American Standard Hampton 2770.732 Installation Instructions

BAR SINK FAUCETS
Thank you for selecting American-Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--
please read these instructions carefully before you begin.
060477-YYY220A (2.2 GPM)
SPOUT KIT
060477-YYY150A (1.5 GPM)
SPOUT KIT
066070-YYY0A
(2.2 GPM) AERATOR
M922881-YYY0A
(1.5 GPM) AERATOR
073542-0070A
SPOUT O-RING
Installation
Instructions
®
2770.732F15
908501-YYY0A
HANDLE BASE
923012-0070A
SPOUT CLIP
028610-0070A
VALVE
907016-YYY0A
ESCUTCHEON
M923049-0070A
PUTTY PLATE
065800-0070A
LOCKNUT
024220-0070A
SUPPLY NUT
2770.732
021470-YYY0A
INDEX CAP
918428-0070A
HANDLE SCREW
042692-0070A
PORCELAIN CROSS
HANDLE
021470-YYY0A
INDEX CAP
918428-0070A
HANDLE SCREW
916503-YYY0A
HANDLE BASE
923002-0070A
HANDLE ADAPTER
CHROME
OIL RUBBED BRONZE
SATIN NICKEL (PVD)
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
© A S A m e r i c a , I n c . 2 0 0 8
Certified to comply with ANSI A112.18.1M
U.S. Patent No. 5,819,789
M 9 6 8 9 4 5 R E V 1. 5
060353-YYY0A
PORCELAIN LEVER HANDLE
012470-YYY0A
END CAP
060354-YYY0A
METAL LEVER HANDLE
Replace the "YYY" with
appropriate finish code
002
224
295
HOT LINE FOR HELP
For toll-free information and answers to your questions, call:
1-800 442-1902
Weekdays 8:00 a.m. to 6:00 p.m. EST
IN CANADA 1-800-387-0369 (TORONTO 1-905-306-1093)
Weekdays 8:00 a.m. to 7:00 p.m. EST
IN MEXICO 01-800-839-12-00
