Cisco DX650 Quick Start Manual

C D C
ISCO ESKTOP OLLABORATION
E DX650 Q S
XPERIENCE UICK TART
1
14
2
3
4
5
6
7
8
13 12 11 10 9
1 Camera 8 Conference
Phone screen Stop Video
2 9
Keypad 10 Speakerphone
3
microSD slot 11 Mute
4
5 Transfer 12 Headset
6 End Call 13 Volume
7 Hold 14 Handset
1 2 3 4 5 6 7 8
Lock Computer port
1 6
2 microUSB port 7 Auxiliary port
3 Line in/out 8 USB port
4 Power 9 HDMI
5 Network port
Setup Assistant
The Setup Assistant runs automatically the first
time that you use your phone. To set up Email,
Chat, WebEx, and Visual Voicemail, follow the
onscreen instructions.
Connect to wireless network
1. Tap .
2. Tap Settings.
3. Toggle on Wi-Fi.
4. Select a wireless network from the list of
available networks.
5. Enter your credentials and tap Connect.

Lock screen

To unlock the screen, enter your PIN and press #.
Log in with Cisco Extension Mobility
1. Tap Sign In As New User.
2. Enter your user ID and PIN.
3. If you are prompted, select a device profile.
Adjust screen timeout
1. Tap .
2. Tap Settings.
3. Tap Display.
4. Tap Sleep.
9
5. Select the length of time that your phone can
be inactive before the screen locks.
Gestures
Gesture Action
Tap Use your fingertip to press the
touchscreen.
Tap and Tap and wait two seconds.
hold
Swipe Tap and move.
Drag Tap and hold, then move.
Double Tap twice in quick succession.
tap
Pinch open Tap with two fingers, then move
your fingers apart.
Pinch close Tap with two fingers, then move
your fingers together.
Navigation
Icon Action
Tap Back to go to the previous page or
application, or to dismiss the onscreen
keyboard.
Tap Home to view the home screen.
Tap Phone to launch the phone application.
Tap Recents to view the list of recently
used applications.
Widgets
Use widgets to access phone features and other
applications on your home screen.
To add a widget to the home screen:
1. Tap .
2. Tap Widgets.
3. Tap and hold a widget.
4. Drag the widget to an empty space on the
home screen.

Phone application

Place call
To a contact
1. Tap .
2. Drag a contact from the contact list to the call.
With speakerphone
1. Press .
2. Dial the number.
With headset
and enter a number. If is lit,
Press
press New Call and enter a number.
End call
With speakerphone
Press or .
With headset
Press or .
Keep another call on same line
. If necessary, remove the call from hold
Press
first.
