Goodman SS-PCB50 Product Specifications

P S
RODUCT PECIFICATIONS
PCB
C
OMMERCIAL
50 Hz
S -C
ELF
P A
ACKAGE IR
7½, 10,
AND
[26.4 kW to 52.8 kW]
C
OOLING
90,000 180,000 BTU/
TO
Standard Features
• Dual high-effi ciency scroll compressors with
internal motor protection (2-stage cooling;
three compressors on 15-ton units)
• Compressor grommets for vibration isolation
• Time delay for compressor sequencing
• Fully charged systems
• High- and low-pressure controls on all systems
• Mild ambient switch
• Two independent condenser coils for
2-stage operation
• Totally enclosed, permanently lubricated ball-
bearing outdoor fan motors
• Enhanced copper tube/aluminum fi n coils
• Expansion valve evaporator coil
• Vertical discharge with removable grilles
• Galvanized steel, powder-coated drain pan with
3/4" (19mm) NPT condensate connection
• Belt-driven, variable-pitch sheave permits multi-
speed adjustment
• Centrifugal fan for quiet and effi cient operation
• Filters (2" [50.8mm] disposable) provided
with unit
• Operates up to 125°F ambient temperature
SS-PCB50
S
ERIES
ONTAINED
C
ONDITIONER
15 T
ON
C :
APACITY
H
www.goodmanmfg.com
The PCB Commercial 50 Hz self-contained
packaged air conditioner is designed for
ground-level or rooftop application.
Cabinet Features
• Heavy-gauge, zinc-coated steel cabinet with
weather-resistant powder-paint fi nish
• Fully insulated with blankets of insulation
• Built-in fi lter rack
• Factory wiring conveniently arranged for
installation of accessories
• Control box and compressors easily accessible
from side access panels
Accessory Heat Kit Features
• Control circuitry arranged to readily
permit staging
• Rust-resistant nickel chromium heating elements
• Primary and secondary limit protection
• Factory-installed one-time fuses on all models
Accessories
• Room thermostat; Low-ambient control
• Rooftop Lift Kit; Roof curb
• Economizers (horizontal and vertical)
• Manual/motorized fresh air damper
• Horizontal Duct Kit (Downfl ow to Horizontal
Conversion)
• Electric heat capacities 15 kW-30 kW @ 415V
50 Hz (fi eld-installed accessory)
• Panel Louver Kit
6/06
Supersedes 12/05
