Safety Instructions; Care And Maintenance; Warranty - Topcom TwinTalker 1100 User Manual

5.5. Battery Charge Level/Low Battery Indication
• The BATTERY CHARGE LEVEL is indicated by the number of squares
present inside the BATTERY icon on the LCD Screen.
• When the BATTERY CHARGE LEVEL is low, the BATTERY icon will flash
to indicate that the batteries need to be replaced or recharged.
5.6. Using rechargeable batteries.
Important: Do not charge this unit using an AC/DC ADAPTER with regular
"AAA" alkaline batteries installed. Only use the optional AC/DC
ADAPTER with "AAA" rechargeable batteries (not included).
To use the PMR with an AC/DC ADAPTER and rechargeable batteries do the
following:
1. Insert four (4) "AAA" rechargeable batteries (not included).
2. Plug the 7,5 V DC / 200 mA ADAPTER (not included) into the EAR/MIC/
CHARGER JACK on the top of the unit and turn it ON by pressing the
POWER button.
NOTE: The unit cannot transmit calls while the batteries are being charged. It
takes approximately 8 to 10 hours to fully charge the batteries..
S p
Mic
Headset use
You can operate the PMR using a headset (not included).Plug the headset into
the EAR/MIC jack (5).
5.7. Sending Call Tones
You can use Call Tones to alert the other user to identify yourself. You can also
use Call Tones to signal the beginning or the end of a transmission.
1. Press and release the CALL button. The CALL TONE continues for 3
seconds.
2. Your CALL TONES will transmit to nearby receivers set to the same
channel.
7.6. Electromagnetic Interference/Compatibility:
Nearly every electronic device is susceptible to electromagnetic interference
(EMI) if inadequately shielded, designed or otherwise configured for
electromagnetic compatibility.
Turn your unit OFF in any facilities where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that is sensitive to
external RF energy.
Turn your unit OFF when on board an aircraft when instructed to do so. Any
use of the unit must be accordance with airline regulations or crew
instructions.

8. CARE AND MAINTENANCE

To clean the unit, wipe with a soft cloth dampened with water. Don't use a
cleaner or solvents on the unit; they can harm the case and leak inside,
causing permanent damage. Battery contacts may be wiped with a dry lint-free
cloth. If the unit gets wet, turn it off and remove the batteries immediately. Dry
the BATTERY COMPARTMENT with a solf cloth to minimize potential water
damage. Leave the cover off the BATTERY COMPARTMENT overnight or until
completely dry. Do not use the unit until completely dry.

9. WARRANTY

This equipment comes with a 24-month warranty. The warranty will be
honoured on presentation of the original or a copy bill or receipt, provided the
date of purchase and the unit type are indicated.
During the time of the warranty Topcom will repair free of charge any defects
caused by material or manufacturing faults. Topcom will at its own discretion
fulfil its warranty obligations by either repairing or exchanging the faulty
equipment.
Any warranty claims will be invalidated as a result of intervention by the buyer
or unqualified third parties.
Damage caused by inexpert treatment or operation, and damage resulting
from the use of non-original parts or accessories not recommended by
Topcom is not covered by the warranty.
The warranty does not cover damage caused by outside factors, such as
lightning, water and fire, nor does it apply if the unit numbers on the equipment
have been changed, removed or rendered illegible.
Note: Please do not forget to enclose your receipt if you return the equipment.
6. SPECIFICATIONS
Channels 8 Channels
Output Power (TX) Output Power :0.5W (Maximum)
Range Up to 3 Km (open field)

7. SAFETY INSTRUCTIONS

7.1. Damage antenna.
Do not use any communicator that has a damaged Antenna. If a damaged
antenna comes in contact with the skin, a minor burn may result.
7.2. Batteries.
As batteries can cause property damage and/or bodily injury such as burns if
conductive material such as jewelry, keys or beaded chains touches exposed
terminals. The material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged battery, particularly
when placing it inside a pocket, purse or other container with metal objects.Do
not replace or charge batteries in a potentially explosive atmosphere. Contact
sparking may occur while installing or removing batteries and cause an
explosion.
7.3. For vehicles with air bag.
Do not place your Communicator in the area over an air bag or in the air bad
deployment area. Air bags inflate with great force. If a communicator is placed
in the bag deployment area and the air bag inflates, the communicator may be
propelled with great force and cause serious injury to the occupants of vehicle.
7.4. Potentially Explosive Atmospheres.
Turn your communicator off when in any area with a potentially explosive
atmosphere, unless it is a type specifically qualified for such use. Sparks in
such areas could cause an explosion or fire resulting in bodily injury or even
death.
7.5. Blasting caps and areas
To avoid possible interference with blasting operation, turn your communicator
off near electrical blasting caps or in a 'blasting area' or in areas posted : 'Turn
off two way radio'. Obey all signs and instructions.
Note : Areas with potentially explosive atmospheres are often, but not always,
clearly marked. They include fueling areas such as below deck on boats, fuel
or chemical transfer or storage facilities; areas where the air contains
chemicals or particles, such as grain, dust or metal powders; and any other
area where you would normally be advised to turn off your vehicle engine.
The CE symbol indicates that the unit complies with the essential
requirements of the R&TTE directive.
www.topcom.net
