  • Page 1: Product Record Information

    Product Guide Model 4651330 IMPORTANT: Fill out the product record information below. Serial Number See rating label on grill for serial number. Date Purchased For support and to register your grill, please visit us at www.charbroil.com If you have questions or need assistance during assembly, please call 1-800-241-7548.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DANGER Product Record Information ......1 If you smell gas: For Your Safety .

  • Page 3: Installation Safety Precautions

    WARNING WARNING CALIFORNIA PROPOSITION 65 Do not attempt to repair or alter the regulator/valve 1. Combustion by-products produced when using for any “assumed” defect. Any modification to this this product contain chemicals known to the State of assembly will void your warranty and create the risk California to cause cancer, birth defects, and other of a gas leak and fire.

  • Page 4: Use And Care

    USE AND CARE Regulator/Valve Cylinder Leak Test (Cont’d.) Propane Gas Cylinders If you cannot stop a leak, remove cylinder from regulator and - Your grill is designed to operate with one 16.4 oz. disposable check for damaged threads, dirt and debris on regulator and cylinder (Dot 39 Cylinder) that is 7 3/8”...
  • Page 5 Safety Tips WARNING 1. Before opening LP cylinder valve, check the coupling nut for tightness. 2. When grill is not in use, turn off all control knobs and LP cylinder valve. For Safe Use of Your Grill and to Avoid Serious Injury: 3.

  • Page 6: Grill Maintenance

    Grill Maintenance CAUTION - Allow grill to cool before cleaning. Frequency of cleaning is determined by how often grill is used. SPIDER ALERT! DO NOT use self-cleaning oven to clean any grill part. Extreme heat would remove any chrome plating and cause premature rusting.

  • Page 7: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of manufacture*.

  • Page 8: Parts List/ Parts Diagram

    Parts List Key Qty Description Part # Lid Handle ..... G102-0001-9031 Lid ......G102-0002-0031 Hinge Brackets .
  • Page 9 Assembly BURNER (F) - Position Heat Shield (G) as shown at right below and place into Bottom (H). HEAT RESISTANT SHIELD (G) - Insert narrow end of Burner (F) through large hole in side of Bottom (H) and rest burner bracket on Shield (G). - Insert one 1/4-20 x 3/8”...

  • Page 10: Assembly

    Assembly (Con’t.) #10-24 x 3/4” SCREW (O) HEAT DISTRIBUTION PLATE (E) - Assemble Side Handles (I) to Bottom (H) using two each #10-24 x 3/4” Screws (O), Fiber Washers (L) and #10-24 Flange Nuts (N) SIDE HANDLE (I) per Handle (I). - Rest the notches on ends of Heat Distribution Plate (E) on Side Handles Screws (O) inside Bottom (H).
  • Page 11 Assembly (Con’t.) - Before assembly, inspect Regulator (J) for damage, dirt or debris accumulation. Clean out if present. - With knob pointing down , insert Regulator/Valve (J) into end of Burner (F). Notch in Regulator/Valve (J) MUST engage dimple in end of Rotate clockwise to lock Burner (F).

  • Page 12: Troubleshooting

    EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Troubleshooting Prevention/Solution is turned on. Problem Possible Cause Burner will not Light. • Out of Propane • Replace Cylinder. • Retighten cylinder. •...
  • Page 15 NOTES...
  • Page 16 Char-Broil© , LLC P.O. Box 1240 Columbus, GA31902–1240 Printed in China...
