TOOLS OF THE TRADE

Listed next are the majority of the tools required to perform an installation. Having the proper
tools will make the installation that much easier. Some of these tools are necessities; some will
just make the job easier.
Allen Wrenches (2mm, 3mm and 4mm)
Electric drill with assorted drill bits
Heat shrink tubing
Phillips and flat blade screw drivers
Pliers (standard and needle nose)
RTA (real time analyzer)
Soldering iron and solder
Utility knife
Wire brush or sandpaper for chassis grounding
Reference CD with 1 kHz Sine Wave at 0dB level (all bits high)

END PANEL LAYOUTS

Figure 1
Figura 1
Abbildung 1
Figure 2
Figura 2
Abbildung 2
1.
2.
sense signal from radio and turn amplifier on when needed, turn off after 1 minute
© 2007 directed electronics—all rights reserved
CO300.2
1 2 3
CO6002
1 2 3
When lit indicates that the amplifier is on.
Connect speaker output from factory radio to amplifier, will auto
DMM or VOM
Grommets
Marking pen
Nylon tie straps
Wire crimper
Wire cutters
Wire strippers
4 5 6 7
4 5 6 7
8 9
8 9
3
