Generac Power Systems 005210-0 Owner's Manual page 45

1 026812 2
2 075580 1
3 0F6364A 1
4 039253 4
5 022145 2
6 022129 6
7 045771 2
8 * 0F1570 1
9 032552 1
10 029032 1
11 025424 1
12 0F0397 1
13 0A5547 1
14 048031C 4
15 0D1509 1
16 * 0E0591 1
17 059402 1
18 037561 1
19 0E1028C 1
20 059401 1
21 * 091526 4
22 * 049226 4
23 026915 2
24 062522 1
25 022127 1
26 022259 2
27 ** 050279 1
050280 1
28 0A6125 2
29 0F6155 1
30 * 0E1104 1
31 * 0E0668 1
32 * 0E0590 1
33 * 0C5133 1
34 * 0E0665 1
35 * 0E1108 1
36 * 033138 1
37 * 022152 1
38 * 0E0645 1
39 * 034339 1
40 059194 1
41 057823 2
42 040173 2
43 * 089617 1
44 030340 1
45 0A7040 1
* INCLUDED IN ITEM 19 (CARBURETOR ASSY )
ELBOW 90D 3/4 NPT
FLANGE FUEL INLET
FUEL RGLTR 1.5L REWORK
SCREW HHC M8-1.25 X 20 G8.8
WASHER FLAT 5/16 ZINC
WASHER LOCK M8-5/16
NUT HEX M8-1.25 G8 YEL CHR
BODY CARBURETOR ASSEMBLY
BARBED EL 90 5/16 X 1/8 NPT
HOSE 9/32 ID
NIPPLE PIPE 3/4 NPT X 6
HOSE CRANKCASE BREATHER
COVER AIR CLEANER
CLAMP HOSE BAND 1/4
DECAL INLET PRESSURE
ADAPTER CARB. TO AIR CLNR
FILTER ELEMENT
NUT WING 1/4-20 NYLK
ASSY CARBURETOR 1.5L C1 CPL
CARBURETOR GASKET
SCREW PPHM M5-0.8 X 12 ZNC
WASHER LOCK M5
NIPPLE CLOSE 3/4 X 1.375
STUD TH 1/4-20 X 3 G2 ZNC FULL
NUT HEX 1/4-20 STEEL
NUT HEX 5/16-18 STEEL
DECAL FUEL INLET NG
DECAL FUEL INLET LPG
STUD 5/16-18 X 1.25 F THR
HARNESS FUEL JUMPER SINGLE REG
GASKET AIR CLEANER ADAPTER
O-RING 2-028 1.38 X 1.50 X .06
VENTURI 18MM
O-RING 29.82 X 2.62
SCREW THROTTLE PIN STOP
THROTTLE ARM REWORK
SCREW HHM #10-32 X 5/8
WASHER LOCK #10
LEVER THROTTLE STOP
BARBED EL 90 3/8 NPT X 5/8
HOSE 5/8 ID LPG & NG (24" LG)
CLAMP HOSE #10 .56 - 1.06
CLAMP HOSE #5.5 .62-.62
BARBED STR 1/4 NPT X 1/4 MALE
HOSE 1/4 ID SAE 30R7
BRACKET-RAD HOSE
NOTES:
1. REGULATOR (I/N 3) AS SHOWN IN ILLUSTRATION IS SET UP FOR
NATURAL GAS APPLICATION.
2. TO CONFIGURE REGULATOR FOR LP VAPOR, SWITCH HOSE BARB,
HOSE CLAMP (I/N 41) AND HOSE (I/N 40) FROM "OUT-1" TO "OUT-2".
REPLACE PIPE PLUG FROM "OUT-2" TO "OUT-1". USE PIPE SEALANT
ON HOSE BARB AND PIPE PLUG. MAKE SURE TO KEEP PORTS FREE
FROM DEBRIS DURING RECONFIGURATION PROCESS.
3.** FOR LP VAPOR APPLICATION SUBSTITUE LPG FUEL INLET DECAL P/N
050280 FOR NG FUEL INLET DECAL P/N 050279 (ITEM 27).
4 . WHEN SWITCHING FUEL TYPES, THE PROPER DIP SWITCH SITTINGS
MUST BE MADE TO THE CONTROL PANEL. SEE OWNERS MANUAL, FUEL
SECTION FOR MORE DETAILS.
