NT4.0 - IP Address - 17 -...
- Page 18 PLANET VIP-110/VIP-210 Web Configuration Guide Select the network card for your LAN. Select the appropriate radio button - Obtain an IP address from a DHCP Server or Specify an IP Address, as explained. Specify an IP Address If your PC is already configured with an IP address, check with your network administrator before making the following changes.
- Page 19 PLANET VIP-110/VIP-210 Web Configuration Guide Windows NT4.0 - DNS - 19 -...
-
Page 20: Checking Tcp/Ip Settings - Windows 2000
PLANET VIP-110/VIP-210 Web Configuration Guide Checking TCP/IP Settings - Windows 2000: Select Control Panel - Network and Dial-up Connection. a) Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Network Configuration (Win 2000) b) Select the TCP/IP protocol for your network card. - Page 21 PLANET VIP-110/VIP-210 Web Configuration Guide TCP/IP Properties (Win 2000) Ensure your TCP/IP settings are correct with one of the following description. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Win- dows setting.
-
Page 22: Checking Tcp/Ip Settings - Windows Xp
PLANET VIP-110/VIP-210 Web Configuration Guide Checking TCP/IP Settings - Windows XP Select Control Panel - Network Connection. a) Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Network Configuration (Windows XP) b) Select the TCP/IP protocol for your network card. - Page 23 PLANET VIP-110/VIP-210 Web Configuration Guide TCP/IP Properties (Windows XP) Ensure your TCP/IP settings are correct with one of the following description. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Win- dows setting.
-
Page 24: Lan Ip Address Configuration Via Web Configuration Interface
Subnet Mask, LAN mask of VIP-110/VIP-210 Default: 255.255.255.0 DHCP server Config Number of DHCP VIP-110/VIP-210 is capable of working as a DHCP server, the DHCP client num- ber is the Client allowed DHCP clients in its network. Default: 30 Start address Beginning IP address of DHCP client IP assignment. -
Page 25: Wan Ip Address Configuration Via Web Configuration Interface
PLANET VIP-110/VIP-210 Web Configuration Guide Please click on the REBOOT link to restart machine to macke the changes effective, WAN IP address configuration via web configuration interface Execute your web browser, and insert the IP address (default: 192.168.0.1) of VIP in the adddress bar. -
Page 26: Internet Access Setup
Internet Access Setup Ÿ When WAN interface of VIP-110/VIP-210 is properly configured, with default Windows TCP/IP settings, no changes need to be made on LAN side PC for Internet access. If using a specified (fixed) IP address on your PC, refer to the user manual for details of the required... - Page 27 VIP-110/VIP-210's default IP Address of 192.168.0.1. Also, the Network Mask must be set to 255.255.255.0.Ensure that your PC and VIP-110/VIP-210 are on the same network segment. (If you don't have a router, this must be the case.) - 27 -...
-
Page 28: Overview On The Web Interface Of Vip-110/Vip-210
Provides user input data fields, check boxes, and for changing machine configu- ration settings w Displays machine running configuration To start VIP-110/VIP-210 web configuration, you must have one of these web browsers installed on computer for management w Netscape Communicator 4.03 or higher w Microsoft Internet Explorer 4.01 or higher with Java support... -
Page 29: Manipulation Of Vip-110/Vip-210 Via Web Browser
After TCP/IP configurations on your PC, you may now open your web browser, and input 192.168.0.1 to logon VIP-110/VIP-210 web configuration page. VIP–110/VIP-210 will prompt for logon username/password: admin / 123 VIP-110/VIP-210 logon page (Log on VIP-110/VIP-210 via username/password: admin /123 ) VIP-110/VIP-210 main page - 29 -... -
Page 30: Internet Access Setup
PLANET VIP-110/VIP-210 Web Configuration Guide Start administration When you browse the left control panel in VIP-110/VIP-210 web configuration, the main function menus are listed in the left control panel: internet Access Setup, Dialplan Setup, H.323 Settings, Tools, Advanced Configuration and Help Menus. These major configuration menus have related sub-menus and parameters, following sections will give you an overall illustration of the function- ality in VIP-110/VIP-210. -
Page 31: Parameter Description
Default: 192.168.0.10 ii. WAN Four connection types supported in VIP-110/VIP-210: PPPoE/PPTP, Fixed IP, and DHCP PPPoE/PPTP screen VIP-110/VIP-210 natively integrates with PPPoE client, this makes VIP-110/VIP-210 is able to PPPoE/PPTP establish Internet connection via popular ADSL access. The configuration menu is used to configure and PPTP related information in VIP-110/VIP-210. - Page 32 IP address assigned by ISP for the PPPoE connec- tion. Default: 0.0.0.0 Authentication VIP-110/VIP-210 implements two types of authentication protocol. This parameter protocol used for specifying which authentication protocol VIP will use to send authentica- tion message to the server.
- Page 33 Default 0.0.0.0 IP ToS VIP-110/VIP-210 allows users to set the 8-bit Service Type field in the IP header for all the packets it sends across the WAN interface. The Service Type field is divided into five subfields, among which four subfileds are user configurable. This command is used to set these subfields.
- Page 34 DHCP screen Parameter Description DHCP client Enable or disable DHCP client function in VIP-110/VIP-210 Default: DHCP client in VIP-110/VIP-210 is disabled Router name If your ISP demands a particular Hostname/router name for - 34 -...
- Page 35 Default: off Cloned Some ISPs may require you to use MAC (physical) address for Internet connection. MAC address Please enter the MAC address of network interface card on workstation here. Default: MAC address of WAN interface on VIP-110/VIP-210. - 35 -...
-
Page 36: Dial Plan Management
The dial plan management menu allows you to modify and display the dial plan. Dial plan Concept Before you start setting up the dial plan in VIP-110/VIP-210, following basic concept associated with the dialplan in VIP-110/VIP-210 should be explained in advance. Ÿ... - Page 37 PLANET VIP-110/VIP-210 Web Configuration Guide Hunt Group The “Hunt Group” here is an interpreter between phone number and Destination ID. VIP phone table will base on the number you dialed to find the related hunt group. So, different numbers can map to the same hunt group.
- Page 38 PLANET VIP-110/VIP-210 Web Configuration Guide Dial plan/Dial setting Screen The Setup screen of the Dial Settings Dial Plan including: Telephone Settings, which allows one to Add, Delete, Find, or List telephone num- bers. Hunt Group Settings, which allows one to...
- Page 39 PLANET VIP-110/VIP-210 Web Configuration Guide Phone number setting screen You may modify VIP telephone address table here: you may add (delete, find or list) desired telephone number mapping to hunt group at this menu. Telephone Telephone number to match. This is only part of Number the total dialed string.
- Page 40 PLANET VIP-110/VIP-210 Web Configuration Guide Hunt Group setting screen You may modify VIP telephone hunt group table here: you may add (delete, find or list) desired hunt group at this menu. We can add (delete, find or list) desired hunt group ID mapping to destination ID at this menu. If you want to make the port calls to the secondary receiver, you can click one “More Destinations”...
- Page 41 PLANET VIP-110/VIP-210 Web Configuration Guide Save to NVRAM setting Screen After Dialplan configurations, you may save the modifications in this menu Clear Dialplan setting screen You may clear all the existing dialplan configurations and restore default dialplan configurations in this menu; however, the “clear” action will not take effects until this action is saved into machine via the “Save to NVRAM”...
- Page 42 PLANET VIP-110/VIP-210 Web Configuration Guide If you’re not familiar with dialplan configurations, you Hint may directly click on the dialplan help menu for more information. Dialplan Help Menu Screen - 42 -...
-
Page 43: H.323 Configurations
H.323 Alias configurations in this category: i. General H.323 Configuration VIP-110/VIP-210 H.323 configuration page is used to configure H.323 parameters, these pa- rameters are designed to meet most calling environment. Parameter Description Display Name This field is to set the display name information that is carried in the H.323 setup messages. - Page 44 PLANET VIP-110/VIP-210 Web Configuration Guide Default: 30000 Outgoing Fast Start This field is to enable or disable the Fast start mode on the outgoing side of the call. Default: off Incoming Fast Start This field is to enable or disable the Fast start mode on the incoming side of the call.
- Page 45 Default: 2 Time-to-Live When the VIP-110/VIP-210 registers to a gatekeeper, it specifies the duration of the validity of the registration in the timeToLive field in the RRQ message it sends to the gatekeeper. The gatekeeper may optionally change the timeToLive by returning...
- Page 46 Default:0 endpoint_prefix This command is used to set the H.323 prefix that the VIP-110/VIP-210 will uses when registering to an H.323 gatekeeper. After registering to a gatekeeper using the prefix, the gatekeeper will map all Admission Request with destination matching the prefix to VIP-110/VIP-210.
- Page 47 PLANET VIP-110/VIP-210 Web Configuration Guide ii. H.323 Aliases Configuration This command is used to create and delete aliases that are registered with the gatekeeper - 47 -...
-
Page 48: Tools Menu
PLANET VIP-110/VIP-210 Web Configuration Guide Tools Menu VIP-110/VIP-210 provides a utility menu, which can adjust system-wide parameters, such as telnet access, system password, firmware upgrade, and display of system configurations. There are six sub configuration menus: Password Setup, Telnet Access, Firmware Upgrade, System Status, H.323 Configuration Status, and Voice Port status. -
Page 49: Advanced Configuration Menu
PLANET VIP-110/VIP-210 Web Configuration Guide Advanced Configuration menu Advanced configuration menu in VIP-110/VIP-210 provides more Internet application compatibility adjustment, which can eliminate inconvenience brought by the NAT algorithm. There are six sub configuration menus: Virtual Servers, Port Forwarding, Special Application, DMZ, Dynamic DNS, and Access Control. -
Page 50: Help Menu
PLANET VIP-110/VIP-210 Web Configuration Guide Help Menu VIP-110/VIP-210 integrates online help menu, which can bring brief introduction of each feature in machine. More information can be found in this user’s manual or the Command line Reference guide. You may click on the desired topic to view the help content... -
Page 51: Configuration Samples
VIP together and make the call. Assume that we have a second ITG, called VIP B, which is a VIP-110 with default setting as well. Now, let’s setup its WAN IP address to another, e.g. ‘172.16.0.2’ and connect it together to VIP A with the following three steps. - Page 52 PLANET VIP-110/VIP-210 Web Configuration Guide ITG>net store ITG>net reset <confirm prompt and restart machine>. Step 2. Connect WAN port of VIP A and VIP B to the same switch or hub, please make sure the connection is ready. Step 3.
- Page 53 PLANET VIP-110/VIP-210 Web Configuration Guide VIP A: Hunt Group Dest. ID Dest. 172.16.0.2 VIP B: Hunt Group Dest. ID Dest. 172.16.0.1 Now, once VIP A get a dialed number “02” it will direct to VIP B. The same to VIP B, ‘01’ will map to VIP A without doubt.
- Page 54 PLANET VIP-110/VIP-210 Web Configuration Guide After all of above, your VIP can work to each other. - 54 -...
