AUTO REPEATER FUNCTION
NOTE: This function is available for the USA ver-
sion only.
STORING A NON STANDARD REPEATER
USING DIFFERENT OPERATING MODES
This function automatically activates the repeater set-
tings (DUP or DUP– and tone encoder ON/OFF) when
the operating frequency falls within the general re-
peater output frequency range and deactivates them
when outside of the range.
Set the auto repeater function ON-1 or ON-2 in set
mode in advance. (p. 62) When set ON, repeater set-
tings are automatically activated according to the table
below.
ON-1 automatically sets the duplex setting and ON-2
automatically sets the duplex setting and tone encoder
automatically.
Frequency range and offset direction
FREQUENCY RANGE
145.200–145.495 MHz
146.610–146.995 MHz
147.000–147.395 MHz
For the USA version, turn the auto repeater function
OFF in set mode. (p. 62)
Turn the quick split function ON in set mode. (p. 61)
Push [AM/FM] to select FM mode.
• Pushing [AM/FM] toggles between AM and FM modes.
Push [A/B] to select VFO A.
Rotate the tuning dial to set the repeater output fre-
quency.
• Set the tuning step if desired.
Push [A/B] to select VFO B.
Rotate the tuning dial to set the repeater input fre-
quency.
Push [A/B] to select VFO A.
Push [SPLIT] to turn the split function ON.
Push [F3]( ) to turn the previously set tone en-
coder ON.
!1 Push [MW] for 2 sec. to store the contents in the se-
lected memory channel.
4
DUPLEX DIRECTION
minus duplex
minus duplex
plus duplex
