- Page 1 User’s Manual 10/100/1000Base-T PCI Express Gigabit Ethernet Adapter ENW-9702 www.PLANET.com.tw...
-
Page 2: User Manual Of Enw
Trademarks Copyright PLANET Technology Corp. 2013. Contents subject to which revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. -
Page 3: Table Of Contents
User Manual of ENW-9702 Table of Contents CHAPTER 1 INTRODUCTION....................4 1.1 Package Content..........................5 1.2 Features ............................5 1.3 Gathering Tools and Documentations .................... 5 CHAPTER 2 HARDWARE INSTALLATION ................6 2.1 LED Definition ..........................6 2.2 Hardware Installation........................7 CHAPTER 3 DRIVER INSTALLATION.................. -
Page 4: Chapter 1 Introduction
User Manual of ENW-9702 Chapter 1 Introduction Thank you for purchasing PLANET ENW-9702 PCI Express Gigabit Ethernet adapter. It is a 10/100/1000Mbps Ethernet adapter for PCI local bus-compliant PCs, supports Auto-Negotiation for 10/100/1000Mbps Ethernet connection. More Bandwidth and Advanced Functions... -
Page 5: Package Content
IEEE 802.3x Full-Duplex Flow Control Complies to Microsoft and Linux Platform 1.3 Gathering Tools and Documentations To install the ENW-9702 Gigabit Ethernet adapter, you need the following items: A suitable screw driver Your operating system documentation ... -
Page 6: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation 2.1 LED Definition The faceplate of ENW-9702 has two LED: Link / ACT and 1000. The pictures below have showed the faceplate of ENW-9702. Table 2-1 explains the function and state of the LED. Figure 1: Long Profile Bracket of ENW-9702... -
Page 7: Hardware Installation
User Manual of ENW-9702 2.2 Hardware Installation Step 1: Please turn off your PC. Step 2: Remove any metal decorations from your hands and wrists. Step 3: Remove the cover from your PC. Step 4: Locate an empty PCI Express slot and remove the corresponding back plate. Save the screw for use in Step 6. -
Page 8: Chapter 3 Driver Installation
The following installation uses ENW-9702 and operates under Windows XP; the Install procedures will be similar to the Windows Server 2003. After installing ENW-9702 to your PC and boot up, Windows XP will detect it and you have to install driver. - Page 9 User Manual of ENW-9702 Please move and right click the mouse button for Ethernet Controller item and select “Update Driver”. Please select the second option and click “Next”. - 9 -...
- Page 10 Please select “Include this location in the search” and then click “Browse” to specify the driver location to install. (Assume "D" is your CD-ROM drive, the driver can be found in D:\ENW-9702\Win_XP_2000_2003_2003R2\WinXP). Click “Next” to continue. WinXP will show this dialog box to prompt you the driver has not passed Windows logo testing, please click “Continue Anyway”, then WinXP will start to install the driver.
-
Page 11: Installing Driver To Windows 7 / Server 2008
The following installation uses ENW-9702 and operates under Windows 7; the Install procedures will be similar to the Windows Server 2008. After installing ENW-9702 to your PC and boot up, Windows 7 will detect it and you have to install driver. - Page 12 User Manual of ENW-9702 Please move and right click the mouse button for Ethernet Controller item and select “Update Driver Software” Please select “Browser my computer for driver software” for next step. - 12 -...
- Page 13 Insert the bundled CD into the CD-ROM driver. Please click “Browse” to specify the driver location to install. (Assume "E" is your CD-ROM drive, the driver can be found in E:\ENW-9702\Win_7\64). Click “Next” to continue. The driver installs process. - 13 -...
- Page 14 User Manual of ENW-9702 During the Driver installation, it will pop up one Windows Security message. Please Click “Install this driver software anyway” button for continue installation. Click “Close” button to complete the driver installation. - 14 -...
-
Page 15: Installing Driver To Linux
User Manual of ENW-9702 3.3 Installing Driver to Linux <Requirements> - Kernel source tree (supported Linux kernel 2.6.x and 2.4.x) - For linux kernel 2.4.x, this driver supports 2.4.20 and latter. - Compiler/binutils for kernel compilation <Quick install with proper kernel settings>... - Page 16 User Manual of ENW-9702 GATEWAY=192.168.1.254 BROADCAST=192.168.1.255 b. DHCP: DEVICE=eth0 BOOTPROTO=dhcp ONBOOT=yes <Modify the MAC address> There are two ways to modify the MAC address of the NIC. 1. Use ifconfig: # ifconfig ethX hw ether YY:YY:YY:YY:YY:YY ,where X is the device number assigned by Linux kernel, and YY:YY:YY:YY:YY:YY is the MAC address assigned by the user.
- Page 17 User Manual of ENW-9702 NWAY_OPTION ,where SPEED_MODE = 1000 for 1000Mbps = 100 for 100Mbps = 10 for 10Mbps DUPLEX_MODE = half for half-duplex = full for full-duplex NWAY_OPTION = off for auto-negotiation off (true force) = on for auto-negotiation on (nway force)
-
Page 18: Chapter 4 Specifications
User Manual of ENW-9702 Chapter 4 Specifications ENW-9702 Product 10/100/1000Base-T PCI Express Gigabit Ethernet Adapter Hardware Specification PCI Express serial Bus Interface Attachment Interface 10/100/1000Base-T RJ-45 Copper Interface Media Interface 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) -
Page 19: Ec Declaration Of Conformity
*Model Number : ENW-9702 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address : 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2004/108/EC).
