American Standard 2709 Specification Sheet

ELLISSE OVAL™ PREMIUM AIR BATH
❏
2709.328 Premium Air Bath
• Smooth Air™ massage system with perfectly
smooth air jets throughout tub bottom
• Programmable automatic purge with time
• Acrylic with fiberglass reinforcement
• Pre-leveled tub bottom
• 1.0 HP variable speed, heated blower
• Factory installed power cord with plug
• Deck-mounted electronic control
• Drain and overflow in Chrome included
• EverClean System
®
❏ 2709.328.K2 Premium Air Bath
with Chromatherapy
Same as 2709.328 but also includes:
• Two digitally controlled lights
• Electronic control with color selector and
color cycle function
Nominal Dimensions:
69-1/4" x 38-1/2" x 19-3/4"
(1759 x 978 x 502mm)
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools and air baths with
EverClean incorporate a patented silver-ion additive
®
right into the circulation piping to protect the pipes
from mold, mildew, algae and fungus that could
cause deterioration or staining of the pipes.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
© 2008 AS America Inc.
PREMIUM AIR BATH
To Be Specified - Required:
❏ Color:
❏ Drain included (chrome)
❏ Other Bath Faucet (specify finish):
❏ Grab Bar Kit: 9827-200 two per kit (specify finish):
To Be Specified - Optional:
❏ Apron: 9460.018 (specify color)
❏ Tile Bead Kit: 751755-200
❏ Drain Trim Kit: 1585.200 (specify finish)
❏ Air Blower Remote Mounting Kit: 754025-0071A
For color/finish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
H51
ELLISSE OVAL™
HIGH GLOSS
Rev. 2/08
